media-tech MATRIX PRO VR, MT5510 User Manual

User Manual
MATRIX PRO VR
MT5510
2
EN
Focus adjustments knob
Removable adsorption front cover
Pupil distance adjusting button Adsorption type switch
The object distance adjusting button
Overview
3
EN
Introduction
MT5510 MATRIX PRO VR are virtual reality glasses, you can enjoy 3D mov­ies or games. Device sup­ports smartphones from
3.5” to 6.0” displays (maxi­mum smartphone size: 154x82mm).
How to use
A. Run 3D movie, 3D game or virtual image. B. Make sure that displayed image is split in
two and in proper orientation. C. Open adsorption cover. D. Place smartphone as shown above. E. Adjust lenses to match your pupil distance
PD. F. Adjust object distance. This can adopt
myopia, without wearing myopia lens. G. Make focal adjustment for both eyes sepa-
rately for best clarity. H. If your smartphone is equipped with G-
sensor function you can move your head
to control the view.
3,5-6”
EN
Note! Do not use the device when smartphone is charged. It is recommended to use device in sitting position with back seat angled at 60° and not longer than 30 minutes in order to protect your vision.
Since smartphone is used inside virtual glasses we recom­mend to use MT5511 BT Trigger VR – Bluetooth remote control sold separately.
Due to continuous development specication and appearance of product are subject to change without prior notice. For technical support please visit www.media-tech.eu.
