MASTER-MID GPS
Mobility, Versatility, Flexibility
MT7000
User Manual
Introduction ................................................................................................ 2
EN
Package contents ...................................................................................... 2
Overview ...................................................................................................... 2
Buttons .......................................................................................................... 3
Power On / Power Off .............................................................................. 3
Suspend mode ...........................................................................................4
Installing microSD card ........................................................................... 4
Uninstalling microSD card .....................................................................4
Connecting / Disconnecting USB pendrive ..................................... 4
Storage space .............................................................................................4
Interface ........................................................................................................ 4
Keyboard ...................................................................................................... 4
Touch screen ...............................................................................................5
Desktop ......................................................................................................... 5
Icons on status bar .................................................................................... 5
System settings .......................................................................................... 5
Language setting ......................................................................................6
Date setting ................................................................................................. 6
Wi-Fi connection ........................................................................................ 6
UMTS connection ...................................................................................... 6
Application Management ......................................................................7
Install.............................................................................................................. 7
Uninstall ........................................................................................................ 7
Access to free applications.....................................................................8
Web Browser ............................................................................................... 8
E-mail ............................................................................................................. 8
Watching on-line videos ......................................................................... 9
Photo browsing ........................................................................................10
Music player ..............................................................................................10
Video player ...............................................................................................11
Watching on TV set .................................................................................11
2
GPS Navigation ........................................................................................12
Screen/device unlock.............................................................................12
Restore default settings ........................................................................12
Introduction
Thank you for buying this cutting edge media internet device. MT7000 is equipped with Wi-Fi interface,
GPS receiver, internal built-in rechargeable battery
and touch screen. Please take a moment and read this
manual before using the device.
Package contents
¯ tablet with stylus,
¯ power adaptor AC 220V,
¯ microUSB to USB adaptor,
¯ on-glass mounting support,
¯ car charger DC 12V
¯ user manual.
Overview
DesktopBack
ON/OFF Menu
Power
LED
Headphones
TF Card
DC 5V Input
USB
RESET
Power On
Press and hold ON/OFF button
until you see system logo.
System is loading, it takes
about 1 min.
Power Off
Press and hold ON/OFF button for about 3 seconds, device shutdown options will appear as below:
EN
Buttons
ON/OFF - to power on/off device.
Back – back to previous window.
Menu – show menu options.
Desktop – show main desktop.
Use fi nger and select desired option. If you do not
use for short period your tablet you can switch it into
“suspend” mode for energy saving. If you want to shutdown device select “power off ” option and then click
OK when prompted.
3
Suspend mode
EN
In this mode screen is switched off , Wi-Fi is switched
off , all button except ON/OFF button are disabled. To
recover from suspend mode to normal mode press ON/
OFF button once.
Note! When boarding an airplane turn device into
“suspend mode”. If you want to use tablet during
fl ight go to “Settings/Wireless&networks/Wi-Fi” and
uncheck this option to disable Wi-Fi network card.
Note! Device will automatically switch into “suspend mode” after a time of idle according to “Screen
timeout” setting.
Installing microSD card
Put gently microSD/T-fl ash card into TF card slot. Pin
connectors should face bottom of tablet. Use your fi ngertip to slide card into slot until it is hatched.
Uninstalling microSD card
Exit all applications, go to “Settings/SD card& storage
settings” and click “Unmount SD card”.
In the system notifi cation area “safely remove SD” will
pop-up, you can take out microSD card.
4
Connecting USB pendrive
Go to “Settings/USB mode select/Host mode” and enable it. Now plug pendrive using attached microUSB ->
USB adaptor.
Disconnecting USB pendrive
Exit all applications, then unplug pendrive.
Storage space
There are three storage devices:
¯ SD Card (available when connected), ¯ Internal
Memory, ¯ USB (available when connected).
Interface
Keyboard
Whenever there is need to enter a text – a screen key-
board will appear automatically.
Touch screen
Click: simply tap with one fi nger.
Long press: press and hold on selected item until con-
text menu pop-up.
Drag&Drop: select item and drag it. You can also tap
and slide your fi nger to change desktops or to view another picture (when in photo mode).
Note! Touch screen has auto rotation function
enabled by default. If you do not like this feature
you
can disable it in “Settings/Display/Auto-rotate
screen”.
Desktop
Icons on status bar
Battery level
Actual time
Volume up
Volume down
Wi-Fi connection
Back
Show menu options
Back to main desktop
System settings
On the main desktop click icon and then click „Settings” icon to enter system settings:
EN
5
Language setting
EN
Select “Language & keyboard”, then click “Select language” and select desired system language.
Date setting
Go to “Settings/Date & time settings” and set manually
or mark option “Automatic” – date will be synchronized
automatically when tablet will logon to cell network (it
requires an active UMTS connection).
Wi-Fi connection
Go to “Settings/Wirelles & networks” and click “Wi-Fi”
to enable Wi-Fi card. Then click “Wi-Fi settings” to enter
next menu, then click “Add Wi-Fi network”. Enter parameters provided by your Wi-Fi network administrator.
6
When connection is established under “Wi-Fi” option
there will be information “Connected to [name of network]”. Also Wi-Fi network icon will be displayed on the
status bar.
Note! When you go out of reach of Wi-Fi network or
go to “Suspend mode” or “Power off mode” you will
be disconnected. Device will automatically establish connection when power on. If it does not, go to
“Wi-Fi settings” to uncheck and check again “Wi-Fi”
option to force establishing Wi-Fi connection.
UMTS connection
Power off device and then plug USB UMTS modem.
Power on the device. Go to “Wirelles & networking” settings and turn off “Wi-Fi” connection and then turn on
“Mobile network” .
Next click “Mobile network settings” and enter parameters provided by UMTS operator.
Application Management
Install
On the main desktop click icon, then “explorer” application. Click desired *.apk fi le to run installation. Follow on-screen messages to fi nish installation.
Uninstall
Go to “Settings/Applications/Manage applications”.
EN
Select desired icon and then click “Uninstall” button.
7
Access to free applications
EN
Open “E-Market” icon on desktop, when you run for fi rst
time you will be asked to setup a google account, follow on-screen messages.
8
When google account has been set you can browse
available application, those marked as “free” are free of
charge.
Note! You can also set google account in “Settings/
Accounts & sync/Add account”.
Web Browser
On the main desktop in the right upper corner click
“Earth” icon, a web browser will be started:
Click in the address bar, then screen keyboard will appear, you can enter desired webpage.
E-mail
On the main desktop in the right lower corner click
“Envelope” icon, an e-mail application will be started.
When running for the fi rst time you will be asked to
confi gure your e-mail account fi rst.
Follow on-screen messages to confi gure e-mail box.
For standard e-mail box select POP3 type account.
Enter parameters provided by your e-mail account administrator.
EN
Watching on-line videos
On the main desktop click “YouTube” icon, in the search
fi eld enter phrase to locate video you want to play.
9
Photo browsing
EN
On the main desktop click “Photo” icon to run photo
browser. Application will scan all accessible devices
and will show only supported photo fi les.
10
Select fi le, click it to view in full screen mode. Use fi nger
to swipe across screen to view next/previous fi le. Tap
on screen to pop-up menu options: slideshow, rotation, crop, set as wallpaper, info.
Music player
On the main desktop click “Audio Player” icon to run audio player. Application will scan all accessible devices
and will show only supported music fi les.
Click on selected fi le to start playing. Following screen
will appear:
Video player
On the main desktop click “Video Player” icon to run
video player. Application will scan all accessible devices
and will show only supported video fi les.
Click on selected fi le to start playing. Following screen
Click on selected fi le to start video fi le in full screen
mode.
Watching on TV set
Use special Component-USB cable (optional) and connect tablet to video-in of TV set. Use minijack-cinch
(optional) and connect headphones output to audioin of TV set. During watching click once on the touch
screen, a menu will pop-up. Now click the fi rst icon on
the right and select appropriate TV mode.
Note! If you have a standard AV input in your TV
set – connect only red plug of Component cable to
video input of TV set.
11
EN
GPS Navigation
EN
To access GPS function install GPS navigation application fi rst or use the one bundled with system software.
12
To operate please refer to navigation application user’s
manual.
Screen/device unlock
Press ON/OFF button once to unlock.
Restore default settings
Go to “Settings/Privacy/Factory reset”. Click “reset” icon
and confi rm this operation.
It will erase data from device including:
¯ Your google account,
¯ System and application data and settings,
¯ Downloaded applications.
It will not erase following:
¯ Current system software and bundled applications,
¯ SD card fi les, such as music or photos.
* Functions and technical specifi cation of device are subject to change without prior notice. For technical support please visit www.media-tech.eu
