MAC DVB-T
STICK
Watch & record Digital TV
programs on Your Mac!
MT4170
User Manual
Page 2
EN
Overview ����������������������������������������������������������������������������������������������2 Introduction ����������������������������������������������������������������������������������������2 Feature List ������������������������������������������������������������������������������������������2 System Requirements ���������������������������������������������������������������������� 2 Package Contents ������������������������������������������������������������������������������2 Mac TV Installation for Mac OSX ��������������������������������������������������3 Mac TV Installation for Windows OS �������������������������������������������3 How to use Fuugo Software ���������������������������������������������������������� 4 Initial Use ���������������������������������������������������������������������������������������������� 4 Channel Search ����������������������������������������������������������������������������������4 Switching channels ���������������������������������������������������������������������������5 Program Specific Features ��������������������������������������������������������������5 Program Guide �����������������������������������������������������������������������������������6 Window mode ������������������������������������������������������������������������������������ 7 Keyboard functions ��������������������������������������������������������������������������7 Settings �������������������������������������������������������������������������������������������������7

Overview

Introduction

MT4170 is a compact TV tuner stick that powered by a high performance tuner and demodulator to de­liver digital television (DVB-T) to your Mac or Widows� This stylish USB TV Tuner allows you to watch, record, time-shift and share television programs on your iMac, Macbook, Mac Mini and Windows PC� It captures and
2
displays your HDTV shows in MPEG-2 and H�264/AVC digital format with quality on your computer�

Feature List

Watch and record digital TV on your Mac® and Win­dows PC
Ultra-slim with Mac-style
Superior reception quality for HDTV
Friendly and easy-to-use software
Electronic Program Guide (EPG)
Telescope antenna with High sensitivity
Supporting DTV Receiving
Create favorite program for convenient watching

System Requirements

Mac® with built in USB 2�0 connectivity
G5/1�6 Ghz or higher, Intel processor
Mac® OSX 10�4, 10�5 or higher
512 MB or above RAM
HD Resolutions require dual G5 or Intel Dual Core
Processor
Windows 7/Vista/XP

Package Contents

USB TV stick
Antenna
RF Antenna Converter
Page 3

Mac TV Installation for Mac OSX

Step1. Plug the portable antenna to DVB-T Mini TV Stick Step2. Plug the MT4170 to USB port of your laptop/PC Step3. Please download software, driver and software
manual from:
http://www.media-tech.eu/products/dvb -t-stick/ MT4170
Double click to run installation�

Mac TV Installation for Windows OS

Step1. Plug the portable antenna to MT4170 Step2. Plug the MT4170 to USB port of your laptop/PC� Step3. Please download software, driver and software
manual from:
http://www.media-tech.eu/products/dvb -t-stick/ MT4170
Double click to run installation�
Step4. Click language to continue installation� During the installation, you also need to accept to install Mi­crosoft Visual C++ package�
EN
3
Page 4
EN

How to use Fuugo Software

Initial Use

After the application (Fuugo T V) is installed and launched for the first time, user is asked to select the country where MT4170 is used� Country Selection is il­lustrated with flag symbols� Next user is asked to accept EULA, and enter a valid product key� Product key can be entered also later, however within 90 day trial period�

Channel Search

Behind the intro sequence, channels are searched au­tomatically according to selected country� After chan­nel search is finished, the application starts playing the first found channel� If you face problems in chan-
4
Page 5
nel search, please find more information on channel search in the later chapter�

Switching channels

Channels can be switched by swiping left-to-right for next channel, or right–to-left for previous channel� Swiping can be done in several ways:
Two-finger swipe on the Mac Book Trackpad / Swipe on touch screen optimized Windows device
Mouse click & swipe left/right on a normal mouse
PgUp/PgDown press from keyboard
You may switch to a specific channel also via channel bar� Swipe upwards and select the logo of the desired channel from the channel bar� Also the number keys in the keyboard can be used in switching directly to a certain channel�
EN
Program Specific Features
While watching a program, you may right click (on win­dows pc) or double-finger click (on MacBook) anywhere on the screen to access a program related Menu Card�
5
Page 6
The menu card has two sides; program related actions,
EN
and program description� You may change between the sides anytime by tapping at the top of the Menu card� In Menu card, the following actions can be performed:
Adding the program to Favorite program
Enter Extras view for reading extra information of
the program
Record / Stop recording the program

Program Guide

You may access Program Guide by swiping downwards and selecting “Program Guide” from the view bar�
In Program Guide, Menu card can be accessed by right clicking (on windows pc) or double-finger clicking (on MacBook) the screen over the program� In Menu card,
6
the following actions can be performed:
Adding the program to Favorite program
Enter Extras view for reading extra information of
the program
Record / Stop recording the program
From Program Guide, also the recordings can be ac­cessed by selecting “Record­ings” from the top menu� In Recordings view, Menu card can be invoked by tapping over the desired recording� The following actions can be performed:
Enter Extras view for
Page 7
reading extra information of the recorded program
Play the selected recording
Remove the selected recording
In the Recordings view you can access Schedulings view, where the scheduled programs are listed�
When a recording is played, list of the recordings can be invoked by swiping upwards; from the list, you may select a recording you wish to play� When you swipe up again, control panel is invoked; you can pause and resume video, and jump inside the video�

Window mode

Window mode button from the view bar (or keyboard
key “F”) changes window size smaller� In the small win­dow, channels can be changed normally by swiping left/right, or PgUp/PgDown� Volume can be controlled with +/- buttons� To return to Full Screen view, double click the video or press “F” key�

Keyboard functions

Key Command in Windows Mode Action
PgUp Channel change forwards
PgDown Channel change backwards
+/= Add volume
-/_ Reduce volume
space Pause/Resume
m Mute
esc Exit Fuugo
Key Command in Normal Full-Screen Action
e Program Guide
Backspace Back

Settings

From the Settings menu the user can adjust and alter several properties affecting the behavior and appear­ance of the application� Settings menu can be accessed through View bar�
EN
7
Page 8
Updating application
EN
The application (Fuugo TV) can be easily updated to the latest version via the Internet� First check if there is a newer version available by clicking on “Check Update”� If Fuugo finds a newer version, it can be downloaded by clicking on “Download Update”� It may take some time to download the update� After the installer package has been downloaded, it can be installed by clicking on “In­stall Update”� When the latest version of Fuugo has been installed, follow the on-screen instructions�
Channel Search
In Settings menu channel search can be started� You can choose the country where you are located from the coun­try specific channel search� Fuugo will find you the chan­nels from your area� If channels are not found, please make sure that the re­ceiver antenna is properly attached to the USB receiver� You may also need to change the location in order to im­prove the signal quality� In case of traveling, you may want to search for the local channels with the country specific
8
channel search� You may also want to update your chan­nels in case of new channels are available in your area�
Parental Control
Fuugo offers you a possibility to activate the Parental Control from the Settings menu� You can set the age lim­it for TV programs, in scale from one to eighteen years� In order to activate the Parental Control password is need­ed, the default password is 1234 and it can be changed� After Parental control is activated, a lock symbol is shown in Program Guide for restricted TV programs� When Parental Control is set, Fuugo will automatically filter all TV programs that are over the set age limit� Note, that in some countries Parental Control information is not available in the national TV broadcasting�
Specification and appearance of product are subject to change without prior notice. For technical support please visit www.media-tech.eu.
