DESCRIPTION
module
low
cost and low
power consumption module which
With seamless roaming capabilities and advanced security, GB8632 can also interact
p
pp
is a
has all the WiFi and Bluetooth function. The highly integrated module makes
the possibilities of web browsing, VoIP, Bluetooth headsets and other applications.
with different vendors’ 802.11b/g/n Access Points in the wireless LAN.
The wireless module complies with IEEE 802.11 b/g/n standard and it can achieve up
to a s
The wireless module complies with IEEE 802.11 b/g/n standard and it can achieve up
to a speed of 65Mbps with single stream in 802.11n, 54Mbps as specified in IEEE
802.11g, or 11Mbps for IEEE 802.11b to connect to the wireless LAN.
*802.11 b/g/n + Bluetooth 2.1 + EDR *Dimension =10.0 x 10.0 x 1.4 mm
*Co-existence considered *Single antenna needed
eed of 65Mbps.
-
-
*No external clock source needed * RoHS compliant/Lead Free
*Shielding module
Specification
Input Power DC 3.3 V
Module Connection 60Pin, LGA
Dimensions 10 x 10 x 1.4mm
HW Interface WiFi : SDIO/SPI
BT: UART
Standard 802.11b : DSSS
802.11g/n : OFDM
BT: Bluetooth 2.1 + EDR
Data rate(Mbps) 802.11b:11(Max)
802.11g:54(Max)
802.11n:65(Max)
BT:2.0(EDR) of 1, 2 & 3
Frequency Range 802.11b/g/n:2.412 ~2.472GHz
BT:2.402 ~ 2.480GHz
y
RF receive sensitivit
802.11b 11Mbps:-87dBm(Typ)
802.11g 54Mbps:-72dBm(Typ)
RF transmit power
802.11n 6
802.11b: <13dBm
5Mbps:-69dBm(Typ)
802.11g/n: <15dBm
BT: <2.0 dBm
Security WEP(64/128 bits)
WPA(TKIP + 802.1X)
802.11i(AES, TKIP,802.1X)
Temperature Range -
20 ℃
-40 ℃ ~
~ 55 ℃(Operating)
85 ℃(Storage)
Humidity Max. 95% Non-Condensing
Compliance RoHS compliant/Lead Free
this module should not be installed and operating in conjunction with any
other antenna or transmitter , additional equipment authorization may be
required if radio is installed and operating in conjunction with any other
antenna or transmitter
Use of radio module in host system which not indicated in FCC filing may
subject to additional Permissive change equipment authorization.
How to do labeling
: “Contains FCC ID: QI6-M3”
