Measurement Computing USB-1608G User Manual

USB-1608G
User's Guide
Multifunction DAQ Device
Document Revision 1A November 2014 © Copyright 2014
Trademark and Copyright Information
Measurement Computing Corporation, InstaCal, Universal Library, and the Measurement Computing logo are either trademarks or registered trademarks of Measurement Computing Corporation. Refer to the Copyrights & Trademarks section on mccdaq.com/legal for more information about Measurement Computing trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies.
© 2014 Measurement Computing Corporation. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measur Corporation.
Notice
Measurement Computing Corporation does not authorize any Measurement Computing Corporation product for use in life support systems and/or devices without prior written consent from Measurement Computing Corporation. Life support devices/systems are devices or systems that, a) are intended for surgical implantation into the body, or b) support or sustain life and whose failure to perform can be reasonably expected to result in injury. Measurement Computing Corporation products are not designed with the components required, and are not subject to the testing required to ensure a level of reliability suitable for the treatment and diagnosis of people.
ement Computing
Table of Contents
Preface
About this User's Guide ....................................................................................................................... 5
What you will learn from this user's guide ......................................................................................................... 5
Conventions in this user's guide ......................................................................................................................... 5
Where to find more information ......................................................................................................................... 5
Chapter 1
Introducing the USB-1608G ................................................................................................................. 6
Functional block diagram ................................................................................................................................... 6
Chapter 2
Installing the USB-1608G ..................................................................................................................... 7
Unpacking........................................................................................................................................................... 7
Installing the software ........................................................................................................................................ 7
Installing the hardware ....................................................................................................................................... 7
Calibrating .......................................................................................................................................................... 7
Self-calibration ................................................................................................................................................................. 7
Factory calibration ............................................................................................................................................................ 7
Firmware updates ............................................................................................................................................... 7
Chapter 3
Functional Details ................................................................................................................................. 8
Analog input modes ............................................................................................................................................ 8
Software paced .................................................................................................................................................................. 8
Hardware paced ................................................................................................................................................................ 8
Burst mode.......................................................................................................................................................... 8
External components .......................................................................................................................................... 9
USB connector .................................................................................................................................................................. 9
LEDs ................................................................................................................................................................................. 9
Screw terminals................................................................................................................................................................. 9
Signal connections ............................................................................................................................................ 11
Analog input ....................................................................................................................................................................11
External clock I/O ............................................................................................................................................................12
Digital I/O ........................................................................................................................................................................12
Trigger input ....................................................................................................................................................................13
Counter input ...................................................................................................................................................................13
Timer output ....................................................................................................................................................................14
Power output ....................................................................................................................................................................14
Ground ................................................................................................................................................................ .............14
Mechanical drawings ................................................................................................................................ ........ 15
Chapter 4
Specifications ...................................................................................................................................... 16
Analog input ..................................................................................................................................................... 16
Accuracy ........................................................................................................................................................... 17
Analog input DC voltage measurement accuracy ............................................................................................................17
Noise performance ...........................................................................................................................................................17
Settling time .....................................................................................................................................................................17
Analog input calibration ................................................................................................................................... 17
Digital input/output........................................................................................................................................... 18
External trigger ................................................................................................................................ ................. 18
External clock input/output............................................................................................................................... 19
Counter ............................................................................................................................................................. 19
3
USB-1608G User's Guide
Timer ................................................................................................................................................................ 20
Memory ............................................................................................................................................................ 20
Power ................................................................................................................................................................ 20
USB .................................................................................................................................................................. 20
Environmental .................................................................................................................................................. 21
Mechanical ....................................................................................................................................................... 21
Screw terminal connector ................................................................................................................................. 21
Differential mode pinout ..................................................................................................................................................21
Single-ended mode pinout ...............................................................................................................................................22
Declaration of Conformity .................................................................................................................. 23
4

About this User's Guide

What you will learn from this user's guide

This user's guide describes the Measurement Computing USB-1608G data acquisition device and lists device specifications.

Conventions in this user's guide

For more information
Text presented in a box signifies additional information and helpful hints related to the subject matter you are reading.
Caution! Shaded caution statements present information to help you avoid injuring yourself and others,
damaging your hardware, or losing your data.
bold text Bold text is used for the names of objects on a screen, such as buttons, text boxes, and check boxes.
italic text Italic text is used for the names of manuals and help topic titles, and to emphasize a word or phrase.

Preface

Where to find more information

Additional information about the USB-1608G is available on our website at www.mccdaq.com. You can also contact Measurement Computing Corporation by phone, fax, or email with specific questions.
Knowledgebase: kb.mccdaq.com Tech support form: www.mccdaq.com/support/support_form.aspx Email: techsupport@mccdaq.com Phone: 508-946-5100 and follow the instructions for reaching Tech Support
For international customers, contact your local distributor. Refer to the International Distributors section on our website at www.mccdaq.com/International.
5
Chapter 1

Introducing the USB-1608G

The USB-1608G is a USB 2.0 high-speed device that provides the following features:
16 single-ended (SE) or eight differential (DIFF) analog input channels Eight individually configurable digital I/O channels Two counter channels (32-bit) that count TTL pulses One timer output channel (32-bit) Screw terminals for field wiring connections
The USB-1608G is powered by the +5 volt USB supply from your computer; no external power is required. A USB cable is shipped with the device.
The USB-1608G device is compatible with both USB 1.1 and USB 2.0 ports. The speed of the device may be limited when using a USB 1.1 port due to the difference in transfer rates on the USB 1.1 versions of the protocol (low-speed and full-speed).

Functional block diagram

USB-1608G functions are illustrated in the block diagram shown here.
Figure 1. Functional block diagram
6
Chapter 2

Installing the USB-1608G

Unpacking

As with any electronic device, you should take care while handling to avoid damage from static electricity. Before removing the device from its packaging, ground yourself using a wrist strap or by simply touching the computer chassis or other grounded object to eliminate any stored static charge.
Contact us immediately if any components are missing or damaged.

Installing the software

Refer to the MCC DAQ Quick Start for instructions on installing the software on the MCC DAQ CD. Refer to the device product page on the Measurement Computing website for information about the included and optional software supported by the USB-1608G.
Install the software before you install your device
The driver needed to run the USB-1608G is installed with the software. Therefore, you need to install the software package you plan to use before you install the hardware.

Installing the hardware

To connect a USB-1608G to your system, turn on your computer and connect the USB cable to an available USB port on the computer or to an external USB hub connected to the computer. Connect the other end of the USB cable to the USB connector on the device. No external power is required.
When you connect the device for the first time, a Found New Hardware dialog opens when the operating system detects the device. The dialog closes after the device is installed.
A green Status LED indicates the device status. When the LED is on, the device is powered and ready for operation. When the LED is off, the device is not powered or did not initialize. Figure 3 on page 9 shows the location of the Status LED. If the Status LED is on but then turns off, the computer has lost communication with the device. To restore communication, disconnect the USB cable from the computer and then reconnect it. This should restore communication, and the LED should turn on.
Caution! Do not disconnect any device from the USB bus while the computer is communicating with
the USB-1608G, or you may lose data and/or your ability to communicate with the device.

Calibrating

Self-calibration

The USB-1608G supports self-calibration with InstaCal. Calibrate the device whenever the ambient temperature changes by more than ±10 °C from the last self-calibration.

Factory calibration

The Measurement Computing Manufacturing Test department performs the initial factory calibration. Contact Measurement Computing for details about how to return your device and have it calibrated to the factory specifications.

Firmware updates

Your DAQ device contains firmware that can be updated in the field if required. Firmware is available for download at www.mccdaq.com/firmware.aspx.We recommend that you check this page periodically to see if an update to your device firmware is available.
7
Chapter 3

Functional Details

Analog input modes

The USB-1608G device can acquire analog input data in two basic modes – software paced and hardware paced.

Software paced

You can acquire one analog sample at a time in software paced mode. You initiate the A/D conversion with a software command. The analog value is converted to digital data and returned to the computer. Repeat this procedure until you have the total number of samples that you want.
The sample rate in software paced mode is system-dependent and can range from 33 S/s to 4000 S/s.

Hardware paced

You can acquire data from up to 16 channels in hardware paced mode. The analog data is continuously acquired, converted to digital values, and written into the FIFO buffer on the device until you stop the scan. The FIFO buffer is serviced in blocks as the data is transferred from the FIFO buffer to the computer memory buffer. You start a continuous scan with either a software command or with an external hardware trigger event.
The maximum sampling rate in hardware paced mode from one to 16 channels is 250 kS/s aggregate.

Burst mode

When using the onboard pacer, you can enable burst mode for more precise timing between samples. When burst mode is enabled, each successive channel in a scan is sampled at the maximum A/D rate. This ensures that samples from each channel are taken as close as possible to the same absolute point in time. When burst mode is disabled, data is sampled at evenly spaced intervals, allowing maximum settling time and best amplitude accuracy. Multi-channel scanning with burst mode enabled and disabled is shown in Figure 2.
Figure 2. Multi-channel scan with burst mode enabled and disabled
The burst mode sample period is 4 µs. You can trigger the acquisition with the external trigger, and control the clock period with the internal or
external A/D pacer clock. Pacing from the external clock always operates with burst mode enabled.
8
USB-1608G User's Guide Functional Details
1
Screw terminal pins 1 to 27
4
Activity LED
2
Screw terminal pins 28 to 54
5

USB connector

3
Status LED

External components

The USB-1608G has the following external components (see Figure 3):
USB connector LEDs Screw terminals
Figure 3. External components
USB connector
The USB connector provides +5 V power and communication. No external power supply is required.

LEDs

The USB-1608G has two LEDs – Status and Activity.
The Status LED turns on when the device is detected and installed on the computer. The Activity LED blinks when data is transferred, and is off otherwise.
Figure 3 shows the location of each LED.

Screw terminals

The screw terminals provide the following connections:
16 SE (CH0 to CH15) or eight DIFF (CH0H/CH0L to CH7H/CH7L) analog inputs Eight digital I/O bits (DIO0 to DIO7) One external clock input (AICKI) and one external clock output (AICKO) for analog inputs One digital trigger input (TRIG) Two counter inputs (CTR0, CTR1) One timer output (TMR) One power output (+5V) Analog ground (AGND) and digital ground (GND) connections
The single-ended mode pinout is shown in Figure 4, and the differential mode pinout is shown in Figure 5.
9
USB-1608G User's Guide Functional Details
Figure 4. SE mode pinout
Figure 5. DIFF mode pinout
10
USB-1608G User's Guide Functional Details

Signal connections

Analog input

You can configure the analog inputs for SE or DIFF mode. The input voltage range is software selectable for ±10 V, ±5 V, ±2 V, or ±1 V.
With SE mode, connect up to 16 inputs to screw terminals CH0 to CH15. SE mode requires two wires:
Connect one wire to the signal you want to measure (CHx). Connect one wire to the analog ground reference (AGND).
Refer to Figure 4 on page 10 for the location of the SE inputs. With DIFF mode, connect up to eight differential inputs to screw terminals CH0H/CH0L to CH7H/CH7L.
DIFF mode requires two wires plus a ground reference:
Connect one wire to the high/positive signal (CHxH). Connect one wire to the low/negative signal (CHxL). Connect one wire to the analog ground reference (AGND).
Refer to Figure 5 on page 10 for the location of the DIFF inputs.
Floating voltage source
When connecting DIFF voltage inputs to a "floating" voltage source, make sure the DIFF input channel has a DC return path to ground. To create this path, connect a resistor from each low channel input to an AGND pin. A value of approximately 100 kΩ can be used for most applications.
Leave unused input channels either floating or tied to an AGND terminal. Source impedances should be kept as small as possible to avoid settling time and accuracy errors.
Figure 6 shows DIFF channels 0-3 connected to a ground path resistor.
Figure 6. DIFF connections with ground path resistor
Channel-gain queue
The USB-1608G channel-gain queue feature allows you to configure a list of channels, modes, and gains for each scan. The settings are stored in a channel-gain queue list that is written to local memory on the device.
The channel-gain queue list contains one or more channel numbers, modes, and range settings. You can configure up to 16 elements. The channels can be listed in any order, and can include duplicate channels for sampling at different ranges.
11
USB-1608G User's Guide Functional Details
Element
Channel
Range
Mode
0
CH5
BIP5V
SE
1
CH1
BIP10V
DIFF
2
CH15
BIP1V
SE
3
CH5
BIP5V
SE
An example of a 4-element list is shown in the table below.
Sample channel-gain queue list
Carefully match the gain to the expected voltage range on the associated channel or an over range condition may occur. Although this condition does not damage the device, it does produce a useless full-scale reading, and can introduce a long recovery time due to saturation of the input channel.
For more information about analog signal connections
For more information about analog input connections, refer to the Guide to DAQ Signal Connections (available on our web site at www.mccdaq.com/signals/signals.pdf).

External clock I/O

The device has one external clock input (AICKI) and one external clock output (AICKO) for the analog inputs.
When using an external clock, AICKO outputs the pulse generated from AICKI. When using the internal clock, AICKO outputs the ADC scan clock.

Digital I/O

You can connect up to eight digital I/O lines to DIO0 through DIO7. Each digital channel is individually configurable for input or output. The digital I/O terminals can detect the state of any TTL-level input. Refer to the schematic shown in Figure 7.
Figure 7. Schematic showing switch detection by digital channel DIO0
If you set the switch to the +5 V input, DIO0 reads TRUE (1). If you move the switch to GND, DIO0 reads FALSE (0).
Internal pull-up/down configuration
Unconnected inputs are pulled low by default to 0 V through 47 resistors via jumper W1 on the circuit board. The pull-up/pull-down voltage is common to all 47 kΩ resistors. Complete the following steps to configure these inputs to pull high (+5V).
Caution! The discharge of static electricity can damage some electronic components. Before removing the
device from its housing, ground yourself using a wrist strap or touch the computer chassis or other grounded object to eliminate any stored static charge.
1. Turn the device over and rest the top of the housing on a flat, stable surface.
2. Peel off the four rubber feet on the bottom of the device to access the screws.
3. Remove the four screws from the bottom of the device.
4. Hold both the top and bottom sections together, turn the device over and rest it on the surface, then
carefully remove the top section of the case to expose the circuit board.
12
USB-1608G User's Guide Functional Details
5. Configure jumper W1 for either pull-up or pull-down. The jumper is configured by default for pull-down.
Figure 8 shows the location of the jumper on the board.
Figure 8. W1 jumper location
Figure 9 shows the jumper configured for pull-up and pull-down.
Figure 9. W1 jumper configurations
6. Replace the top section of the case, and fasten it to the bottom section with the four screws. Replace the
rubber feet onto each screw.
For more information about digital signal connections
For general information about digital signal connections and digital I/O techniques, refer to the Guide to Signal Connections (available on our web site at www.mccdaq.com/signals/signals.pdf).

Trigger input

The TRIG terminal is an external digital trigger input. The trigger mode is software selectable for edge or level sensitive.
Edge sensitive mode is configurable for rising or falling edge. Level sensitive mode is configurable for high or low level.
The default setting at power up is edge sensitive, rising edge.
Retrigger mode
Retrigger mode lets you set up repetitive analog input or output trigger events. The trigger is automatically re­armed after it is activated. Use software to set the A/D or D/A trigger count (the number of samples you want per trigger).

Counter input

The CTR0 and CTR1 terminals are 32-bit event counters that can accept frequency inputs up to 20 MHz. The internal counter increments when the TTL levels transition from low to high.
13
USB-1608G User's Guide Functional Details

Timer output

The TMR terminal is a pulse width modulation (PWM) timer output that can generate a pulse output with a programmable frequency in the range of 0.0149 Hz to 32 MHz. The timer output parameters are software selectable. Figure 10 shows the timer output schematic.
Figure 10. Timer output schematic

Power output

The +5V terminal can output up to 10 mA maximum. You can use this terminal to supply power to external devices or circuitry.
Caution! The +5V terminal is an output. Do not connect to an external power supply or you may damage the
device and possibly the computer.

Ground

The analog ground (AGND) terminals provide a common ground for all analog channels. The digital ground (GND) terminals provide a common ground for the digital, counter, timer, and clock
channels and the power terminal.
14
USB-1608G User's Guide Functional Details

Mechanical drawings

Figure 11. USB-1608G circuit board (top) and enclosure dimensions
15
Parameter
Condition
Specification
A/D converter type
Successive approximation
ADC resolution
16 bits
Number of channels
8 differential, 16 single-ended Software-selectable
Input voltage range
±10 V, ±5 V, ±2 V, ±1 V Software-selectable per channel
Absolute max input voltage
CHx relative to AGND
±25 V max (power on) ±15 V max (power off)
Input impedance
1 GΩ (power on) 820 Ω (power off)
Input bias current
±10 nA
Input bandwidth
All input ranges, small signal (–3 dB)
750 kHz
Input capacitance
60 pf
Max working voltage (signal + common mode)
±10V range
±10.2 V max relative to AGND
±5V range
±10.2 V max relative to AGND
±2V range
±9.5 V max relative to AGND
±1V range
±9.0 V max relative to AGND
Common mode rejection ratio
(fIN = 60 Hz, all input ranges)
86 dB
Crosstalk
Adjacent differential mode channels, DC to 100 kHz
–75 dB Input coupling
DC
Sampling rate
0.0149 Hz to 250 kHz; software-selectable
Trigger source
TRIG (see External trigger on page 18)
Sample clock source
Internal A/D clock or external A/D clock (AICKI pin)
Burst mode
4 µs Software-selectable using the internal A/D clock; always enabled when using the external clock (AICKI pin).
Throughput Software paced
33 to 4000 S/s typ, system dependent
Hardware paced
250 kS/s max
Channel gain queue
Up to 16 elements
Software-selectable range for each channel
Warm-up time
15 minutes min

Specifications

All specifications are subject to change without notice. Typical for 25 °C unless otherwise specified. Specifications in italic text are guaranteed by design.

Analog input

Table 1. General analog input specifications
Chapter 4
16
USB-1608G User's Guide Specifications
Range
Gain error (% of reading)
Offset error (µV)
INL error (% of range)
Absolute accuracy at Full Scale (µV)
Gain temperature coefficient (% reading/°C)
Offset temperature coefficient (µV/°C)
±10 V
0.024
915
0.0076
4075
0.0014
47
±5 V
0.024
686
0.0076
2266
0.0014
24
±2 V
0.024
336
0.0076
968
0.0014
10
±1 V
0.024
245
0.0076
561
0.0014
5
Range
Counts
LSBrms
±10 V
6
0.91
±5 V
6
0.91
±2 V
7
1.06
±1 V
9
1.36
Range
4 µS settling accuracy (% FSR)
6 µS settling accuracy (% FSR)
±10 µS settling accuracy (% FSR)
±10 V
0.0061
0.0031
0.0015
±5 V
0.0061
0.0031
0.0015
±2 V
0.0061
0.0031
0.0015
±1 V
0.0061
0.0031
0.0015
Parameter
Specification
Recommended warm-up time
15 minutes min
Calibration method
Self-calibration (firmware)
Calibration interval
1 year (factory calibration)
Calibration reference
+5 V, ±2.5 mV max. Actual measured values stored in EEPROM.
Tempco: 5 ppm/°C max
Long term stability: 15 ppm/1000 hours

Accuracy

Analog input DC voltage measurement accuracy

Table 2. DC accuracy components and specifications. All values are (±)

Noise performance

For the peak-to-peak noise distribution test, a differential input channel is connected to AGND at the input terminal block, and 32,000 samples are acquired at the maximum rate available at each setting.
Table 3. Noise performance specifications

Settling time

Settling time is defined as the accuracy that can be expected after one conversion when switching from a channel with a DC input at one extreme of full scale to another channel with a DC input at the other extreme of full scale. Both input channels are configured for the same input range.
Table 4. Input settling time specifications in µS, typical

Analog input calibration

Table 5. Analog input calibration specifications
17
USB-1608G User's Guide Specifications
Parameter
Specification
Digital type
CMOS
Number of I/O
8
Configuration
Each bit may be configured as input (power on default) or output
Pull-up configuration
The port has 47 kΩ resistors configurable as pull-ups or pull-downs (default) via internal jumper (W1).
Digital I/O transfer rate (system-paced)
33 to 8000 port reads/writes or single bit reads/writes per second typ, system dependent.
Input high voltage
2.0 V min
5.5 V absolute max
Input low voltage
0.8 V max –0.5 V absolute min 0 V recommended min
Output high voltage
4.4 V min (IOH = –50 µA)
3.76 V min (IOH = –2.5 mA)
Output low voltage
0.1 V max (IOL = 50 µA)
0.44 V max (IOL = 2.5 mA)
Output current
±2.5 mA max
Parameter
Specification
Trigger source
TRIG input
Trigger mode
Software programmable for edge or level sensitive, rising or falling edge, high or low level. Power on default is edge sensitive, rising edge.
Trigger latency
1 µs + 1 clock cycle max
Trigger pulse width
100 ns min
Input type
Schmitt trigger, 33 Ω series resistor and 49.9 kΩ pull-down to ground
Schmitt trigger hysteresis
0.4 V to 1.2 V
Input high voltage
2.2 V min
5.5 V absolute max
Input low voltage
1.5 V max –0.5 V absolute min 0 V recommended min

Digital input/output

Table 6. Digital I/O specifications

External trigger

Table 7. External trigger specifications
18
USB-1608G User's Guide Specifications
Parameter
Specification
Terminal names
AICKI, AICKO
Terminal types
AICKI: Input, active on rising edge AICKO: Output, power on default is 0 V, active on rising edge
Terminal descriptions
AICKI: Receives sampling clock from external source
AICKO: Outputs the internal A/D sampling clock, or the pulse generated from AICKI when in external clock mode.
Input clock rate
250 kHz max
Clock pulse width AICKI: 400 ns min
AICKO: 400 ns min
Input type
Schmitt trigger, 33 Ω series resistor, 47 kΩ pull-down to ground
Schmitt trigger hysteresis
0.4 V to 1.2 V
Input high voltage
2.2 V min
5.5 V absolute max
Input low voltage
1.5 V max –0.5 V absolute min 0 V recommended min
Output high voltage
4.4 V min (IOH = –50 µA)
3.76 V min (IOH = –2.5 mA)
Output low voltage
0.1 V max (IOL = 50 µA)
0.44 V max (IOL = 2.5 mA)
Output current
±2.5 mA max
Parameter
Specification
Terminal names
CTR0, CTR1
Number of channels
2 channels
Resolution
32-bit
Counter type
Event counter
Input type
Schmitt trigger, 33 Ω series resistor, 47 kΩ pull-down to ground
Input source
CTR0 (pin 52) CTR1 (pin 51)
Counter read/writes rates (software paced)
33 to 8000 reads/writes per second typ, system dependent Input high voltage
2.2 V min, 5.5 V max
Input low voltage
1.5 V max, –0.5 V min
Schmitt trigger hysteresis
0.4 V min, 1.2 V max
Input frequency
20 MHz, max
High pulse width
25 ns, min
Low pulse width
25 ns, min

External clock input/output

Table 8. External clock I/O specifications

Counter

Table 9. Counter specifications
19
USB-1608G User's Guide Specifications
Parameter
Specification
Terminal name
TMR
Timer type
PWM output with count, period, delay, and pulse width registers
Output value
Default state is idle low with pulses high, software-selectable output invert
Internal clock frequency
64 MHz
Register widths
32-bit
High pulse width
15.625 ns min
Low pulse width
15.625 ns min
Output high voltage
4.4 V min (IOH = –50 µA)
3.76 V min (IOH = –2.5 mA)
Output low voltage
0.1 V max (IOL = 50 µA)
0.44 V max (IOL = 2.5 mA)
Output current
±2.5 mA max
Parameter
Specification
Data FIFO
4 kS analog input
Non-volatile memory
32 KB (28 KB firmware storage, 4 KB calibration/user data)
Parameter
Condition
Specification
Supply current (Note 1)
Quiescent current
230 mA
+5 V user output voltage range
Available at terminal block pin 42
4.5 V min to 5.25 V max
+5 V user output current
Available at terminal block pin 42
10 mA max
Parameter
Specification
USB device type
USB 2.0 (high-speed)
Device compatibility
USB 1.1, USB 2.0
USB cable type
A-B cable, UL type AWM 2725 or equivalent. (Min 24 AWG VBUS/GND, min 28 AWG D+/D–)
USB cable length
3 m (9.84 ft) max

Timer

Table 10. Timer specifications

Memory

Table 11. Memory specifications

Power

Table 12. Power specifications
Note 1: This is the total quiescent current requirement for the device that includes up to 10 mA for the Status
LED. This does not include any potential loading of the digital I/O bits or the +5V terminal.
USB
Table 13. USB specifications
20
USB-1608G User's Guide Specifications
Parameter
Specification
Operating temperature range
0 °C to 55 °C max
Storage temperature range
–40 °C to 85 °C max
Humidity
0% to 90% non-condensing max
Parameter
Specification
Dimensions (L × W × H)
127 × 89.9 × 35.6 mm (5.00 × 3.53 × 1.40 in.)
User connection length
3 m (9.84 ft) max
Parameter
Specification
Connector type
Screw terminal
Wire gauge range
16 AWG to 30 AWG
Pin
Signal name
Pin description
Pin
Signal name
Pin description
1
CH0H
AI channel 0 HI
28
CH7L
AI channel 7 LO
2
CH0L
AI channel 0 LO
29
CH7H
AI channel 7 HI
3
AGND
Analog ground
30
AGND
Analog ground
4
CH1H
AI channel 1 HI
31
CH6L
AI channel 6 LO
5
CH1L
AI channel 1 LO
32
CH6H
AI channel 6 HI
6
AGND
Analog ground
33
AGND
Analog ground
7
CH2H
AI channel 2 HI
34
CH5L
AI channel 5 LO
8
CH2L
AI channel 2 LO
35
CH5H
AI channel 5 HI
9
AGND
Analog ground
36
AGND
Analog ground
10
CH3H
AI channel 3 HI
37
CH4L
AI channel 4 LO
11
CH3L
AI channel 3 LO
38
CH4H
AI channel 4 HI
12
AGND
Analog ground
39
AGND
Analog ground
13
NC
No connection
40
AGND
Analog ground
14
AGND
Analog ground
41
AGND
Analog ground
15
NC
No connection
42
+5V
+5V power output
16
AGND
Analog ground
43
AGND
Analog ground
empty
empty
17
GND
Digital ground
44
GND
Digital ground
18
DIO0
DIO channel 0
45
AICKI
AI clock input
19
DIO1
DIO channel 1
46
AICKO
AI clock output
20
DIO2
DIO channel 2
47
NC
No connection
21
DIO3
DIO channel 3
48
NC
No connection
22
DIO4
DIO channel 4
49
TRIG
Trigger input
23
DIO5
DIO channel 5
50
GND
Digital ground
24
DIO6
DIO channel 6
51
CTR1
Counter 1 input
25
DIO7
DIO channel 7
52
CTR0
Counter 0 input
26
GND
Digital ground
53
TMR
Timer output
27
NC
No connection
54
GND
Digital ground

Environmental

Table 14. Environmental specifications

Mechanical

Table 15. Mechanical specifications

Screw terminal connector

Table 16. Screw terminal connector specifications

Differential mode pinout

Table 17. 8-channel differential mode pinout
21
USB-1608G User's Guide Specifications
Pin
Signal name
Pin description
Pin
Signal name
Pin description
1
CH0
AI channel 0
28
CH15
AI channel 15
2
CH8
AI channel 8
29
CH7
AI channel 7
3
AGND
Analog ground
30
AGND
Analog ground
4
CH1
AI channel 1
31
CH14
AI channel 14
5
CH9
AI channel 9
32
CH6
AI channel 6
6
AGND
Analog ground
33
AGND
Analog ground
7
CH2
AI channel 2
34
CH13
AI channel 13
8
CH10
AI channel 10
35
CH5
AI channel 5
9
AGND
Analog ground
36
AGND
Analog ground
10
CH3
AI channel 3
37
CH12
AI channel 12
11
CH11
AI channel 11
38
CH4
AI channel 4
12
AGND
Analog ground
39
AGND
Analog ground
13
NC
No connection
40
AGND
Analog ground
14
AGND
Analog ground
41
AGND
Analog ground
15
NC
No connection
42
+5V
+5V power output
16
AGND
Analog ground
43
AGND
Analog ground
empty
empty
17
GND
Digital ground
44
GND
Digital ground
18
DIO0
DIO channel 0
45
AICKI
AI clock input
19
DIO1
DIO channel 1
46
AICKO
AI clock output
20
DIO2
DIO channel 2
47
NC
No connection
21
DIO3
DIO channel 3
48
NC
No connection
22
DIO4
DIO channel 4
49
TRIG
Trigger input
23
DIO5
DIO channel 5
50
GND
Digital ground
24
DIO6
DIO channel 6
51
CTR1
Counter 1 input
25
DIO7
DIO channel 7
52
CTR0
Counter 0 input
26
GND
Digital ground
53
TMR
Timer output
27
NC
No connection
54
GND
Digital ground

Single-ended mode pinout

Table 18. 16-channel single-ended mode pinout
22

Declaration of Conformity

Manufacturer: Measurement Computing Corporation Address: 10 Commerce Way Suite 1008 Norton, MA 02766 USA
Category: Electrical equipment for measurement, control and laboratory use. Measurement Computing Corporation declares under sole responsibility that the products
USB-1608G
to which this declaration relates is in conformity with the relevant provisions of the following standards or other documents:
EC EMC Directive 2004/108/EC: General Requirements, EN 61326-1:2006 (IEC 61326-1:2005). Emissions:
EN 55011 (2007) / CISPR 11(2003): Radiated emissions: Group 1, Class A EN 55011 (2007) / CISPR 11(2003): Conducted emissions: Group 1, Class A
Immunity: EN 61326-1:2006, Table 3.
IEC 61000-4-2 (2001): Electrostatic Discharge immunity. IEC 61000-4-3 (2002): Radiated Electromagnetic Field immunity.
To maintain compliance to the standards of this declaration, the following conditions must be met.
The host computer, peripheral equipment, power sources, and expansion hardware must be CE
compliant.
All I/O cables must be shielded, with the shields connected to ground. I/O cables must be less than 3 meters (9.75 feet) in length. The host computer must be properly grounded. The host computer must be USB 2.0 compliant. Equipment must be operated in a controlled electromagnetic environment as defined by Standards EN
61326-1:2006, or IEC 61326-1:2005.
Note: Data acquisition equipment may exhibit noise or increased offsets when exposed to high RF fields (>1V/m) or transients.
Declaration of Conformity based on tests conducted by Chomerics Test Services, Woburn, MA 01801, USA in October, 2010. Test records are outlined in Chomerics Test Report #EMI5736.10.
We hereby declare that the equipment specified conforms to the above Directives and Standards.
Carl Haapaoja, Director of Quality Assurance
Measurement Computing Corporation
10 Commerce Way
Suite 1008
Norton, Massachusetts 02766
(508) 946-5100
Fax: (508) 946-9500
E-mail: info@mccdaq.com
www.mccdaq.com
Loading...
