AI-EXP48
User's Guide
Document Revision 2, March, 2009
© Copyright 2009, Measurement Computing Corporation
HM AI-EXP48.doc
Your new Measurement Computing product comes with a fantastic extra —
Management committed to your satisfaction!
Thank you for choosing a Measurement Computing product—and congratulations! You own the finest, and you can now enjoy
the protection of the most comprehensive warranties and unmatched phone tech support. It’s the embodiment of our mission:
To provide PC-based data acquisition hardware and software that will save time and save money.
Simple installations minimize the time between setting up your system and actually making measurements. We offer quick and
simple access to outstanding live FREE technical support to help integrate MCC products into a DAQ system.
Limited Lifetime Warranty: Most MCC products are covered by a limited lifetime warranty against defects in materials or
workmanship for the life of the product, to the original purchaser, unless otherwise noted. Any products found to be defective in
material or workmanship will be repaired, replaced with same or similar device, or refunded at MCC’s discretion. For specific
information, please refer to the terms and conditions of sale.
Harsh Environment Program: Any Measurement Computing product that is damaged due to misuse, or any reason, may be
eligible for replacement with the same or similar device for 50% of the current list price. I/O boards face some harsh
environments, some harsher than the boards are designed to withstand. Contact MCC to determine your product’s eligibility for
this program.
30 Day Money-Back Guarantee: Any Measurement Computing Corporation product may be returned within 30 days of
purchase for a full refund of the price paid for the product being returned. If you are not satisfied, or chose the wrong product by
mistake, you do not have to keep it.
These warranties are in lieu of all other warranties, expressed or implied, including any implied warranty of merchantability or
fitness for a particular application. The remedies provided herein are the buyer’s sole and exclusive remedies. Neither
Measurement Computing Corporation, nor its employees shall be liable for any direct or indirect, special, incidental or
consequential damage arising from the use of its products, even if Measurement Computing Corporation has been notified in
advance of the possibility of such damages.
3
Trademark and Copyright Information
TracerDAQ, Universal Library, Measurement Computing Corporation, and the Measurement Computing logo are either
trademarks or registered trademarks of Measurement Computing Corporation.
Windows, Microsoft, and Visual Studio are either trademarks or registered trademarks of Microsoft Corporation
LabVIEW is a trademark of National Instruments.
CompactFlash is a registered trademark of SanDisk Corporation.
XBee and XBee-PRO are trademarks of MaxStream, Inc.
All other trademarks are the property of their respective owners.
Information furnished by Measurement Computing Corporation is believed to be accurate and reliable. However, no
responsibility is assumed by Measurement Computing Corporation neither for its use; nor for any infringements of patents or
other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any patent or
copyrights of Measurement Computing Corporation.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any
means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measurement
Computing Corporation.
Notice
Measurement Computing Corporation does not authorize any Measurement Computing Corporation product for use
in life support systems and/or devices without prior written consent from Measurement Computing Corporation.
Life support devices/systems are devices or systems which, a) are intended for surgical implantation into the body,
or b) support or sustain life and whose failure to perform can be reasonably expected to result in injury.
Measurement Computing Corporation products are not designed with the components required, and are not subject
to the testing required to ensure a level of reliability suitable for the treatment and diagnosis of people.
4
Table of Contents
Preface
About this User’s Guide ....................................................................................................................... 6
What you will learn from this user’s guide ......................................................................................................... 6
Conventions in this user’s guide ......................................................................................................................... 6
Where to find more information ......................................................................................................................... 6
Chapter 1
Introducing the AI-EXP48 ..................................................................................................................... 7
Overview: AI-EXP48 features ............................................................................................................................ 7
Software features ................................................................................................................................................ 7
Chapter 2
Installing the AI-EXP48 ......................................................................................................................... 8
What comes with your AI-EXP48 shipment? ..................................................................................................... 8
Hardware .......................................................................................................................................................................... 8
Optional components ........................................................................................................................................................ 8
Additional documentation ................................................................................................................................................. 8
Unpacking the AI-EXP48 ................................................................................................................................... 8
Connecting to the parent A/D device with the DSUB25 expansion connector................................................... 9
Connecting the device for I/O operations ......................................................................................................... 10
User connectors................................................................................................................................................................10
Screw terminal pin out .....................................................................................................................................................11
Expansion connector ........................................................................................................................................................12
Cabling .............................................................................................................................................................................13
Associating CJC channels with thermocouple channels ................................................................................... 13
Chapter 3
Specifications ...................................................................................................................................... 14
Analog input ..................................................................................................................................................... 14
Accuracy ..........................................................................................................................................................................14
Thermocouples ................................................................................................................................................................14
Power consumption .......................................................................................................................................... 15
Environmental .................................................................................................................................................. 15
Mechanical ....................................................................................................................................................... 15
User connectors ................................................................................................................................................ 15
Declaration of Conformity .................................................................................................................. 18
5
Preface
About this User’s Guide
What you will learn from this user’s guide
This user’s guide explains how to install, configure, and use the AI-EXP48 so that you get the most out of its
analog input features.
This user’s guide also refers you to related documents available on our web site, and to technical support
resources.
Conventions in this user’s guide
For more information on …
Text presented in a box signifies additional information and helpful hints related to the subject matter you are
reading.
Caution! Shaded caution statements present information to help you avoid injuring yourself and others,
damaging your hardware, or losing your data.
< : > Angle brackets that enclose numbers separated by a colon signify a range of numbers, such as those assigned
to registers, bit settings, etc.
bold text Bold text is used for the names of objects on the screen, such as buttons, text boxes, and check boxes. For
example:
1. Insert the disk or CD and click the OK button.
italic text Italic text is used for the names of manuals and help topic titles, and to emphasize a word or phrase. For
example:
The InstaCal installation procedure is explained in the Quick Start Guide.
Never touch the exposed pins or circuit connections on the board.
Where to find more information
The following electronic documents provide helpful information relevant to the operation of the AI-EXP48.
MCC's Specifications: AI-EXP48 (the PDF version of the Specifications chapter in this guide) is available
on our web site at www.mccdaq.com/pdfs/Specs/AI-EXP48-spec.pdf.
MCC's Quick Start Guide is available on our web site at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.
MCC's Guide to Signal Connections is available on our web site at
www.mccdaq.com/signals/signals.pdf.
MCC's Universal Library User's Guide is available on our web site at
www.mccdaq.com/PDFmanuals/sm-ul-user-guide.pdf.
MCC's Universal Library Function Reference is available on our web site at
www.mccdaq.com/PDFmanuals/sm-ul-functions.pdf.
MCC's Universal Library for LabVIEW™ User’s Guide is available on our web site at
www.mccdaq.com/PDFmanuals/SM-UL-LabVIEW.pdf.
AI-EXP48 User's Guide (this document) is also available on our web site at
www.mccdaq.com/PDFmanuals/AI-EXP48.pdf.
6
Chapter 1
Introducing the AI-EXP48
Overview: AI-EXP48 features
The AI-EXP48 is an expansion module used to add 48 single-ended or 24 differential analog inputs to
compatible hardware, such as the USB-1616HS Series devices.
The AI-EXP48 connects to the parent device via a 25-pin expansion connector. The AI-EXP48 supports all of
the analog input and temperature input capabilities of the parent device.
The AI-EXP48 can measure up to 48 channels of voltage or up to 24 channels of temperature. Each input
channel is software configurable for either voltage or thermocouple. The analog inputs are provided on six rows
of removable screw terminals.
The voltage measurement speed is the same as the parent device. When measuring thermocouples, the parent
device must be configured for differential inputs.
The AI-EXP48 receives power from the parent device. An external power supply may be required to supply
sufficient power to both devices.
Software features
For information on the features of InstaCal and the other software included with your AI-EXP48, refer to the
Quick Start Guide that shipped with your device. The Quick Start Guide is also available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.
Check www.mccdaq.com/download.htm for the latest software version.
7
Installing the AI-EXP48
What comes with your AI-EXP48 shipment?
The following items are shipped with the AI-EXP48.
Hardware
AI-EXP48
Chapter 2
Clips (2) used to lock the AI-EXP48 and parent device together when connected directly
Optional components
You can connect the AI-EXP48 to a USB-1616HS series parent device using the optional CA-96A cable.
CA-96 cable
Additional documentation
In addition to this hardware user's guide, you should also receive the Quick Start Guide (available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf). This booklet supplies a brief description of
the software you received with your AI-EXP48 and information regarding installation of that software. Please
read this booklet completely before installing any software or hardware.
Unpacking the AI-EXP48
As with any electronic device, you should take care while handling to avoid damage from static
electricity. Before removing the AI-EXP48 from its packaging, ground yourself using a wrist strap or by simply
touching the computer chassis or other grounded object to eliminate any stored static charge.
If any components are missing or damaged, notify Measurement Computing Corporation immediately by
phone, fax, or e-mail:
Phone: 508-946-5100 and follow the instructions for reaching Tech Support.
Fax: 508-946-9500 to the attention of Tech Support
Email: techsupport@mccdaq.com
8
AI-EXP48 User's Guide Installing the AI-EXP48
Connecting to the parent A/D device with the DSUB25 expansion
connector
You can use the 25-pin expansion connector to connect to a compatible parent device, such as a USB-1616HS
Series device.
You can either mate the expansion connectors directly or use the optional expansion cable to connect the two
devices. Do the following:
1. Disconnect the USB cable from the parent device.
If the parent device is connected to an external power supply, remove the external power cable from the
device.
2. Connect the two devices together by one of the following methods:
o Direct connect method: The parent device must have a female DSUB25 expansion connector to use
this method. Push the expansion module's DSUB25 connector into the DSUB25 connector on the
parent device. Lock the two devices together by inserting the two clips provided (one per side).
The image below shows the AI-EXP48 directly connected a USB-1616HS-4.
Figure 1. Direct connect method
o Cable method: Connect the appropriate cable (not included) from the DSUB25 connector on the AI-
EXP48 to the expansion connector on the parent device. The image below shows the AI-EXP48
connected to a USB-1616HS-4 via the CA-96A cable.
Figure 2. Cable method
9
AI-EXP48 User's Guide Installing the AI-EXP48
Connector type
Six banks of removable screw-terminal blocks
25-pin male DSUB connector (for connection to parent device)
Wire gauge range (screw terminals)
14 AWG to 30 AWG
3. Connect the external power supply, if used, to the power input port of the parent device, and then plug it
into an AC outlet.
Note: Connecting external power to the device before connecting the USB cable to the computer allows the
parent device to inform the host computer upon connection of the USB cable that the device requires
minimum power from the computer's USB port.
4. Connect the USB cable from the parent device to the host computer's USB port.
Connect to a USB 2.0 high speed hub to achieve the highest transfer rate (480 Mbps). When connected to a
USB 1.1 full-speed port, the transfer rate is limited to 12 Mbps.
Connecting the device for I/O operations
User connectors
The following table lists the device connectors and compatible hardware for the AI-EXP48.
User connectors and hardware
10
AI-EXP48 User's Guide Installing the AI-EXP48
Terminal
block
Device
label
(Signal description)
Device
label
(Signal description)
Terminal
block
Analog In
TB1
A
(Analog common)
63L
(CH 63)
Analog In
TB6
16H
(CH 16)
55H
(CH 55)
24L
(CH 24)
A
(Analog common)
A
(Analog common)
62L
(CH 62)
17H
(CH 17)
54H
(CH 54)
25L
(CH 25)
A
Analog common
A
(Analog common)
61L
(CH 61)
18H
(CH 18)
53H
(CH 53)
26L
(CH 26)
A
(Analog common)
A
(Analog common)
60L
(CH 60)
19H
(CH 19)
52H
(CH 52)
27L
(CH 27)
A
(Analog common)
Analog In
TB2
A
(Analog common)
59L
(CH 59)
Analog in
TB5
20H
(CH 20)
51H
(CH 51)
28L
(CH 28)
A
(Analog common)
A
(Analog common)
58L
(CH 58)
21H
(CH 21)
50H
(CH 50)
29L
(CH 29)
A
(Analog common)
A
(Analog common)
57L
(CH 57)
22H
(CH 22)
49H
(CH 49)
30L
(CH 30)
A
(Analog common)
A
(Analog common)
56L
(CH 56)
23H
(CH 23)
48H
(CH 48)
31L
(CH 31)
A
(Analog common)
Analog In
TB3
A
(Analog common)
47L
(CH 47)
Analog In
TB4
32H
(CH 32)
39H
(CH 39)
40L
(CH 40)
A
(Analog common)
A
(Analog common)
46L
(CH 46)
33H
(CH 33)
38H
(CH 38)
41L
(CH 41)
A
(Analog common)
A
(Analog common)
45L
(CH 45)
34H
(CH 34)
37H
(CH 37)
42L
(CH 42)
A
(Analog common)
A
(Analog common)
44L
(CH 44)
35H
(CH 35)
36H
(CH 36)
43L
(CH 43)
A
(Analog common)
Screw terminal pin out
Single-ended mode pin out
11
AI-EXP48 User's Guide Installing the AI-EXP48
Terminal
block
Device
label
(Signal description)
Device
label
(Signal description)
Terminal
block
Analog In
TB1
A
(Analog common)
63L
(CH 31 LO)
Analog In
TB6
16H
(CH 8 HI)
55H
(CH 31 HI)
24L
(CH 8 LO)
A
(Analog common)
A
(Analog common)
62L
(CH 30 LO)
17H
(CH 9 HI)
54H
(CH 30 HI)
25L
(CH 9 LO)
A
Analog common
A
(Analog common)
61L
(CH 29 LO)
18H
(CH 10 HI)
53H
(CH 29 HI)
26L
(CH 10 LO)
A
(Analog common)
A
(Analog common)
60L
(CH 28 LO)
19H
(CH 11 HI)
52H
(CH 28 HI)
27L
(CH 11 LO)
A
(Analog common)
Analog In
TB2
A
(Analog common)
59L
(CH 27 LO)
Analog in
TB5
20H
(CH 12 HI)
51H
(CH 27 HI)
28L
(CH 12 LO)
A
(Analog common)
A
(Analog common)
58L
(CH 26 LO)
21H
(CH 13 HI)
50H
(CH 26 HI)
29L
(CH 13 LO)
A
(Analog common)
A
(Analog common)
57L
(CH 25 LO)
22H
(CH 14 HI)
49H
(CH 25 HI)
30L
(CH 14 LO)
A
(Analog common)
A
(Analog common)
56L
(CH 24 LO)
23H
(CH 15 HI)
48H
(CH 24 HI)
31L
(CH 15 LO)
A
(Analog common)
Analog In
TB3
A
(Analog common)
47L
(CH 23 LO)
Analog In
TB4
32H
(CH 16 HI)
39H
(CH 23 HI)
40L
(CH 16 LO)
A
(Analog common)
A
(Analog common)
46L
(CH 22 LO)
33H
(CH 17 HI)
38H
(CH 22 HI)
41L
(CH 17 LO)
A
(Analog common)
A
(Analog common)
45L
(CH 21 LO)
34H
(CH 18 HI)
37H
(CH 21 HI)
42L
(CH 18 LO)
A
(Analog common)
A
(Analog common)
44L
(CH 20 LO)
35H
(CH 19 HI)
36H
(CH 20 HI)
43L
(CH 19 LO)
A
(Analog common)
1 13
14 25
Differential mode pin out
Expansion connector
The AI-EXP48 has a 25-pin male DSUB connector that connects directly to the 25-pin female DSUB connector
on compatible hardware or through the appropriate cable to compatible hardware.
Figure 3. 25-pin male DSUB expansion connector
12
AI-EXP48 User's Guide Installing the AI-EXP48
CJC channels
TC channels
CJC6
TC8 through TC11
CJC7
TC12 through TC15
CJC8
TC16 through TC19
CJC9
TC20 through TC23
CJC10
TC24 through TC27
CJC11
TC28 through TC31
Cabling
If the parent device has a 25-pin expansion connector, you can use the CA-96A cable to connect with the AIEXP48.
Figure 4. CA-96A cable
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections (available at www.mccdaq.com/signals/signals.pdf).
Associating CJC channels with thermocouple channels
TC channels must immediately follow their associated CJC channels in the channel array. For accurate
thermocouple measurements, associate CJC channels with the TC channels as listed below.
When measuring thermocouples, the parent device must be configured for differential inputs.
13
Number of channels
48 single-ended/24 differential inputs
Voltage measurement speed
1 µs per channel
Input ranges, software or sequencer programmable
Bipolar: ±10 V, ±5 V, ±2 V, ±1 V , ±0.5 V, ±0.2 V, ±0.1 V,
universal thermocouple
Signal to noise and distortion
72 dB typical for ±10 V range, 1 kHz fundamental
Total harmonic distortion
-80 dB typical for ±10 V range, 1 kHz fundamental
Bias current
40 pA typical (0 °C to 35 °C)
Crosstalk
-75 dB DC to 60 Hz; -65 dB @ 10 kHz, typical
Input impedance
10 MΩ single-ended, 20 MΩ differential
Over-voltage protection
±30 V
Voltage range
(note 1)
Accuracy
±(% of reading + % range)
23°C ±10 °C, 1 year
Temperature coefficient
±(ppm of reading + ppm range)/°C
Noise (cts
RMS) (note 2)
-10 V to 10 V
0.031% + 0.008%
14 + 8
2.0
-5 V to 5 V
0.031% + 0.009%
14 + 9
3.0
-2 V to 2 V
0.031% + 0.010%
14 + 10
2.0
-1 V to 1 V
0.031% + 0.02%
14 + 12
3.5
-500 mV to 500 mV
0.031% + 0.04%
14 + 18
5.5
-200 mV to 200 mV
0.036% + 0.05%
14 + 12
8.0
-100 mV to 100 mV
0.042% + 0.10%
14 + 18
14.0
TC type
Temperature range (°C)
Accuracy (±°C)
Noise typical (±°C)
J
-200 to + 760
1.7
0.2 K -200 to + 1200
1.8
0.2 T -200 to + 400
1.8
0.2 E -270 to + 650
1.7
0.2 R -50 to + 1768
4.8
1.5
S
-50 to + 1768
4.7
1.5
N
-270 to + 1300
2.7
0.3 B +300 to + 1400
3.0
1.0
Specifications
Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design.
Analog input
Table 1. Analog input specifications
Chapter 3
Accuracy
Table 2. Analog input accuracy specifications
Note 1: Specifications assume differential input single-channel scan, 1 MHz scan rate, unfiltered,
CMV=0.0 V, 30 minute warm-up, exclusive of noise, -FS to +FS.
Note 2: Noise reflects 10,000 samples at 1 MHz, typical, differential short
Thermocouples
Table 3. TC types and accuracy (Note 3)
Note 3: Assumes 16384 oversampling applied, CMV = 0.0V, 60 minute warm-up, still environment, and
25 °C ambient temperature; excludes thermocouple error; TCin = 0° C for all types except B
(1000 °C)
14
AI-EXP48 User's Guide Specifications
Power consumption (per board)
400 mW maximum (supplied by parent product, such as USB-1616HS series)
Operating temperature range
-30 °C to +70 °C
Storage temperature range
-40 °C to +80 °C
Relative humidity
0 to 95% non-condensing
Vibration
MIL STD 810E, category 1 and 10
Dimensions
269 mm (W) x 92 mm (D) x 45 mm (H ) (10.6" x 3.6" x 1.6")
Weight
400 g (0.88 lbs)
Connector type
Six banks of removable screw-terminal blocks
Wire gauge range
14 AWG to 30 AWG
Communications connector
25-pin DSUB, male
Compatible cable
CA-96A
(also mates directly with USB-1616HS series products)
Power consumption
Table 4. Power consumption specifications
Environmental
Table 5. Environmental specifications
Mechanical
Table 6. Mechanical specifications
User connectors
Table 7. Screw terminal connector specifications
Table 8. Expansion connector specifications
15
AI-EXP48 User's Guide Specifications
Terminal block
Device label
(Signal description)
Device label
(Signal description)
Terminal block
Analog In
A
(Analog common)
63L
(CH 63)
Analog In
16H
(CH 16)
55H
(CH 55)
24L
(CH 24)
A
(Analog common)
A
(Analog common)
62L
(CH 62)
17H
(CH 17)
54H
(CH 54)
25L
(CH 25)
A
Analog common
A
(Analog common)
61L
(CH 61)
18H
(CH 18)
53H
(CH 53)
26L
(CH 26)
A
(Analog common)
A
(Analog common)
60L
(CH 60)
19H
(CH 19)
52H
(CH 52)
27L
(CH 27)
A
(Analog common)
Analog In
A
(Analog common)
59L
(CH 59)
Analog in
20H
(CH 20)
51H
(CH 51)
28L
(CH 28)
A
(Analog common)
A
(Analog common)
58L
(CH 58)
21H
(CH 21)
50H
(CH 50)
29L
(CH 29)
A
(Analog common)
A
(Analog common)
57L
(CH 57)
22H
(CH 22)
49H
(CH 49)
30L
(CH 30)
A
(Analog common)
A
(Analog common)
56L
(CH 56)
23H
(CH 23)
48H
(CH 48)
31L
(CH 31)
A
(Analog common)
Analog In
A
(Analog common)
47L
(CH 47)
Analog In
32H
(CH 32)
39H
(CH 39)
40L
(CH 40)
A
(Analog common)
A
(Analog common)
46L
(CH 46)
33H
(CH 33)
38H
(CH 38)
41L
(CH 41)
A
(Analog common)
A
(Analog common)
45L
(CH 45)
34H
(CH 34)
37H
(CH 37)
42L
(CH 42)
A
(Analog common)
A
(Analog common)
44L
(CH 44)
35H
(CH 35)
36H
(CH 36)
43L
(CH 43)
A
(Analog common)
Table 9. Single-ended mode pin out
16
AI-EXP48 User's Guide Specifications
Terminal block
Device label
(Signal description)
Device label
(Signal description)
Terminal block
Analog In
A
(Analog common)
63L
(CH 31 LO)
Analog In
16H
(CH 8 HI)
55H
(CH 31 HI)
24L
(CH 8 LO)
A
(Analog common)
A
(Analog common)
62L
(CH 30 LO)
17H
(CH 9 HI)
54H
(CH 30 HI)
25L
(CH 9 LO)
A
Analog common
A
(Analog common)
61L
(CH 29 LO)
18H
(CH 10 HI)
53H
(CH 29 HI)
26L
(CH 10 LO)
A
(Analog common)
A
(Analog common)
60L
(CH 28 LO)
19H
(CH 11 HI)
52H
(CH 28 HI)
27L
(CH 11 LO)
A
(Analog common)
Analog In
A
(Analog common)
59L
(CH 27 LO)
Analog in
20H
(CH 12 HI)
51H
(CH 27 HI)
28L
(CH 12 LO)
A
(Analog common)
A
(Analog common)
58L
(CH 26 LO)
21H
(CH 13 HI)
50H
(CH 26 HI)
29L
(CH 13 LO)
A
(Analog common)
A
(Analog common)
57L
(CH 25 LO)
22H
(CH 14 HI)
49H
(CH 25 HI)
30L
(CH 14 LO)
A
(Analog common)
A
(Analog common)
56L
(CH 24 LO)
23H
(CH 15 HI)
48H
(CH 24 HI)
31L
(CH 15 LO)
A
(Analog common)
Analog In
A
(Analog common)
47L
(CH 23 LO)
Analog In
32H
(CH 16 HI)
39H
(CH 23 HI)
40L
(CH 16 LO)
A
(Analog common)
A
(Analog common)
46L
(CH 22 LO)
33H
(CH 17 HI)
38H
(CH 22 HI)
41L
(CH 17 LO)
A
(Analog common)
A
(Analog common)
45L
(CH 21 LO)
34H
(CH 18 HI)
37H
(CH 21 HI)
42L
(CH 18 LO)
A
(Analog common)
A
(Analog common)
44L
(CH 20 LO)
35H
(CH 19 HI)
36H
(CH 20 HI)
43L
(CH 19 LO)
A
(Analog common)
Table 10. Differential mode pin out
17
Declaration of Conformity
Manufacturer: Measurement Computing Corporation
Address: 10 Commerce Way
Suite 1008
Norton, MA 02766
USA
Category: Electrical equipment for measurement, control and laboratory use.
Measurement Computing Corporation declares under sole responsibility that the product
AI-EXP48
to which this declaration relates is in conformity with the relevant provisions of the following standards or other
documents:
EC EMC Directive 2004/108/EC: Electromagnetic Compatibility, EN 61326-1:2006, (IEC 61326-1:2005)
Emissions: Group 1, Class A
EN 55022 (1993)/CISPR 22: Radiated and Conducted emissions.
Immunity: EN 61326-1:2006, (IEC 61326-1:2005)
IEC 61000-4-2 (2001): Electrostatic Discharge immunity.
IEC 61000-4-3 (2002): Radiated Electromagnetic Field immunity.
IEC 61000-4-4 (2004): Electric Fast Transient Burst immunity.
IEC 61000-4-5 (2001): Fast Surge immunity.
IEC 61000-4-6 (2003): Radio Frequency Common Mode immunity.
To maintain the safety, emission, and immunity standards of this declaration, the following conditions must be
met.
The host computer, peripheral equipment, power sources, and expansion hardware must be CE compliant.
Equipment must be operated in a controlled electromagnetic environment as defined by Standards EN
61326-1:2006, or IEC 61326-1:2005.
Shielded wires must be used for all I/Os and must be less than 3 meters (9.75 feet) in length. Clips must be used with
the AI-EXP48.
The host computer must be properly grounded.
The host computer must be USB2.0 compliant and IOtech USB cables (CA-179-x) must be used.
A protective ESD wrist strap should be used when connecting or disconnecting leads from screw terminal blocks.
Alternatively, unplug the unit from the host computer when making connections. Protective housings (IOtech p/n
CN-241-12) can be placed over the removable terminal blocks to protect signals from ESD during operation.
If external DC power is needed, a TR-2U power supply must be used.
Note: Data acquisition equipment may exhibit noise or increased offsets when exposed to high RF fields
(>1V/m) or transients.
Declaration of Conformity based on tests conducted by Smith Electronics, Inc., Cleveland, OH 44141, USA in
December, 2005. Test records are outlined in Smith Electronics Test Report “Personal Daq/3000 Series with
PDQ30 Expansion Module” and “PDAQ3000-PDQ30 Addenda”. Further testing was conducted by Chomerics
Test Services, Woburn, MA. 01801, USA in January, 2009. Test records are outlined in Chomerics Test report
#EMI5245.09.
We hereby declare that the equipment specified conforms to the above Directives and Standards.
Carl Haapaoja, Director of Quality Assurance
Measurement Computing Corporation
10 Commerce Way
Suite 1008
Norton, Massachusetts 02766
(508) 946-5100
Fax: (508) 946-9500
E-mail: info@mccdaq.com
www.mccdaq.com
Loading...
