EnOcean switch transmitter
General specifications
Transmission frequency
868.3MHz
Transmission power
10mW max
Dimensions LxWxH
80x80mmx15mm
Working temperature
-25 ~ +65°C
Storage temperature
-25 ~ +65°C
Mechanical switch cycles
> 50.000
Certifications
CE and R&TTE directive 1999/5/CE
Humidity
0 ~ 95% RH
Brick or stone
20meter, up to 3 walls maximum
Reinforced concrete
10meter, up to 1 wall/ceiling maximum
Drywall / Wood
30meter, up to 5 walls maximum
■
Features :
Easy configuration & installation
·
Wireless
·
Batteryless
·
Maintenance free
·
High reliability
·
Up to 30 meter wireless distance for indoor appliation
·
■
Description :
This switch transmitter is wireless, batteryless and maintenance free. A radio signal is sent out and its energy is
generated during pressing on one of its buttons.
The switches can be placed at any point of the room and change at will. Their plastic mechanical support allows it to be
adapted and fixed on a wall either by screws or by adhesive.
- It is therefore particularly suitable for electrical installations without embedding, such as: renovations of residential
installation modification or offices with mobile walls.
WPD-06SWT
- Just press a button on the switch to remotely control WPD-06. Before use, the switch must be paired first before use.
Refer WPD-06 datasheet for more information.
Range in the buildings
Made in
EU
File Name:WPD-06SWT-SPEC 2014-12-25
