Meade 60AZ-D User Manual

© 2003

Rev. C

0603

Instruction Manual

Polaris 60AZ-D:
60mm (2.4”) Altazimuth Refracting Telescope

Meade Instruments Corporation

6001 OAK CANYON, IRVINE, CALIFORNIA 92618-5200 U.S.A.

[phone] ■FAX: [phone] ■www.meade.com

– 2 –

WARNING:

NEVER USE AN POLARIS 60AZ-D TELESCOPE TO LOOK AT THE SUN!

LOOKING AT OR NEAR THE SUN WILL CAUSE INSTANT AND
IRREVERSIBLE DAMAGE TO YOUR EYE. EYE DAMAGE IS OFTEN
P AINLESS, SO THERE IS NO W ARNING TO THE OBSERVER THAT DAMAGE
HAS OCCURRED UNTIL IT IS TOO LATE. DO NOT POINT THE TELESCOPE
OR ITS VIEWFINDER AT OR NEAR THE SUN. DO NOT LOOK THROUGH
THE TELESCOPE OR ITS VIEWFINDER AS IT IS MOVING.

CHILDREN

SHOULD ALWAYS HAVE ADULT SUPERVISION WHILE OBSERVING.

MEADE LIMITED WARRANTY

Every Polaris telescope, spotting scope, and telescope accessory is warranted by Meade Instruments Corporation
(“Meade”) to be free of defects in materials and workmanship for a period of ONE YEAR from the date of original
purchase in the U.S.A. Meade will repair or replace a product, or part thereof, found by Meade to be defective, provided
the defective part is returned to Meade, freight-prepaid, with proof of purchase. This warranty applies to the original
purchaser only and is non-transferable. Meade products purchased outside North America are not included in this
warranty, but are covered under separate warranties issued by Meade international distributors.

RGA Number Required: Prior to the return of any product or part, a Return Goods Authorization (RGA) number must
be obtained from Meade by writing, or by calling [phone]. Each returned part or product must include a written
statement detailing the nature of the claimed defect, as well as the owner’s name, address, and phone number.

This warranty is not valid in cases where the product has been abused or mishandled, where unauthorized repairs have
been attempted or performed, or where depreciation of the product is due to normal wear-and-tear. Meade specifically
disclaims special, indirect, or consequential damages or lost profit which may result from a breach of this warranty. Any
implied warranties which cannot be disclaimed are hereby limited to a term of one year from the date of original retail
purchase.

This warranty gives you specific rights. You may have other rights which vary from state to state.
Meade reserves the right to change product specifications or to discontinue products without notice.
This warranty supersedes all previous Meade product warranties.

– 3 –

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Standard Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Unpacking and Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Altazimuth Mount Movements and Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Viewfinder Focusing and Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Using the Telescope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Calculating Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

A Few Words About Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
