Technical Manual

MDT Motion Detector

SCN-BWM55.01

SCN-BWM55.G1

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

2

1 Content

1 Content ................................................................................................................................................. 2

2 Overview ............................................................................................................................................... 4

2.1 Overview devices ........................................................................................................................... 4

2.2 Usage & possible applications ....................................................................................................... 4

2.3 Exemplary Circuit Diagram ............................................................................................................ 5

2.4 Structure & Handling ..................................................................................................................... 6

2.5 Functions ....................................................................................................................................... 7

2.6 Settings at the ETS-Software ......................................................................................................... 8

2.7 Commissioning .............................................................................................................................. 8

3 Communication Objects ....................................................................................................................... 9

3.1 Overview and Usage ...................................................................................................................... 9

3.2 Default settings of the communication objects .......................................................................... 16

4 Reference ETS-Parameter .................................................................................................................. 18

4.1 General Settings .......................................................................................................................... 18

4.2 Light Channel 1/2/HCV ................................................................................................................ 20

4.2.1 General Settings ................................................................................................................... 20

4.2.2 Channel Mode Selection ...................................................................................................... 21

4.2.3 Follow-up time ..................................................................................................................... 22

4.2.4 Force or lock object .............................................................................................................. 23

4.2.5 Output object ....................................................................................................................... 24

4.2.6 External Push Button Input .................................................................................................. 27

4.2.7 Process Diagram ................................................................................................................... 28

4.2.8 Master/Slave Operation ....................................................................................................... 32

4.2.8.1 Light channel ................................................................................................................. 32

4.2.8.2 HCV ................................................................................................................................ 32

4.3 Alarm/Motion Direction .............................................................................................................. 33

4.3.1 Alarm .................................................................................................................................... 33

4.3.2 Motion Direction .................................................................................................................. 35

4.4 Logic Function .............................................................................................................................. 36

4.4.1 Activation of the Logic function ........................................................................................... 36

4.4.2 Logic function 1-4 ................................................................................................................. 37

4.5 LED ............................................................................................................................................... 39

4.6 Scenes .......................................................................................................................................... 40

4.7 Brightness .................................................................................................................................... 41

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

3

5 Index ................................................................................................................................................... 42

5.1 Register of illustrations ................................................................................................................ 42

5.2 List of tables................................................................................................................................. 43

6 Attachment ......................................................................................................................................... 44

6.1 Statutory requirements ............................................................................................................... 44

6.2 Routine disposal .......................................................................................................................... 44

6.3 Assemblage .................................................................................................................................. 44

6.4 Datasheet .................................................................................................................................... 45

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

4

2 Overview

2.1 Overview devices

The manual refers to the following devices: (Order code printed in bold type):

 SCN-BWM55.01 Motion detector, 2 Pyro detectors, matt finish

o 2 Pyro-detectors, Sensitivity separately adjustable for day/night/presence

2 separate configurable Light channels, HCV and Alarm channel;
4 Logic functions (And-/Or-/XOR-function) configurable;
green, white, red LED freely configurable;
8 scenes activatable and adjustable;
Motion direction detection

 SCN-BWM55.G1 Motion detector, 2 Pyro detectors, glossy finish

o Functions as above

2.2 Usage & possible applications

The MDT motion detector switches depending on the ambient brightness and presence. It can be
used for demand-driven switching in order to switch economically and only when required. The
motion detector can thus help to reduce unnecessary switching times to a minimum, especially in
commercial premises, but also in rooms that are seldom used, such as bathrooms and toilets or
rooms that are used as passageways such as hallways.
An additional channel transmits the presence information in the room to other trades such as
heating, ventilation, air-conditioning or blind control systems. This means that the motion detector
can also be used in other trades.
The MDT motion detector is designed for wall mounting and impresses with its flat design and 180°
detection range.

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

5

2.3 Exemplary Circuit Diagram

Figure 1: Exemplary circuit diagram

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

6

2.4 Structure & Handling

The following figure shows a motion detector in principle presentation:

Figure 2: Structure

In addition to the standard elements, programming button and KNX connection, the position of the
sensors and the LEDs is shown on the picture above:

S1/S2 sensor 1/sensor 2
R red LED (Programming-LED)
G green LEDs
W white LED

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

7

2.5 Functions

The motion detector functions are divided into the following areas: general settings, light channels 1
and 2, HCV, alarm, logic, LED, scenes and brightness:

 General Settings

The general settings are used for the basic configuration of the motion detector. Basic
settings for sensitivity and basic settings for brightness can be made here as well as the
follow-up times. In addition, a cyclically sending "In operation" telegram can be activated.

 Light channel 1 and 2

Light channel 1 and 2 can be parameterised and activated/deactivated separately from each
other. The active sensors can be parameterised for each light channel. The operating modes
fully automatic and half-automatic (manual switching on) are available. Furthermore,
different values for day/night (depending on the day/night object) can be sent. A switching
object, a scene object or an absolute value (dimming absolute) can be sent as an output
object. Each light channel can be given priority by a force control object or a blocking object

 HCV

The heating, climate and ventilation channel is the interface of the motion detector to other
systems. In contrast to the light channels, the HCL channel has adjustable monitoring time
slots with which the presence in the room can be observed. By using this channel, it is
possible to control the ventilation of a room as required or to switch other HCV functions in
presence/absence, for example.

 Alarm

The alarm channel is used to detect movements during absence. For this purpose, the
channel has a separate sensitivity setting and its own enable/disable object with which
monitoring can be started.
In this menu you can also activate the motion direction detection.

 Logic

Up to 4 different logics can be activated. These can be set with the functions AND, OR, XOR.
Each logic block can be activated with up to two internal logic objects and up to four external
logic objects. Switching commands, scenes, values or 2-bit priority control objects can be
sent as output objects.

 LED

A white, green and red LED are available for display. The green LED can be used to signal
movements or the LED can be switched depending on an external object.
The white LED can be parameterised as night light or motion indicator. Furthermore, the LED
can be switched via a separate object. The brightness of the LED is adjustable from 1-100%.
The red LED can be used either as pure programming LED or switched via a separate object.

 Scenes

Up to 8 scenes can be activated which can cause adjustable actions in the light channels 1/2.

 Brightness

The correction of the measured brightness value and the sending conditions for the light
value can be set here.

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

8

2.6 Settings at the ETS-Software

Selection at the product database

Manufacturer: MDT Technologies
Product family: Presence detector
Product type: Wall mounted
Medium Type: Twisted Pair (TP)
Product name: SCN-BWM55.01 ; Motion detector 180°
Order number: dependent of the used type, e.g. SCN-BWM55.01

2.7 Commissioning

After wiring, the allocation of the physical address and the parameterization of every channel follows:

(1) Connect the interface with the bus, e.g. MDT USB Interface
(2) Switching the power supply
(3) Set bus power up
(4) Press the programming button at the device (red programming LED lights)
(5) Loading of the physical address out of the ETS-Software by using the interface (red LED goes

off as soon as this process was completed successfully)

(6) Loading of the application, with requested parameterization
(7) If the device is enabled you can test the requested functions (also possible by using the ETS-

Software)

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

3 Communication Objects

3.1 Overview and Usage

The following table shows the available objects and their usage:

No.

Name

Object function

Data type

Direction

Info

Usage

Note

Objects per light channel:

0

Light channel 1 -
Output 1

Dimming absolute
Switching
Scene

DPT 5.001
DPT 1.001
DPT 17.001

send

Light channel
sends output
telegram

Switch actuator /
Dimming actuator

Data point type depends on the
parameter "Object type for
output - light". Object sends
values according to the set
parameters.

1

Light channel 1 -
Output 1 (night)

Switching

DPT 1.001

Send

Light channel
sends switching
telegram

Switch actuator

Object is displayed when object
is activated via parameter
"Separate switch object at
night"

2

Light channel 1 - Input

Output 2

DPT 1.001

Send

Light channel
sends switching
telegram

Switch actuator

Object is displayed when
output 2 (additional switching
object) is activated

3

Light channel 1 - Input

External push button
short

DPT 1.001

receive

Light channel
reacts to incoming
telegram

External push
button

The object is permanently
displayed and is used to
override the automatic control
of the light channel.

4

Light channel 1 - Input

External push button
long

DPT 1.001

receive

Light channel
reacts to incoming
telegram

External push
button

The object is permanently
displayed and is used to
override the automatic control
of the light channel.

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

5

Light channel 1 - Input

External motion (Slave)

DPT 1.001

receive

Light channel
reacts to incoming
telegram

Additional motion
detector
configured as slave

Object is permanently
displayed and is required for
the Master/Slave function

6

Light channel 1 - Input

Force control/
Lock object

DPT 2.001/
DPT 1.003

receive

Light channel
reacts to lock
command / Force
control

External push
button for
blocking/overriding
the motion
detector

Object is displayed after
activation; DPT depends on
parameter settings

7

Light channel 1 - Input

Lock object ON

DPT 1.003

receive

Light channel
reacts to lock
command

External push­button for blocking
the motion
detector

Object is displayed after
activation

8

Light channel 1 - Status

Status automatic mode

DPT 1.011

send

Light channel
sends status

Visu, Diagnostics,
Display

Object is permanently
displayed and has the value 1 if
light channel is in automatic
mode.

9

Light channel 1 - Input

Switch dark

DPT 1.001

receive

Light channel
reacts to incoming
telegram

External button for
overriding the
brightness
dependency

Object is displayed when the
parameter "Brightness" is set
to "Basic setting or active
object ´Dark´"

+10

next light channel

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

Objects per HCV:

40

HCV - Output 1

Dimming absolute
Switching
Scene

DPT 5.001
DPT 1.001
DPT 17.001

send

HCV channel sends
output telegram

Switch actuator /
Dimming actuator/
Heating actuator

Data point type depends on the
parameter "Object type for
output – climate (HCV)". Object
sends values according to the
set parameters.

43

HCV - Input

External push button
short

DPT 1.001

receive

HCV channel
reacts to incoming
telegram

External push
button

The object is permanently
displayed and is used to
override the automatic control
of the HCV channel.

44

HCV - Input

External push button
long

DPT 1.001

receive

HCV channel
reacts to incoming
telegram

External push
button

The object is permanently
displayed and is used for
overriding the automatic
control of the HCV channel.

45

HCV - Input

External Motion

DPT 1.001

receive

HCV channel
reacts to incoming
telegram

Additional motion
detector
configured as slave

Object is permanently
displayed and is required for
the Master/Slave function

46

HCV - Input

Force control/
Lock object

DPT 2.001/
DPT 1.003

receive

HCV channel
reacts to lock
command / Force
control

External push
button for
blocking/overriding
the motion
detector

Object is displayed after
activation; DPT depends on
parameter settings

47

HCV - Input

Lock object ON

DPT 1.003

receive

HCV channel
reacts to lock
command

External push­button for blocking
the motion
detector

Object is displayed after
activation

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

48

HCV

Status automatic mode

DPT 1.011

send

HCV channel sends
status

Visu, Diagnostics,
Display

Object is permanently
displayed and has the value 1 if
HCV channel is in automatic
mode.

49

HCV

Switch dark

DPT 1.001

receive

HCV channel
reacts to incoming
telegram

External button for
overriding the
brightness
dependency

Object is displayed when the
parameter "Brightness" is set to
"Basic setting or active object
´Dark´"

Objects per Alarm:

50

Alarm - Output 1

Switching

DPT 1.001

send

Alarm channel
sends switching
command

Switch actuator,
Visu, Display, etc.

Object is permanently
displayed and sends the value 1
if the Alarm function detects a
motion

51

Alarm - Night mode

Switching

DPT 1.001

send

Alarm channel
sends switching
command

Switch actuator,
Visu, Display, etc.

Object is displayed when object
is activated via parameter
"Separate switch object at
night"

56

Alarm - Input

Lock/Enable

DPT 1.003

receive

Alarm channel
reacts to incoming
telegram

Push button for
switching
presence/absence,
etc.

Object is permanently
displayed; The type of the
object is set via parameter
"Lock object or enable object";
Object is used to lock/enable
the alarm function.

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

General objects/ LEDs /Scene/ Motion direction:

60

Day/Night toggle

Day = 0 / Night = 1
Day = 1 / Night = 0

DPT 1.001

receive

Motion detector
reacts to incoming
telegram

Push button,
Time-switch etc.

Object is activated in the
general settings and switches
between day/night operation

61

LED Green

Switching

DPT 1.001

receive

Motion detector
reacts to incoming
telegram

Push button etc.

Object can be activated in
menu LED and switches the
green LED

62

LED Red

Switching

DPT 1.001

receive

Motion detector
reacts to incoming
telegram

Push button etc.

Object can be activated in
menu LED and switches the red
LED

63

LED White

Switching

DPT 1.001

receive

Motion detector
reacts to incoming
telegram

Push button etc.

Object can be activated in
menu LED and switches the
LED

64

Scene

Input

DPT 17.001

receive

Motion detector
reacts to incoming
telegram

Push button etc.

Object is permanently
displayed and calls up the
adjusted settings in light
channel 1/2

65

Output heartbeat

Status

DPT 1.001

send

Motion detector
sends Status

Visu, Diagnostics,
Failure detection
etc.

Object can be activated in the
general settings and sends
cyclically a "1" telegram if
device is on the bus.

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

67

Brightness sensor

Status

DPT 9.004

Send

Motion detector
sends measured
value

Visu, Diagnostic,
etc.

Object is permanently
displayed and sends the
currently measured brightness
value

70

Motion direction 1

Switch at motion from
right to left

DPT 1.001

Send

Motion detector
sends switching
command

Switch actuator,
etc.

Motion direction detection can
be activated in the menu
Alar

71

Motion direction 2

Switch at motion from
left to right

DPT 1.001

Send

Motion detector
sends switching
command

Switch actuator,
etc.

Motion direction detection can
be activated in the menu
Alar

Technical Manual Motion Detector SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

Logic functions:

80­83

Logic 1

Input C-F

DPT 1.001

receive

Motion detector
reacts to incoming
telegram

Any 1 bit value
from the KNX
system

Objects are displayed when the
external inputs are activated
for this logic

84

Logic 1

Output 1

DPT 1.001/
DPT 17.001/
DPT 5.001/
DPT 2.001

send

Logic sends output
telegram

actuator
technology

Object is permanently
displayed when logic is active;
DPT according to the setting
"Output object"

+5

next logic

Table 1: Overview and Usage of the communication objects

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

16

3.2 Default settings of the communication objects

Default settings

No.

Name

Function

Length

Priority

C R W T U

0

Light channel 1 -
Output 1

Dimming absolute
Switching
Scene

1 Byte/
1 Bit/
1 Byte

Low X X X
1

Light channel 1 -
Output 1 (night)

Switching

1 Bit

Low X X X 2

Light channel 1 -
Output 2

Switching

1 Bit

Low X X X 3

Light channel 1 -
Input

External push button short

1 Bit

Low X X 4

Light channel 1 -
Input

External push button long

1 Bit

Low X X 5

Light channel 1 -
Input

External Motion (Slave)

1 Bit

Low X X 6

Light channel 1 -
Input

Force control/
Lock object

2 Bit/
1 Bit

Low X X 7

Light channel 1 -
Input

Lock object On

1 Bit

Low X X 8

Light channel 1 -
Status

Status Automatic mode

1 Bit

Low X X X 9

Light channel 1 -
Input

Switch dark

1 Bit

Low X X

+10

next light channel

40

HCV - Output 1

Dimming absolute
Switching
Scene

1 Byte/
1 Bit/
1 Byte

Low X X X

43

HCV - Input

External push button short

1 Bit

Low X X

44

HCV - Input

External push button long

1 Bit

Low X X 45

HCV - Input

External Motion

1 Bit

Low X X

46

HCV - Input

Force control/
Lock object

2 Bit/
1 Bit

Low X X
47

HCV - Input

Lock object On

1 Bit

Low X X 48

HCV - Status

Status Automatic mode

1 Bit

Low X X X 49

HCV - Input

Switch dark

1 Bit

Low X X 50

Alarm - Output 1

Switching

1 Bit

Low X X X 51

Alarm - Night mode

Night mode

1 Bit

Low X X X 56

Alarm - Input

Lock/Enable

1 Bit

Low X X 60

Day/Night toggle

Switching

1 Bit

Low X X

61

LED green

Switching

1 Bit

Low X X 62

LED red

Switching

1 Bit

Low X X

63

LED white

Switching

1 Bit

Low X X 64

Scene

Input

1 Bit

Low X X

65

Output heartbeat

Status

1 Bit

Low X X X

67

Brightness sensor

Status

1 Bit

Low X X X

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

17

70

Motion direction 1

Switch at motion from right
to left

1 Bit

Low X X 71

Motion direction 2

Switch at motion from left to
right

1 Bit

Low X X
80-83

Logic 1

Input C-F

1 Bit

Low X X X

X

84

Logic 1

Output 1

1 Bit/
1 Byte/
2 Bit

Low X X X

+ 5

next logic

Table 2: Communication objects - Standard settings

The pre-set default settings can be taken from the tables above. The priority of the individual

communication objects as well as the flags can be adapted as required by the user. The flags assign

the respective task to the communication objects in the programming. C stands for communication,

R for reading, W for writing, T for transmission, and U for updating.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

18

4 Reference ETS-Parameter

4.1 General Settings

The following figure shows the submenu for general settings:

Figure 3: General Settings

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

19

The following table shows the possible settings for this menu:

ETS-Text

Dynamic range

[Default value]

Comment

Day/Night Object

 not used
 used
 used, read after reset

Setting whether a day/night
object is to be used and
whether it should be queried in
the case of a reset.

Value for Day/Night

 Day = 0 /Night = 1
 Day = 1 /Night = 0

Polarity of the Day/Night object

Toggle Day/Night

 At next presence
 directly at toggle

Setting when day/night
changeover is active

Basic setting of sensitivity

Release sensitivity for day

1-8

[6]

Setting of the release sensitivity
in day mode

Release sensitivity for night

1-8

[3]

Setting of the release sensitivity
in night mode

Presence sensitivity

1-8

[8]

Sensitivity adjustment when
presence detected

Basic setting of brightness

Sensor activation below (day)

10-2000Lux

[200]

Setting of the brightness
threshold below which the
sensor is activated in day mode

Sensor activation below (night)

10-2000Lux

[10]

Setting of the brightness
threshold below which the
sensor is activated in night
mode

Switch-off when exceeding

 not active
 10-2000Lux

Setting of the brightness
threshold from which the
sensor is deactivated

Filter short-term darkening

 not active
 active

Activation of a filter for short­term brightness fluctuations

Forced retrigger

 not active
 After presence and

follow-up time

 after fix time

Activation of a release time
from forced control

Follow-up time for force/
Release time for force

30s-12h

Setting the release time

Release of push button input

 After presence and

follow-up time

 after fix time

Activation of a release time
from the override by an
external push button

Follow-up time for force/
Release time for force

30s-12h

Setting the release time

Cylial sedig hearteat

 not active
 1min – 24h

Activation of a cyclic
"heartbeat" telegram

Table 3: Parameter - General Settings

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

20

The following table shows the general communication objects:

Number

Name

Length

Usage

60

Day/Night toggle

1 Bit

Switchover between day and night mode

65

Output heartbeat

1 Bit

Sendig of a yli hearteat telegra

Table 4: Communication objects - General Settings

4.2 Light Channel 1/2/HCV

4.2.1 General Settings

The following figure shows the basic settings for a light channel:

Figure 4: Basic settings - light channel

The following table shows the possible settings for these parameters:

ETS-Text

Dynamic range

[Default value]

Comment

Active sensors

 -­ 1-
 -2
 12

Setting which sensors are active for the
selected channel

Information about
placement of sensors

Parameter displays a sketch with
information about the sensors S1 and
S2

Sensitivity

 Basic setting (General

setting)

 individual

Basic setting: The sensitivity settings
from the menu "General settings" are
used.
Individual: Individual values can be set
for the sensitivity of this light channel.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

21

Brightness
(only light channel
1/2)

 Basic setting (General

setting)

 Basic setting or active

ojet Dark

 Independent of

brightness

Basic setting: The light channel uses
the brightness settings of the general
settings.

Basi setting or ative ojet Dark:

The light channel uses the brightness
settings of the general settings, but can
be switched independent of brightness
with a "1" on the object "Dark".
Independent of brightness: The light
channel switches independently of the
measured brightness

Motion filter in
standby

 not active, no filtering
 active, delete short

movement

Only in fully automatic mode!

Activation of a motion filter in standby
mode (= output is switched off)

Number of monitoring
time slots
(only for HCV)

0-32

[3]

Definition of how many movements
have to be detected before switch-on

Length of monitoring
time slot
(only for HCV)

0-3000s

[30s]

Determination of the length for a
monitoring time slot

Table 5: Basic settings - light channel

The parameters brightness and monitoring time slot are explained in more detail as follows:

 Brightness (only light channel 1/2)

Sensor activation/deactivation is only available for the light group. In this way, the presence
detector can be assigned a specific work area. The parameter "Sensor activation below" defines
the brightness threshold below which the detector detects presence. No movement is detected
above this threshold, but the detector does not switch off the light as soon as the brightness is
exceeded. This can be achieved with the parameter "Switch-off when exceeding". However, this
value should not be set too low, as this can result in a continuous on/off switching.

 Monitoring time slot (only HCV)

The monitoring time slot is only available for one HCV channel. This means that a longer
detection time is required for switching on. In order to switch on the channel, at least, one
detection must have taken place in each of the set monitoring time slots

4.2.2 Channel Mode Selection

A distinction can be made between two operating modes: Fully automatic and half-automatic:

 Fully automatic

If the motion detector is set as fully automatic, each detected presence causes the output to
be switched on and is switched off again after the follow-up time has expired.

Half automatic

In half automatic mode, the output is switched on via the "External push-button short"
object and is automatically switched off again after the follow-up time has expired..

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

22

4.2.3 Follow-up time

The following figure shows the available settings for the follow-up time:

Figure 5: Follow-up time

The delay time describes the time that expires after the last detection of a movement until the
output is switched off. For example, with a follow-up time of 3 minutes, the light would be switched
on for at least 3 minutes with motion detection. Each new detection leads to a retriggering and thus
to a restart of the follow-up time..
In addition, a "reduction of follow-up time" can be activated. In this case, two additional parameters
are displayed:
Maximum duration for short time presence: Indicates the duration between the first and last
motion detection to activate the short-time presence..
Follow-up time for short time presence: Indicates the duration of the follow-up time if the short­time presence has been activated.
If the first and last movement within the set duration for short-time presence was detected when
short-time presence was activated, the output is not switched on for the regular follow-up time, but
only for the follow-up time of the short-time presence.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

23

4.2.4 Force or lock object

The following figure shows the settings for the force control/lock object:

Figure 6: Settings - Force control/lock object

The following table shows the possible settings for these parameters:

ETS-Text

Dynamic range

[Default value]

Comment

Force or lock object

 Force control object
 Lock object universal
 Lock object universal and

force object ON

Select whether a force control object
or a lock object is to be used

Action at
locking

 Switch ON
 Switch OFF
 Lock (current state)

Parameter only available for lock
object;

Defines the status which is to be sent
when the device is locked

Table 6: Settings - Force control/lock object

The motion detector can be overridden with the force control/lock object and call up a certain status.
The force control object knows 3 possible states:

 Force control ON (control = 1, value = 1)

The oad for ON is sent unconditionally to the output object. The evaluation is then
stopped and the release time for force control begins. If nothing is received on the force
control object after the release time has expired, normal operation is resumed..

 Force control OFF (control = 1, value = 0)

The command for "OFF" is sent unconditionally to the output object. The evaluation is then
stopped and the release time for force control begins. If nothing is received on the force
control object after the release time has expired, normal operation is resumed.

 Force control AUTO (control = 0, value = 0)

After that the normal operation of the detector is continued

As an alternative to the force control object, 1 or 2 locking objects of size 1 bit can be displayed. 3
different states can be configured for the lock object universal:
 Switch ON

The light channel sends the output value ON and remains in the ON state until the locking
process is deactivated..

 Switch OFF

The light channel sends the output value OFF and remains in the OFF state until the locking
process is deactivated..

 Lock (current state)

The light channel is locked in its current state and remains locked until the locking process is
deactivated..

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

24

By activating "Lock object ON", the light channel sends the output value ON and remains in the ON
state until the locking process is deactivated..
The following table shows the corresponding communication objects:

Number

Name

Length

Usage

6

Lock object

1 Bit

Locking the light channel

6

Force control object

2 Bit

Activate/deactivate force control

7

Lock object ON

1 Bit

Switching on the light channel and locking the
light channel in the ON state

Table 7: Communication objects - Force control/lock object

4.2.5 Output object

The following figure shows the settings for the output object:

Figure 7: Settings - Output object

The following table shows the possible settings for these parameters:

ETS-Text

Dynamic range

[default value]

Comment

Object type for output
– light

 Switching
 Dimming absolute
 Scene

Selection of the output object to be
triggered with the light channel

Table 8: Settings - Output object

The parameter "Object type for output" defines the data point type of the output object.

Output object: Switching

If the object type "Switching" is selected, a separate object for night operation can be displayed. For
example, the main light can be switched on during daytime operation and a small orientation light
can be switched on during night time operation.
The following table shows the general communication objects:

Number

Name

Length

Usage

0

Light channel 1 – Output 1
(day)

1 Bit

Switching function of the light channel for
daytime operation

1

Light channel 1 – Output 1
(night)

1 Bit

Switching function of the light channel for night
operation

2

Light channel 1 – Output 2

1 Bit

Second switching function of the light channel

Table 9: Communication objects - Output object "switching"

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

25

Output object: Dimming absolute

If the output object is set to "Dimming absolute", different dimming values for day and night can be
defined:

Figure 8: Settings - Output object Dimming absolute

In addition, an orientation light can be activated to leave the room. The orientation light is called up
when the follow-up time of the light channel has expired. Without orientation light, the channel
would be switched off without delay. The orientation light now causes the output to call up the
parameterised value for the switch-off delay day/night. The light channel is not switched off until the
switch-off delay for day/night has expired.
In addition to the output object Dimming asolute, a second output object "Switching" is displayed.
The following table shows the general communication objects:

Number

Name

Length

Usage

0

Light channel 1 – Output 1
– Dimming absolute

1 Byte

Dimming function of the light channel

2

Light channel 1 – Output 2

1 Bit

Second switching function of the light channel

Table 10: Communication objects - Output object "Dimming absolute"

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

26

Output object: Scene

If the object type "Scene" is selected, scene numbers for the value On/Off for day/night operation
can be sent..
I additio to the output ojet See, a seod output ojet "Swithig" is displayed.
The following table shows the general communication objects:

Number

Name

Length

Usage

0

Light channel 1 – Output 1
– Scene

1 Byte

Scene function of the light channel
2

Light channel 1 – Output 2

1 Bit

Second switching function of the light channel

Table 11: Communication objects - Output object "Scene"

Cyclical sending

Output object 1 (depending on the parameterisation Switching, absolute dimming or scene) can send
the parameterised value cyclically. In addition, the second switching object can also send its value
cyclically.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

27

4.2.6 External Push Button Input

The following figure shows the settings for the external push-button input:

Figure 9: Settings - External push button input

The following table shows the possible settings for these parameters:

ETS-Text

Dynamic range

[default value]

Comment

External push button
input reacts to

 only ON
 ON and OFF

Selection whether the external push­button input can switch the light
channel only ON or ON and OFF.

Table 12: Setting - External push button input

With the external push-button input, the motion detector can be switched on independently of
movement detection..
The object for the "external push-button short" switches the motion detector to the next state (see
also 4.2.7 Process Diagram).
In contrast, the object "External push button long" always switches the motion detector directly On
or Off.
The following table shows the general communication objects:

Number

Name

Length

Usage

3

Light channel 1 – Input –
External push button short

1 Bit

Object for the output of an external push-button;
is used for manual switching between the states
of the light channel or for switching on the light
channel in the half-automatic mode.

4

Light channel 1 – Input –
External push button long

1 Bit

Object for the output of an external push-button;
is used for manual switching on of the light
channel

Table 13: Communication objects - External push button input

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

28

4.2.7 Process Diagram

Fully automatic without orientation light:

Figure 10: Process diagram - Fully automatic without orientation light

In the operating mode "Fully automatic", the motion detector switches on automatically when
movement is detected. The object "External push button short" can be used to override the
automatic mode of the motion detector and force the motion detector into manual mode. From this
mode, the detector automatically returns to auto mode according to the settings in the menu
"General settings" - "Release of push button input"
If the output of the light channel is switched on (automatic mode - ON or manual mode - ON) and the
light channel is switched off via the object "External push button short", then the light channel is
blocked for 10 seconds for motion detection in order to leave the room and prevent brief restart.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

29

Fully automatic within orientation light:

Figure 11: Process diagram - Fully automatic within orientation light

The fully automatic mode with orientation light extends the fully automatic mode of operation by the
orientation light status. The orientation light can be activated as soon as the parameter "Object type
for output - light" is set to absolute dimming.
The orientation light is switched on as soon as the follow-up time of the light channel has expired.
The output is then switched to the orientation light state and can thus dim the light to a darker level
in order to be able to leave the room safely.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

30

Half automatic without orientation light:

Figure 12: Process diagram - Half automatic without orientation light

In the "half-automatic" operating mode, the motion detector has to be switched on manually via the
object "External push button short". The light channel is automatically switched off again after the
follow-up time has expired (= no motion detection for the set follow-up time).
The object "External push button short" can additionally override the light channel. The motion
detector can be switched to manual mode by pressing twice.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

31

Half automatic within orientation light:

Figure 13: Process diagram - Half automatic within orientation light

The half-automatic mode of operation with orientation light extends the half-automatic mode by the
orientation light status. The orientation light can be activated as soon as the parameter "Object type
for output - light" is set to absolute dimming.
The orientation light is switched on as soon as the follow-up time of the light channel has expired.
The output is then switched to the orientation light state and can thus dim the light to a darker level
in order to be able to leave the room safely.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

32

4.2.8 Master/Slave Operation

4.2.8.1 Light channel

In larger rooms often more than one motion detector is required. For detecting presence all over
the room, motion detectors have to be allocated in the whole room. But also in this case a detected
presence shall cause always the same settings independent of the place of detection. In this case one
detector operates as Master and an arbitrary number of motion detectors work as Slave.
The settings for the Master/Slave mode a e ade i the sueu light groups.

The Slaves must be configured as follows:

 Adjustment to fully automatic (every movement shall be sent)
 Set follow-up time to the same value as the Master
 Set object type for output - light to Swithig
 Activate cyclic sending for the output object

o Parameter: Output object 1 sends cyclic at ON
o Guide value: 1min; for longer follow-up times, e. g. at 15min the cyclic sending can

be increased to e. g. 5 min in order to reduce the bus load.

 Set Brightness parameter to brightness independent

The Master is parameterized as fully or half-automatic as desired.
A value of 10 minutes is recommended as the common follow-up time..

The objects have to be connected as follows:

 All output objects of the Slaves (Object 0) have to be connected with the object external

motion - Slave (Object 5) of the Master.

The master now evaluates every self-detected movement as well as movement detected by the
slaves. The master then switches the light groups according to its own settings, regardless of who has
detected the motion..

4.2.8.2 HCV

The Master/Slave control can also be applied to the HCV channel. The settings for the slave are the
same as for the slaves for the lighting groups. However, the settings for the brightness values do not
apply to the HCV channel. The observation windows must be set according to individual
requirements.
The objects have to be connected as follows:

 All output objects of the slaves (Object 40) have to be connected to the object External

motion (Object 45) of the master.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

33

4.3 Alarm/Motion Direction

4.3.1 Alarm

The following figure shows the settings for the alarm function:

Figure 14: Settings - Alarm function

The following table shows the parameter settings for alarm detection:

ETS-Text

Dynamic range

[default value]

Comment

Active sensors

 -­ 1-
 -2
 12

Setting which sensors are active for
alarm detection

Information about
placement of sensors

Parameter displays a sketch with
information about the sensors S1 and
S2

Release sensitivity for
Day/Night

1-6

[3 (Day), 2 (Night)]

Adjustment of sensitivity for triggering
the alarm in standby mode (no motion
detected)

Presence sensitivity

1-8

[6]

Adjustment of the sensitivity after a
first motion has been detected

Motion filter in
Standby

 not active, no filtering
 active, filter short motion

Activation of a motion detector at
standby (= output is switched off)

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

34

Follow-up time

1s-4h

[5min]

Setting the follow-up time

Locking or enabling
object

 Lock object universal
 Enabling object

Setting whether a locking or enabling
object is to be used

Separate switch object
at night

 not active
 active

Displays a separate object for night
mode

Output object sends at

 only On
 On and Off

Output filter for the first output object

Output object sends
cyclic

 not active
 10s-60min

Activation of cyclic sending for the first
output object

Table 14: Settings - Alarm function

The alarm function can be used to monitor a room in case of absence and to call certain actions in
the KNX system during motion detection.

The individual parameters are described in more detail below:

Release sensitivity for Day/Night

The release sensitivity describes the sensitivity in stand-by mode (the output is switched off, no
motion has been detected)

Presence sensitivity

Presence sensitivity describes the sensitivity in presence mode (the output is switched on, a motion
has been detected.).

Motion filter in Standby

In order to avoid false detection, a motion filter can be activated which filters out very short motions
e. g. by draughts.

Follow-up time

The follow-up time describes the time that expires after the last detection of a motion until the
output is switched off. For example, with a follow-up time of 3 minutes, the light would be switched
on for at least 3 minutes with motion detection. Each new detection leads to a retriggering and thus
to a restart of the follow-up time..

Locking or enabling object

To lock or enable the alarm channel, you can activate a lock or enabling object. The lock object
switches off the channel with a 1, the enable object activates the alarm channel with a 1..

Separate switch object at night

This parameter displays a separate switch object for night mode..

Output object sends at

This parameter can be used to activate a sending filter for the output. If you want the output to send
only ON commands, you have to use the setting "only ON".

Output object sends cyclic

Activation of cyclic sending for object 50 "Alarm - output 1".

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

35

The following table shows the corresponding communication objects:

Number

Name

Length

Usage

50

Alarm – Output 1

1 Bit

Output of the Alarm function

51

Alarm – Night mode

1 Bit

Output of the Alarm function at night mode

56

Alarm Input – Lock

1 Bit

Locking the alarm function

56

Alarm Input – Enable

1 Bit

Enabling the alarm function

Table 15: Communication objects - Alarm function

4.3.2 Motion Direction

The following figure shows the parameters for motion direction detection:

Figure 15: Settings - Motion direction

The following table shows the parameter settings for motion direction detection:

ETS-Text

Dynamic range

[default value]

Comment

Motion direction

 not active
 active

Activation of motion direction
detection

Place of
installation

 Corridor
 Room

Setting where the motion detector is
mounted

Table 16: Settings - Motion direction

The motion direction detection allows to detect in which direction a person is moving.
With the setting "place of installation", the behaviour of the detection is set. For example, frontal
movements are filtered out more strongly with the setting "Place of installation - room" than with
the setting "corridor". For elongated rooms, the setting "corridor" should be used. In this location
and configuration, motion direction detection shows the best results.

The following table shows the corresponding communication objects:

Number

Name

Length

Usage

70

Motion direction 1 –
right to left

1 Bit

Object sends a 1 if the right sensor has detected a
motion first and then the left sensor

71

Motion direction 1 –
left to right

1 Bit

Object sends a 1 if the left sensor has detected a
motion first and then the right sensor

Table 17: Communication objects - Motion direction

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

36

4.4 Logic Function

4.4.1 Activation of the Logic function

The following figure shows the activation of the logic functions 1-4:

Figure 16: Activation - Logic function

After activating the logic function, a submenu is displayed for the corresponding logic function in
which the logic can be further parameterized accordingly.
The parameter "Request inputs after bus voltage reset" defines whether the external inputs of the
logic are to be queried after a restart..

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

37

4.4.2 Logic function 1-4

The following figure shows the submenu for a logic block:

Figure 17: Submenu - Logic function

The following table shows the parameter settings for the logic function:

ETS-Text

Dynamic range

[default value]

Comment

Function

 AND
 OR
 XOR

Setting the logic function

Output object

 Switching
 Value
 Scene
 Force 2bit

Setting the output object for logic

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

38

Send conditions

 At input telegram
 At output change
 send only 0 at output

change

 send only 1 at output

change

 send only 0 at input

telegram

 send only 1 at input

telegram

Setting the sending condition:
At input telegram: The output value is
sent with each input telegram,
regardless of whether the output value
has changed or not.
At output change: The output value is
only transmitted if the output has
changed.
Send only 0/1 at output change: The
output value is only transmitted if the
output changes and the logic has the
corresponding value (false/true).
Send only 0/1 at input telegram: The
output value is sent with each input
telegram if the logic has the
corresponding value (false/true).

Internal input A/B

 not active
 normal
 inverse

Activation of an internal object as logic
input

Object number

0-99

[0]

Selection of the internal object ­Attention: Only bit values are
evaluated correctly!

External input C-F

 not active
 normal
 inverse

Activation of an external object as logic
input

Initialise logic
input with…
after reset

 Wert 0
 Wert 1

Setting of a pre-assignment of the logic
after a bus voltage reset

Table 18: Submenu - Logic

The logic function can be used to logically link different objects. Each logic function can link and
evaluate up to 2 internal objects and up to 4 external objects. The sending condition can be used to
adjust the transmission behaviour of the output.
The following table shows the corresponding communication objects:

Number

Name

Length

Usage

80

Logic 1 – Input C

1 Bit

External input for logic function

81

Logic 1 – Input D

1 Bit

External input for logic function

82

Logic 1 – Input E

1 Bit

External input for logic function

83

Logic 1 – Input F

1 Bit

External input for logic function

84

Logic 1 – Output 1

1 Bit/
2 Bit/
1 Byte

Output of logic function; size and DPT depending
o the paraeter Output ojet

Table 19: Communication objects - Logic

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

39

4.5 LED

The following figure shows the submenu LED:

Figure 18: Submenu - LED

The following table shows the parameter settings for the submenu LED:

ETS-Text

Dynamic range

[default value]

Comment

LED green

 not active
 active at motion
 active at motion, only during

the day

 active over external object
 active over external object,

flashing

Setting the lighting behaviour of the
green LED

LED red

 only as programming-LED
 active over external object,

flashing

Setting the lighting behaviour of the
red LED

LED white
(night light)

 not active
 active at night when motion

(Light channel 1)

 active at night when motion

(Light channel 2)

 active at night when motion

(Light channel 1 and 2)

 active at night over external

object „Switching

 always active at night

Setting the lighting behaviour of the
white LED

Brightness at
night

0-100%

[10%]

Setting the brightness of the white
LED in night mode

Table 20: Submenu LED

The motion detector has 2 green, one white and one red LED..
The lighting characteristics of the LEDs can be adjusted according to the parameters listed above. A
typical application for the use of the white LED would be e. g. the use as night light.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

40

The following table shows the corresponding communication objects:

Number

Name

Length

Usage

61

LED green

1 Bit

Switching the green LED via external object

62

LED red

1 Bit

Switching the red LED via external object

63

LED white

1 Bit

Switching the white LED via external object

Table 21: Communication objects - LED´s

4.6 Scenes

The following figure shows the submenu Scene:

Figure 19: Submenu - Scenes

The following table shows the parameter settings for the submenu Scenes:

ETS-Text

Dynamic range

[default value]

Comment

Scene A-H number

1-63

[not active]

Setting the scene number

Scene A-H Light
channel 1/2

 not active
 Lock active ON
 Lock active OFF
 Lock active
 Lock disable
 Set external push button

input to value 1

 Set external push button

input to value 0

 Enable Day
 Enable Night

Setting the action for light channel 1/2
for calling up the scene

Table 22: Submenu - Scene

The scene function can be used to initiate actions for light channel 1/2 by sending the corresponding
scene numbers. For example, the value of the disable function can be changed or the value of the
external input button can be changed.

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

41

The following table shows the corresponding communication objects:

Number

Name

Length

Usage

64

Scene – Input

1 Byte

Calling up the scene

Table 23: Communication objects - Scene

4.7 Brightness

The following figure shows the submenu for Brightness:

Figure 20: Submenu - Brightness

The following table shows the parameter settings for the submenu Brightness:

ETS-Text

Dynamic range

[default value]

Comment

Correction Lux value

-50% - 50%

[0%]

Setting the correction of the lux value

Send brightness at
change of

 not send
 10 - 1200Lux

Setting the transmission condition for
sending the light value in case of
change

Cyclical sending light
value

 not used
 5s - 30min

Activation of cyclic sending of the light
value

Table 24: Submenu - Brightness

In the menu "Brightness" the brightness measurement value can be corrected in percent. To make a
correction, proceed as follows:

 Measure the actual lux value at the installation location of the motion detector with a lux

meter

 Reading out the measured value of the motion detector

 Calculate the deviation: 1 −

𝑀𝑎 𝑎  𝑖 

𝑀𝑎 𝑎  𝑥

 Enter the deviation as correction for the lux value

In addition, the transmission behaviour of the light value can be adjusted. The light value can be
transmitted either cyclically or in the case of changes..

The following table shows the corresponding communication objects:

Number

Name

Length

Usage

67

Brightness sensor – Status

2 Byte

Sending the state of the brightness value

Table 25: Communication object - Brightness

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

42

5 Index

5.1 Register of illustrations

Figure 1: Exemplary circuit diagram ........................................................................................................ 5

Figure 2: Structure ................................................................................................................................... 6

Figure 3: General Settings ..................................................................................................................... 18

Figure 4: Basic settings - light channel .................................................................................................. 20

Figure 5: Follow-up time ....................................................................................................................... 22

Figure 6: Settings - Force control/lock object ....................................................................................... 23

Figure 7: Settings - Output object ......................................................................................................... 24

Figure 8: Settings - Output object Dimming absolute ........................................................................... 25

Figure 9: Settings - External push button input..................................................................................... 27

Figure 10: Process diagram - Fully automatic without orientation light ............................................... 28

Figure 11: Process diagram - Fully automatic within orientation light ................................................. 29

Figure 12: Process diagram - Half automatic without orientation light ................................................ 30

Figure 13: Process diagram - Half automatic within orientation light .................................................. 31

Figure 14: Settings - Alarm function ...................................................................................................... 33

Figure 15: Settings - Motion direction................................................................................................... 35

Figure 16: Activation - Logic function .................................................................................................... 36

Figure 17: Submenu - Logic function ..................................................................................................... 37

Figure 18: Submenu - LED ..................................................................................................................... 39

Figure 19: Submenu - Scenes ................................................................................................................ 40

Figure 20: Submenu - Brightness........................................................................................................... 41

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

43

5.2 List of tables

Table 1: Overview and Usage of the communication objects ............................................................... 15

Table 2: Communication objects - Standard settings ............................................................................ 17

Table 3: Parameter - General Settings .................................................................................................. 19

Table 4: Communication objects - General Settings ............................................................................. 20

Table 5: Basic settings - light channel.................................................................................................... 21

Table 6: Settings - Force control/lock object ......................................................................................... 23

Table 7: Communication objects - Force control/lock object ............................................................... 24

Table 8: Settings - Output object ........................................................................................................... 24

Table 9: Communication objects - Output object "switching" .............................................................. 24

Table 10: Communication objects - Output object "Dimming absolute" ............................................. 25

Table 11: Communication objects - Output object "Scene" ................................................................. 26

Table 12: Setting - External push button input ..................................................................................... 27

Table 13: Communication objects - External push button input .......................................................... 27

Table 14: Settings - Alarm function ....................................................................................................... 34

Table 15: Communication objects - Alarm function .............................................................................. 35

Table 16: Settings - Motion direction .................................................................................................... 35

Table 17: Communication objects - Motion direction .......................................................................... 35

Table 18: Submenu - Logic .................................................................................................................... 38

Table 19: Communication objects - Logic.............................................................................................. 38

Table 20: Submenu LED ......................................................................................................................... 39

Table 21: Communication objects - LED´s ............................................................................................. 40

Table 22: Submenu - Scene ................................................................................................................... 40

Table 23: Communication objects - Scene ............................................................................................ 41

Table 24: Submenu - Brightness ............................................................................................................ 41

Table 25: Communication object - Brightness ...................................................................................... 41

Technisches Handbuch Bewegungsmelder SCN-BWM55.x1

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: [phone] • Fax: [phone] • [e-mail] • www.mdt.de

44

6 Attachment

6.1 Statutory requirements

The above-described devices must not be used with devices, which serve directly or indirectly the

purpose of human, health- or lifesaving. Further the devices must not be used if their usage can

occur danger for humans, animals or material assets.

Do not let the packaging lying around careless, plastic foil/ -bags etc. can be a dangerous toy for kids.

6.2 Routine disposal

Do not throw the waste equipment in the household rubbish. The device contains electrical devices,

which must be disposed as electronic scrap. The casing contains of recyclable synthetic material.

6.3 Assemblage

Risk for life of electrical power!

All activities on the device should only be done by an electrical specialist. The county specific
regulations and the applicable EIB-directives have to be observed.

SCN-BWM55.x1

MDT Motion Detector

MDT Motion Detector, ush mounted

Version

SCN-BWM55.01 Motion Detector, 2 pyro detectors and 1 light sensor Flush mounted, white matt nish

SCN-BWM55.G1 Motion Detector, 2 pyro detectors and 1 light sensor Flush mounted, white shiny nish

The MDT Motion Detector with light sensor captures the smallest movements with its built in pyro detectors and high
resolution lens. After motion detection and below an adjusted brightness value a 1Bit („1“) telegram or 1Byte dimming
value (0...100%) is send to the bus. The sensitivity is adjustable in 10 steps. If there is no movement a 1Bit („0“) telegram
or 1Byte dimming value (0...100%) is send to the bus after an adjustable follow up time.

Fits 55mm systems:

• GIRA Standard 55, E2, Event, Esprit

• BERKER S1, B3, B7

• JUNG A500, Aplus, Acreation, AS500

• MERTEN 1M, M-Smart, M-Plan, M-Pure

The MDT Motion Detector is a ush mounted device for xed installations in dry rooms. For project design and

commissioning of the Motion Detector it is recommended to use the ETS. Please download the application software at
www.mdt.de/downloads.html

• Production in Germany, certied according to ISO 9001

• Fits 55mm systems:

- GIRA Standard 55, E2,E22, Event, Esprit

- BERKER S1, B3, B7

- JUNG A500, Aplus, Acreation, AS500

- MERTEN 1M, M-Smart, M-Plan, M-Pure

• Motion detector with light sensor and 2 pyro detectors

• Motion detection angle H 180° / V 15°, covered area 6-10m

• Suitable for pets up to 12kg

• Sensitivity separately adjustable for day/night/presence

• 2 light channels, 1 channel for HVAC and alarm

• Detection of moving direction

• Short time presence to reduce stopping time

• Master/slave function, scenes and logical functions

• Objects for integrated night light, green/red LED and brightness value

• Day/night function, orientation light function

• Block and forced setting functions with release time

• Input object for external button with release time

• Integrated bus coupling unit

• 3 years warranty

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: + 49 - 2263 - 880

•

Fax: + 49 - 2263 - 4588 • [e-mail]

•

www.mdt.de

Stand: 0217

DIN EN ISO 9001

TAW Cert

Zert.Nr.1905606

N

MDT Motion Detector

Technical Data

SCN-BWM55.01

white matt nish

SCN-BWM55.G1

white shiny nish

Covered area (Diameter)

Movement * 6 - 10m 6 - 10m

Sensitivity adjustable in 10 steps adjustable in 10 steps

Angular coverage horizontal 180° 180°

Angular coverage vertical 15° 15°

Dynamic range of light sensor 5 - 1000 Lux 5 - 1000 Lux

Recommended mounting height 1,05 - 1,20m 1,05 - 1,20m

Specication KNX interface TP-256 TP-256

Available application software ETS 4/5 ETS 4/5

Permitted wire gauge

KNX busconnection terminal

0,8mm Ø, solid core 0,8mm Ø, solid core

Power supply KNX bus KNX bus

Power consumption KNX bus typ. <0,3W <0,3W

Operation temperature range

0 to + 45°C 0 to + 45°C

Enclosure

IP 20 IP 20

Dimensions (W x H)

55mm x 55mm 55mm x 55mm

Installation depth in socket

12mm 12mm

Examplary circuit diagram SCN-BWM55.x1 Compatible to 55mm programs

Manufacturer Series

Berker B.7 Glas polarweiss
Berker B.3 Alu polarweiss
Berker S.1 polarweiss
Berker B.1 polarweiss matt
Berker B.7 Glas Alu
Berker S.1 polarweiss matt
Gira Standard 55 reinweiss seidenmatt
Gira E2 reinweiss seidenmatt
Gira Esprit Glas mint
Gira Esprit Glas weiss
Gira Event Alu
Gira Event reinweiss matt
Merten M-Smart polarweiss brillant
Merten M-Plan polarweiss edelmatt
Merten M-Arc polarweiss edelmatt
Merten M-Pure
Merten M-Plan Echtglas brillantweiss
Merten M-Smart polarweiss
Jung AS500 alpinweiss
Jung A500 alpinweiss
Jung A500 alpinweiss
Jung Aplus Alu
Jung A500 Alu

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1

Tel.: + 49 - 2263 - 880

•

Fax: + 49 - 2263 - 4588 • [e-mail]

•

www.mdt.de

Stand: 0217

DIN EN ISO 9001

TAW Cert

Zert.Nr.1905606

N
