INTRODUCTION
Congratulations on your purchase of MX -2575 Cable Tester.
MX has a product range of over 3500 products. MX categories include home theater
Cables and Connectors, Computer/Laptop Accessories, Pro Audio/Studio Cables and
Connectors, Audio/Video Components and Accessories, Fiber Optic Components and
Accessories, Cable TV Components and Accessories.
MX Cable Tester is professional's choice for multi-function cable testers. It tells you the
exact wiring of any cable or adapter and even allows testing of cables that are
terminated via connectors. Its intermittent detection allows you to wiggle a cable and
know if there was a connection at any time - even if you didn't see the LEDs change!
With the functions of test tone generation, phantom power detects, and grounded XLR
shield detect, this the perfect utility tool!
Our Commitment
There are many outstanding technological innovations in the world. Through innovative
thinking we are committed to enriching the lives of people all around the world. It
aspires us to go beyond and touch people in ways that could make their lives more
satisfying. We continuously aim to exceed our customer’s expectations.
http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 3
Page 4
FEATURES
Connectors: XLR, TRS1/4", RCA, TRS1/8", TT and MIDI
Cable Wiring Display clearly shows which pin is wired to what.
The Cable Wiring Display clearly shows continuity, opens and shorts for each
pin.
Installed Cable Testing: Connect the tester to one end of the cable and see if any
of the lines are shorted together. Then, connect a shorting connector onto the
other end of the cable and if the lines are good, the Cable Wiring display will
show them as all shorted to each other.
Test Tone Generation: The tester generates a 1 kHz or 440Hz tone.
Grounded Shield Detect: Confirms that the XLR connector shield is connected to
Pin 1 (grounded).
Runs on 9v Dc batteries (not included).
http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 4
Page 5
One Package Includes:
(1) Tester
(1) Testing Leades
(1) User's Manual
WARNING:
Dos and Don’ts
TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK OR PRODUCT
DAMAGE
1. Do not expose this apparatus to rain, moisture dripping or splashing and make
sure that no objects filled with liquids are placed on the apparatus.
2. Do not install or place the unit in a bookcase or built in cabinets or in another
confined space. Ensure the unit is well ventilated.
3. To prevent the risk of electric shock or fire hazard due to overheating do not
obstruct the unit’s ventilation opening with newspaper, tablecloths, curtains and
other similar items.
4. Do not install near any heat sources such as radiators, heat registers, stoves or
other such apparatus.
5. Do not place sources of naked flames near unit such as lighted candles etc.
6. Clean the apparatus only with dry cloth.
7. Unplug apparatus during lighting storms or when unused for long time.
8. Protect the power cord from being walked on or pinched, particularly at plug end.
9. Only use accessories specified by the manufacturer.
10. Refer all servicing to qualified service personnel only.
