M&C TechGroup SP30-H1 Datasheet

SP30-H1.1/EX2

Embracing Challenge

Electrically heated sample probe
tube series SP®

Version SP30-H1.1/EX2, SP30-H2/EX2 and SP30-H1.1-V/EX2
for gas sample probe SP3200 and SP3200V
for sampling from and mounting in ex-zone 2

Special Features

Approval according to ATEX for sam-



pling from Ex-zone 2

Approval according to ATEX for mount-



ing in Ex-zone 2

Completely heated sample tube



Electronic temperature controller



Dierent lengths



Unheated pre-lters or extensions pos-



sible

Simultaneously heated pre-lter pos-



sible

Easy mounting



Two temperature sensor versions



Application

The electrically heated M&C sample probe
tube SP30-H../EX2 is used in extractive sam­pling systems to avoid cooling and conden­sation of the sample in the insitu tube from
the sample point to the heated sample probe
SP3200-H. It can be used for sampling from
Ex-zone 2 and mounting in Ex-zone 2.

To avoid a premature demage by cooling
and condenstaion in dust loaded proc­esses, we recommend a heated tube type
SP30-H1.1-V/EX2, including an insitu pre-filter
V20-2/30, heated up with the tube.

Description

The electrically heated M&C sample tube
SP30-H../EX2 is available in 0,6 m and 1,0 m,
length.

With a mounting flange with 4 welded screws
the heated sample tube SP30-H../EX2 can
be easily fixed both to the flange at the
sample point and the probe head SP3200-H.
The heated sample tubes SP30-H1.1/EX2 and
SP30-H2/EX2 is equipped with a G3/4»i thread
connector at the tube end. This enables fixing
a standard non heated sample tube or pre­filter to the heated insitu tube.

The electrical cartridge heater is located inside
a double tube system, completely separated
from the process. At the version SP30-H1.1-V/
EX2 the included large pre-filter V20-2/30 is
heated up with the sample tube.

The temperature of the heated tube has to
be adjusted in relation to the temperature
class. The tube versions SP30-H1.1/EX2 and
SP30-H2/EX2 have an internal diameter of
22 mm. The internal diameter of the version
SP30-H1.1-V/EX2 is reduced to 6 mm to opti­mise the tube dead volume.

For temperature control of the heated sample
tube the electronic controller HEX5-0.2.08 is
used. It is applicable for separate mounting
in Ex-zone 2. The controller depending on
the desired temperature class is programmed
correspondingly ex works.

Technical specications and illustrations are without
obligation, subject to modications. 11.09

M&C TechGroup Germany GmbH • Rehhecke 79 • 40885 Ratingen • Germany
[e-mail] • www.mc-techgroup.com • Fon [phone] • Fax [phone]

2.16

210

120

Ø 130

20

∅ 160

14 40

M12

L1

Terminals

Ø 42,2

G3/4"

PG13,5

Temperature-Sensor

Power

Temperature of pre filter in dependence of controller
temperature at 20°C ambient temperature.

500

ø 64

210

120

ø 130

ø 160

14

40

M12

L1

Terminals

PG13,5

Temperature
Sensor

Power

Controller temperature

180°C

Temperature of pre filter

135°C

Dimensions

Probe tube SP30-H1.1/EX2 and SP30-H2/EX2

Dimensions in mm

Temperatue controller HEX5-0.2.08

Ø 6,5

SICHERUNG NICHT
UNTER SPANNUNG
HERAUSNEHMEN!

DO NOT REMOVE
FUSE WHEN
ENERGIZED!

Sicherung 1A
Fuse 1A

250

225

A1 A2

Probe tube with pre-filter SP30-H1.1-V/EX2

200

14

12 11

91

7 8 10 11 1312 14 1615

6

42 3 5

120

175

Dimensions in mm

145

Technical Data

®

SP30-H1.1/EX2 SP30-H2/EX2 SP30-H1.1-V/EX2

length 520 mm, ø 60 mm,
filter porosity 2µm, integrated
and heated

ISO 228/1

3

II 3 G Ex nA II T5 to T2 see table temperature class

Technical specications and illustrations are without
obligation, subject to modications. 11.09

>2 g/m

3

Heated sample tube Series SP
Type

Temperature sensor Fe-CuNi PT100 2 wire Fe-CuNi

Temperature controller external

Probe tube length L1 max. 1 m

Sample temperature max. depending on the temperature class (see table temperature classes). Please specify with order.

Operating temperature max. depending on the temperature class (see table temperature classes). Please specify with order.

Pre-filter optional optional V20-2/30 insiti filter

Sample gas inlet connection G3/4"i DIN ISO 228/1 pre-filter with G1 1/2"i DIN

Dust loading max. 2 g/m

Probe tube volume 380 ml/m 420 ml

Sample pressure max. 5 bar g

Storage temperature -30 °C to +70 °C

Ready for operation 2 h

Power supply 230V 50/60Hz or 115V 50/60Hz

Heating capacity 0,6m: 600W, 1m: 800W (other length/capacities on request)

Electrical connections terminals, max. 4 mm2, 2x PG13,5 cable gland, terminal range 6-12mm

Electrical standard EN 61010, EN60519-1

Degree of protection IP54 EN 60529

Ex-marking

Ambient temperature connection box of the heated sample tube: -20 to +70°C

Mounting flange DN65 PN6, Form B with 4 welded screws on both sides M 12x 40 mm

Material of parts in contact with the sample stainless steel 1.4539 1.4539, SS316Ti/SS316

2.16
