Page 1
The McMillen Auger Drives by Paladin,
feature a wide variety of auger diameters,
lengths and style for every digging application.
Comes with various mounts available for most
applications.
• 5 to 60 GPM available
• Extensions available for deeper digging
• Augers available up to 48” diameter
• Planetary reduction auger drives
• 2 speed auger drives available
• 1 to 2 year warranty, additional 1 year planetary
warranty on select drives
• Fully welded flighting for added auger strength
AUGERS
For Skid-Steer Loaders, Compact Tractors, Mini Compact
Loaders, Excavators, Mini Excavators, Tractor Loader Backhoes
and Telehandlers
Page 2
75 Series - X975, X1475, X1975, X2475 & X3575
Output speed and torque specifications are based on theoretical values and are provided for comparative purposes only.
Specifications and design are subject to change without notice and without liability, therefore, whenever applicable specifications are in accordance with SAE standards.
Specifications X975
Maximum auger diameter 24" 610 mm
Minimum hydraulic flow 6 GPM 30 LPM
Maximum hydraulic flow 15 GPM 57 LPM
Max. Continuous Operating PSI 3000 PSI 207 bar
Output shaft options
2 9/16” round,
and 2” hex
65 mm,
51 mm
Output Speed
Flow Speed
6 GPM 23 LPM 36 RPM
8 GPM 30 LPM 47 RPM
10 GPM 38 LPM 60 RPM
12 GPM 45 LPM 71 RPM
15 GPM 57 LPM 89 RPM
Output Torque
Pressure Torque
2000 PSI 141 BAR 1000 lb. ft. 1356 N. m.
2500 PSI 176 BAR 1277 lb. ft. 1731 N. m.
3000 PSI 211 BAR 1500 lb. ft. 2034 N. m.
Specifications X1475
Maximum auger diameter 30" 762 mm
Minimum hydraulic flow 10 GPM 38 LPM
Maximum hydraulic flow 25 GPM 95 LPM
Max. Continuous Operating PSI 3000 PSI 207 bar
Output shaft options
2 9/16” round,
and 2” hex
65 mm,
51 mm
Output Speed
Flow Speed
10 GPM 38 LPM 38 RPM
12 GPM 45 LPM 45 RPM
14 GPM 53 LPM 53 RPM
15 GPM 61 LPM 60 RPM
20 GPM 76 LPM 75 RPM
25 GPM 95 LPM 94 RPM
Output Torque
Pressure Torque
2000 PSI 138 BAR 1600 lb. ft. 2169 N. m.
2500 PSI 172 BAR 2000 lb. ft. 2712 N. m.
3000 PSI 207 BAR 2377 lb. ft. 3223 N. m.
2 Year Comprehensive Warranty • The 75 Series Offers a 5 Year "No Hassle" Planetary Gearbox Warranty
All 75 Series hydraulic motor drives the auger through a sealed planetary gear reduction. The heavy duty all
gear design gives these units a long life with minimal maintenance and service costs. 75 Series drive units
are completely sealed with all moving components running in oil for total lubrication on a constant basis. All
models feature reverse rotation for quick backout when obstructions are encountered. The systems’ hydraulic
relief valve protects the units from damage when the auger hits large immovable objects.
AUGERS
Page 3
www.paladinattachments.com
Specifications X1975
Maximum auger diameter 36" 914 mm
Minimum hydraulic flow 15 GPM 57 LPM
Maximum hydraulic flow 30 GPM 114 LPM
Max. Continuous Operating PSI 3000 PSI 207 bar
Output shaft options
2 9/16” round,
and 2” hex
65 mm,
51 mm
Output Speed
Flow Speed
15 GPM 57 LPM 49 RPM
18 GPM 68 LPM 58 RPM
20 GPM 76 LPM 65 RPM
24 GPM 91 LPM 78 RPM
28 GPM 106 LPM 90 RPM
30 GPM 114 LPM 97 RPM
Output Torque
Pressure Torque
2000 PSI 138 BAR 1856 lb. ft. 2516 N. m.
2500 PSI 172 BAR 2328 lb. ft. 3156 N. m.
3000 PSI 207 BAR 2769 lb. ft. 3754 N. m.
Specifications X2475
Maximum auger diameter 36" 914 mm
Minimum hydraulic flow 20 GPM 76 LPM
Maximum hydraulic flow 35 GPM 132 LPM
Max. Continuous Operating PSI 3000 PSI 207 bar
Output shaft options
2 9/16” round,
and 2” hex
65 mm,
51 mm
Output Speed
Flow Speed
20 GPM 76 LPM 52 RPM
22 GPM 83 LPM 57 RPM
24 GPM 91 LPM 63 RPM
26 GPM 98 LPM 68 RPM
28 GPM 106 LPM 78 RPM
30 GPM 114 LPM 68 RPM
35 GPM 132 LPM 73 RPM
Output Torque
Pressure Torque
2000 PSI 138 BAR 2308 lb. ft. 3129 N. m.
2500 PSI 172 BAR 2895 lb. ft. 3925 N. m.
3000 PSI 207 BAR 3451 lb. ft. 4686 N. m.
Specifications X3575
Maximum auger diameter 48" 914 mm
Minimum hydraulic flow 24 GPM 76 LPM
Maximum hydraulic flow 30 GPM 114 LPM
Max. Continuous Operating PSI
2500 PSI 172 bar
Output shaft options 2” hex 51 mm
Output Speed
Flow Speed
24 GPM 91 LPM 45 RPM
27 GPM 102 LPM 50 RPM
30 GPM 114 LPM 78 RPM
Output Torque
Pressure Torque
2500 PSI 172 BAR 3566 lb. ft. 4834 N. m.
3000 PSI 207 BAR 4279 lb. ft. 5801 N. m.
Subject to change without notice.
Output speed and torque specifications are based on theoretical values and are provided for comparative purposes only.
