S MANUAL
USER
GUITAR EFFECT MACHINE
Spesification
Frequency range: 400Hz-2.5KHz
Maximum of output voltage:1.5V frequency of reference
Power supply: 9V
Dimension: 280 x 125 x 90 mm
Net Weight: 1.8kg
Operation instructions
By rocking your foot back and forth on the pedal, you can
the effect that the guitar effect machine has on
instrument instantaneously. Toe down will
When placing the pedal in one position, you will hear a
frequency. This boost can be used
feedback of a desired overtone.
Guitar effect machine set-up instructions
Insert a 9 volt battery and / or plug in AC Adapter. The
operate on either power source.
Run a cord from your instrument to the effect machine input
Run anther cord from your amplifier input into the effect
jack.
point: 1000Hz
change
the tone of your
give you more treble, heel
down will give you more bass. The speed and amount of effect you
use depends on your style of playing.
boost in that
particular to add sustain and create
effect machine
will
jack.
machine output
To turn the pedal on, push the toe of the pedal down again, until you
feel another click .
P.
C
.B
OAR
D
B
ATT
E
R
Y
Power Amplifier
Guitar Effect Machine
Electric Guitar
Notice
This unit is shipped from the factory possible without a battery to prevent
damage from leakage. A 9-volt transistor radio battery must be installed
for operation if an AC adapter is not going to be used. We recommend
a high quality alkaline battery. The adapter jack requires a 5.5/2.1mm
coax plug. Most standard 9VDC AC adapters with greater than 20ma
current capability will work.
