McIntosh HR071, HR072, HR073 Programming Manual

McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 www.mcintoshlabs.com
HR070 Series
Remote Control
Programming Guide
2
Use only fresh batteries of the required size and recommended type. When the battery voltage is low, the Push-button will blink 5 times after another Push-button on the Remote Control is pressed. Do not mix old and new batteries, different types of batteries (standard, alkaline, or rechargeable), or rechargeable batteries of different capacities.
If the Remote Control will not be used for an extended period, remove the batteries. They can leak chemicals and destroy the Remote Control.
When discarding the Remote Control, comply with local rules or regulations. Bat­teries should never be thrown away or incin­erated but disposed of in accordance with the local regulations concerning battery disposal.
For additional information please visit the McIn­tosh Web Site at www.mcintoshlabs.com.
Introduction
The McIntosh HR070 Series Remote Controls (HR070, HR071, HR072 and HR073) supplied with McIntosh Preamplifiers, Integrated Amplifiers, A/V Control Centers, and Source Components not only control a McIntosh Component System, but also have the ability of controlling non McIntosh Components in your system. Refer to figures 1 through 4
The HR70 Series Remote Controls have stored in permanent memory the necessary information to send the correct commands to the component to be controlled. By entering a five digit numeric code the commands for controlling the component is activated.
1. Open the battery compartment cover (located on the back of the remote).
2. Place the AA batteries in the compartment and match the + and - polarity symbols inside.
3. Replace the cover.
Battery Information
Installing Batteries
Figu re 1
AA
AA
AA
AA
Push Up and Lift Out to Remove Battery Cover
3
Copyright 2011 © by McIntosh Laboratory, Inc.
Table of Contents
Introduction ................................................................ 2
Battery Information ................................................... 2
Installing Batteries ..................................................... 2
HR070 Remote Control, figure 1 ............................... 2
HR071 Remote Control, figure 2 ............................... 3
HR072 Remote Control, figure 3 ............................... 3
HR073 Remote Control, figure 4 ............................... 3
Table of Contents .......................................................3
Programming a Component ....................................... 4
Searching for Code .................................................... 4
Verify Programmed Codes ........................................ 5
Diagnostic Assistance ................................................ 5
Component Control Codes ....................................6 -22
Figu re 2 Figu re 3 Figu re 4
4
Program this Remote Control by first find the codes for the components you want to program (starting on page 7) and then follow the steps below:
1. Turn on the component (in this example, the TV).
2. Press TV Push-button on the Remote Control to be programmed. Refer to figure 5.
3. Press and hold SET Push-button until the Push­button illuminaton blinks twice, then release.
4. Enter the first five-digit code (using the numeric push-buttons) for the component (TV) and brand that you wish to program. The Push-button blinks once as each digit is entered. If the code is valid, the Push-button blinks twice.
Note: If the Push-button does not blink twice, repeat
steps 2 to 4 and tr y entering the code again.
5. Aim the McIntosh Remote Control at the compo­nent and press Power Off. The TV should turn Off. If it does not, repeat steps 3–5, trying each code for your brand until you find one that works. If you cannot find a working TV code refer to “Searching Codes” on this page.
Note: There might be more than one Program Code
Number capable of switching power Off to the TV. Choose the Code Number with the great­est number of desired active commands for the TV to be controlled.
6. Repeat steps 1 to 5 for the other components you want to control. For future reference, write down each working component code below:
HR Series Remote Control Programming
Assigned Push-button Component Program Code
TV CBL SAT AUX DVR
Programming a Component
If your component (TV in the Programming a Compo­nent example) does not respond to the Remote Control after trying all codes listed for your (TV) brand, or if your TV brand is not listed, try searching for your code:
1. Switch On the TV you wish to control.
2. Press the TV Push-button on the Remote Control once.
3. Press and hold SET Push-button until the Push­button illuminaton blinks twice, then release.
4. Enter 9 9 1, then the component group number (see below). The Push-button blinks twice.
Code Number Component Group
0 Cable (Cable Converter, Video Accessories,
Satellite Receivers)
1 TV
2 VCR (VCRs, DVD Players)
3 Audio (Audio Ampliers, Audio Amp
/Tuners, CD Players)
5. Aim the Remote Control at the TV and press Power Off. The Remote Control sends IR Codes from its library to the selected TV, starting with the most popular code first. If the component responds, go to step 7.
6. If the component does not respond, press LEVEL+ Push-button and the Remote Control will test the next code for that TV type. Continue to press LEVEL+ Push-button until the TV switches Off.
Note: Press LEVEL- Push Button to try the previ­ous code.
7. Now that you have found the correct code, press SET to save the code that worked for the TV. The
Push-button will blink twice to indicate the
code has been saved. To search for other compo­nent codes, repeat steps 1 to 5.
Searching for Code
Used to activate Programming Mode
Component Push-buttons
Flashes during Programming
Figu re 5
Push-buttons used to enter Program Code
Component Push-buttons
5
Verify Programmed Codes
At any time, an already entered code to operate a specific component can be verified. For example, to find out which code is assigned to your TV perform the following steps:
1. Press TV once.
2. Press and hold SETUP Push-button until the Push-button blinks twice, then release.
3. Enter 9 9 0. The Push-button blinks twice.
4. To view the first digit of the stored code press 1. Count the light blinks (for example, three blinks =
3), and write down the number.
Note: If a code digit is 0, the Push-button does not blink.
5. Repeat step 4 for the four remaining digits, using 2 for the second digit, 3 for the third digit, 4 for the fourth digit, and 5 for the fifth digit.
6. To check for other component, repeat steps 1—5, substituting the component push-button you would like to check.
Programming the Remote Control
Diagnostic Assistance
Difculty Suggested Remedy
does not blink when you press a Push-button
Try pressing other push­buttons; replace the bat­teries
blinks when you press a key, but device does not respond
Make sure the remote control is aimed at your component and is not more than 40 feet away
blinks one long blink while in SETUP mode
An entry error has occurred (for example, pressing the wrong push-button); try entering the sequence again
Difculty Suggested Remedy
Remote Control does not control component or commands are not working­properly
Try all listed codes for the component; make sure the component operates with the original remote control
CH+, CH-, and LAST do not work for your RCA TV
Due to design of RCA TVs from 1983 to 1987, only the original TV Remote Control will operate these functions
Channels do not change properly when directly entering digits to change channels
If the original remote con­trol required you to press Enter to change channels, press SELECT on the McIntosh Remote Control after entering the channel number
Restoring Default Settings
In the unlikely event the Remote Control no longer controls McIntosh Components (the default McIntosh Command Codes were accidentally deleted) follow the steps below to restore them:
1. Press Push-button on the Remote Control to be restored to default Command Codes. Refer to figu re 5.
2. Press and hold SET Push-button until the Push­button illumination blinks twice, then release.
3. Enter the five-digit code (using the numeric push­buttons) for the version of the McIntosh Remote Control (model number is located near the bottom of the remote control)
Note: If the McIntosh Component the Remote
Control came with was changed (in the Setup Mode) to respond to the “Alternate Control Codes” then enter the Alternate Control Code
five digit number instead of the Normal Con­trol Code Number.
HR Series Remote Control Programming
Remote Control Model Number
Normal or Alternate Code
Code Number
HR070 or HR071 Normal 32428
HR070 or HR071 Alternate 32429
HR072 Normal 32436
HR072 Alternate 32437
HR073 Normal 32431
The Push-button blinks once as each digit is entered. If the code is valid, the Push-button blinks twice.
Note: If the Push-button does not blink twice, repeat
steps 2 to 4 and tr y entering the code again.
4. Aim the Remote Control at the McIntosh Compo­nent and verify normal operation using the remote control.
6
Amplifier
Adcom ......................................................3 057 7, 3110 0
Bose .................................................................... 30674
Car ver ................................................................ 30892
Curtis Mathes ..................................................... 30300
Durabrand ...........................................................31561
Elan .................................................................... 30647
GE ...................................................................... 30078
Harman/Kardon ................................................. 30892
JVC......................................................................30 331
Left Coast ........................................................... 30892
Lenoxx ................................................................ 31561
Marantz .............................................................. 30892
McIntosh ............................................................ 30251
Modulaire ........................................................... 30395
NEC ................................................................... 30264
Optimus ........................... 30395, 30013, 30300, 30823
Parasound ........................................................... 30246
Philips ................................................................ 30892
Pioneer ........................................30013, 30300, 30823
Polk Audio ......................................................... 30892
RadioShack ........................................................ 30395
RCA ............................................. 30013, 30300, 30823
Realistic...................................................30395, 30013
Shure .................................................................. 30264
Sony ........................................................ 30689, 30815
Soundesign ......................................................... 30 078
Victor ..................................................................30 331
Ward s ......................................................30078, 30013
Ya m a h a ...................................................30354, 30133
Cable Set Top Box
A-Mark ................................................... 00008, 00144
ABC .................... 00237, 00003, 00008, 00014, 00017
Accuphase ...................................00003, 00014, 00017
Acorn ................................................................. 00237
Action ................................................................. 00237
Active ................................................................. 00237
Americast ........................................................... 00899
Amino .................................................................01822
Archer ................................................................ 00237
BCC .................................................................... 00276
Bell & Howell .................................................... 00014
Bell South ........................................................... 00899
British Telecom .................................................. 00003
Century .............................................................. 00008
Citation ............................................................... 00017
Clearmaster ........................................................ 00883
ClearMax............................................................ 00883
Cool Box ............................................................ 00883
Coolmax ............................................................. 00883
Digeo ................................................................... 01187
Digi .................................................................... 00637
Director .............................................................. 00476
Dumont .............................................................. 00637
DX Antenna ....................................................... 0150 0
Emerson ............................................................. 00014
Fosgate ............................................................... 00276
Fujitsu .................................................................. 014 97
GE ...................................................................... 0 014 4
General Instrument ..................... 00476, 00810, 00276
.....................................................00003, 00012, 00014
Gibralter ............................................................. 00003
GMI .................................................................... 00883
GoldStar ............................................................. 0 014 4
Hamlin ................................................... 00009, 00273
Hitachi ..........................................0003, 00008, 00009
Insight .....................................................00476, 00810
Jebsee ................................................................. 00014
Jerrold ..... 00476, 00810, 00276, 00003, 00012, 00014
Maspro ................................................................ 01510
Memorex ............................................................ 00000
Mitsubishi .......................................................... 00003
Motorola ...........................01376, 00476, 00810, 00276
...........................................01187, 01254, 0 0 014, 01106
Multitech ............................................................ 00883
Myrio ..................................................................018 22
NEC ....................................................................01496
Nova Vision ........................................................ 00008
Novaplex ................................................ 00008, 00017
NSC ........................................................ 00012, 00637
Oak ..................................................................... 00017
Pace ..................................01877, 00877, 00237, 00008
Panasonic ............ 00000, 00008, 00144, 00107, 01488
Panther ............................................................... 00637
Paragon ......................................00000, 00008, 00525
Penney ...................................................... 0000, 00637
Philips ..................................................... 013 05, 0 0317
Pioneer ..................01877, 00877, 00144, 00533, 01500
Prism .................................................................. 00012
Pulsar .................................................................00000
Quasar ................................................................00000
RadioShack ........................................................ 00883
RCA .....................................................................012 56
Regal ...........................................00276, 00279, 00273
Runco ................................................................. 00000
Samsung ................................................. 00003, 00144
Scientific Atlanta .............0187 7, 00877, 00477, 0 0237
........................................00003, 00000, 00008, 00012
..................................................................00017, 01510
Sony ........................................................ 01006, 01460
Sprucer ............................................................... 0 014 4
Starcom .................................................. 00003, 00014
Stargate .............................................................. 00014
Storm .................................................................. 00637
Sumitomo ........................................................... 0150 0
Supercable .......................................................... 0 0276
Supermax ........................................................... 00883
Thomson .............................................................01256
Tocom ................................................................. 00012
Torx .................................................................... 00003
7
Component Control Codes
Cable Set Top Box, con’t
Toshiba ................................................... 00000, 01509
Tri st a r ................................................................. 00883
United Cable ...............................00276, 00003, 00014
US Electronics ............... 00276, 00003, 00008, 00017
V2 ....................................................................... 0 0883
Videoway ...........................................................00000
Viewmaster ........................................................ 00883
Vision ................................................................. 00883
Vortex View ....................................................... 00883
Zenith .............................. 00000, 00525, 00899, 00017
Cable/PVR Combination
Americast ........................................................... 00899
Amino .................................................................01822
Digeo ................................................................... 01187
General Instrument ............................................ 00 810
Jerrold ................................................................ 0 0810
Motorola ............................ 01376 , 00 810, 01187, 01106
Myrio ..................................................................018 22
Pace ......................................................... 01877, 0 0 237
Pioneer .................................................... 01877, 00877
RCA .....................................................................012 56
Scientific Atlanta .................................... 01877, 00877
Sony ................................................................... 010 06
Supercable .......................................................... 0 0276
Thomson .............................................................01256
Zenith ................................................................. 00899
CD Player
Acoustic Research .............................................. 30420
Admi ral .............................................................. 30305
Aiwa .................................................................... 30157
Arcam .................................................................30157
Audio Research ...................................................30157
Burmester ........................................................... 30420
Cairn ...................................................................30157
California Audio Labs ............................30029, 30303
Cambridge Soundworks ...................................... 30157
Car ver ......................................................30157, 30179
Curtis Mathes ..................................................... 30032
Denon ......................................... 30626, 30003, 30034
DKK ................................................................... 30000
DMX Electronics ................................................30157
Emerson ............................................................. 30305
Fisher ....................................................... 30000, 30179
Funai .................................................................. 30305
Garrard ....................................................30393, 30420
Genexxa ................................................. 30032, 30305
Grundig ...............................................................30157
Hafler .................................................................. 3017 3
Harman/Kardon ........................... 30100, 30157, 30173
Hitachi ................................................................ 30 032
Inkel .........................................................30157, 30180
Integra ................................................................. 30101
Jerrold ................................................................ 30003
JVC......................................................... 30032, 30072
Kenwood . 30626, 30000, 30029, 30028, 30037, 30190
KLH ................................... 31318, 313 72, 31373, 31711
Krell ....................................................................30157
Linn .....................................................................30157
LXI .......................................................... 30179, 30305
Magnavox ......................... 30157, 30038, 30274, 30305
Marantz .....30626, 30029, 30157, 30038, 30180, 30435
Matsui .................................................................30157
McIntosh .....................................30256, 30290, 30660
MCS ................................................................... 30029
Memorex ............. 30000, 30032, 30179, 30420, 30468
Micromega ..........................................................30157
Miro ................................................................... 30000
Mission ................................................................30157
Modulaire ........................ 30000, 30032, 30087, 30179
.....................................................30180, 30420, 30468
MTC ................................................................... 30420
NSM ....................................................................30157
Onkyo ...................................................... 31327, 30101
Optimus ...........................30000, 30032, 30037, 30087
..............................30179, 30305, 30393, 30420, 30468
Panasonic ........................ 30029, 30303, 30388, 30752
Parasound ........................................................... 30420
Penney ................................................................ 30029
Philips ..........................................30626, 30157, 30274
Pioneer ................. 31062, 30032, 31087, 30305, 30468
Polk Audio ..........................................................30157
Proceed............................................................... 30420
Proton .................................................................. 30157
QED ....................................................................30157
Quad ....................................................................30157
Quasar ................................................................ 30029
RadioShack 30000, 30032, 30179, 30180, 30420, 30468 RCA 31062, 30032, 30053, 30179, 30305, 30420, 30468
Realistic........................... 30000, 30032, 30087, 30179
.......................................... 30180,30305, 30420, 30468
Revox ..................................................................30157
Roksan ............................................................... 30435
Rotel ........................................................ 30157, 30420
SAE ..................................................................... 30157
Sansui .......................................... 30000, 30157, 30305
Sanyo ...........................................30000, 30087, 30179
Scott ................................................................... 30305
Sears ........................................................ 30179, 30305
Sharp ........................................... 30037, 30034, 30180
Sherwood ............................................................3018 0
Sonic Frontiers ....................................................30157
Sony .....................30490, 30000, 30100, 31364, 30185
Sugden .................................................................30157
Sylvania ............................................................... 30157
Symphonic ..............................................30180, 30305
TAG McLaren ..................................................... 30157
Tand y .................................................................. 30032
Tasc a m ....................................................30393, 30420
Loading...
+ 15 hidden pages
