MBT Lighting ST7500DMX User Manual

Professional Lighting Technology

DMX Strobe

ST7500DMX

User Guide

Please read these instructions carefully before use

1B

TABLE OF CONTENTS

1. Introduction

2. Safety Precaution

3. Technical Specifications

4. General Functions

5. How To Change The Lamp

6. How To Control the Unit

A. By Master/Slave Built In Preprogrammed Function

B. By Easy Controller

C. By universal DMX Controller

7. DMX512 Configuration

8. DMX512 Connection

9. Troubleshooting

10. Fixture Cleaning

2B

1. Introduction

Congratulations on the purchase of your new strobe light. We are confident you will

enjoy many trouble free hours with this unit. To assist with the care and use of the

product we have prepared this short guide.

2. Safety Precaution

• Avoid direct eye exposure.

• Disconnect from mains power before replacing lamp or servicing.

• Always replace the lamp with same type.

• To prevent fire or shock hazard, do not expose this unit to rain or

moisture.

• Do not use this product continuously longer than 15 minutes under

maximum speed and dimmer.

The following points are important for safety as well as for the smooth installation

and performance of the unit.

• Unpack carefully and be sure that no damage has occurred during transportation.

• It is very important to ground the yellow/green conductor in order to meet safety

regulations.

• Do not connect the device to any dimmer pack.

• The electrical work that is necessary for installation must be done by qualified

personnel.

• Be sure to locate the unit in a place with adequate ventilation at least 15 cm from

the walls. Be sure that no ventilation slots are blocked.

• Be careful that no liquids or other objects can enter into the unit. If this ever

happens, disconnect the main power immediately.

• In the event of serious operating problems, turn off the power immediately. Never

try to repair the unit by yourself. Repairs carried out by non-qualified personnel

can lead to serious damage or malfunction. Please contact your dealer for

technical assistance. Always use genuine spare parts.

• Always remember to unplug the unit from the mains power before any service is

done.
