PARDL24PRO
User Manual
Please read this user manual before using this product.
Features
Voltage: AC100-240V 50/60Hz
Power: 80W
24pcs*3W high power LEDs
6 DMX channels
1. Digital display
1. MENU (display ADDR): A001-A512
2. CHND (choose channel): 3CH/6CH
3. SLND (master/slave): M/NAST is master, SLAV is slave
4. SHND (choose effect):
A. SOUN (sound control), press DOWN to confirm
B. COLO (COL1,COL2…COL7, AUTO)
C. FADE (speed SP01-SP08)
5. MANU (get three colors):
RED (0-255)
GREEN (0-255)
BLUE (0-255)
6, FHRS: (using time of light)
2,DMX operation
3CH mode:
0
Black-out
CH1
1-255
Red
0
Black-out
CH2
1-255
Green
0
Black-out
CH3
1-255
Blue
6CH Mode:
0
Black-out
CH1
1-255
Red
0
Black-out
CH2
1-255
Green
0
Black-out
CH3
1-255
Blue
CH4
0-15
Black-out
16-255
Color mixation auto run(slow to fast)
0-127
Black-out
CH5
128-255
Strobe speed
0-31
Black-out
CH6
32-255
Brightness(dark to bright)
Safety instruction
This device has left our premises in absolutely perfect condition.
In order to maintain this condition and to ensure a safe operation,
it is absolutely necessary for the user to follow the safety
instructions and warning notes written in this manual.
Please note: information is subject to change without prior
notice.
CAUTION!
Be careful with your operations. With a dangerous voltage you can
suffer a dangerous electric shock when touching the wires！
Electric shock when touching the wires!
