MBO 921 Instruction Manual

© by 4MBO International Electronic AG, Germany

MBO DVD-PLAYER 921

BEDIENUNGSANLEITUNG

INSTRUCTION MANUAL

MODE D’EMPLOI

GEBRUIKSAANWIJZING

ISTRUZIONI PER L’USO

MANUAL DE INSTRUCCIONES

MANUAL DE INSTRUÇÕES

DVD-CD-Abspielgerät

1

CONTENTS

CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

INTRODUCTION

Dear Customer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Attention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Disc Formats Supported by this Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

IMPORTANT SAFETY INSTRUCTION

Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Region Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Safety Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5

Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Power Cord Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Nonuse Periods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

No Fingers or other Objects Inside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Keep away from Water/Magnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Condensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

If there is Noise Interference on the TV while a Broadcast is being reveived . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

DESCRIPTION OF THE DEVICE

Front of the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Rear of the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

REMOTE CONTROL

Description of Key Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Preparing the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

CONNECTIONS

Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11

Connecting to Amplifier with Dolby Digital/DTS Decoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12

REPRODUCTION

Selecting the Type of Disc for the Type of TV Connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting to the Multi-System TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting to the NTSC TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2

Connecting to the PAL TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 3

DVD PLayback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Basic Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Stopping Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

After Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-14

Rapid Advance (Rapid Reverse) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Skipping Ahead or Back to Chapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Still Picture (Pause) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Frame Advance (Step) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 4

Slow-Motion Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 4

DIRECT SELECTION OF SCENES

Selecting Scenes by Title Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Selecting Scenes by Chapter Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 5

Selecting Scenes by Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

REPEAT PLAY

Repeat Viewing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 5

Repeating Sections between two Specific Points (A-B Repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Displaying the Information of the Scene to be Viewed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 6

CONVENIENT FUNCTIONS

Displaying the Scene with a Larger and Closer View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Changing Audio Soundtrack Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Clearing/Displaying of Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 6

Changing Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

Viewing from another Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 7

Using a DVD Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Using the Menu Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 7

Switching to another TV System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2

CONTENTS

Turning Off the Volume of the DVD Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

VIDEO CD PLAYBACK

Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Basic Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Menu Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 8

Playback control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

After Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Stopping Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Rapid Advance (Rapid Reverse) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Skipping Ahead or Back to Tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 9

Still Picture (Pause) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Frame Advance (Step) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 0

Slow-Motion Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 0

Informaton (Video CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

REPEAT PLAY

Repeat Viewing (Listening) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 0

Repeating Sections between two Specific Points (A-B Repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

AUDIO CD PLAYBACK

Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1

Basic Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Information (Audio CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Stopping Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Rapid Advance (Rapid Reverse) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Skipping Ahead or Back to Tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1

Still Picture (Pause) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Programming Audio CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2

To clear the ordering Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

INITIAL SETTINGS

Changing the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Rating Level Setting (DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2- 23

Disc Menu Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Audio Soundtrack Language Selection (DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 3

Subtitle Language Selection (DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 3- 24

TV D isplay Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 4-25

TV System Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 5

Video Output Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Audio Output Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 5

On Screen Display (OSD) Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 6

Screen Saver Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Viewing from another Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 6

GENERAL

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28

Handling Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 8

If the Surface is soiled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 8

Moisture on the Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 9

Improper Disc Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Disc which cannot be Played with this Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

DEFINITION OF TERMS

Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Chapter Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 9

Playback control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 9

Time Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Title Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Track Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Video CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 0

3

INTRODUCTION

FEATURES

we congratulate to your new DVD-Player and we are glad you have decided for the player
from 4MBO. The product you have bought is state of the art, of highest quality and has many
advanced features.

Please read the operation manual in order to familiarise yourself with all the possibilities of your
DVD-Player. Follow the instructions in order to ensure reliable operation and a long service life of
the appliance.

Duplication, transmission, copying, storing on electronic media and translations into foreign
languages in any form whatsoever, using any media whatsoever and the distribution of the
document or parts thereof is forbidden without the express written permission of 4MBO
International Electronic AG.

The operating instructions are there to provide information. Their contents are not the subject of
a contract. All of the data stated are merely nominal values.

Subject to technical modifications.
Closing date: 02/2002

The lightening flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated « dangerous voltage » within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying the
appliance.

DVD: a completely new dimension in video entertainment

• Subtitles may be displayed in one of a maximum of 32 languages*

• The audio soundtrack can be heard in up to “n” languages*

• The multi-angle function allows you to choose the viewing angle of scenes which were shot
from a number of different angles.
(Limited to DVD discs recorded with multiple camera angles.)

* The number of the languages recorded is dependent on the DVD disc used.

Support MP3 & DTS playback

High quality digital audio

•

With the linear PCM sound of a 48 kHz/16 bit through 96 kHz/24 bit, audio quality exceeding
that of audio CD becomes possible.

Many convenient features

• Direct access of favorite scenes (title/chapter/time/track search)

• Parental lock settings to prevent play of disc unsuitable for some audiences [DVD only]

Compatible with PAL DVD disc (video CD) and NTSC DVD disc (video CD)

• This DVD player can play disc in either PAL or NTSC system. However, the DVD player must be
connected to a multi-system TV to play both PAL DVD disc (video CD) and NTSC DVD disc
(video CD). The use of a multi-system TV is recommended.

Compatible with video CD and audio CD as well as DVD

DEAR CUSTOMER

ATTENTION

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE REAR COVER
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL

CAUTION

RISK OF ELECTRIC

SHOCK, DO NOT OPEN

4

INTRODUCTION / IMPORTANT SAFETY INSTRUCTION

The unit can play back discs bearing any of the following marks:

1. DVD 5. Audio CD

2. Video CD 6. CD-R

3. SVCD 7. CD-RW

4. DVCD 8. MP3-CD

This unit employs a laser. Due to possible eye injury, only qualified service personnel should re­move the cover or attempt to service this device. Use of controls or adjustments or performance
of procedures other than those specified herein may result in hazardous radiation exposure.

VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.

This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful inter­ference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for Help.

Since it is usual for DVD movies to be released at different times in different regions of the world,
all players have region codes and disc can have an optional region code. If you load a disc of a
different region code to your player, you will see the region code notice on the screen. The disc
will not play, and should be unloaded.

There are 6 regions (also called “locales”).
Each DVD player and disc will be played in one region ONLY.

1: Canada, U.S., U.S. Territories

2: Japan, Europe, South Africa, Middle East (including Egypt)

3: Southeast Asia, East Asia (including Hong Kong)

4: Australia, New Zealand, Pacific Islands, Central America, Mexico, South America, Caribbean

5: Former Soviet Union, Indian Subcontinent, Africa (also North Korea, Mongolia)

6: China

1. Read these instructions.

2. Keep these instructions.

3. Head all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water. Water must not be allowed to drip or spray onto the

player. Do not place items containing liquid on the player.

6. Clean only with a damp cloth.

7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-

ratus including amplifiers) that produce heat.

9. Protect the power cord from being walked on or pinched particularly at plug, convenience

receptacles, and the point where they exit from the apparatus.

DISC FORMATS
SUPPORTED BY THIS PLAYER

CLASS I

LASER PRODUCT

CAUTION

REGION CODES

Manufactured under licence of Dolby
Laboratories.
"Dolby”, "AC-3” and the double-D symbol are
trademarks belonging to Dolby Laboratories.
Confidential, unpublished document.
©1992-1997 Dolby Laboratories.
All rights reserved.

WARNING LOCATION:
INSIDE ON LASER COVERSHIELD.

NOTE

1

2

3

4

5

6

SAFETY INSTRUCTION

5

IMPORTANT SAFETY INSTRUCTION

IMPORTANT
SAFETY
PRECAUTIONS

POWER CORD
PROTECTION

PLACEMENT

NONUSE PERIODS

NO FINGERS OR OTHER
OBJECTS INSIDE

KEEP AWAY FROM
WATER/MAGNET

10. Only use attachments/accessories specified by the manufacturer.

11. Unplug this apparatus during lighting storms or when unused for long periods of time.

12. Never make or change connections with the power switched on.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way; such as when the power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

Please read and observe all warnings and instructions carefully given in this instruction manual
before operating the DVD Player. This set has been designed and manufactured to assure perso­nal safety. Improper use can result in electric shock or fire hazard!

To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal
injury, please observe the following:

• Hold the plug firmly when connecting or disconnecting the AC power cord.

• Keep the AC power cord away from heating appliances.

• Never put any heavy object on the AC power cord.

• Do not attempt to repair or reconstruct the AC power cord in any way.

Avoid placing the unit in areas of:

• direct sunlight or heating radiators, or closed automobiles

• high temperature (over 35° C) or high humidity (over 90%)

• much dust as the internal parts may be seriously damaged

• When the unit is not being used, turn it off.

• When left unused for a long period of time, the unit should be unplugged from the house-

hold AC outlet.

• Touching internal parts of this unit is dangerous, and may cause serious damage to the unit.

Do not attempt to disassemble the unit.

• Do not put any foreign object on the disc tray.

• Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit,

serious damage could occur.

• Never bring a magnet or magnetized object near the unit.

• Place the unit in a horizontal position, and do not place anything heavy on it.

Moisture may form on the lens in the following conditions:

• immediately after a heater has been turned on

• in a steamy or very humid room

• when the unit is suddenly moved from a cold environment to a warm one

If moisture forms inside this unit, it may not operate properly. In this case, turn on the power and
wait about one hour for the moisture to evaporate.

Depending on the reception condition of the TV, interference may appear on the TV monitor
while you watch a TV broadcast and the unit is left on. This is not a malfunction of the unit or
the TV. To watch TV broadcast, turn off the unit. DVD’s and Video CD’s contain recordings in
both PAL and NTSC format. Use the menu to select the CD/DVD that suits the television you have
connected.

CONDENSATION

IF THERE IS NOISE
INTERFERENCE ON THE TV
WHILE A BROADCAST IS
BEING RECEIVED

STACKING

6

DESCRIPTION OF THE DEVICE

STOP

PAUSE / STEPPLAYEJECT

PHONES LEVEL

DVD / VCD / CD PLAYER

PHONESPOWER

PREV. NEXT

Mp3

DOLBY

DIGITAL

DIGITAL OUT

VIDEO

+–

WARNING

DO NOT OPEN

RISK OF ELECTRIC SHOCK

AUDIO OUT VIDEO OUT

Front RearCoaxialOptical

Center Woofer

B/U

G/Y

R/V

Video S-Video

SCART OUT

AC IN

LL

R

FRONT OF THE DEVICE

REAR OF THE DEVICE

VIDEO

CD

ALL

MP3

VCD

DIGITAL

TOTAL

PROG

88 88

88 88 8

DISPLAY

1 2 3 4 5 6 7 8 9 10 11 12

1

POWER-Switch
2 Power Indicator-LED
3 Headphone jack

7

Eject (open/close)
8 Play
9 Pause/ Step

10 Stop
11 Previous (capter)
12 Next (capter)

4 Headphone Volume
5 Display
6 Disc Tray

1 2 3 4 5 6 7 8

1

Optical audio output (digital)
2 Coaxial audio output (digital)
3 Analog audio output

5.1 Channel (optional)

4

RBG/YUV-Channel

(video output)
5 Composite video output
6 Super VHS video output

7 Scart out, combined

audio-/video output für
european TV-sets

8

Power plug

9

1 2 3 4 5 6 7 8

14 13 12 11 10

16

15

1

Indicates DVD is inserted
2 Indicates CD is inserted
3 Indicates Disk is playing
4 Indicates repeatfunction active
5 Shows the Titlenumber
6 Shows the Capternumber

7

Indicates a program is active
8 Indicates Dolby Digital is active
9 Indicates DTS is active

10 Indicates Karaoke-mode
11 Counter

12 Indicates Pause-mode
13

Displays that Disk has different angles
14 Indicates VCD is inserted
15 Indicates MP3-CD is inserted
16 Indicates CD in use

2

7

REMOTE CONTROL

17
18

19

20

21
22
23

24

25

26

27

28

29

30

PLAY/SEL.

+

–

–

VIDEO

POWER

TV SYS.

1

4

7

2

5

8

3

6

90

SETUP EJECT

PROGRAM

CLEAR

MUTE

GOTOREPEAT

PBC

MENU

1/ALL

AB

TITLE

SUBTITLE

AUDIO

ANGLE

VOLUME

F.F W DF.B W D

STOP

KEY

ECHO

ZOOM

SURROUND

INFO.

SLOW

VOCAL

PAUSE/STEP

NEXT

PEEV.

+

REMOTE CONTROL UNIT CONTROLS

1
2

3

4
5
6

7
8

9

10

11

12

13

14
15
16

NOTE

This remote control is a new improved
model. Maybe you will find different
figures of the remote control (e.g. on
the package).

Description of key functions

1. ON / OFF (Standby)

2. TV SYS (choose your type of TV: PAL/NTSC

and Multi-System TV)

3. NUMERIC buttons

4. REPEAT (1/ALL) button (Repeat title, disc, track

or repeat off).

5. A-B button (Repeat scene A - beginning -

until B - end - or repeat off)

6. MENU

7. PBC (playback control)

8. AUDIO (change language)

9. SUBTITLE (change subtitles)

10. PREV capter

NEXT capter

11. PAUSE /STEP

12. CURSOR

13. SLOW

14. INFO

15. KEY #/

16. ZOOM

17. EJECT (open/close disk tray)

18. SETUP

19. PROGRAM

20. CLEAR

21. GOTO

22. MUTE

23. TITLE

24. VOLUME

25. ANGLE (if supported by the DVD)

26. FFWD (search forward)

FBWD (search backward)

27. STOP

28. PLAY /SEL.

29. SURROUND

30. ECHO +/-

8

REMOTE CONTROL

PREPARING THE REMOTE
CONTROL

Battery Installation

Open the battery compartment and insert two AAA-size batteries with the (+) and (-) marks
correctly aligned, as shown.
Batteries used up are special waste - please dispose properly! Do not use rechargeable (NiCd)
batteries.

Battery life

• The batteries normally last for one year or longer. Battery life may vary depending on the
conditions of use.

• If the remote control unit fails to work even when it is operated near the player, replace the
batteries.

• Use batteries of size R3/AAA/1,5V.

NOTE:

• Do not use rechargeable (NiCd) batteries.

• Do not attempt to recharge the batteries.

• Never short-circuit or apply heat to the batteries.

• Do not drop, step on or otherwise impact the remote control unit.

• Do not mix old and new batteries or different types of batteries.

• When not using the remote control for a long time, remove batteries. Otherwise the electro­lyte may leak which may damage the remote control.

• If electrolyte should come in contact with parts of your body, wash it off thoroughly with
water.

Operating range of the remote control unit

• The remote control must point at the IR-receiver on the DVD-player.

• The operating range of the infrared signal is up to 7m. The angle is supposed to be smaller
that 30° (illustration page 9).

• The operating range may also vary according to the brightness of the room.

NOTE:

• Do not point bright lights to the remote control sensor.

• Do not put any objects between player and conrol unit.

• Do not use the DVD-player remote control unit simultanously with other remote controls.

IMPORTANT:

Batteries are hazardous
waste. Do not dispose
them together with the
household garbage.

!

9

REMOTE CONTROL / CONNECTIONS

STOP

PAUSE / STEPPLAYEJECT

PHONES LEVEL

DVD / VCD / CD PLAYER

PHONESPOWER

PREV. NEXT

Mp3

DOLBY

DIGITAL

DIGITAL OUT

VIDEO

+–

PLAY/SEL.

+

–

–

VIDEO

POWER

TV SYS.

1

4

7

2

5

8

3

6

90

SETUP EJECT

PROGRAM

CLEAR

MUTE

GOTOREPEAT

PBC

MENU

1/ALL

AB

TITLE

SUBTITLE

AUDIO

ANGLE

VOLUME

F.F WDF.BW D

STOP

KEY

ECHO

ZOOM

SURROUND

INFO.

SLOW

VOCAL

PAUSE/STEP

NEXT

PEEV.

+

sensor for remote control IR-signal

CONNECTING TO A TV

• Ensure that all equipment to be connected are switched off or disconnect the AC power cords.

• Before connecting other equipment study the instructions.

• Watch the colour coding of the connecting cables.

A. Connecting to a Stereo TV

1 TV (not supplied)
2 DVD-Player
3 Audio-/videocable (not supplied)
4 S-videocable (not supplied)

5 to audio input (red, white)
6 to video input (yellow)
7 to S-video-input
8 Scartcable (supplied)
9 Power cord (supplied)

10 to AC outlet (110-240 V, 50/60 Hz)

S-video output

The S- (seperate) video output connector seperates the colour (C) and luminance (Y) signals befo­re transmitting them to the TV in order to achieve a sharper picture. Audio signals are not trans­mitted. If your TV is equipped with an S-video input, use a S-video cable (not supplied) to connect
the S-video output of the player with the S-video in jack of your TV. This will optimise your image
reproduction.

IMPORTANT!

Never make or change connections
with the power switched an.

10

CONNECTIONS

WARNING

DO NOT OPEN

RISK OF ELECTRIC SHOCK

AUDIO OUT VIDEO OUT

Front RearCoaxialOptical

Center Woofer

B/U

G/Y

R/V

Video S-Video

SCART OUT

AC IN

LL

R

I

N

O

U

T

ILL. A

556 7

1

3

2

4

10

9

8

B. Connecting to a Mono TV
1 TV (not supplied)

2 DVD-player
3 Audio-/videocable (not supplied)
4 Scartcable (supplied)

ILL. B

WARNING

DO NOT OPEN

RISK OF ELECTRIC SHOCK

AUDIO OUT VIDEO OUT

Front RearCoaxialOptical

Center Woofer

B/U

G/Y

R/V

Video S-Video

SCART OUT

AC IN

LL

R

I

N

OUT

1

3

2

4

11

CONNECTIONS

AUDIO OUT VIDEO OUT

Front RearCoaxialOptical

Center Woofer

B/U

G/Y

R/V

Video S-Video

SCART OUT

LL

R

I

N

O

U

T

1

3

2

8

7

CONNECTING TO AMPLIFIER
WITH DOLBY DIGITAL/DTS
DECODER

D. Connecting to a Dolby Digital decoder or an analog Amplifier

When the DVD is recorded in Dolby Digital/DTS, the Dolby Digital/DTS Bitstreams are transmitted
from the player´s OPTICAL and COAXIAL digital audio output connector. When the DVD-player
is connected to a Dolby Digital decoder, you can enjoy theaterquality audio right in your home.
(An optional audio cable is required when an optical Dolby Digital decoder is used.)

1 TV (not supplied)
2 DVD-player
3 Audio-/videocable (not supplied)
4 Scartcable (supplied)
5 S-videocable (not supplied)
6 Coax-digitalcable (not supplied) or
7 Optical digitalcable (LWL), not supplied or
8 Audiocable for analog output (not supplied), no decoder neccessary
9 Decoder or amplifier with Dolby Digital/DTS decoder (not supplied)

4

6

NOTE:

Remove the dust protection cap
from the optical digital output.
Mostly the plugs of the optical
digital cable have also dust
protections. Always
reattach the caps
when no using
the connector.

5

9

C. Connecting to Audio Equipment
1 Audio equipment (not supplied)

2 TV (not supplied)
3 DVD-player
4 Audio-/videocable (not supplied)
5 Scartcable (supplied)

WARNING

DO NOT OPEN

RISK OF ELECTRIC SHOCK

AUDIO OUT VIDEO OUT

Front RearCoaxialOptical

Center Woofer

B/U

G/Y

R/V

Video S-Video

SCART OUT

AC IN

LL

R

I

N

OUT

ILL. C

1

3

2

4

5

Both the DVD discs and video CDs have the material recorded in the PAL and NTSC systems. Refer
to the table below to select the correct disc type for the type of connected TV.

DISC TV Monitor

PAL Played in the PAL system.

NTSC Played in the NTSC system.

DISC TV Monitor

PAL No clear images are shown

on the screen.

NTSC Played in the NTSC system.

12

CONNECTIONS / REPRODUCTION

Concerning the digital audio output

Depending on the disc format, either Dolby Digital sound or Linear PCM sound will be outputted
from the unit´s digital audio output connector (PCM/Dolby Digital) as shown in the table below.

DiSC Sound Recording Format Digital Audio Output From Connector

DVD Dolby Digital Dolby Digital Bitstream

Linear PCM Linear PCM (96 kHz Samplingrate only)

Audio-CD Linear PCM Linear PCM (44,1 kHz Samplingrate only)

Video-CD MPEG Linear PCM (44,1 kHz Samplingrate only)

Note:

• For DVDs, sound having 96 kHz sampling cav be outputted from the unit´s digital output
connector.

Information:

• Dolby Digital is a digital sound compression technique developed by the Dolby Laboratories
Licensing Corporation. Supporting 5.1-channel surround sound, as well as stereo (2-channel)
sound, this technique enables a large quantity of sound data to be efficienly recorded on a disc.

• Linear PCM is a signal recording format used in audio CDs. While audio CDs are recorded in

44.1 kHz/16bit, DVD are recorded in 48 kHz/16 bit up to 96 kHz/24 bit.

• If you have a Dolby Pro Logic Surround decoder, you will obtain the full benefit of Pro Logic
from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as well as
from titles with the Dolby Surround mark.

Caution for the digital output connector:

• Do not connect an amplifier (with an optical digital input connector) which does not contain
the Dolby Digital decoder.

• Otherwise attemting to play DVD may cause such a high level of noise that it may be harmful
to your ears and damage your speakers.

• Video CDs and audio CDs can be played as they would normally be played.

SELECTING THE TYPE OF
DISC FOR THE TYPE OF TV
CONNECTED

CONNECTING TO
THE MULTI-SYSTEM TV

CONNECTING
TO THE NTSC TV

13

Preparations

• Press on the power button of the TV set, and select “VIDEO” as the TV input.

• Press on the power button of the stereo system if the player has been connected to a stereo
system.

1. Press on the POWER button.

2. Press EJECT to open the disc tray.

3. Place a disc onto the tray. Hold the disc without touching either of its surfaces, position it with

the printed title side facing up, align it with the guides, and place it in its proper position.

4. Press EJECT.

• The disc tray is automatically closed and play commences if the disc does not have any

menus recorded on it.

• If the disc has one or more titles recorded on it, a menu screen will appear on the TV

monitor after a few moments.

NOTE:

Steps 5 and 6 are available only when a menu is recorded on the disc.

5. Press , or , or the number button(s) to select the preferred title.
NOTE:

For selection of a title, a double-digital number must be input, i.e. 01 for chapter 1, 02 for
chapter 2, etc.

6. Press PLAY/SEL. Play of the selected item now commences.

7. Press STOP. The reproduction is suspended.

Press STOP.
INFORMATION:

• When the player is stopped the position where STOP was pressed is saved.

•

Pressing PLAY/SEL again continues playing at this position.
Opening the disc tray or pressing STOP again deletes the saved position. However, this
function is only available for CD’s/DVD’s that show the current playing time during play.

Stopping play and returning to the menu screen (when a menu screen is available on the
disc).

Press MENU. Play is suspended, and the “SETUP MENU“ screen is displayed.

If it is not being used the player can be switched to standby by pressing the POWER button on
the remote control. Pressing the POWER switch on the device itself switches it off.

NOTE:

• The disc continues to rotate while the menu is displayed even after the player has finished

playing a particular item. When no further selections are to be played, be sure to press the
STOP button to clear the menu display.

• If the disc is placed in upside down (and it is a single sided disc), the DVD display will indi-

cate “NO DISC”.

REPRODUCTION

DVD PLAYBACK

BASIC PLAY

STOPPING PLAY

CONNECTING
TO THE PAL TV

DISC TV Monitor

PAL Played in the PAL system.

NTSC No clear images are shown

on the screen.

AFTER OPERATION

14

REPRODUCTION / DIRECT SELECTION OF SCENES

INFORMATION:

• When “ ” appears while a button is being operated, it means that the corresponding
operation is prohibited by the disc.

By the remote control:

Press F.BWD or F.FWD down during play.

• The speed of advance (FF x2, FF x4, FF x8, FF x16, FF x32) or reverse (FR x2, FR x4, FR x8,
FR x16, FR x32) changes for every press of the F.FWD or F.BWD button.

• Normal play is resumed when the PLAY/SEL button is pressed.

Skipping ahead

Press NEXT on the remote control or on the main unit during play.

• A chapter is skipped each time the button is pressed.

Skipping back

Press PREV on the remote control or on the main unit during play.

• When the button is pressed once midway through a chapter, play returns to the start of that
chapter. When it is pressed again, a chapter is skipped each time the button is pressed.

Press PAUSE/ STEP once during play.

• The screen suspends.

To return to normal play

Press PLAY/SEL.

Press PAUSE/ STEP during play.

• The disc is advanced by one frame each time the button is pressed.

To return to normal play

Press PLAY/SEL.

Press SLOW during play.

• The speed of advance (SF x1/2, SF x1/4, SF x1/8, SF x1/16, SF x1/32) changes for every press
of the SLOW button.

To return to normal play
Press PLAY/SEL.

INFORMATION:

• Slow-motion play backwards impossible.

1. Press GOTO during play.

2. Press , to move the cursor to the title number .

3. Press the number button(s) to select the preferred title.

4. Press PLAY/SEL.

Play now commences from chapter 1 of the selected title.

Selecting a double-digit number
Example: 10
Press „1“ and then „0“.

INFORMATION:

• When “ ” appears while a button is being operated, it means that the corresponding
operation is prohibited by the disc.

• Selecting Scenes by Title Number possible during play only.

RAPID ADVANCE
(RAPID REVERSE)

SKIPPING AHEAD OR
BACK TO CHAPTERS

STILL PICTURE (PAUSE)

FRAME ADVANCE (STEP)

SLOW-MOTION PLAY

SELECTING SCENES
BY TITLE NUMBER

1. Press GOTO during play.

2. Press , to move the cursor to the chapter number .

3. Press the number button(s) to select the preferred chapter.

4. Press PLAY/SEL.

Play now commences from the selected chapter.

Selecting a double-digit number
Example: 10
Press „1“ and then „0“.

INFORMATION:

• When “ ” appears while a button is being operated, it means that the corresponding
operation is prohibited by the disc.

• Selecting Scenes by Chapter Number possible during play only.

Example:

Viewing after 15 minutes have elapsed from the title start.

1. Press GOTO twice during play.

2. Press the number button(s) to specify the starting position.

Example :

To specify “15 min. 00 sec.”, press „0“, „1“, „5“, „0“, „0“.

• h (0) : min (00) : sec (00)

3. Press PLAY/SEL.

Play now commences from the specified position.

NOTE:

• These operations work only with discs for which the elapsed playing time appears on the
unit’s display during playback.

• For some discs, play may not start from the specified position even when the steps above have
been performed correctly.

INFORMATION:

• When “ ” appears while a button is being operated, it means that the corresponding
operation is prohibited by the disc.

Press 1/ALL during play.
Each time this button is pressed, the TV monitor changes and the disc will repeat a chapter or

title.

• Repeat of chapter being played

• Repeat of title being played

• Repeat of disc being played

• Cancel repeat mode

To return to normal play
Press 1/ALL REPEAT several times until “REP CANCEL” is displayed.

NOTE:

• Repeat play works only with discs for which the elapsed playing time appears on the unit’s
display during playback.

• Repeat play may not work correctly with some DVDs.

15

REPEAT VIEWING

DIRECT SELECTION OF SCENES / REPEAT PLAY

SELECTING SCENES BY TIME

SELECTING SCENES BY
CHAPTER NUMBER

16

REPEAT PLAY / CONVENIENT FUNCTIONS

1. Press A-B during play at the point where repeat play is to commence (A).

2. Press A-B again at the point where repeat play is to be concluded (B).

Repeat play of the selection between points A and B starts.

To return to normal play

Press A-B again.
(“REP CANCEL” appears on the TV monitor.)

NOTE:

• A-B repeat play works only within a chapter.

Displaying the information of the scene to be viewed

1. Press INFO during play, viewing the actual mark f. e. DVD, the subtitle , the language

, the time digit f. e. 0:07:58, the title , the chapter .

2. Press INFO a number of times, the title , the chapter , the time digit f. e. 0:07:59,

the selected TV Type , the language , the subtitle , the angle , the Audio Output

will show in sequence on the screen.

Stop displaying the information of the scene to be viewed

Press INFO a number of times until the information disappears.

This zoom in function enables you to take a closer look at the scene you are viewing that is
especially a considerate function when you are seeing a science fiction or adventure film.

1. Press ZOOM during play.

2. Press ZOOM once to see the scene in 2 times of size; press twice to see the scene in 4 times

of size.

To return to normal play

Press ZOOM a number of times until “X1” show on the screen.
The position of the scene can be moved during zooming by pressing the , or and but­tons.

It is possible to change the audio language from the one selected at the initial settings to a dif­ferent language, if available. (This operation works only with discs on which multiple audio sound­track languages are recorded.)

1. Press AUDIO during play.

2. Press AUDIO a number of times until the preferred language is selected.

INFORMATION:

• When the preferred language is not selected even after pressing the button several times, it
means that language is not available on the disc.

• When the power is turned on or the disc is removed, the language heard is the one selected
at the initial settings. If this language is not recorded on the disc, only the available language
on the disc will be heard.

If a disc has subtitles recorded on it, they can either be cleared or displayed on the TV monitor.
(This operation works only with discs on which the subtitle language is recorded.)

Press SUBTITLE during play to display the desired subtitle or clear it.
When this button is pressed once, the first subtitle recorded on the disc will display. The rest of
the subtitles recorded will display in sequence for every press of the SUBTITLE button.

• Usually a circulation will happen while switching to another language, that is you can cancel

the subtitle by pressing this button a number of times until “OFF” appears on the screen.

It is possible to change the subtitle language from the one selected at the initial settings to a
different language, if available.
(This operation works only with discs on which multiple subtitle languages are recorded.)

1. Press SUBTITLE during play.

DISPLAYING THE
INFORMATION OF THE
SCENE TO BE VIEWED

REPEATING SECTIONS
BETWEEN TWO SPECIFIC
POINTS (A-B REPEAT)

DISPLAYING THE SCENE
WITH A LARGER AND
CLOSER VIEW

CHANGING AUDIO
SOUNDTRACK LANGUAGE

CLEARING/DISPLAYING
OF SUBTITLES

CHANGING SUBTITLE
LANGUAGE

17

When no subtitles are recorded “ ” will be displayed instead of the language number.

2. Press SUBTITLE a number of times until the preferred language is selected.
The display will disappear after 5 seconds.

NOTE:

• In some cases, the subtitle language is not changed immediately
to the selected one.

INFORMATION:

• When the preferred language is not selected even after pressing the button several times, it
means that the language is not available on the disc.

• When the power is turned on or the disc is removed, subtitles appear in the language selec­ted at the initial settings. If this language is not recorded on the disc, they appear in the disc’s
priority language.

Some DVD discs may contain scenes which have been shot simultaneously from a number of dif­ferent angles. For these discs, the same scenes can be viewed from each of these different angles
using the ANGLE button. (The recorded angles differ depending on the disc used.)

1. Press ANGLE during play.

2. Press ANGLE a number of times until the preferred viewing angle is selected.
Press the ANGLE button a number of times to change the viewing angle.

NOTE:

• This function will only work on discs where different angles have been recorded.

• The viewing angles are shown on the unit’s display and you can select one from them for
viewing .

Some DVD discs have unique menu structures called DVD menus. For example, DVDs program­med with complex contents provide guide menus, and those recorded with various languages
provide menus for audio and subtitle language. Although the DVD menu’s contents and operati­on differ from disc to disc, the following explains basic operation when this feature is used.

1. Press MENU during play (eventually press TITLE).
The DVD menu available on the disc is now displayed.

2. Press , , , to select the preferred item.

3. Press PLAY/SEL.

The selected item is now executed.

When the menu continues onto another screen

Repeat steps 2 and 3.

To return to the previous menu screen

Press MENU (eventually press TITLE).

The functions described below are not available for all CD’s/DVD’s.

1. Press PBC.

2. Press PLAY/SEL.

3. Press MENU.

A DVD chapter menu is displaying now.

4. Press , , , or number button(s) to select the preferred item.

5. Press PLAY/SEL.

The selected item is now executed.

USING THE MENU FUNCTION

CONVENIENT FUNCTIONS

VIEWING FROM ANOTHER
ANGLE

USING A DVD MENU

18

Both the DVD discs and video CDs have the material recorded in
the PAL and NTSC systems. This unit provides PAL, NTSC and
Multi TV systems for your selection. (Refer to page 18 for the examples)

1. Press TV SYS during play.

2. Press TV SYS button a number of times to switch to the desired TV system.

• We strongly recommend you to select AUTO system in order to autoplay the corresponding
disc materials and prevent the unnecessary exchanging process.

NOTE:

• Press the TV SYS button once to switch to NTSC system. Press twice to switch to PAL system.
Press 3 times to switch to AUTO system.

This unit provides a MUTE function for you to temporarily turn it off.

1. Press MUTE during play.

2. Press MUTE button a number of times to turn on/off the volume.

• When “MUTE” is shown on the screen, the volume of the DVD player was turned off. To turn
on the volume, press the button a number of times until “MUTE OFF” appears on the screen.

• Press on the POWER button of the TV set, and select “Video” as the TV input.

• Press on the POWER button of the stereo system if the player has been connected to a
stereo system.

1. Press on the POWER button.

2. Press EJECT to open the disc tray.

3. Place a disc onto the tray.

Hold the disc without touching either of its surfaces, position it with the printed title side
facing up, align it with the guides, and place it in its proper position.

4. Press PLAY/SEL.

For video CDs without playback control:

Play is commenced.

For video CDs provided with playback control:

A menu appears after a few moments.

• This function works only with video CDs with playback control (version 2.0).

• The details differ depending on the disc concerned.
Also refer to the instructions accompanying the disc.

1. Press on the POWER button.

2. Press EJECT to open the disc tray.

3. Place a disc onto the tray.

Hold the disc without touching either of its surfaces, position it with the printed title side
facing up, align it with the guides, and place it in its proper position.

4. Press PLAY/SEL.

After steps 1 to 4 above the menus are displayed on the TV monitor:

5. Press the number button(s) to select the preferred item.
A doubledigital number must be input while selecting items. For example, 01, 02, 03, etc..

6. Press PLAY/SEL.

The player now starts to play the selected item.

NOTE:

, , , are not effective for selecting items for video CDs.

CONVENIENT FUNCTIONS / VIDEO CD PLAYBACK

SWITCHING TO ANOTHER
TV SYSTEM

TURNING OFF THE VOLUME
OF THE DVD PLAYER

PREPARATIONS

BASIC PLAY

MENU PLAY

19

VIDEO CD PLAYBACK

STOPPING PLAY

SKIPPING AHEAD OR
BACK TO TRACKS

RAPID ADVANCE
(RAPID REVERSE)

PLAYBACK CONTROL

If a video CD has “PLAYBACK CONTROL” written on its disc or jacket, it means that particular
scenes or information can be selected for viewing interactively with the TV monitor using the
menu screen.

When the menu continues onto another screen

After step 4, press NEXT.
To return to the previous menu screen press PREV.

Stopping play and returning to the menu screen

Press STOP.

• Play is suspended, and the menu screen is displayed.

When the unit is not in use, remove the disc and press POWER to turn off the unit.

NOTE:

• The disc continues to rotate while the menu is displayed even after the player has finished
playing a particular item. When no further selections are to be played, be sure to press the
STOP button to clear the menu display.

• If the disc is placed in upside down (and it is a single sided disc), the DVD display will indi­cate “NO DISC”.

INFORMATION:

• When “ ” appears while a button is being operated, it means that the corresponding
operation is prohibited by the disc.

Press STOP.

By remote control:

Press F.BWD or F.FWD down during play.

• The speed of advance (FF x2, FF x4, FF x8, FF x16, FF x32) or reverse (FR x2, FR x4, FR x8,
FR x16, FR x32) changes for every press of the F.FWD or F.BWD button.
Press PLAY/SEL to continue the normal play.

INFORMATION:

• When PREV/NEXT is pressed during menu play, a menu screen may sometimes be recalled.

Skipping ahead

Press NEXT during play.
A track is skipped each time the button is pressed.

Skipping back

Press PREV during play.
When the button is pressed once midway through a track, play returns to the start of that track.

When it is pressed again, a track is skipped each time the button is pressed.

INFORMATION:

• When PREV/NEXT is pressed during menu play of video CDs, a menu screen may sometimes
be recalled.

AFTER OPERATION

20

VIDEO CD PLAYBACK

/ REPEAT PLAY

Press PAUSE/STEP once during play.
The screen suspends.

To return to normal play

Press PLAY/SEL.

Press PAUSE/STEP twice during play.
The disc is advanced by one frame each time the button is pressed.

To return to normal play

Press PLAY/SEL.

Press SLOW during play.
The speed of advance (SF x2, SF x4, SF x8, SF x16, SF x32, NORMAL PLAY) changes for every press

of the SLOW button.

NOTE:

• The speed of the slow-motion play may differs from the recording condition of the discs. Each
disc may have different slow-motion play speed. This is normal.

To return to normal play
Press PLAY/SEL.

INFORMATION:

• Slow-motion playback in reverse direction is not possible.

Displaying the information of the scene to be viewed

1. Press INFO during play.

2. Some information about the scene will show in sequence on the screen as below.

- Number of video track being played

- Elapsed time

- Audio mark being played

Stop displaying the information of the scene to be viewed
Press INFO a numbers of times until the information disappears.

NOTE:

This function is only available when Playback Control function is off.
Press 1/ALL during play.

Each time this button is pressed, the TV monitor changes:

- Repeat of track being played

- Repeat of entire disc contents

- Cancel repeat mode

To return to normal play
Press 1/ALL REPEAT several times until “REPEAT OFF” is displayed.

NOTE:

• Repeat play works only with discs for which the elapsed playing time appears on the unit’s
display during playback.

STILL PICTURE (PAUSE)

FRAME ADVANCE (STEP)

SLOW-MOTION PLAY

INFO (VIDEO CDS)

REPEAT VIEWING (LISTENING)

21

RAPID ADVANCE
(RAPID REVERSE)

SKIPPING AHEAD OR BACK
TO TRACKS

REPEAT PLAY / AUDIO CD PLAYBACK

PREPARATIONS

INFORMATION (AUDIO CDS)

BASIC PLAY

STOPPING PLAY

1. Press A-B during play at the point where repeat play is to commence (A).

2. Press A-B again at the point where repeat play is to be concluded (B).

Repeat play of the selection between points A and B starts.

To return to normal play

Press A-B again.
(“REP CANCEL” appears on the TV monitor.) Or you can press STOP button to cancel the repeat
function and then press PLAY/SEL button to restart.

NOTE:

• A-B repeat play works only within a chapter.

Press on the POWER button of the TV set, and select “Video” as the TV input. Press on the

POWER button of the stereo system if the player has been connected to a stereo system.

1. Press on the POWER button.

2. Press EJECT to open the disc tray.

3. Place a disc onto the tray. Hold the disc without touching either of its surfaces, position it with

the printed title side facing up, align it with the guides, and place it in its proper position.

4. Press EJECT.

Play is commenced.

Displaying the information of the playing track

1. Press INFO during play.

"TRACK” is displayed (e.g. 2/6 - track 2 of 6), together with the current playing time and the
selected TV system.

Stop displaying the information of the playing track
Press INFO a numbers of times until the information disappears.

NOTE:

• The on-screen display only works if the TV is switched on.

Press STOP.

By the remote control:

Press F.BWD or F.FWD down during play.

• The speed of advance (FF x2, FF x4, FF x8, FF x16, FF x32) or reverse (FR x2, FR x4, FR x8,
FR x16, FR x32) changes for every press of the F.FWD or F.BWD button.

• Normal play is resumed when the PLAY/SEL button is pressed.

Skipping ahead

Press NEXT during play.
A track is skipped each time the button is pressed.

Skipping back

Press PREV during play.
When the button is pressed once midway through a track, play returns to the start of that track.
When it is pressed again, a track is skipped each time the button is pressed.

REPEATING SECTIONS
BETWEEN TWO SPECIFIC
POINTS (A-B REPEAT)

22

Press PAUSE/STEP during play.
The player will be placed in the pause mode.

To return to normal play
Press PLAY/SEL or another PAUSE/STEP.

1. Press STOP.

2. Press PROGRAM.

3. Press the number button(s) to arrange the play list.

Please note that the tracks must be entered with three digits, e.g. 003 for track no. 3 on the CD.

4. The and buttons can be used to switch to the next track entry. A total of 9 tracks can
be programmed.

5. Press PLAY/SEL.

NOTE:

• If the order is not changed, all tracks on the CD sill be played in sequence by default. If all the
tracks on the CD are not transferred into the play list, play stops when all the tracks that you
have selected have been played.

Press CLEAR (after pressing the program button) to cancel the last ordering setting. Pressing the
CLEAR button deletes the track order.

NOTE:

• To change individual tracks, enter the program list at the relevant position using the and

buttons and enter the new track number.

• Programming only works if the TV is switched on.

Choose a 4-digit password you like

1. Press SETUP button while in stop-mode.

2. Press , buttons to select

“CUSTOM SETUP“

.

Confirm by pressing the PLAY/SEL button.

3. Press , buttons to select password-option “CHANGE PASSWORD“.

4. Press PLAY/SEL.

Key in the old 4-digit password using the numeric buttons (factory default is: 9999).

5. Now key in the new 4-digit password you chose. Then press PLAY/SEL.

Do not forget your password, otherwise you will not be able to set the parental control for DVDs.

To end configurations:

To stop configuring your DVD-Player either press the SETUP button or select: "END SETUP”.

This function can be used to stop DVD discs that are unsuitable for children from being played.
Many DVD’s have a "Child Protection Code”. If the pre-programmed setting is lower than the
setting stored on the disc, the disc cannot be played.

1. Press SETUP button while in stop-mode.

2. Press , buttons to select

“CUSTOM SETUP“

.

Confirm by pressing the PLAY/SEL button.

3. Press , buttons to select “PARENTAL CONTROL“.

4. Input your 4-digit password and confirm with PLAY/SEL.

5. Press , , , to rate the level and press PLAY/SEL. The rating is locked.

Do not forget your password. The rating is locked and this setting cannot be changed unless the
correct password is entered.

REPEAT PLAY

/ INITIAL SETTINGS

PROGRAMMING
AUDIO CDS

TO CLEAR THE
ORDERING SETTING

CHANGING THE
PASSWORD

RATING LEVEL
SETTING (DVD)

STILL PICTURE (PAUSE)

Access level 1-8 settings
Access level 8:

No restriction, all DVD’s can be played.

Access level 7 – 2:

General DVD’s can be played

Access level 1:

Children’s DVD’s can be played

23

To return to CUSTOM SETUP

Select “RETURN“ and press PLAY/SEL.

To return the TV monitor to the SETUP MENU

Select “RETURN” and press PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

NOTE:

• Some discs may not be encoded with specific rating level information though its disc jacket
says that is for “adults”. For those discs, the age restriction will not work.

• Individual settings cannot be called up whilst a DVD is playing. Please stop DVD first.

You can select the language of the disc menu messages of DVDs.

1. Press SETUP in the stop mode.

2. Select “LANGUAGE SETUP” and press PLAY/SEL.

3. Press to select “OSD LANGUAGE”.

4. Press , to select the preferred language.

5. Press PLAY/SEL.

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

Programs can always be played in the same audio soundtrack language even after the disc is
replaced or the power is turned off and on.

1. Press SETUP in the stop mode.

2. Select “LANGUAGE SETUP” and press PLAY/SEL.

3. Press or to select “AUDIO SETUP ”.

4. Press PLAY/SEL.

5. Press , , , to select the preferred setting.

6. Press PLAY/SEL to confirm the setting.

To return the TV monitor to the SETUP MENU

Press PLAY/SEL or select “RETURN”.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

INFORMATION:

• If the language selected is not available on the disc, the soundtrack will be heard in the
top-priority language on the disc.

Programs can always be played in the same subtitle language even after the disc is replaced or
the power is turned off and on.

1. Press SETUP in the stop mode.

2. Select “LANGUAGE SETUP” and press PLAY/SEL.

3. Press or to select “SUBTITLE”.

4. Press PLAY/SEL.

5. Press , , , to select the preferred language.

6. Press PLAY/SEL to change the setting.

INITIAL SETTINGS

AUDIO SOUNDTRACK
LANGUAGE SELECTION
(DVD)

SUBTITLE LANGUAGE
SELECTION (DVD)

DISC MENU
LANGUAGE SETTING

24

To return the TV monitor to the SETUP MENU

Press PLAY/SEL or select “RETURN“.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

INFORMATION:

• If the subtitle language selected is not available on the disc, the top-priority language on the
disc will be used.

The type of TV set (4:3 or 16:9) connected to the player and a wide screen picture type for a 4:3
TV set can be set.

1. Press SETUP in the stop mode.

2. Press or to select “SCREEN SETUP” and press PLAY/SEL.

3. Press or to select “TV TYPE”.

4. Press , , , to select the preferred TV display.

4:3 (factory setting)

Select “NORMAL/PS“ for a conventional
size TV set.
Black bands appear at top and bottom of
screen (letter-box style).

4:3

Select “NORMAL/LB“ for a conventional size
TV set. Video material formatted in the pan &
scan style is played in that style (the left and
right edges are cut off).

• Video material not formatted in the pan & scan style is played in the letter-box style.

16:9

Select “WIDE“ for a wide-screen TV set.
Played in (16:9) “FULL” size.

• Setting the wide-screen TV to “FULL” mode is also necessary.

* Each screen shows an example when the video material for a wide-screen is played.

5. Press PLAY/SEL, to change the setting.

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

INITIAL SETTINGS

TV DISPLAY SETTING

4:3 Normal/LB

4:3 Normal/PS

16:9 Kinoformat

*

*

*

25

Both the DVD discs and video CDs have the material recorded in the PAL and NTSC systems. This
unit provides PAL, NTSC and Multi TV systems for your selection.
(Refer to page 12 - 13 for the examples).

1. Press SETUP.

2. Press , to select “SCREEN SETUP” and press PLAY/SEL.

3. Press , to select “TV SYSTEM”.

4. Press , , , to select the appropriate TV system for your clearest view.

• We strongly recommend you to select ”MULTI TV” system in order to autoplay the corres-
ponding disc materials and prevent the unnecessary exchanging process.

5. Press PLAY/SEL to make the setting.

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

The type of video output for your DVD player can be set. Here we provide “S-RGB“ and “YUV“
for your choice.
The normal video signal at the Scart connector or the "VIDEO OUT” chinch output is not
affected.

1. Press SETUP.

2. Press , to select “CREEN SETUP” and press PLAY/SEL.

3. Press , to select “VIDEO OUTPUT”.

4. Press , , , to select the preferred video output setting.

5. Press PLAY/SEL.

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

The type of audio output for your DVD player can be set. Here we provide “CENTER“, “REAR“,
“SUBWOOFER“, “LPCM48 kHz“, “96 kHz“, “ANALOG“, “SPDIF/RAW“ und “SPDIF/PCM“
for your choice.

1. Press SETUP.

2. Press , to select “AUDIO SETUP” and press PLAY/SEL.

3. Press , to select “AUDIO OUTPUT”.

4. Press , , , to select the preferred video output setting.

If the DVD player is being connected to a conventional stereo amplifier, select "2KANAL”. If
the DVD player is being connected to an amplifier with a digital input (Dolby Digital 5.1 or
DTS decoder) select "5.1KANAL”, "SPDIF/RAW” or "SPDIF/PCM”.

5. Press PLAY/SEL.

NOTE:

In case no sound output is obtained, make sure that your choice of Audio output is correct.

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

VIDEO OUTPUT
SETTING

AUDIO OUTPUT
SETTING

INITIAL SETTINGS

TV SYSTEM SETTING

You can select the language used for the on screen display (OSD) of your TV monitor.

1. Press SETUP.

2. Press , to select “LANGUAGE SETUP” and press PLAY/SEL.

3. Press , to select “OSD LANGUAGE”.

4. Press , , , to select the preferred language.

5. Press PLAY/SEL to change the setting.

To return the TV monitor to the SETUP MENU
Select “RETURN“ and press PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

If the screen saver is activated using the following instructions, it will appear when the device is
in stop mode if nothing happens for 60 seconds.

1. Press SETUP.

2. Press , to select “SCREEN SETUP” and press PLAY/SEL.

3. Press , to select “SCREEN SAVER” and select “ON“ or “OFF“.

4. Press PLAY/SEL.

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

Mit Hilfe dieser Funktion können Sie sich ein und dieselbe Szene aus verschiedenen Kamera­perspektiven ansehen.

1. Press SETUP during play.

2. Press , to select “CUSTOM SETUP” and press PLAY/SEL.

3. Press , , , to select “ANGLE ON/OFF”.

4. Press PLAY/SEL.

If you have set “ANGLE“ off, then you will not be able to select another viewing angle during
play through the remote control.

NOTE:

• This function will only work on discs where different angles have been recorded.

• The viewing angles are shown on the unit’s display and you can select one from them for
viewing .

To return the TV monitor to the SETUP MENU

Select the "RETURN” menu item by moving the left-hand bar to the bottom and pressing

PLAY/SEL.

To finish the setup operation

Press SETUP to exit or select “EXIT”.

26

INITIAL SETTINGS

ON SCREEN DISPLAY (OSD)
LANGUAGE SETTING

SCREEN SAVER SETTING

VIEWING FROM
ANOTHER ANGLE

27

GENERAL

SYMPTOM (COMMON) REMEDY

No power • Insert the power plug securely into the power outlet.

• Check if the ON/OFF button on the front of the player is set to on.

• Check if there is power at the AC outlet by plugging in another appliance.

Play fails to start even when • Condensation has formed: wait about 1 to 2 hours to allow the player to dry out.
PLAY is pressed • This player cannot play discs other than DVDs, video CDs, audio CDs and DVCDs,

Super video CDs, MP3- CDs, CD-Rs, CD-RWs, SVDs.

• Check if the disc is defective by trying another disc.

• Check the region (locale) code.

Play commences but then • The disc may be dirty and may require cleaning.
stops immediately • Ensure that the disc is installed with the label side up.

No picture • Ensure that the equipment is connected properly.

• Ensure that the input setting for the TV is “AV” or “Video”.

• Check if the TV is switched on.

No sound • Ensure that the equipment is connected properly.

• If using a HiFi amplifier, try another sound source.

• Check the Audio Output Setting menu to make sure that 2 CHANNEL is selected.

Distorted sound • Ensure that the input settings for the TV and stereo system are proper.

• No sound is heard during still picture (pause) or slow-motion play.

Distorted picture • Check the disc for fingerprints and clean with a soft cloth, wiping from center to edge.

• Sometimes a small amount of picture distortion may appear. This is not a malfunction.

Completely distorted picture • The disc format is not according to the TV-set used (PAL/NTSC).
or no color in picture

Picture is distorted during rapid • The picture will be somewhat distorted at times: This is normal.
advance or rapid reverse

No rapid advance (or rapid • Some discs may have sections which prohibit rapid advance (o rrapid reverse).
reverse) play

No 4:3 (16:9) picture • Choose the correct setup “TV DISPLAY” item which matches the TV set used.

No operations can be performed • Check the batteries are installed with the correct polarities (+ and –).
with the remote control • The batteries are depleted: replace them with new ones.

• Point the remote control unit at the remote control signal sensor and operate.

• Operate the remote control unit at a distance of not more than 7 meters from the remote
control signal sensor.

• Remove the obstacles between the remote control unit and remote control signal sensor.

No key operation (by the unit • Turn the unit off and then back to on. Alternatively, turn off the unit, disconnect the
and/or the remote control) AC power cord and then reconnect it.
is effective (The player may not be operating properly due to lightning, static electricity or some other

external factor.)

Before requesting service for this unit, check the chart below for a possible cause of the problem
you are experiencing. Some simple checks or a minor adjustment on your part may eliminate the
problem and restore proper operation.

TROUBLESHOOTING

28

GENERAL

SYMPTOM (DVD) REMEDY

Play does not commence • Confirm the “PARENTAL CONTROL” setup.
even when title is selected

Audio soundtrack and/or subtitle • If the audio soundtrack and/or subtitle language does not exist on the disc, the language
language is not the one selected will not be selected at the initial settings seen/heard.
at the initial settings

No subtitles • Subtitles appear only with discs which contain them.

• Subtitles are cleared from the TV monitor. Press SUBTITLE to display the subtitles.

Alternative audio soundtrack • An alternative language is not selected with discs which do not contain more than
subtitle) languages fail to be one language.
selected

Angle cannot be changed • This function is dependent on software availability. Even if a disc has a number of

angles recorded, these angles may be recorded for specific scenes only.

SYMPTOM (VIDEO-CD) REMEDY

No menu play • This function works only for video CDs with playback control (version 2.0).

• Hold the disc by the edges so the surface will not be soiled with fingerprints. (A)
Fingerprints, dirt and scratches can cause skipping and distortion.

• Do not write on the label side with a ball-point pen or other writing utensils.

• Do not use record cleaning sprays, benzine, thinner, static electricity prevention liquids or
any other solvent.

• Be careful not to drop or bend the disc.

• Do not install more than 1 disc on the disc tray.

• Do not try to close the disc tray when the disc is not installed properly. (B)

• Be sure to store the disc in its exclusive case when not in use.

Wipe gently with a soft, damp (water only) cloth. When wiping discs, always move the cloth from the
center hole toward the outer edge. (If you wipe the discs using a circular motion, circular scratches
are likely to occur, which will cause noise.)

HANDLING
PRECAUTIONS

Schublade

Disk

(A)

(B)

IF THE SURFACE IS SOILED

(C)

O X

tray disc

29

ANGLE

CHAPTER NUMBER

SUBTITLES

DVD

PLAYBACK CONTROL

TIME DIGIT

TITLE NUMBER

TRACK NUMBER

VIDEO CD

GENERAL / DEFINITION OF TERMS

If the disc is brought from a cold to a warm environment, moisture may form on the disc.
Wipe this moisture off with a soft, dry, lint-free cloth before using the disc.

You can damage discs if you store them in the following places:

• Areas exposed to direct sunlight

• Humid or dusty areas

• Areas directly exposed to a heat outlet or heating appliance

• CD-ROM

• CDV

• CD-G

• DVD with a Locale No. other than that shown on the DVD unit’s Region Code Label on the
rear panel

• Do not try to play Photo CD

• Be sure to turn the unit off and disconnect the AC power cord before maintaining the unit.

• Wipe this unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth
which has been dipped in a weak soap-and-water solution and wrung out thoroughly, and
then wipe again with a dry cloth.

• Never use alcohol, benzine, thinner, cleaning fluid or other chemicals.
And do not use compressed air to remove dust.

Recorded onto some DVD discs are scenes which have been simultaneously shot from a number
of different angles (the same scene is shot from the front, from the left side, from the right side,
etc.). With such discs, the ANGLE button can be used to view the scene from different angles.

These numbers are recorded on DVD discs. A title is subdivided into many sections, each of which
is numbered, and specific parts of video presentations can be searched quickly using these numbers.

These refer to a high-density optical disc on which high-quality pictures and sound have been
recorded by means of digital signals. Incorporating a new video compression technology (MPEG
II) and high-density recording technology, DVD enables esthetically pleasing full-motion video to
be recorded over long periods of time (for instance, a whole movie can be recorded).
DVD has a structure consisting of two 0.6 mm thin discs which are adhered to each other. Since
the thinner the disc, the higher the density at which the information can be recorded, a DVD disc
has a greater capacity than a single 1.2 mm thick disc. Since the two thin discs are adhered to
each other, there is the potential to achieve double-sided play soemtime in the future for even
longer duration play.

This is recorded on a video CD (version 2.0). The scenes or informa-tion to be viewed (or listened
to) can be selected interactively with the TV monitor by looking at the menu shown on the TV
monitor.

These are the printed lines appearing at the bottom of the screen which translate or transcribe
the dialogue. They are recorded on DVD discs.

This indicates the play time which has elapsed from the start of a disc or a title. It can be used to
find a specific scene quickly. (It may not work with some discs.)

These numbers are recorded on DVD discs. When a disc contains two or more movies, these
movies are numbered as title 1, title 2, etc.

These numbers are assigned to the tracks which are recorded on video CDs and audio CDs. They
enable specific tracks to be located quickly.

This contains recordings of pictures and sound whose quality is on a par with that of videotape.
This player also supports video CDs with playback control (version 2.0).

MAINTENANCE

IMPROPER DISC
STORAGE

DISC WHICH CANNOT BE
PLAYED WITH THIS PLAYER

MOISTURE ON THE DISC

30

SPECIFICATIONS

Modell : MBO DVD-PLAYER 921

Power Requirements : AC 100-240 V AC ±10%, 50/60Hz

Power Consumption : 0,8 A (maximum)

Video Signal System : NTSC/PAL

Video Decompression : MPEG-2 (ISO/IEC-13818), MPEG-1, MPEG-3, MPEG-4

Weight : < 4,0 kg

Dimensions : 430 x 90 x 302 mm (W x H x D)

Disc Played : (1) DVD-video-disc

(2) Compact-disc (video CD, CD-DA)

S-video output connector (separate
YC signal output connector) :

Y output : 1 Vp-p (with 75 Ohm load, sync, negative polarity)

C output : 0,286 Vs-s (with 75 Ohm load, sync, negative polarity)

Video Signal Output : 1 Vs-s (with 75 Ohm load, sync, negative polarity)

Analog Output : 2 Vrms (330 Ohm, 0 dB at 1 kHz)

Audio Signal Output
Characteristics : AC 3 decoder for 5.1 channel analog output (6x Cinch)

AC 3/5.1 digital output (coaxial, optical), linear PCM

DVD Linear Audio : Frequency response: 48 kHz sampling; 4 Hz to 22 kHz

96 kHz sampling; 4 Hz to 44 kHz
S/N ratio: 105 dB
Dynamic range: 95 dB
Wow & flutter: below measureable limits

Total harmonic distortion: 0.004%

CD Audio : Frequency response: 4 Hz to 20 kHz

Digital Output : 0,5 Vs-s (with 75 Ohm)

Phones Jack : 32 Ohm (30 mW), min. 8 Ohm matching impedance

Outputs : 3 Cinch RGB / YUV output

Video Section : 1 Cinch Video output

1 S-video output
1 SCART output

Audio Section : 6 Analog output (Left/Right, Front/Rear, Center, Subwoofer)

1 Digital output PCM/Dolby Digital (Coaxial)
1 Digital output PCM/Dolby Digital (Optical)

Remote Control : DC 3V (AAA x2) Infra-red

• Specifications are subject to change without notice.

• Weight and dimensions are approximate.

The DVD player contains technology that is protected by copyright and belongs to Macrovision Corporation and other copyright holders. This
technology is protected by US patent conditions and laws pertaining to other intellectual property. This copyrighted technology may only be
used with the permission of the Macrovision Corporation. The equipment may only be used in the private sector or used for other restricted
purposes - permission from the Macrovision Corporation is required for any other use.

www.MBOservice.net

WARRANTY CONDITIONS

Congratulations on your purchase of this product from 4MBO International Electronic AG, Fabrikstraße
45, D-73207 Plochingen. You are now the owner of a device of the highest technical standard and
tried-and-tested quality. If, however, you should have a problem with this product at any time please
observe the following warranty conditions:

1. We will provide a guarantee for this device, when used correctly, for a period of 24 months
calculated from the date of purchase from your dealer. We will remedy any possible defects at our
cost, insofar that the fault is a result of material defects or production errors. The date of pur­chase must be demonstrated by presentation of an invoice, till receipt or other proof of purchase.

2. The guarantee becomes invalid if repairs are carried out without the express consent of our
company.

3. You do, of course, retain all legal rights both in relation to our company and in relation to the
seller of this device in addition to the rights provided by this guarantee.

4. If you have questions regarding this device, or technical problems, please contact our

appointed service provider:

JET GmbH, Am Weimarer Berg 6, 99510 Apolda
Our helpline telephone number is printed on the reverse of this page.
Please have the following available during your call:

a) Description of any errors observed
b) Proof of purchase or receipt

5. We are happy to deal with repairs outside the guarantee period at cost. If an estimate is required,
we will have to charge you for this, but this cost will of course be deducted from your final
invoice if we carry out the work required.

Yours faithfully

Customer Support
4MBO International Electronic AG
