CA-101 KEYBOARD USER MANUAL

0

CA-101 Keyboard User Manual

V1.0

Thanks a lot for purchasing our product. If there is any question, please feel free to contact us.

This manual may have something inaccurate in technology, unsuited with the product’s functions and operations or the
misprints. The manual’s content will change with the enhanced functions of the product, as well as give the regular advance or
renew the product and procedure in this manual. The renewed content will be added in the new edition of this manual and no
separate notice will be given.

NOTES

 LCD display can be easily damaged. Please do not press or exposure in sunshine for a long time;


The joystick can be easily damaged. If it needs to be repaired, please wrap and ship it by using original or

safety packaging;

 This keyboard should be used in certain range of temperature and humidity, referring the technical index.
 Please connect the keyboard correctly as this manual requires.

1

Conteúdo

Main Features ................................................................................................................................................................... 3

Control .......................................................................................................................................................................... 3

Control protocol ........................................................................................................................................................... 3

Divided control by host and auxiliary keyboard ........................................................................................................... 3

Features and functions ................................................................................................................................................. 3

Install Introduction ........................................................................................................................................................... 3

2

Main Features

CA-101 keyboard is compatible with all of our company’s full series embedded DVRs. These keyboards can control
speed dome and PTZ either directly, or through the DVRs. Also they can control DVRs as well.

Control

Completely replace the all functions of DVR front panel. Any operation is indicated in LCD display.
One keyboard can manage 31 DVRs maximum.
Control speed dome and PTZ: The speed dome and PTZ address is among 0~254.

Control protocol

Contain 9 kinds of speed dome and PTZ protocol. Users can require installing other specific protocol if the keyboard
has not contained. We will send the modified procedure to you to update keyboard procedure via RS-485
communication port, as it does not need to change hardware in advance.

Divided control by host and auxiliary keyboard

Classifying control can be supported in controlling embedded DRV, and 15 auxiliary keyboard can be connected, and
the ID ranging from 0 to 15
Classifying control can be supported in controlling quick DOME and decoder, and 15 auxiliary keyboard can be
connected, and the ID ranging from 0 to 15.

Features and functions

The flexibility of system is improved wisely as any equipments connect with RS485 can be set in different protocols
and baud rates. Due to all the configuration can be done on the LCD display, it is not needed to look for how to
change the protocol.

Install Introduction

Back panel interface introduction

PTZ-CON PTZ-AUX

RS485

10 9 8 7 6 5 4 3 2 1

EXPORT

Ta Tb

Gr

Ra Rb G

ound

DVR-AUX DVR-CON

G Ra Rb

Ta Tb

10 1

RS48 5-EX POR

T

PTZ DVR PW

DC-12V

1 2 3 4 5 6 7 8 9

3
