W-4
USER’S G
UIDE
Automatic Washer
Table of Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Instructions . . . . . . . . . . . . . . . . 2
Controls At A Glance . . . . . . . . . . . . . 3-4
Special Features . . . . . . . . . . . . . . . . . . 5
Operating Tips. . . . . . . . . . . . . . . . . . . . 6
Care and Cleaning. . . . . . . . . . . . . . . . . 7
Storing the Washer . . . . . . . . . . . . . . . . 7
Before you Call. . . . . . . . . . . . . . . . . . 8-9
Warranty. . . . . . . . . . . . . . . . . . . . . . . . 11
Guide de L’Utilisateur . . . . . . . . . . . . . 12
Guía del Usuario . . . . . . . . . . . . . . . . . 24
Form No. A/11/02 Part No. 6 2307430 ©2002 Maytag Appliances Sales Co.
KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Welcome
Congratulations on your purchase of a Maytag Clothes
Washer! Your satisfaction is very important to us.
Read this manual for best results. It contains instructions to acquaint you with proper operating and maintenance procedures.
In addition you will find a Laundering Tips guide
packed with your clothes washer. It contains information
on recommended laundering procedures, stain removal
and special laundering situations.
Save time and money. If something should
go wrong, we suggest consulting the
“Before You Call” section in the back of this
book. It is designed to help you solve basic
problems before consulting a servicer.
However, should you need assistance in the future, it is
helpful to:
1) Have complete model and serial number identification of your washer. This is located on a data plate on
the top edge of the control panel. Record these numbers below for easy access.
Model Number
__ __ __ __ __ __ __ __ __ __
Serial Number
__ __ __ __ __ __ __ __ __ __
Date of Purchase
__________________________
1
NOTE: In our continuing effort to improve the quality of our appliances, it may be necessary to make
changes to the washer without revising this guide.
2) IMPORTANT: Keep this guide and the sales receipt
in a safe place for future reference. Proof of original purchase date is needed for warranty service.
If you have questions, write us (include your model
number and phone number) or call:
Maytag Appliances Sales Company
Attn: CAIR
®
Center
P.O. Box 2370
Cleveland, TN 37320-2370
1-800-688-9900 USA
1-800-688-2002 CANADA
1-800-688-2080 USA TTY (for deaf, hearing
impaired or speech impaired)
Mon.–Fri., 8am–8pm Eastern Time
Internet: http://www.maytag.com
For service and warranty information, see back page.
WARNING – Hazards or unsafe practices which
COULD result in severe personal injury or death.
CAUTION – Hazards or unsafe practices which
COULD result in minor personal injury.
What you need to
know about safety
instructions
Warning and Important Safety Instructions appearing in
this manual are not meant to cover all possible conditions and situations that may occur. Common sense, caution, and care must be exercised when installing, maintaining or operating appliance.
Always contact your dealer, distributor , service agent, or
manufacturer about problems or conditions you do not
understand.
Recognize safety
symbols, words, labels
WARNING
CAUTION
1. Read all instructions before using the appliance.
2. As with any equipment using electricity and having
moving parts, there are potential hazards. T o use this
appliance safely, the operator should become familiar with the instructions for operation of the appliance and always exercise care when using it.
3. Do not install or store this appliance where it will be
exposed to the weather.
4. Install and level washer on a floor that can support
the weight.
5. This appliance must be properly grounded. Never
plug the appliance cord into a receptacle which is
not grounded adequately and in accordance with
local and national codes. See installation instructions for grounding this appliance.
6. To avoid the possibility of fire or explosion:
a. Do not wash items that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry-cleaning solvents, other flammable
or explosive substances as they give off vapors
that could ignite or explode. Hand wash and line
dry any items containing these substances.
Any material on which you have used a cleaning
solvent, or which is saturated with flammable liquids or solids, should not be placed in the washer
until all traces of these liquids or solids and their
fumes have been removed.
These items include acetone, denatured alcohol,
gasoline, kerosene, some liquid household cleaners, some spot removers, turpentine, waxes and
wax removers.
b. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give of f vapors that
could ignite or explode.
c. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not
been used for such a period, before using a washing machine or combination washer-dryer, turn
on all hot water faucets and let the water flow
from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame
during this time.
7. Do not reach into the appliance if the tub or agitator
is moving.
8. Do not allow children or pets to play on, in, or in front
of the appliance. Close supervision is necessary when
the appliance is used near children and pets.
9. Do not tamper with controls.
10. Do not repair or replace any part of the appliance or
attempt any servicing unless specifically recommended in published user-repair instructions that
you understand and have the skills to carry out.
11. Unplug power supply cord before attempting to
service your washer.
12. The agitator should not be removed. If the agitator
is removed, it must be replaced by pushing down
completely and the locking screw tightened before
the washer is operated.
13. Store laundry aids and other material in a cool, dry
place where children cannot reach them.
14. Do not wash or dry items that are soiled with vegetable or cooking oil. These items may contain some
oil after laundering. Due to the remaining oil, the
fabric may smoke or catch fire by itself.
15. Do not use chlorine bleach and ammonia or acids
(such as vinegar or rust remover) in the same wash.
Hazardous fumes can form.
16. Do not machine wash fiberglass materials. Small
particles can stick to fabrics washed in following
loads and cause skin irritation.
17. Before the appliance is removed from service or discarded, remove the door to the washing compartment.
18. Inlet hoses are subject to damage and deterioration
over time. Check the hoses periodically for bulges,
kinks, cuts, wear or leaks and replace them every
five years.
Important Safety Instructions
WARNING —
To reduce the risk of fire, explosion, electric shock or personal injury when
using your washer, follow basic safety precautions, including the following:
Save These Instructions
2
3
Controls At A Glance
1
Select CycleStep
1
(Features may vary according to model.)
Press the control dial in and turn clockwise to the desired cycle. Pull the knob
out to start the washer.
REGULAR is used for normal, sturdy
fabrics. Cycles available:
EXTRA HEAVY (select models) –
Approximately 16-18 minutes of
wash time
HEAVY – Approximately 14-18 min-
utes of wash time
(NORMAL) – Approximately 10-13
minutes of wash time
LIGHT – Approximately 7-9 minutes of
wash time
EASY CARE/PERMANENT PRESS is designed
to minimize wrinkles with a cool-down spray rinse
following the wash. Cycles available:
HEAVY – Approximately 10-14 minutes of wash time
(NORMAL) – Approximately 7-9 minutes of
wash time
LIGHT – Approximately 5-6 minutes of wash time
DELICATES is designed for items
requiring delicate wash action.
Cycles available:
NORMAL – Approximately 10-12 min-
utes of wash time
LIGHT – Approximately 7-9 minutes of
wash time
Turn the WATER LEVEL knob
to the setting that matches the
size of the load.
Select models offer infinite settings. Choose a specific setting or
any point in between.
If more water is needed once the
fill is complete, turn the knob to
reset and then to the proper setting.
Super
Large
Medium
Mini
3/4 – Full
1/2 – 3/4 Full
1/3 – 1/2 Full
1/4 Full
REMEMBER: Items must circulate freely for best
results.
WATER LEVEL SETTING LOAD SIZE
4
Step Select Water Level (Features may vary according to model.)
Turn the WASH/RINSE knob to
the desired water temperatures.
Follow the garment care label for
best results. Use the chart at right
as a guide.
2
2
Step Select Water Temperature
3
3
White and heavily
soiled, color-fast
items
Delicate items
Moderately soiled,
colored items; most
Easy Care/Permanent
Press items
Brightly colored,
lightly soiled items;
washable woolens
WASH/RINSE TEMPS LOAD TYPE
Hot/Cold
Warm/Warm
(select models)
Warm/Cold
Cold/Cold
Step Start Washer
5
5
• Add detergent and any additives.
• Add load and close lid.
• Pull the control dial out to start.
Step
4
4
Provides additional rinse at the end of
the cycle to more completely remove
laundry additives, suds,
perfumes, etc.
OPTION USE
Extra Rinse
(select models)
REMEMBER: In wash water temperatures below 65° F, detergents do not dissolve well or clean well. Care labels define cold
water as up to 85° F.
Select Extra Rinse (if desired) (select models)
5
Special Features
Bleach Dispenser (select models)
The dispenser automatically dilutes liquid chlorine
bleach before it reaches your wash load. To use, follow
these steps:
1. Measure liquid chlorine bleach carefully, following
the instructions on the bottle.
2. Add the bleach to the dispenser before adding the
load. Avoid splashing or over-filling the dispenser.
NOTE:
• Never pour undiluted liquid chlorine bleach directly
onto the load or into the wash tub. It is a powerful
chemical and can cause fabric damage, such as tearing or color loss, if not used properly.
• If you prefer to use color-safe, non-chlorine bleach,
pour it into the wash tub with your detergent. Do not
pour non-chlorine bleaches into the bleach dispenser.
Fabric Softener Dispenser
This dispenser automatically releases liquid fabric softener at the proper time during the cycle. To use, follow
these steps:
1. Pour a measured amount of desired liquid into dispenser to fill line only.
2. If liquid comes below line, add warm water.
NOTE:
• Do not stop the washer during the first spin. This will
cause the dispenser to empty too soon.
•Never pour fabric softener directly on the load. It will
leave spots and stains.
• Use the dispenser for liquid fabric softeners only.
Pour liquid chlorine bleach into
bleach dispenser.
Pour liquid fabric softener into cup and
dilute with warm water.
6
Operating Tips
Loading
• Put dry, unfolded clothes loosely in the tub, up to the
top row of holes for a maximum load.
• Do not wrap large items like sheets around the agitator.
• Mix large and small items for best circulation. Wash
bulky items like blankets separately.
• When laundering permanent press items or items of
delicate construction, washable woolens or loosely
knit items, never use less than the MEDIUM water
level setting. This will minimize shrinkage, wrinkling
and pulling of seams.
• For best results, add the detergent to washtub before
adding the load.
• Close lid carefully to avoid slamming.
Additional Tips
• If the washer stops during the spin, it may be due to
an unevenly distributed load. If this happens, push in
the control knob, open the lid, redistribute the load,
close the lid and pull out the control knob. The spin
will resume at the point it was interrupted.
• The washer will pause briefly throughout each cycle.
These pauses are normal.
For detailed information on sorting, pretreating
stains, etc., see the enclosed Laundry Tips pamphlet.
Detergent
• Use either liquid or granular laundry detergent. For
best results, be sure detergent is added to the
washer BEFORE the load and be sure wash water
is above 65
° F.
•Use the correct amount of detergent for the load size,
soil level and water conditions. Use more detergent if
you have hard water and very soiled loads.
If you have soft water or a lightly soiled load, use less
detergent. (See manufacturer’s instructions.)
•Wipe up any detergent spills on the washer.
• This washer is designed so that it will not agitate or
spin when the lid is open. It will, however, fill with
the lid open so water is available for pretreating stains
or diluting fabric softener.
• If you open the lid during a cycle, the washer will
stop. When the lid is closed and the control knob
pulled out, the washer will continue the cycle at the
point it was interrupted.
7
Care and Cleaning
Turn off the water faucets after finishing the day’s washing. This will shut off the water supply to the washer and
prevent the unlikely possibility of damage from escaping water.
Use a soft cloth to wipe up all detergent, bleach or other
spills as they occur.
Clean the following as recommended:
Control Panel – clean with a soft, damp cloth and glass
cleaner. Do not use abrasive powders or cleaning
pads.
Cabinet – clean with soap and water followed with an
appliance wax, if desired.
Fabric Softener Dispenser
1. Pull the dispenser off of the top of the agitator.
2. Soak for one hour in sink or container in hot
water and dishwashing liquid.
3. Hold hands over top and bottom of dispenser and
shake to loosen buildup.
4. Rinse with clean, hot water.
5. Repeat process if necessary.
6. Replace dispenser on agitator.
Do not use dishwashing liquid
inside the washer. Oversudsing can
occur.
Storing the Washer
Interior – hard water deposits may be removed, if need-
ed, using a recommended cleaner labeled washer
safe.
Lint Filter – it is self-cleaning and requires no mainte-
nance. The filter is located under the agitator on the
bottom of the washtub. During the wash and rinse
portion of the
cycle, lint is collected on the filter. Then during
the spin and
drain the filter is
cleaned automatically.
Washers can be damaged if water is not removed from
hoses and internal components before storage. Prepare
the washer for storage as follows:
• Select NORMAL on the REGULAR cycle and add
one cup of bleach OR white vinegar to a full load of
water without clothes. (Do not mix bleach and vinegar in the same wash. Hazardous fumes can form.)
Run the washer through a complete cycle.
• Turn the water faucets off and disconnect the inlet
hoses.
• Disconnect the washer from the electrical supply and
leave the washer lid open to let air circulate inside the
tub.
• If the washer has been stored in below-freezing temperatures, allow time for the washer to thaw out prior
to use.
• After storage, select NORMAL on the REGULAR
cycle and run the washer through a complete cycle.
8
Won’t fill
Won’t spin or drain
Won’t agitate
Check these points if your washer...
Before You Call
• Plug cord into live electrical outlet.
• Check fuse or reset circuit breaker.
• Turn the control knob to proper cycle and pull knob out to start the washer. If
equipped with buttons, be sure they are fully depressed.
• Turn both faucets on fully.
• Straighten inlet hoses.
• Disconnect hoses and clean screens. Hose filter screens may be plugged.
• Check fuse or reset circuit breaker.
• Make sure lid is completely closed.
• Turn the control knob to proper cycle and pull knob out to start the washer. If
equipped with buttons, be sure they are fully depressed.
• Close lid and pull knob out to start the washer. For your safety, washer will
not agitate or spin unless the lid is closed.
• The washer is equipped with a lid switch failure detector. If the lid switch
should malfunction, the detector will stop operations for your safety. Call for
service.
• Unevenly distributed load. Redistribute the load, close the lid and pull knob
out. Check for leveling. Be sure water level is acceptable for load size.
• Check fuse or reset circuit breaker.
• Straighten drain hoses. Eliminate kinked hoses. If there is a drain restriction,
call for service.
• Close lid and pull knob out to start the washer. For your safety, washer will
not agitate or spin unless the lid is closed.
• The washer is equipped with a lid switch failure detector. If the lid switch
should malfunction, the detector will stop operations for your safety. Call for
service.
• Suds lock – caused by too much suds. Rewash without detergent. Use correct
amount of a low-sudsing detergent.
• The washer may have sensed an unevenly distributed load. Redistribute the
load in the tub, close the lid and pull the control knob out.
•Anormal spin speed is recommended for heavy loads like jeans or towels.
For problem laundry solutions (i.e. fabric damage, residue, tangling) and special laundry care procedures, see the enclosed Laundry Tips pamphlet.
(cont.)
Load is wet
9
Leaks water
Is noisy
Fills with
the wrong temperature water
Stops
Check these points if your washer...
• Unevenly distributed load. Redistribute the load, close the lid and pull knob
out. Check for leveling. Be sure water level is acceptable for load size.
• Plug cord into live electrical outlet.
• Check fuse or reset circuit breaker.
• Turn the control knob to proper cycle and pull knob out to start the washer.
• Close lid and pull knob out to start the washer. For your safety , washer will not
agitate or spin unless lid is closed.
• This may be a pause or soak period in the cycle. Wait briefly and it may start.
• The washer is equipped with a lid switch failure detector. If the lid switch
should malfunction, the detector will stop fill operations for your safety. Call
for service.
• Make sure hose connections are tight.
• Make sure end of drain hose is correctly inserted and secured to drain facility.
• Avoid extended soaking – soak for 30 minutes or less.
•Avoid overloading.
• Be sure washer is leveled properly as outlined in installation manual.
• Weak floors can cause vibration and walking.
• Be sure rubber feet are installed on leveling legs.
• Operating sounds will vary depending on agitation speed.
• Turn both faucets on fully.
• If equipped with a temperature selector knob, be sure it is set directly on a
temperature setting and not between settings.
• Make sure temperature selection is correct.
• Make sure hoses are connected to correct faucets and inlet connections. Be
sure water supply is regulated correctly. Flush water line before filling
washer.
• Check the water heater. It should be set to deliver a minimum 120°F (49°C)
hot water at the tap. Also check water heater capacity and recovery rate.
• Disconnect hoses and clean screens. Hose filter screens may be plugged.
Before You Call (cont.)
For further assistance contact Maytag Appliances Sales Company, Maytag Customer Assistance:
U.S. 1-800-688-9900 or Canada 1-800-688-2002
U.S. customers using TTY for deaf, hearing impaired or speech impaired, call 1-800-688-2080.
10
Notes
Loading...
