Maytag W10057352A User Manual

GAS DRYER

USE & CARE GUIDE

SÉCHEUSE À GAZ

GUIDE D’UTILISATION ET D’ENTRETIEN

FOR QUESTIONS ABOUT FEATURES, OPERATION/PERFORMANCE,

PARTS, ACCESSORIES OR SERVICE CALL: 1.800.688.9900

IN CANADA, CALL: 1.800.807.6777

VISIT OUR WEBSITE AT WWW.MAYTAG.COM

IN CANADA, WWW.MAYTAG.CA

W10057352A

AU CANADA, POUR ASSISTANCE, INSTALLATION OU SERVICE,

COMPOSEZ LE : 1.800.807.6777

OU VISITEZ NOTRE SITE INTERNET À

WWW.MAYTAG.CA

TABLE OF CONTENTS

DRYER SAFETY......................................................................3

INSTALLATION INSTRUCTIONS .........................................5

Tools and Parts...................................................................5

Optional Pedestal...............................................................5

Location Requirements.......................................................6

Electrical Requirements......................................................8

Gas Supply Requirements ..................................................9

Venting Requirements......................................................10

Plan Vent System..............................................................12

Install Vent System ...........................................................13

Install Leveling Legs .........................................................14

Make Gas Connection......................................................14

Connect Vent ...................................................................15

Connect Inlet Hose...........................................................15

Level Dryer ......................................................................16

Complete Installation .......................................................16

DRYER USE..........................................................................17

Starting Your Dryer...........................................................17

Stopping Your Dryer ........................................................19

Pausing or Restarting........................................................19

Control Lock ....................................................................19

Drying and Cycle Tips......................................................19

Status Indicator.................................................................20

Cycles ..............................................................................20

Optional Features.............................................................22

Changing Cycles, Options and Modifiers.........................22

Drying Rack Option .........................................................23

DRYER CARE......................................................................24

Cleaning the Dryer Location ............................................24

Cleaning the Lint Screen ..................................................24

Cleaning the Dryer Interior...............................................24

Removing Accumulated Lint............................................24

Water Inlet Hoses.............................................................25

Vacation, Storage and Moving Care.................................25

Changing the Drum Light.................................................25

TROUBLESHOOTING........................................................26

Dryer Operation...............................................................26

Dryer Results....................................................................27

ASSISTANCE OR SERVICE...................................................29

In the U.S.A......................................................................29

In Canada.........................................................................29

MAYTAG

MAJOR APPLIANCE WARRANTY.....................30

TABLE DES MATIÉRES

SÉCURITÉ DE LA SÉCHEUSE...............................................31

INSTRUCTIONS D'INSTALLATION ...................................33

Outillage et pièces ...........................................................33

Piédestal facultatif ............................................................33

Exigences d'emplacement................................................34

Spécifications électriques .................................................36

Spécifications de l'alimentation en gaz ............................37

Exigences concernant l'évacuation ..................................38

Planification du système d’évacuation .............................40

Installation du système d’évacuation................................41

Installation des pieds de nivellement................................42

Raccordement au gaz.......................................................42

Raccordement du conduit d’évacuation...........................43

Raccordement du tuyau d'alimentation............................43

Mise à niveau de la sécheuse...........................................44

Achever l’installation........................................................44

UTILISATION DE LA SÉCHEUSE.........................................45

Mise en marche de la sécheuse........................................45

Arrêt de la sécheuse .........................................................47

Pause ou remise en marche..............................................47

Verrouillage des commandes ...........................................47

Conseils pour les programmes..........................................48

Témoins lumineux............................................................48

Programmes .....................................................................49

Caractéristiques supplémentaires .....................................50

Changement des programmes, options et modificateurs ..51

Grille de séchage .............................................................52

ENTRETIEN DE LA SÉCHEUSE ...........................................53

Nettoyage de l'emplacement de

la sécheuse......................................................................53

Nettoyage du filtre à charpie............................................53

Nettoyage de l’intérieur de la sécheuse............................53

Retrait de la charpie accumulée.......................................54

Tuyaux d'arrivée d'eau.....................................................54

Précautions à prendre avant les vacances,

un entreposage ou un déménagement .............................54

Changement de l’ampoule d’éclairage

du tambour.......................................................................54

DÉPANNAGE ......................................................................55

Fonctionnement de la sécheuse .......................................55

Résultats de la sécheuse ...................................................55

ASSISTANCE OU SERVICE..................................................57

Aux États-Unis..................................................................57

Au Canada .......................................................................57

GARANTIE .......................................................................58

DRYER SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

You can be killed or seriously injured if you don't immediately

DANGER

WARNING

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, or to prevent property damage, personal injury, or death.

follow instructions.

can be killed or seriously injured if you don't

You instructions.

– Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this

or any other appliance.

– WHAT TO DO IF YOU SMELL GAS:

Do not try to light any appliance.

•

Do not touch any electrical switch; do not use any phone in your building.

•

Clear the room, building, or area of all occupants.

•

Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's

•

instructions. If you cannot reach your gas supplier, call the fire department.

•

– Installation and service must be performed by a qualified installer, service agency, or

the gas supplier.

In the State of Massachusetts, the following installation instructions apply:

■

Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by

the State of Massachusetts.

■

If using a ball valve, it shall be a T-handle type.

■

A flexible gas connector, when used, must not exceed 3 feet.

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions,

WARNING:

including the following:

■ Read all instructions before using the dryer.

■ Do not place items exposed to cooking oils in your dryer.

Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.

■ Do not dry articles that have been previously cleaned in,

washed in, soaked in, or spotted with gasoline, drycleaning solvents, or other flammable or explosive substances as they give off vapors that could ignite or explode.

■ Do not allow children to play on or in the dryer. Close

supervision of children is necessary when the dryer is used near children.

■ Before the dryer is removed from service or discarded,

remove the door to the drying compartment.

■ Do not reach into the dryer if the drum is moving.

■ Do not install or store the dryer where it will be exposed

to the weather.

■ Do not tamper with controls.

■ Do not repair or replace any part of the dryer or attempt

any servicing unless specifically recommended in this Use and Care Guide or in published user-repair instructions that you understand and have the skills to carry out.

■ Do not use fabric softeners or products to eliminate static

unless recommended by the manufacturer of the fabric softener or product.

■ Do not use heat to dry articles containing foam rubber or

similarly textured rubber-like materials.

■ Clean lint screen before or after each load.

■ Keep area around the exhaust opening and adjacent

surrounding areas free from the accumulation of lint, dust, and dirt.

■ The interior of the dryer and exhaust vent should be

cleaned periodically by qualified service personnel.

■ See installation instructions for grounding requirements.

SAVE THESE INSTRUCTIONS

IMPORTANT: The gas installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or the Canadian Natural Gas and Propane Installation Code, CSA B149.1.

The dryer must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70 or Canadian Electrical Code, CSA C22.1.

INSTALLATION INSTRUCTIONS

Tools and Parts

Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here.

For a garage installation, you will need to place the 10" (25.4 cm) pedestal at least 9" (22.9 cm) above the floor. You will need to place the 15.5" (39.4 cm) pedestal at least

3.5" (8.9 cm) above the floor.

 8" or 10" pipe wrench  8" or 10" adjustable wrench (for gas

connections)

 Flat-blade screwdriver  Adjustable wrench that opens to 1" (2.5

cm) or hex-head socket wrench (for adjusting dryer feet)

1/4" nut driver or socket wrench

(recommended)

 Level  Knife  Vent clamps  Pipe-joint compound resistant to LP gas  Caulking gun and compound (for

installing new exhaust vent)

 Pliers  Tape measure

Parts supplied

Remove parts package from dryer drum. Check that all parts are included.

NOTE: Do not use leveling legs supplied with dryer if installing on a pedestal.

A. Leveling legs (4) B. “Y” connector C. Short inlet hose

D. Inlet hose with right-angle connector

E. Rubber washer

Parts needed

Check local codes. Check existing electrical supply and venting. See “Electrical Requirements” and “Venting Requirements” before purchasing parts.

Mobile home installations require metal exhaust system hardware available for purchase from the dealer from whom you purchased your dryer. For further information, please refer to the “Assistance or Service” section.

Optional Pedestal

Are you placing the dryer on a pedestal? You have the option of purchasing pedestals of different heights separately for this dryer. You may select a 10" (25.4 cm) or 15.5" (39.4 cm) pedestal with drawer. The pedestal will add to the total height of the dryer for a total height of approximately 48" (121.9 cm) or 53.5" (135.9 cm), respectively.

A. 10" (25.4 cm) pedestal B. 15.5" (39.4 cm) pedestal

The pedestals are available in several colors. To order, call the dealer from whom you purchased your dryer or refer to the “Assistance or Service” section.

Pedestal Height Color Part Number

10" (25.4 cm) White MHP1000SQ

15.5" (39.4 cm) White XHP1550VW

15.5" (39.4 cm) Crimson XHP1550VF

15.5" (39.4 cm) Evergreen XHP1550VP

15.5" (39.4 cm) Oxide XHP1550VJ

Stack Kit

Are you planning to stack your washer and dryer? To do so, you will need to purchase a Stack Kit. To order, call the dealer from whom you purchased your dryer or refer to the “Assistance or Service” section. Ask for Part Number 8212640.

Door Reversal Kit

Are you planing to reverse the door swing direction on your PERFORMANCE SERIES dryer? To do so, you will need to purchase a Door Reversal Kit. To order, call the dealer from whom you purchased your dryer or refer to the “Assistance or Service” section. Ask for Part Number W10200372.

Backguard

If you are installing your PERFORMANCE SERIES washer and dryer and wish to avoid having loose items fall behind your machines, you may purchase a pair of washer/dryer backguards. These will reduce the chance of items falling behind the machines during operation. To order, call the dealer from whom you purchased your dryer or refer to the “Assistance or Service” section. Ask for Part Number 8558694 (White).

Location Requirements

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as gasoline, away from dryer.

Place dryer at least 18 inches (46 cm) above the floor for a garage installation.

Failure to do so can result in death, explosion, or fire.

You will need

 A location that allows for proper exhaust installation. A gas dryer must be exhausted to

the outdoors. See “Venting Requirements.”

 A separate 30-amp circuit.  If you are using a power supply cord, a grounded electrical outlet located within

2 ft (61 cm) of either side of the dryer. See “Electrical Requirements.”

 Cold water faucets located within 4 ft (1.2 m) of the dryer, and water pressure of 20-100

psi (137.9-689.6 kPa). You may use the cold water supply from your washer using the “Y” connector provided.

 A sturdy floor to support the total dryer weight of 200 lbs (90.7 kg). The combined weight

of a companion appliance should also be considered.

 A level floor with a maximum slope of 1" (2.5 cm) under entire dryer. If slope is greater

than 1" (2.5 cm), install Extended Dryer Feet Kit, Part Number 279810. Clothes may not tumble properly and automatic sensor cycles may not operate correctly if dryer is not level.

 For a garage installation, you will need to place the dryer at least 18" (46 cm) above the

floor. If using a pedestal, you will need 18" (46 cm) to the bottom of the dryer.

Do not operate your dryer at temperatures below 45ºF (7ºC). At lower temperatures, the dryer might not shut off at the end of an automatic cycle. This can result in longer drying times.

The dryer must not be installed or stored in an area where it will be exposed to water and/or weather.

Check code requirements. Some codes limit, or do not permit, installation of the dryer in garages, closets, mobile homes or sleeping quarters. Contact your local building inspector.

NOTE: No other fuel-burning appliance can be installed in the same closet as a dryer.

Installation clearances

The location must be large enough to allow the dryer door to open fully.

Dryer Dimensions

51½"

(130.81 cm)

38"

(96.52 cm

)

*31½" (80 cm)

27"

(68.6 cm)

*Most installations require a minimum 5" (12.7 cm) clearance behind the dryer for the

exhaust vent with elbow. See “Venting Requirements.”

Installation spacing for recessed area or closet installation

The following spacing dimensions are recommended for this dryer. This dryer has been tested for spacing of 0" (0 cm) clearance on the sides and rear. Recommended spacing should be considered for the following reasons:

 Additional spacing should be considered for ease of installation and servicing.  Additional clearances might be required for wall, door and floor moldings.  Additional spacing should be considered on all sides of the dryer to reduce noise transfer.  For closet installation, with a door, minimum ventilation openings in the top and bottom

of the door are required. Louvered doors with equivalent ventilation openings are acceptable.

 Companion appliance spacing should also be considered.

Custom undercounter installation - Dryer only

(0 cm)

38" min. (96.52 cm)

1"* (2.5 cm)

27" (68.6 cm)

1"* (2.5 cm)

*Required spacing

Closet installation - Dryer only

1"*

(2.5 cm)

18" min.* (45.72 cm)

31½"

(80 cm)

14" max.* (35.6 cm)

5"**

(12.7 cm)

48 in.

(310 cm2)

24 in.

(155 cm2)

A. Side view - closet or confined area B. Closet door with vents

*Required spacing

**For side or bottom venting, 0" (0 cm) spacing is allowed.

Recessed or closet installation - Dryer on pedestal

(7.6 cm)

14" max.* (35.6 cm)

18" min.* (45.72 cm)

3"*

(7.6 cm)

3"*

Recommended installation spacing for cabinet installation

 For cabinet installation, with a door, minimum ventilation openings in the top of the

cabinet are required.

7"* (17.8 cm)

*Required spacing

**For side or bottom venting, 0" (0 cm) spacing is allowed.

7"* (17.8 cm)

5"**

(12.7 cm)

31¹₂"

(80.0 cm)

1"* (2.5 cm)

1" 1"

(68.6 cm)

(2.5 cm)

27"

(2.5 cm)

9"* (22.9 cm)

(2.5 cm)

27"

(68.6 cm)

(2.5 cm)

1"*

(2.5 cm)

A. Recessed area B. Side view - closet or confined area

*Required spacing

**For side or bottom venting, 0" (0 cm) spacing is allowed.

31½"

(80 cm)

5"**

(12.7 cm)

Recommended installation spacing for recessed or closet installation, with stacked washer and dryer

The dimensions shown are for the recommended spacing.

48 in.2 *

(310 cm2)

3"* (7.6 cm)

*Required spacing

24 in.

(155 cm2)

1"* (2.5 cm)

6"* (15.2 cm)

76"

(193 cm)

5"*

(12.7 cm)

(2.5 cm)

27"

(68.6 cm)

(2.5 cm)

*Required spacing

Mobile home - Additional installation requirements

This dryer is suitable for mobile home installations. The installation must conform to the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 (formerly the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD Part 280) or Standard CAN/CSA-Z240 MH.

Mobile home installations require:

 Metal exhaust system hardware, which is available for purchase from your dealer.  Special provisions must be made in mobile homes to introduce outside air into the dryer.

The opening (such as a nearby window) should be at least twice as large as the dryer exhaust opening.

Electrical Requirements

WARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

 120 Volt, 60 Hz., AC only, 15- or 20-amp fused electrical supply is required. A time-delay

fuse or circuit breaker is recommended. It is also recommended that a separate circuit serving only this dryer be provided.

GROUNDING INSTRUCTIONS

■

For a grounded, cord-connected dryer: This dryer must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This dryer is equipped with a cord having an equipmentgrounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

WARNING:

Improper connection of the equipmentgrounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative or personnel if you are in doubt as to whether the dryer is properly grounded. Do not modify the plug provided with the dryer: if it will not fit the outlet, have a proper outlet installed by a qualified electrician.

SAVE THESE INSTRUCTIONS

Gas Supply Requirements

WARNING

Explosion Hazard Use a new CSA International approved gas supply line. Install a shut-off valve. Securely tighten all gas connections. If connected to LP, have a qualified person make sure

gas pressure does not exceed 13" (33 cm) water column.

Examples of a qualified person include: licensed heating personnel,

authorized gas company personnel, and authorized service personnel.

Failure to do so can result in death, explosion, or fire.

Gas Type

Natural gas:

This dryer is equipped for use with Natural gas. It is design-certified by CSA International for LP (propane or butane) gases with appropriate conversion.

 Your dryer must have the correct burner for the type of gas in your home. Burner

information is located on the rating plate in the door well of your dryer. If this information does not agree with the type of gas available, contact your dealer or call the phone numbers referenced in the “Assistance or Service” section.

LP gas conversion: Conversion must be made by a qualified technician.

No attempt shall be made to convert the appliance from the gas specified on the model/serial rating plate for use with a different gas without consulting your gas company.

Gas supply line

 Must include

immediately upstream of the gas connection to the dryer. See illustration.



/2” IPS pipe is recommended.



/8” approved aluminum or copper tubing is acceptable for lengths under 20 ft (6.1 m) if

local codes and gas supplier permit.

 If you are using Natural gas, do not use copper tubing.  Lengths over 20 ft (6.1 m) should use larger tubing and a different size adapter fitting.  If your dryer has been converted to use LP gas,

used. If the total length of the supply line is more than 20 ft (6.1 m), use larger pipe. NOTE: Pipe-joint compounds that resist the action of LP gas must be used. Do not use

TEFLON

 Must include a shutoff valve:

In the U.S.A.:

An individual manual shutoff valve must be installed within six (6) feet (1.8 m) of the dryer in accordance with the National Fuel Gas Code, ANSI Z223.1. The location should be easy to reach for opening and closing.

In Canada:

An individual manual shutoff valve must be installed in accordance with the B149.1, Natural Gas and Propane Installation Code. It is recommended that an individual manual shutoff valve be installed within six (6) feet (1.8 m) of the dryer.

The location should be easy to reach for opening and closing.

/8" NPT minimum plugged tapping accessible for test gauge connection,

/8” LP compatible copper tubing can be

®†

tape.

/8” flexible gas connector

/8” pipe to flare adapter fitting

/8” NPT minimum plugged tapping

D. ½" NPT gas supply line

E. Gas shutoff valve

Gas supply connection requirements

 Use an elbow and a

and the dryer gas pipe, as needed to avoid kinking.

 Use only pipe-joint compound. Do not use TEFLON  This dryer must be connected to the gas supply line with a listed flexible gas connector that

complies with the standard for connectors for gas appliances, ANSI Z21.24 or CSA 6.10.

/8” flare x 3/8” NPT adapter fitting between the flexible gas connector

®†

tape.

†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.

Burner input requirements

The gas pipe that comes out through the rear of your dryer has a

/8” male pipe thread.

Elevations above 10,000 ft (3,048 m):

 When installed above 10,000 ft (3,048 m) a 4% reduction of the burner Btu rating shown

on the model/serial number plate is required for each 1,000 ft (305 m) increase in elevation.

Gas supply pressure testing

 The dryer must be disconnected from the gas supply piping system during pressure testing

at pressures greater than ½ psi.

Dryer gas pipe

Venting Requirements

WARNING

1½" (3.8 cm)

*6¼" (15.9 cm)

A. ½" NPT gas supply line

/8” NPT dryer pipe

*NOTE: If the dryer is mounted on a pedestal, the gas pipe height must be an additional 10"

(25.4 cm) or 15.5" (39.4 cm) from the floor, depending on the pedestal model. For a garage installation, the gas pipe height must be an additional 18" (46 cm) from the floor.

If using an existing vent system

 Clean lint from the entire length of the system and make sure exhaust hood is not plugged

with lint.

 Replace any plastic or metal foil vent with rigid or flexible heavy metal vent.  Review vent system chart. Modify existing vent system if necessary to achieve the best

drying performance.

Fire Hazard Use a heavy metal vent. Do not use a plastic vent. Do not use a metal foil vent. Failure to follow these instructions can result in death

or fire.

WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED OUTDOORS.

IMPORTANT: Observe all governing codes and ordinances.

The dryer exhaust must not be connected into any gas vent, chimney, wall, ceiling or a concealed space of a building.

If this is a new vent system

Vent material

 Use a heavy metal vent. Do not use plastic or metal foil vent.  4" (10.2 cm) heavy metal exhaust vent and clamps must be used.

10.2 cm

4" (10.2 cm) heavy metal exhaust vent

Vent products can be purchased from your dealer or by calling Maytag Services. For more information, see the “Assistance or Service” section.

Rigid metal vent

 For best drying performance, rigid metal vents are recommended.  Rigid metal vent is recommended to avoid crushing and kinking.

Flexible metal vent

 Flexible metal vents are acceptable only if accessible for cleaning.  Flexible metal vent must be fully extended and supported when the dryer is in its

final location.

 Remove excess flexible metal vent to avoid sagging and kinking that may result in

reduced airflow and poor performance.

 Do not install flexible metal vent in enclosed walls, ceilings or floors.

Elbows

45° elbows provide better airflow than 90° elbows.

Good Better

Clamps

 Use clamps to seal all joints.  Exhaust vent must not be connected or secured with screws or other fastening devices

that extend into the interior of the duct. Do not use duct tape.

Exhaust

Recommended hood styles are shown here.

(10.2 cm)

4" (10.2 cm)

A. Louvered hood style

B. Box hood style

The angled hood style (shown here) is acceptable.

(10.2 cm)

2½"

(6.4 cm)

 An exhaust hood should cap the vent to keep rodents and insects from entering the home.  Exhaust hood must be at least 12" (30.5 cm) from the ground or any object that may be in

the path of the exhaust (such as flowers, rocks or bushes, snow line, etc.).

 Do not use an exhaust hood with a magnetic latch.

Clamp

Improper venting can cause moisture and lint to collect indoors, which may result in:

Moisture damage to woodwork, furniture, paint, wallpaper, carpets, etc.

Housecleaning problems and health problems.

Plan V ent System

Choose your exhaust installation type

Recommended exhaust installations

Typical installations vent the dryer from the rear of the dryer. Other installations are possible.

A. Dryer B. Elbow C. Wall

D. Exhaust hood

E. Clamps

F. Rigid metal or flexible metal vent G. Vent length necessary to connect elbows H. Exhaust outlet

Optional exhaust installations

This dryer can be converted to exhaust out the right side, left side or through the bottom. If you prefer, you may contact your local dealer to have the dryer converted

A. Standard rear offset exhaust installation B. Left or right side exhaust installation C. Bottom exhaust installation

Alternate installations for close clearances

Venting systems come in many varieties. Select the type best for your installation. Two closeclearance installations are shown. Refer to the manufacturer’s instructions.

A. Over-the-top installation (also available with one offset elbow) B. Periscope installation

NOTE: The following kits for close clearance alternate installations are available for purchase. Please see the “Assistance or Service” section to order.

 Over-the-Top Installation:

Part Number 4396028

 Periscope Installation (For use with dryer vent to wall vent mismatch):

Part Number 4396037 - 0" (0 cm) to 18" (45.72 cm) mismatch Part Number 4396011 - 18" (45.72 cm) to 29" (73.66 cm) mismatch Part Number 4396014 - 29" (73.66 cm) to 50" (127 cm) mismatch

Special provisions for mobile home installations

The exhaust vent must be securely fastened to a noncombustible portion of the mobile home structure and must not terminate beneath the mobile home. Terminate the exhaust vent outside.

Determine vent path

Vent system chart

NOTE: Side and bottom exhaust installations have a 90º turn inside the dryer. To determine

maximum exhaust length, add one 90º turn to the chart.

Number of 90º turns or elbows

0 Rigid metal

1 Rigid metal

2 Rigid metal

3 Rigid metal

4 Rigid metal

Type of vent Box or louvered

hoods

64 ft (20 m)

Flexible metal

36 ft (11 m)

54 ft (16.5 m) 31 ft (9.4 m)

44 ft (13.4 m) 27 ft (8.2 m)

35 ft (10.7 m) 25 ft (7.6 m)

27 ft (8.2 m) 23 ft (7 m)

Angled hoods

58 ft (17.7 m) 28 ft (8.5 m)

48 ft (14.6 m) 23 ft (7 m)

38 ft (11.6 m) 19 ft (5.8 m)

29 ft (8.8 m) 17 ft (5.2 m)

21 ft (6.4 m) 15 ft (4.6 m)

 Select the route that will provide the straightest and most direct path outdoors.  Plan the installation to use the fewest number of elbows and turns.  When using elbows or making turns, allow as much room as possible.  Bend vent gradually to avoid kinking.  Use the fewest 90° turns possible.

Determine vent length and elbows needed for best drying performance

 Use the following Vent system chart to determine type of vent material and hood

combinations acceptable to use. NOTE: Do not use vent runs longer than those specified in the Vent system chart.

Exhaust systems longer than those specified will:

 Shorten the life of the dryer.  Reduce performance, resulting in longer drying times and increased energy usage.

The Vent system chart provides venting requirements that will help to achieve the best drying performance.

Install Vent System

1. Install exhaust hood. Use caulking compound to seal exterior wall opening around

exhaust hood.

2. Connect vent to exhaust hood. Vent must fit inside exhaust hood. Secure vent to exhaust

hood with 4" (10.2 cm) clamp.

3. Run vent to dryer location. Use the straightest path possible. See “Determine vent path” in

“Plan Vent System.” Avoid 90º turns. Use clamps to seal all joints. Do not use duct tape, screws or other fastening devices that extend into the interior of the vent to secure vent.

Install Leveling Legs

WARNING

Excessive Weight Hazard Use two or more people to move and install dryer. Failure to do so can result in back or other injury.

1. To protect the floor, use a large flat piece of cardboard from the dryer carton. Place

cardboard under the entire back edge of the dryer.

2. Firmly grasp the body of the dryer (not the console panel). Gently lay the dryer on the

cardboard. See illustration.

3. Examine the leveling legs. Find the diamond marking.

Make Gas Connection

1. Remove the red cap from the gas pipe.

2. Using a wrench to tighten, connect the gas supply to the dryer. Use pipe-joint compound

on the threads of all non-flared male fittings. If flexible metal tubing is used, be sure there are no kinks.

A. Flared male fitting B. Non-flared male fitting

NOTE: For LP gas connections, you must use pipe-joint compound resistant to the action of LP gas. Do not use TEFLON

A combination of pipe fittings must be used to connect the dryer to the existing gas line. Shown is a recommended connection. Your connection may be different, according to the supply line type, size and location.

®†

tape.

4. Screw the legs into the leg holes by hand. Use a wrench to finish turning the legs until the

diamond marking is no longer visible.

5. Place a carton corner post from dryer packaging under each of the 2 dryer back corners.

Stand the dryer up. Slide the dryer on the corner posts until it is close to its final location. Leave enough room to connect the exhaust vent.

/8” flexible gas connector

/8” dryer pipe

/8” to 3/8” pipe elbow

/8” pipe-to-flare adapter fitting

†

TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.

3. Open the shutoff valve in the supply line. The valve is open when the handle is parallel to

the gas pipe.

A. Closed valve B. Open valve

4. Test all connections by brushing on an approved noncorrosive leak-detection solution.

Bubbles will show a leak. Correct any leak found.

Connect Vent

1. Using a 4" (10.2 cm) clamp, connect vent to exhaust outlet in dryer. If connecting to

existing vent, make sure the vent is clean. The dryer vent must fit over the dryer exhaust outlet and inside the exhaust hood. Check that the vent is secured to exhaust hood with a 4" (10.2 cm) clamp.

2. Move dryer into its final location. Do not crush or kink vent.

3. Check that there are no kinks in the flexible gas line.

4. Once the exhaust vent connection is made, remove the corner posts and cardboard.

Connect Inlet Hose

The dryer must be connected to the cold water faucet using the new inlet hoses. Do not use old hoses.

1. Turn cold water faucet off and remove washer inlet hose.

2. Remove old rubber washer from inlet hose and replace with new rubber washer provided.

If space permits, attach the brass female end of the “Y” connector to the cold water faucet. NOTE: If “Y” connector can be attached directly to cold water faucet, go to Step 6. If “Y”

connector cannot be attached directly to the cold water faucet, the short hose must be used. Continue with Step 3.

3. Attach short hose to cold water faucet. Screw on coupling by hand until it is seated on

faucet.

4. Using pliers, tighten the couplings with an additional two-thirds turn.

NOTE: Do not overtighten. Damage to the coupling can result.

5. Attach “Y” connector to brass male end of small hose. Screw on coupling by hand until it

is seated on connector.

6. Attach straight end of long hose to “Y” connector.

7. Attach washer cold inlet hose to other end of “Y” connector. Screw on coupling by hand

until it is seated on connector.

8. Using pliers, tighten the couplings with an additional two-thirds turn.

A. Inlet to cold water

NOTE: Do not overtighten. Damage to the coupling can result.

9. Attach angled end of long hose to fill valve at bottom of dryer back panel. Screw on

coupling by hand until it is seated on fill valve connector.

10. Using pliers, tighten the coupling with an additional two-thirds turn.

WARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

NOTE: Do not overtighten. Damage to the coupling can result.

11. Check that the water faucets are on.

12. Check for leaks around “Y” connector, faucet and hoses.

Level Dryer

Check the levelness of the dryer. Check levelness first side to side, then front to back.

If the dryer is not level, prop up the dryer using a wood block. Use a wrench to adjust the legs up or down and check again for levelness.

Complete Installation

1. Check that all parts are now installed. If there is an extra part, go back through the steps to

see which step was skipped.

2. Check that you have all of your tools.

3. Dispose of/recycle all packaging materials.

4. Check the dryer’s final location. Be sure the vent is not crushed or kinked.

5. Check that the dryer is level. See “Level Dryer.”

6. Plug into a grounded 3 prong outlet. Turn on power.

7. Remove any protective film or tape remaining on the dryer.

8. Be sure the water faucets are on.

9. Check for leaks around “Y” connector, faucet and hoses.

10. Read “Dryer Use.”

11. Wipe the dryer drum interior thoroughly with a damp cloth to remove any dust.

12. Set the dryer on a full heat cycle (not an air cycle) for 20 minutes and start the dryer. If the dryer will not start, check the following:

 Controls are set in a running or “On” position.  Start button has been pushed firmly.  Dryer is plugged into a grounded 3 prong outlet.  Electrical supply is connected.  Household fuse is intact and tight, or circuit breaker has not tripped.  Dryer door is closed.  This dryer automatically runs an installation diagnostic routine at the start of its first

cycle.

NOTE: You may notice an odor when the dryer is first heated. This odor is common when the heating element is first used. The odor will go away.

13. When the dryer has been running for 5 minutes, open the dryer door and feel for heat. If you feel heat, cancel cycle and close door. If you do not feel heat, turn off the dryer and check that the gas supply line shutoff valve is open.

 If the gas supply line shutoff valve is closed, open it, then repeat the 5-minute test as

outlined above.

 If the gas supply line shutoff valve is open, contact a qualified technician.

14. If you live in a hard water area, use of a water softener is recommended to control the buildup of scale through the water system in the dryer. Over time, the buildup of lime scale may clog different parts of the water system, which will reduce product performance. Excessive scale buildup may lead to the need for certain part replacement or repair.

DRYER USE

Starting Your Dryer

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as gasoline, away from dryer.

Do not dry anything that has ever had anything flammable on it (even after washing).

Failure to follow these instructions can result in death, explosion, or fire.

WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance.

This manual covers several different models. Your dryer may not have all of the cycles and features described.

The following is a guide to starting your dryer. Please refer to specific sections of this manual for more detailed information.

1. Clean lint screen before each load. See “Cleaning the Lint Screen.”

2. Place laundry in dryer and shut door.

3. Press the POWER/CANCEL button then rotate the dial to select either a Sensor, Timed, or

Steam Cycle. The preset settings and drying time for the cycle chosen will be displayed.

WARNING

Fire Hazard No washer can completely remove oil. Do not dry anything that has ever had any type of oil on

it (including cooking oils). Items containing foam, rubber, or plastic must be dried

on a clothesline or by using an Air Cycle. Failure to follow these instructions can result in death

or fire.

To use a Sensor Cycle

 Press the POWER/CANCEL button.  Rotate the dial to select a Sensor Cycle.  The default dryness setting is Normal in all Sensor Cycles. This dryness level will dry

most loads adequately using the least amount of energy. You can select a different dryness level by pressing SENSOR CYCLES DRYNESS and choosing More Dry,

Normal, or Less Dry. Selecting More Dry, Normal, or Less Dry automatically adjusts the dryness level at which the dryer will shut off.

 Press the WRINKLE PREVENT feature button if this option is desired.  Press the SIGNAL ON/OFF button to set the end of cycle signal.  Press and hold START/PAUSE button until dryer starts (about 1 second).

The Wrinkle Prevent and Cycle Signal features can be adjusted during a Sensor Cycle. If you want to select another Sensor Cycle or Sensor Cycle Dryness, press START/PAUSE once to stop the dryer, make the desired changes, then press START/PAUSE to resume drying.

NOTES:

 A default time is displayed when a Sensor Cycle is selected. During the first few

minutes of the drying process, the cycle time may automatically vary from the default time based on the size and fabric type of the load. Toward the end of the drying process, the estimated time display will adjust again, showing the final drying time.

 Time and Temperature are not adjustable for Sensor Cycles. Pressing the TIME

ADJUST or TIMED CYCLES TEMP buttons will cause a triple beep, indicating that the time cannot be changed.

 A light next to each feature will glow yellow when the feature is selected. The light

will not glow when the selection is unavailable with the cycle or option combinations selected.

 Sensor Cycles Dryness can be changed only with Sensor Cycles. This feature is not

selectable for Timed, Steam, or Sanitize cycles.

How Sensor Cycles Work

The Sensi-Care

drying system improves performance with Auto Moisture Sensing Plus, which advances the cycle as moisture is extracted from clothing. A thermistor (electronic temperature sensor) and moisture sensing strips in the dryer drum help measure the amount of moisture in the clothes as they tumble. An electronic control determines the load type to help save time, avoid overdrying, and increase the accuracy of the end dryness level. After the first 5 minutes of a Sensor cycle, the estimated time display will adjust based on the approximate load size, cycle, dryness level selected and amount of moisture left in the clothes. When the clothes have reached approximately 80% of the dryness level selected, the estimated time display will adjust again, showing the final drying time. Sensi-Care

takes the guesswork out of drying time and enhances fabric

care.

To use a Timed Cycle

 Press POWER/CANCEL.  Rotate the dial to select a Timed Cycle.  Press the TIME ADJUST up or down buttons until the desired drying time is displayed.

Press TIME ADJUST, and the time will change by 1-minute intervals. Press and hold TIME ADJUST, and the time will change by 5-minute intervals. The initial time displayed is the actual drying time.

The Time Adjust feature can be used only with Timed Cycles.

 Press TIMED CYCLES TEMP until the desired temperature glows yellow.

Temperature settings can be changed only with Timed Cycles.

NOTES:

 Sensor Cycles Dryness is not adjustable for Timed, Steam, or Sanitize Cycles. Pressing

the SENSOR CYCLE DRYNESS button will cause the triple beep indicating that this option is not selectable.

 A light next to each feature will glow yellow when the feature is selected. The light

will not glow when the selection is unavailable with the cycle or option combinations selected.

 While a Timed Cycle is running, you can change the settings for Time, Temperature,

the WRINKLE PREVENT feature and the cycle signals. Press the START/PAUSE button once to stop the dryer, allowing you to select another cycle.

+ 42 hidden pages
