Maytag S-8 User Manual

SD-8

Use & Care Guide

Table of Contents

Safety . . . . . . . . . . . . . . . . . . . 1-2

Using the Controls . . . . . . . . . 3-5

Select Temperature Select Signal Select Cycle Select Options Press Start

Operating Tips . . . . . . . . . . . . . . 6

Clean the Lint Filter Load the Dryer Properly

Accessories . . . . . . . . . . . . . . . . 6

Care & Cleaning . . . . . . . . . . . . . 7

Control Panel Tumbler Cabinet Dryer Exhaust System Special Laundry Tips

Door Reverse . . . . . . . . . . . . . . . 8

Dryer Exhaust Tips . . . . . . . . . . . 9

Troubleshooting . . . . . . . . . . . . 10

Service & Warranty . . . . . . . . . 11

Guide d’utilisation et

d’entretien . . . . . . . . . . . . . . 12

Guía de uso y cuidado . . . . . . .24

For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death.

• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

Installation and service must be performed by a qualified installer, service agency or the gas supplier.

WARNING

Safety

WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death.

WARNING

CAUTION – Hazards or unsafe practices which COULD result in minor personal injury.

CAUTION

Installer: Please leave this manual with this appliance.

Consumer: Please read and keep this manual for future reference. Keep sales receipt and/or canceled check as proof of purchase.

Model Number _______________________________

Serial Number ________________________________

Date of Purchase______________________________

If you have questions, call: Maytag Customer Assistance

1-800-688-9900 U.S.A. 1-800-688-2002 Canada (Mon.–Fri. 8 a.m.–8 p.m. Eastern Time) Internet: http://www.maytag.com

U.S.A. Customers using TTY for deaf, hearing impaired or speech impaired, call 1-800-688-2080.

In our continuing effort to improve the quality and performance of our appliances, it may be necessary to make changes to the appliance without revising this guide.

For service information, see page 11.

What You Need to Know About Safety Instructions

Warning and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating appliance.

Always contact your dealer, distributor, service agent or manufacturer about problems or conditions you do not understand.

Recognize Safety Symbols, Words, Labels

WARNING! FIRE HAZARD

Do not place into your dryer items that have been spotted or soaked with vegetable oil or cooking oil. Even after being washed, these items may contain significant amounts of these oils. The remaining oil can ignite spontaneously. The potential for spontaneous ignition increases when the items containing vegetable oil or cooking oil are exposed to heat. Heat sources, such as your clothes dryer, can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this heat cannot escape, the items can become hot enough to catch fire. Piling, stacking or storing these kinds of items may prevent heat from escaping and can create a fire hazard.

All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous. Washing these items in hot water with extra detergent will reduce, but will not eliminate, the hazard. Always use the Cool Down cycle for these items to reduce the items’ temperature. Never remove these items from the clothes dryer hot or interrupt the drying cycle until the items have run through the Cool Down cycle. Never pile or stack these items when they are hot.

1. Read all instructions before using the appliance.

2. To avoid the possibility of fire or explosion: a. Do not dry items that have been previously

cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flammable or explosive substances as they give off vapors that could ignite or explode. Any material on which you have used a cleaning solvent, or which is saturated with flammable liquids or solids, should not be placed in the dryer, until all traces of these flammable liquids or solids and their fumes have been removed. There are many highly flammable items used in homes, such as: acetone, denatured alcohol, gasoline, kerosene, some liquid household cleaners, some spot removers, turpentine, waxes and wax removers.

b. Items containing foam rubber (may be labeled

latex foam) or similarly textured rubber-like materials must not be dried on a heat setting. Foam rubber materials when heated, can under certain circumstances produce fire by spontaneous combustion.

3. Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary when the appliance is used near children and pets.

4. Before the appliance is removed from service or discarded, remove the door to the drying compartment.

5. Do not reach into the appliance if the drum is moving.

6. Do not install or store this appliance where it will be exposed to the weather.

7. Do not tamper with controls.

8. Do not repair or replace any part of the appliance or attempt any servicing unless specifically recommended in published user-repair instructions that you understand and have the skills to carry out.

9. Do not use fabric softeners or products to eliminate static unless recommended for dryer use by the manufacturer of the fabric softener or product.

To reduce the risk of fire, explosion, electric shock, or personal injury when using your dryer, follow basic safety precautions, including the following:

WARNING

Gas leaks may occur in your system and result in a dangerous situation. Gas leaks may not be detected by smell alone. Gas suppliers recommend you purchase and install an UL approved gas detector. Install and use in accordance with the manufacturer's instructions.

WARNING

10. Clean the lint screen before or after each load.

11. Keep the area around the exhaust opening and surrounding areas free from lint accumulation, dust and dirt.

12. The interior of the dryer and exhaust duct should be cleaned periodically by qualified service personnel.

13. This appliance must be properly grounded. Never plug the appliance cord into a receptacle which is not grounded adequately and in accordance with local and national codes. See installation instructions for grounding this appliance.

14. Do not sit on top of the clothes dryer.

Important Safety Notice & Warning

The California Safe Drinking Water and Toxic Enforcement Act of 1986 (Proposition 65) requires the Governor of California to publish a list of substances known to the State of California to cause cancer or reproductive harm, and requires businesses to warn customers of potential exposures to such substances.

Users of this appliance are hereby warned that the burning of gas can result in low–level exposure to some of the listed substances, including benzene, formaldehyde, and soot, due primarily to the incomplete combustion of natural gas or liquid petroleum (LP) fuels. Exhaust ducts should be kept free of obstructions and properly exhausted dryers will minimize exposure.

Safety

SAVE THESE INSTRUCTIONS

Note

• Because of continuing product improvements, Maytag reserves the right to change specifications without notice. For complete details, see the Installation Instructions packed with your product before selecting cabinetry, making cutouts or beginning installation.

STEP 1

STEP 2

Using the Controls

Select Temperature

To select the temperature, turn the temperature control to Regular, Medium, Delicate or Air Fluff.

DRYER TEMPS

Regular

Medium

(select models)

Delicate

Air Fluff

LOAD TYPE

For sturdy cottons or those labeled Tumble Dry.

For permanent press, synthetics, lightweight cottons or items labeled Tumble Dry Medium.

For heat sensitive items labeled Tumble Dry Low or Tumble Dry Warm.

Tumbles without heat. Used for sensitive loads or items needing freshening.

Select Signal (select models)

End of Cycle Signal

Shortly before the cycle is complete, an audible signal will sound. During the cool down portion of the Wrinkle Free Fabrics cycle, the audible signal will sound intermittently.

On select models, the signal can be turned off by moving the knob to OFF.

Cycles and options may vary by model.

Using the Controls

Select Cycle

To select a cycle, rotate the control dial to the desired setting. When using an Auto Dry cycle, the control dial should point between More Dry and Less Dry for most loads.

Loads of larger or bulkier size may require the More Dry setting to completely dry the load. The Less Dry setting is best suited for lightweight fabrics or for leaving some moisture in the clothing at the end of the cycle.

Auto Dry Regular

The Auto Dry Regular cycle is designed to dry loads such as towels, underwear, t-shirts, jeans, etc.

Auto Dry Wrinkle Free Fabrics

The Auto Dry Wrinkle Free Fabrics cycle is designed to dry wrinkle free cottons, synthetic fabrics, double knits and permanent press fabrics automatically. It minimizes wrinkling by providing a longer unheated cool-down period at the end of the cycle.

Time Dry Air Fluff

This cycle can be used to regulate the drying time. Use with Air Fluff, Delicate, Medium (select models) or Regular temperature settings. For timed drying, turn the control dial until the pointer points to the proper time setting in the Time Dry Air Fluff cycle.

Note

• Using the Air Fluff temperature setting will require a longer drying time.

STEP 3

Special Options (select models)

Damp Dry is located on the Time Dry Air Fluff section

of the dial. It is designed to partially dry items and can be used with any temperature selection. Damp Dry will provide 20 minutes of tumbling time, followed by five minutes of cool-down tumbling.

Wrinkle Release will release wrinkles from items that are clean and dry but only slightly wrinkled, such as from a crowded closet or suitcase, or from sitting in the dryer too long after the cycle has ended. Wrinkle Release provides 10 minutes of tumbling followed by five minutes of cool-down tumbling and can be used with any temperature selection.

Note

•The dial can be turned in either direction to select a cycle. Once started, the dial will not advance at a specific rate during the Auto Dry cycles. At first the dial may not advance at all. Toward the end of the cycle (when the load begins to dry) the dial will advance at a more regular rate and much more quickly. This is normal operation.

STEP 5

Press Start

Push this button to start the dryer. The dryer door must be shut for the dryer to operate. If the door is opened during the cycle, the Start button must be pushed again to resume the cycle once the door is closed.

STEP 4

Select Options

Extended Tumble (select models)

Extended Tumble is provided to minimize wrinkles in the Auto Dry Wrinkle Free Fabrics cycle. This feature provides an extra 20 minutes of unheated tumble action at the end of the cycle. Clothes can be removed any time during this portion of the cycle. The additional 20 minutes of unheated tumbling can be cancelled by setting the switch to OFF.

Using the Controls

Operating Tips

Accessories

Optional Drying Rack

Select dryer models are equipped with a drying rack. The drying rack is useful for drying items that require no tumble drying, such as tennis shoes, sweaters, stuffed toys or other delicate items.

Note

• Do not operate the dryer without the lint filter in place.

Clean the Lint Filter

• After each load.

•To shorten drying time.

•To operate more energy efficiently.

Load the Dryer Properly

• Place only one washload in the dryer at a time.

• Mixed loads of heavy and lightweight clothes will dry differently. Lightweight clothes will dry, while heavy clothes may be damp.

• Add one or more similar items to the dryer when only one or two articles need drying. This improves the tumbling action and drying efficiency.

• Overloading restricts tumbling action, resulting in uneven drying as well as excessive wrinkling of some fabrics.

•When drying large, bulky items such as a blanket or comforter, it may be necessary to reposition the load during the cycle to ensure even drying.

Note

•The Drying Rack, part no. 504105, is available when not included with your dryer. See your dealer or call 1-877-232-6771 to order.

Care & Cleaning

Control Panel

Clean with a soft, damp cloth. Do not use abrasive substances.

Tumbler

Remove any stains such as crayon, ink pen or fabric dye from new items (such as towels or jeans) with an all-purpose cleaner. Then tumble old towels or rags to remove any excess stain or cleaning substance. Once these steps are done, stains may still be visible, but should not transfer to subsequent loads.

Cabinet

Wipe off any marks with soap and water. Use an appliance wax once a year if desired.

Dryer Exhaust System

Inspect and clean once a year to maintain optimum performance. The outside exhaust hood should be cleaned more frequently to ensure proper operation. (Refer to the Installation Instructions for more information.)

LAUNDERING TIPS

•Follow the care label instructions or dry on the Regular cycle.

• Be sure the item is thoroughly dry before using or storing.

• May require repositioning to ensure even drying.

•Dry only one blanket at a time for best tumbling action.

• Be sure the item is thoroughly dry before using or storing.

• Use the Wrinkle Free Fabrics cycle to help minimize wrinkling.

• Dry in small loads for best results and remove as soon as possible.

• Use the Regular cycle for soft, fluffy diapers.

• Use the Regular cycle and a delicate temperature setting.

•Place a clean pair of sneakers in the dryer with the item to fluff the down comforters, etc. Adding a couple of dry towels shortens dry time and absorbs moisture.

•DO NOT dry on a heat setting. Use the Time Dry/Air Fluff (no-heat) cycle.

•WARNING – Drying a rubber item with heat may damage it or be a fire hazard.

•DO NOT dryer-dry kapok or foam pillows.

• Use the Regular cycle.

• Add a couple of dry towels and a pair of clean sneakers to help the tumbling action and to fluff the item.

• Use the Time Dry/Air Fluff cycle on a Delicate or Air Fluff temperature depending on the care label instructions.

IMPORTANT: Avoid Dryer Drying . . .

• Fiberglass Items (curtains, draperies, etc.).

• Woolens, unless recommended on the label.

• Vegetable or cooking oil soaked items (see page 2).

ITEM

Bedspreads and Comforters

Blankets

Curtains and Draperies

Cloth Diapers Down-Filled

Items (jackets,

sleeping bags, comforters, etc.)

Foam Rubber

(rug backs, stuffed toys, certain shoulder pads, etc.)

Pillows

Plastics

(shower curtains, outdoor furniture covers, etc.)

Special Laundry Tips

Please follow the care label or manufacturer’s instructions for drying special items. If care label instructions are not available, use the following information as a guide.

Reversing the Door

Follow these steps to reverse the door:

1. Remove four hinge-attaching screws.

2. Remove all nine screws from door and hinges.

3. Pull bottom of door liner out (A), then pull down (B), removing door liner from door panel.

4. Rotate door panel 180° as shown.

5. Remove door strike from door liner and reinstall on opposite side.

6. Insert liner under flange on bottom of door (A), then push top of door liner into place (B).

7. Reinstall nine screws removed in Step 2.

8. Using screwdriver, remove two door plugs and reinstall on opposite side of door opening.

9. Reinstall four hinge attaching screws removed in Step 1.

Door Reverse

Read the installation instructions and the use and care guide.

Let your dryer exhaust the air easily.

Use 4" diameter rigid metal duct. Tape all joints, including at the dryer. Never use lint-trapping screws.

Keep duct runs as straight as possible.

Clean all old ducts before installing your new dryer. Be sure vent flap opens and closes freely. Inspect and clean the exhaust system annually.

Don’t

Allow crushed or clogged ducts and vent.

Don’t

Use longer than necessary duct runs with many elbows.

Don’t

Use plastic, thin foil, or non-metal flexible duct.

Don’t

Restrict your dryer with a poor exhaust system.

Don’t

Let a poor exhaust system cause slow drying.

Plastic or nonmetal flexible duct presents a potential fire hazard.

WARNING

Dryer Exhaust Tips

Troubleshooting

• Be sure the door is shut.

• Is the electrical cord plugged in?

• Has a fuse blown or the circuit breaker tripped?

•Push the Start button again if the door was opened during the cycle.

• Has a fuse blown or the circuit breaker tripped?

• Select a heat setting, not air fluff.

• Check that the gas supply is on for gas dryers.

• Clean the lint filter and exhaust duct.

• Dryer time may have moved into the cool-down portion of the cycle.

• Check all of the above, plus . . .

• Check the exhaust hood outside the house, does it open and close freely?

• Check exhaust system for lint buildup. Ducting should be inspected and cleaned annually.

• Use rigid 4" metal exhaust duct.

• Do not overload. 1 wash load = 1 dryer load.

• Sort heavy items from lightweight items.

•Large, bulky items like blankets or comforters may require repositioning to ensure even drying.

• Check the washer to be sure it is draining properly to extract water from the load.

•Clothes load is too small to tumble properly. Add a few towels.

• Check the load for objects such as coins, nails, etc. Remove promptly from dryer.

• It is normal to hear the dryer gas valve or heating element cycle on and off during the drying cycle.

•The dryer should be level and installed on a solid floor.

• Be sure the rubber feet are installed on the leveling legs.

•A clicking noise may be the timer advancing.

•It is normal for the dryer to hum due to the high velocity of air moving through the dryer drum and exhaust system.

•This is normal operation for an Auto Dry cycle, especially at the beginning of cycle. Once the load begins to dry, the control knob will start to advance. The rate of advancement will be slow at the beginning of the cycle because there is more moisture in the load. As the load becomes more dry, the control knob will advance more quickly.

• Seams, pockets and other similar heavy areas may not be completely dry when the rest of the load has reached the selected dryness level. This is normal. Select the More Dry setting if desired.

• If one heavy item is dried with a lightweight load, such as one towel with sheets, it is possible that the heavy item will not be completely dry when the rest of the load has reached the selected dryness level. Sort heavy items from lightweight items for best drying results.

• Household odors such as from painting, varnishing, strong cleaners, etc. may enter the dryer with the surrounding room air. This is normal as the dryer draws the air from the room, heats it, pulls it through the tumbler and exhausts it to the outside. When these odors are present in the air, ventilate the room completely before using the dryer.

For further assistance contact Maytag ServicesSM, Maytag Customer Assistance: U.S.A. 1-800-688-9900 or

Canada 1-800-688-2002. U.S.A. Customers using TTY for deaf, hearing impaired or speech impaired, call 1-800-688-2080.

Doesn’t Run

Doesn’t Heat

Doesn’t Dry Properly

Is Noisy

Control Knob Advances Slowly

Dries Unevenly

Has an Odor

+ 25 hidden pages
