Maytag MDB7851AWS1, MDB7851AWB1, MDBM601AWS0, MDBM601AWQ0, MDBS561AWB2 Owner’s Manual

THANK YOU for purchasing this high-quality product. If you should experience a problem not covered inTROUBLESHOOTING,
please visit our website at www.maytag.com for additional information. If you still need assistance, call us at 1-800-688-9900.
In Canada, visit our website at www.maytag.ca or call us at 1-800-807-6777.

You will need your model and serial number located near the door on the right-hand or left-hand side of the dishwasher interior.
Para obtener acceso a "lnstrucciones para elusuario de la lavavajillas" en espafiol, o para informaci6n adicional acerca de su

producto visite: www.maytag.com
Tenga listo su nQmero de modelo completo. Puede encontrar su nQmerode modelo y de serieen laetiqueta ubicada cerca de la

puerta al lado derecho o izquierdo del interior de la lavavajillas.

, J- /

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety

messages.

This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."

These words mean:

You can be killed or seriously injured if you don't immediately
follow instructions.

You can be killed or seriously injured if you don't follow

instructions.

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: When using the dishwasher, follow basic precautions, including the following:

[] Read all instructions before using the dishwasher. [] Do not tamper with controls.
[] Use the dishwasher only for its intended function.
[] Use only detergents or rinse agents recommended for use in a

dishwasher, and keep them out of the reach of children.

[] When loading items to be washed:

1) Locate sharp items so that they are not likely to damage the
door seal; and

2) Load sharp knives with the handles up to reduce the risk of cut-
type injuries.

[] Do not wash plastic items unless they are marked "dishwasher

safe" or the equivalent. For plastic items not so marked, check the
manufacturer's recommendations.

[] Do not touch the heating element during or immediately after use.
[] To avoid electrical shock hazard, the sides and back must be

enclosed and the front panels must be attached before electrical
power is applied to the dishwasher. Refer to the installation
instructions for proper grounding procedures.

[] Do not abuse, sit on, or stand on the door, lid, or dish

racks of the dishwasher.

[] To reduce the risk of injury, do not allow children to

play in or on the dishwasher.

[] Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS

EXPLOSIVE. If the hot water system has not been
used for such a period, before using the dishwasher

turn on all hot water faucets and let the water flow
from each for several minutes. This will release any

accumulated hydrogen gas. As the gas is flammable,
do not smoke or use an open flame during this time.

[] Remove the door or lid to the washing compartment

when removing an old dishwasher from service or
discarding it.

SAVE THESE INSTRUCTIONS

W10157791A

GROUNDING iNSTRUCTiONS

For a grounded, cord-connected dishwasher:

The dishwasher must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for
electric current. The dishwasher is equipped with a cord
having an equipment-grounding conductor and a grounding

plug. The plug must be plugged into an appropriate outlet

that is installed and grounded in accordance with all local
codes and ordinances.

WARNING: Improper connection of the equipment-

grounding conductor can result in a risk of electric shock.

SAVE THESE iNSTRUCTiONS

Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.

Check with a qualified electrician or service representative

if you are in doubt whether the dishwasher is properly
grounded. Do not modify the plug provided with the
dishwasher; if it will not fit the outlet, have a proper outlet

installed by a qualified electrician.

For a permanently connected dishwasher:
The dishwasher must be connected to a grounded metal,

permanent wiring system, or an equipment-grounding
conductor must be run with the circuit conductors and

connected to the equipment-grounding terminal or lead on
the dishwasher.

Tip Over Hazard

Prepare and load

dishwasher.

for cleaning and

rinse aid for

drying.

Add detergent _

S%

Prepare and Load the Dishwasher
IMPORTANT: Remove leftover food, bones, toothpicks and other

hard items from the dishes. Remove labels from containers before
washing.

Upper rack Lower rack

Select a cycle and option.

Cycles

Auto

Clean

Options

_ Start dishwasher. .......

_ SlAPJy

Make sure nothing keeps spray arm(s) from
spinning freely. It is important for the water
spray to reach all soiled surfaces.

• Make sure that when the dishwasher door is closed no items
are blocking the detergent dispenser.

• Items should be loaded with soiled surfaces facing down and
inward to the spray as shown. This will improve cleaning and
drying results.

• Avoid overlapping items like bowls or plates that may trap food.

• Place plastics, small plates and glasses in the upper rack.
Wash only plastic items marked "dishwasher safe."

f_

Toavoidthumping/clatteringnoisesduringoperation:Load

dishessotheydonottouchoneanother.Makesurelightweight
loaditemsaresecuredintheracks.

Whenloadingsilverware,alwaysplacesharp
itemspointingdownandavoid"nesting"as

shown.

STEP 2

Add Detergent

NOTE: If you do not plan to run a wash cycle soon, run a rinse

cycle. Do not use detergent.

• Use automatic dishwasher detergent only. Add powder, liquid
or tablet detergent just before starting a cycle.

Fresh automatic
dishwasher detergent

results in better
cleaning. Store tightly
closed detergent

container in a cool,
dry place.

• The amount of detergent to use depends on:
How much soil remains on the items - Heavily soiled loads

require more detergent.

The hardness of the water - If you use too little in hard water,

dishes won't be clean. If you use too much in soft water,
glassware will etch.

Soft to Medium Water (0-6 grains per U.S. gallon)
[typical water softener water and some city water]

Medium to Hard Water (7-12 grains per U.S. gallon)
[well water and some city water]

• Depending on your water hardness, fill the Main Wash section
of the dispenser as shown. Fill the Pre-Wash section to the
level shown, if needed.

NOTE: Fill amounts shown

are for standard powdered
detergent. Follow

instructions on the package

when using other
dishwasher detergent.

Add Rinse Aid

• Your dishwasher is designed to use rinse aid for good drying
performance. Without rinse aid your dishes and dishwasher
interior will have excessive moisture. The heat dry option will
not perform as well without rinse aid.

• Rinse aid keeps water from forming droplets that can dry as

spots or streaks. They also improve drying by allowing water to

drain off of the dishes after the final rinse.

• Rinse aid helps to reduce excess moisture on the dish racks
and interior of your dishwasher.

• Check the rinse aid indicator. Add rinse aid when indicator
drops to "Refill" level.

A ............

A. Cover latch
B. Main Wash section
C. Pre-Wash sec#on

MainWash Pre-Wash

To add rinse aid, turn the dispenser
cap counterclockwise and lift off. Pour
rinse aid into the opening until the
indicator window looks full. Replace
the dispenser cap and turn clockwise.
Make sure cap is fully locked.

turn to lock

NOTE: For most water conditions, the
factory setting of 2 will give good results. Ifyou

have hard water or notice rings or spots, try a
higher setting. Turn the arrow adjuster inside the

dispenser by either using your fingers or inserting a

flat-blade screwdriver intothe center of the arrow ....

and turning.

STEP 3

Select a Cycle (cycles vary by model)

NOTE: Heavier cycles and options affect cycle length. Some
cycles and options will take up to 3V2hours to complete.

Cycles

..........................

.... ..... Auto ....

Heavy Wash - Use for heavily soiled, hard-to-clean items.
Normal Wash - Use for normal food soil. The energy usage label

is based on this cycle.
Light Wash - Use for light food soil.

Rinse Only- (no options apply to this cycle) Do not use detergent.

This is only a rinse that keeps food from drying on your dishes and

reduces odor buildup in your dishwasher until you are ready to
wash a full load.

Insta Wash - Quick cycle for light food soils.

Auto Clean - Use for automatically selecting the number of water

fills best suited for the soil level.

Select Options (options vary by model)

You can customize

your cycles by

pressing the options
desired.

Heated Dry - (all cycles except Rinse Only) use for best drying
results. Turn off by pressing Heat Dry so that the light goes off.

Delay Hours- (any cycle) offers the choice to start the dishwasher
automatically at a later time. Select a wash cycle and options.

Press Delay Hours. Press START/Cancel. Close the door firmly.
Sanitize - (all cycles except Insta Wash and Rinse Only) To

sanitize your dishes and glassware in accordance with NSF/ANSI
Standard 184 for Residential Dishwashers. Raises the water

temperature in the final rinse to approximately 155°F (68°C).
Certified residential dishwashers are not intended for licensed food

establishments.

Tough Scrub (or Tough Scrub Plus) - Use for heavy food soils

and lightly baked-on or dried-on food.
Hi-Temp Wash - (use only with Pots & Pans and Normal wash

cycles) heats the water during the wash portions of the cycle.

Options

iiiiiiiii_

STEP 4

Start or Resume a Cycle

• Run hot water at the sink nearest your dishwasher until the

water is hot. Turn off water.

Push door firmly closed. The door latches
automatically. Select the wash cycle and options
desired OR press START/Cancel to repeat the

same cycle and options as in the previous wash

cycle.

Cleaning the Dishwasher
Clean the exterior of the dishwasher with a soft, damp cloth and
mild detergent. Ifyour dishwasher has a stainless steel exterior, a

stainless steel cleaner is recommended - Stainless Steel Cleaner
and Polish Part Number 31464.

Clean the interior of the dishwasher, with a paste of powdered
dishwasher detergent and water or use liquid dishwasher detergent

on a damp sponge to clean the cooled-down interior.
A white vinegar rinse may remove white spots and film. Vinegar is

an acid, and using it too often could damage your dishwasher.

Put 2 cups (500 mL) white vinegar in a glass or dishwasher-safe

measuring cup on the bottom rack. Run the dishwasher through a
complete washing cycle using an air-dry or an energy-saving dry

option. Do not use detergent. Vinegar will mix with the wash water.

¸¸:¸¸¸¸¸¸¸¸START/i

Cancel

You can add an item anytime before the main wash starts.
Open the door slowly and add the item. Close the door firmly.
Lights will stop flashing when the door is properly shut. After a
slight delay, the cycle resumes automatically at the point of
interruption.

If you have a drain air gap, _1
check and clean it if the _P"

dishwasher isn't draining
well.

Storing the Dishwasher
If you will not be using the dishwasher during the summer months,

turn off the water and power supply to the dishwasher. In the
winter, if the dishwasher could be exposed to near freezing

temperatures or is left in aseasonal dwelling such as a second
home or vacation home, avoid water damage by having your

dishwasher winterized by authorized service personnel.

|

First try the solutions suggested here or visit our website and reference FAQs (Frequently Asked Questions)

to possibly avoid the cost of a service call.

In the U.S.A., www.maytag.com In Canada, www.maytag.ca

Dishwasher is not operating properly

• Dishwasher does not run or stops during a cycle
Is the door closed tightly and latched?

Is the right cycle selected?
Is there power to the dishwasher? Has a household fuse blown,

or has a circuit breaker tripped? Replace the fuse or reset the
circuit breaker. If the problem continues, call an electrician.

Has the motor stopped due to an overload? The motor
automatically resets itself within a few minutes. If it does not

restart, call for service.
Is the water shutoff valve (if installed) turned on?
It is normal for certain cycles to repeatedly pause for several

seconds during the main wash.

• Clean light is flashing
Call for service.

• Dishwasher will not fill
Is the overfill protection float able to

move up and down freely? Press down

to release.

Dishwasher seems to run too long

The dishwasher can run up to 3Y2hours depending on soil

level, water temperature, cycles and options.
Is the water supplied to the dishwasher hot enough? The

dishwasher runs longer while heating water.
Is the dishwasher cycle time within the cycle times? See cycle

sections wash times. A delay automatically occurs in some
wash and rinse cycles until the water reaches the proper

temperature.

This dishwasher is equipped with an optical sensor wash that
detects water temperature, soil and detergent amount. Wash

cycles are adjusted based on what is sensed.
IMPORTANT: The very first wash cycle after installation in your

home will be adjusted to include an additional 2 rinses. This
cycle must not be interrupted for proper sensor adjustment. If

this adjustment cycle is canceled or stopped before the Clean
light comes on at the end of the cycle, the next wash cycle will

repeat this sensor adjustment.

• Water remains inthe dishwasher
Is the cycle complete?

• Detergent remains in the covered section of the dispenser
Is the cycle complete?

Is the detergent lump-free? Replace detergent if necessary.

• White residue on the front of the access panel
Was too much detergent used?

Is the brand of detergent making excess foam? Try a different
brand to reduce foaming and eliminate buildup.

• Odor in the dishwasher
Are dishes washed only every 2 or 3 days? Run a rinse cycle

once or twice a day until you have a full load.
Does the dishwasher have a new plastic smell? Run a vinegar

rinse as described in "Dishwasher Care."

• Condensation on the kitchen counter (built-in models)
Is the dishwasher aligned with the countertop? Moisture from

the vent in the dishwasher console can form on the counter.
Refer to the Installation Instructions for more information.
