IMPORTAMT UKTYIKSMIIONS

To reduce the rfesk of fire, expto-

Sion, etectrk eho<^, property

damage or injury to persons when using the appliant», foliow

basic precautions, including the following:

1. Read all instructions before using the appliance.

2. As with any equipment using electricity and having moving parts, there are

potential hazards. To use this appliance safely, the operator should become familiar with the instructions for opera tion of the appliance and always exer cise care when using it.

3. Do not install or store this appliance where it will be exposed to the weather.

4. Install and level washer on a floor that

can support the weight.

5. This appliance must be properly grounded. Never plug the appliance cord into a receptacle which is not

grounded adequately and in accor dance with local and national codes.

See installation instructions for ground ing this appliance.

6. To avoid the possibility of fire or explo sion:

a. Do not wash items that have been

previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flamma ble or explosive substances as they give off vapors that could ignite or explode. Hand wash and line dry any

items containing these substances.

Any material on which you have used a cleaning solvent, or which is satu

rated with flammable liquids or solids, should not be placed in the washer until all traces of these liq

uids or solids and their fumes have been removed.

These items include acetone, denatured alcohol, gasoline,

kerosene, some liquid house hold cleaners, some spot removers, turpentine, waxes and wax removers.

b. Do not add gasoline, dry-clean

ing solvents, or other flammable or explosive substances to the wash water. These substances give off vapors that could ignite or explode.

c. Under certain conditions, hydro

gen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLO SIVE. If the hot water system

has not been used for such a period, before using a washing machine or combination washerdryer, turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulat

ed hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this time.

7. Do not reach into the appliance if the tub or agitator is moving.

8. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the

appliance is used near children.

9. Do not tamper with controls.

10. Do not repair or replace any part of the appliance or attempt any servic

ing unless specifically recom mended in published user-repair instructions that you understand and have the skills to carry out.

11. Unplug power supply cord before attempting to service your washer.

12, The agitator should not

removed. If the agitator removed, it must be replacée pushing down completely and locking screw tightened before washer is operated.

13. Store laundry aids and o material in a cool, dry place wt children cannot reach them.

14. Do not wash or dry items that soiled with vegetable or coo oil. These items may contain si oil after laundering. Due to

remaining oil, the fabric smoke or catch fire by itself.

15. Do not use chlorine bleach ammonia or acids (such as ^ gar or rust remover) in the s wash, Hazardous fumes can f

16. Do not machine wash fiberc materials. Small particles can to fabrics washed in foilo' loads and cause skin irritation

17. Before the appliance is rem from service or discarded, rer the door to the washing com

ment.

18. Inlet hoses are subject to dar

and deterioration over time, C the hoses periodically for bi

kinks, cuts, wear or leaks replace them every five years

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

mo i s A T A G I A H Q

Control features vary by model.

ST t P l

Press the control dial in and turn in either direction to

the desired cycle. Pull the dial out to start the washer.

Note: All wash times are approximate.

COLORS is designed to clean

colored items as well as dress

shirts, dress pants, business casual and poly/cotton to reduce wrinkling.

HEAVY; 21 minutes of wash time. NORMAL: 15 minutes of wash time.

LIGHT: 9 minutes of wash.

StLta (YClt

COLORS

LIGHT

NORMAL

HEAVY

PRESOAK

EXTRA

RtNSE

WHITES is designed to clean underwear,

T-shirts and other cotton sturdy items like

towels, sheets, jeans etc.

HEAVY; 24-27 minutes of wash time. NORMAL: 15 minutes of wash time. LIGHT: 9 minutes of wash time.

HEAVY WHITES

NORMAL

LIGHT

RINSE

EXTRA RINSE

OFF

SPIN

OFF

Ntm:

Agitation speeds may change during the cycle. You may hear this change

in speed. This is normal.

PRESOAK provides a total of 33

minutes wash time. The first 12 min utes are periods of agitation and soak followed by 21 minutes of agitation.

PRESOAK automatically advances through the wash cycle.

STtP2

SELta »ttrtR UVtl

Move the slide lever up or down to the desired setting. If more water is needed once the fill is complete, move the lever up to

reset and then to the proper setting.

REMEMBER: ftems must circulate freely

for best results.

EXTRA

RINSE

OFFsPIN rinse

-------

WATER LEVEL

RESET

SUPER

LARGE

MEDIUM

MINI

DELICATES

HANDWASH

DELICATES is designed to clean items requiring a gen

tle wash action. This would include blouses and dress shirts. There will be 18 minutes of wash and soak cleaning

action.

HANDWASH: Handwash is designed to clean nylons or

lingerie. There will be 6 minutes of intermittent wash and soak cleaning action.

LO/a>SlZE

SUPER - 3/4 - Full

large - 1/2 - 3/4 Full

MEDIUM-1/3-1/2 Full

MINI -1/4 Full

(o m s

Control features vary by model.

AT A GLANCT ом

ST t P i

Sf L E C T W A T f R

Tt M P E R A T U M

Press the appropriate button to select the wash and rinse temperatures. Follow the gar ment care label tor best results. Use the chart at the right as a guide.

REMEMBER: In wash water temperatures below 65° F, detergents do not dissolve well or dean well. Care labels define cold water as

up to 85° F.

ST t P 4 St L K T A

Ql S T O M I Z f D C Y C L t

Press the appropriate button(s) to

select one or more options.

WASH/RINSE

MAV7650

LOAD TYPE

HOT/COLD - White and heavily soiled

color-fast items

WARM/WARM - Delicate or colorías

items

WARM/COLD - Moderately soiled

colored items; most wrinkle free items

COLD/COLD - Brightly colored, lighth

soiled items; washable woolens

MAV7700

USE

SUPER WASH - Can be used with any

wash cycle to clean very heavily soiled items. Provides fast agitation and nor

mal spin throughout all cycles.

GENTLE WASH - Can be used with

any wash cycle to provide a normal agi tation and slow spin. Use with delicate

items including those labeled “Hand

Wash.”

AUTO TEMPERATURE CONTROL ~

Assures a cold water wash of 75° F and

STfPS

IS T A R T W A S H f R

warm water wash of 95° F. This option assures detergent will dissolve and pro vide optimum cleaning results.

EXTRA RINSE - Provides an addition

al rinse at the end of the cycle to more completely remove laundry additives, suds, perfume, etc.

NORMAL RINSE - Cancels the second

deep rinse. Provides only one deep

rinse.

CANCEL - Press this button to cancel

and reset any of the options.

' Add detergent and any additives ’ Add load and close lid ' Pull the control dial out to start

AUTO

О TEMPERATURE

CONTROL

If Auto Temperature Control is sei

ed with a Warm/Warm, Warm/Colc

Cold/Cold water temperature set

the light will illuminate during the

MAV7650 Only - Auto Tempera

Control is activated automatically v\ warm/warm, warm/cold, or cold/ water temperatures are selected.

OPERAnHG TIPS

Pour liquid chlorine bleach into bleach dispenser,

CHIORINIBUACH DISP{N$№

Pour liquid fabric softener into cup and dilute with warm water.

FA B R I C S O f T t № R Di s p m

The dispenser automatically dilutes liquid

chlorine bleach before it reaches your wash

load. To use, follow these steps:

Measure liquid chlorine bleach carefully,

following the instructions on the bottle.

Add the bleach to the dispenser before

adding the load. Avoid splashing or over filling the dispenser. Wipe up spills.

Never pour undiluted liquid chlorine bleach directly onto the load or into the wash tub. It is a powerful chemical and can

cause fabric damage, such as tearing or color loss, if not used properly.

If you prefer to use color-safe, non-chlo rine bleach, pour it into the wash tub with your detergent. Do not pour non-chlorine

bleaches into the bleach dispenser.

This dispenser automatically releases liquid fabric softener at the proper time

during the cycle. To use, follow these steps;

1. Pour liquid fabric softener into the dispenser using the amount recom

mended on the package.

2. Add warm water to the dispenser

' until it reaches the MAX line. Wipe

up spills.

• Do not stop the washer during the first spin. This will cause the dis

penser to empty too soon.

• Never pour fabric softener directly on the load. It will leave spots and

stains.

• Use the dispenser for liquid fabric softeners only. Clean the area in and around the dispenser fre

quently with hot water, detergent and a soft brush.

Add detergent before the load.

DFTFRGFKT

Use either liquid or granular laundry detergent. For best results, be sure

detergent is added to the washer

BEFORE the load and be sure wash water is above 65° F.

Use the correct amount of detergent for the load size, soil level and water

conditions. Use more detergent if you have hard water and very soiled loads.

If you have soft water or a lightly soiled load, use less detergent. (See manu facturer’s instructions.)

Wipe up any detergent spills on the washer.

f « d«.«ed ItitonnaBon orsortN,

O PE R AT I NG TI P S

coni.

LO A D I N G

Put dry, unfolded clothes loosely in the tub, up to the top row of holes for a maximum load.

Do not wrap large items like sheets around the agitator.

Mix large and small items for best circulation. Wash bulky items like blankets separately.

lO A D S t N S O R " A G I T A 1 D R

The LoadSensor™ agitator is specially designed to be sensitive to every load. The spiral fins will move continuously with large, heavy loads. With smaller, more delicate loads, the spiral fins will move intermittently, or with very light loads, not at all. It is normal to notice a difference in the agitator sound from load to load.

When laundering wrinkle free it< or items of delicate construct washable woolens or loosely

items, never use less than the ME

UM water level setting. This will n mize shrinkage, wrinkling and pul of seams.

For best results, add the deterger washtub before adding the load.

Close lid carefully to avoid slamm

UR E A KD a fA N IN G

Turn off the water faucets after finishing the day’s washing. This will shut off the

water supply to the washer and prevent the unlikely possibility of damage from escap ing water.

ST O R IN G

Washers can be damaged if water is not removed from hoses and internal compo nents before storage. Prepare the washer

for storage as follows:

Select NORMAL on the WHITES cycle and add one cup of bleach OR white vinegar to a full load of water without clothes. (Do not mix bleach and vine-

Use a soft cloth to wipe up all detergent, bleach or other spills as they occur.

Clean the following as recommended:

Control Panel - clean with a soft,

damp cloth and glass cleaner. Do not use abrasive powders or clean ing pads.

gar in the same wash. Hazardous fumes can form.) Run the washer through a complete cycle.

Turn the water faucets off and dis connect the inlet hoses.

• Disconnect the washer from the elec trical supply and leave the washer lid open to let air circulate inside the tub.

Cabinet - clean with soap and wate Interior - hard water deposits may

removed using a recommended f water remover/cleaner labeled m er safe. Follow the cleaner manu turer's directions for use, and m sure the washer is run througi complete cycle to rinse out

remaining cleaning substance.

If the washer has been store' below - freezing temperatures, i time for the washer to thaw out pri use.

After storage, select NORMAL or WHITES cycle and run the wa through a complete cycle.

ШОКЕ YOU UU

For problem laundry solutions (l.e. fabric damage, residue, tangling) and special laundry care procedures, see the enclosed Laundry Tips booklet.

zone for maximum cleaning effectiv-

ness. This sound will vary from load

to load. This is normal.

• Operating sounds will vary depending on agitation speed.

FILLS WITH THE WRONG TEMP ERATURE WATER

• Turn both faucets on fully.

• Make sure temperature selection is correct.

• If Auto Temperature Control is select ed, cold water may feel warmer than cold water from the tap (see page 3).

• Make sure hoses are connected to

correct faucets and inlet connections. Be sure water supply is regulated cor

rectly. Flush water line before filling

washer.

• Check the water heater. It should be set to deliver a minimum 120T (49°C) hot water at the tap. Also check water

heater capacity and recovery rate.

• Disconnect hoses and clean screens. Hose filter screens may be plugged.

CYCLE SELECTOR DIAL VANCES THROUGH “OFF”

• Extra Rinse is selected.

For further assistance contact Maytag

Appliances Sales Company,

Maytag Customer Assistance:

U.S. 1-800-688-9900 dr V

: Canada 1-800-688-2002

U.S. customers using TTY for deaf,

hearing impaired dr speech impaired,

: ; can 1-800-688-2080.

CHECKTHESE POINTS IF

YOUR WASHER...

ALWAYS CHECK FIRST

• Plug cord into live electrical outlet.

• Check fuse or reset circuit breaker.

WONT FILL

• Turn the control dial to proper cycle and pull dial out to start the washer. If equipped wifh buttons, be sure they are

fully depressed.

• Turn both faucets on fully.

• Straighten inlet hoses.

• Disconnect hoses and clean screens. Hose filter screens may be plugged at the faucet.

WONT AGITATE

• Make sure the lid is completely closed.

• Turn the control dial to proper cycle and pull dial out to start the washer. If equipped with buttons, be sure they are

fully depressed.

• Close lid and pull dial out to start the washer. For your safety, washer will not

agitate or spin unless the lid is closed.

• The washer is equipped with a lid switch failure detector. If the lid switch should

malfunction, the detector will stop opera tions for your safety. Call for service.

• Pauses are normal. Wait and see if the

washer will start again.

WONT SPIN OR DRAIN

• Straighten drain hoses. Eliminate kinked hoses. If there is a drain restriction, call for

service.

• Close lid and pull dial out to start the wash er. For your safety, washer will not agitate or spin unless the lid is closed.

• The washer is equipped with a lid switch failure detector. If the lid switch should

malfunction, the detector will stop opera tions for your safety. Call for service.

• If drain height is over five feet, a high-volume pump kit may be neces sary. See installation instructions or

call 1-800-688-9900.

LOAD IS WETTER THAN NORMAL AT THE END OF THE CYCLE

• The washer is designed to reduce spin speed if an unbalanced load is detected. This is normal.

• Redistribute the load in the tub and

set the washer on SPIN.

STOPS

• Turn the control dial to proper cycle and pull dial out to start the washer. If equipped with buttons, be sure they are fully depressed.

• Close lid and pull dial out to start the washer. For your safety, washer will

not agitate or spin unless lid is closed.

• This may be a pause or soak period in the cycle. Wait briefly and it may

start. ,

• The washer is equipped with a lid switch failure detector. If the lid switch

should malfunction, the detector will stop fill operations for your safety. Call for service.

LEAKS WATER

• Make sure water inlet hose connec tions are tight at faucet and water

valve.

• Make sure end of drain hose is cor rectly inserted and secured to drain

facility.

• Avoid extended soaking - soak for 30 minutes or less.

• Avoid overloading.

IS NOISY

• Be sure washer is leveled properly as outlined in installation manual.

• Weak floors can cause vibration and walking.

• Be sure rubber feet are installed on leveling legs.

• A clicking sound may be the LoadSensor™ agitator as it moves the load down through the cleaning

AD-

мш MR щаш

Full One Year Warranty

For one Í1) year from the date of original retail, purdiase, any part which faits in normal home use VWÍI be r^aired or replaced, free of charge.

Limited Warranty

After the first year from date of original retail purdiase, through the time periods listed below, fte parts designates below which fail in normal

home use will be repaired or replaced free of charge for the part itself, with the owner paying all öfter costs, including labor, mileage and transportation.

Second Year - All parts. Tliird through Fifth Vrar - The drive motor. Ail

parts Of the solid state controls (if so equipped). Third ütfoúgh Tenth Year - Ail parts of the

transmission assembly. : Third through Ufefime - The inner wash bas

ket.

Additional Limited Warranty Against RustThrough

Should an exterior c^inet,. including the top, iid and baseframe, rust through: during one

year period starting from the date of retail pur chase, repair or replacement will be made free of (ftarge. After the first and through fte tenth year, repair or replacement will be made free of

charge for the part itself, with the owner paying all other costs, including labor, mileage and transportation.

Please Note: This full warranty and the limited warranty apply when the washer is located in the United Slates or Canada. Washers located elsewhere are covered by the limited warranty

only, including parts which fail during the first

two years.

Canadian Residents

This warranty covers only ftose appliances

installed in Canada that have been listed with

the Canadian Standards Association unless fte

appliances are brought into Canada due to transfer of residence from the United States to

Canada. The specific warranties expressed above are

fte ONLY warranties provided by the manufac turer. This warranty gives you specific legal

rights, and you may also have other rights that vary from state to state.

TO R K t I Y f W A R R A N T Y S t R V I C f

To locate an authorized service company in your area contact the Maytag d< ertrom whom your appliance was purchased; or call Maytag Appliances Sc

Company, Maytag Customer Assistance at the number listed below. She you not receive satisfactory warranty service, please call or write:

Maytag Appliances Sales Company Attn: CAIR® Center

P.O. Box 2370 Cleveland, TN 37320-2370

U.S. 1 -800-688-9900 Canada 1 -800-688-2002 U.S. customers using TTY for deaf, hearing impaired or speech impaired, call 1-800-688-2080.

When contacting Maytag Appliances Sales Company Maytag Gusto Assistance about a service problem, please include the following.

a. Your name, address and telephone number;

b. Model number and serial number (found on the back left of

control panel) of your appliance;

c. Name and address of your dealer and the date the appliance

purchased;

d. A clear description of the problem you are having. e. Proof of purchase.

WH A T I S N O T Ш У Ю B Y \Ш W A R R A N T I E S ;

1. Conditions and damages resulting from any of the following: a. Improper installation, delivery or maintenance. b. Any repair, modification, alteration or adjustment not authorized by

manufacturer or an authorized servicer. Misuse, abuse, accidents, or unreasonable use.

d. Incorrect electric current, voltage or supply.

Improper setting of any control.

2. Warranties are void if the original serial numbers have been removed altered, or cannot be readily determined.

3. Products purchased for commercial or industrial use.

4. The cost of service or service call to:

a. Correct installation errors.

b. instruct the user on proper use of the product. c. Transport the appliance to the servicer.

5. Consequential or incidental damages sustained by any person as a re of any breach of these warranties.

Some states do not allow the exclusion or limitation of consequential or i dental damages, so the above exclusion may not apply.

User’s Guides, service manuals and parts catalogs are available from Maytag Appliances Sales Company, Maytag Customer Assistance.

MAYTAG • 403 W. 4‘" Street N. * P.O. Box 39 • Newton, Iowa 50208
