CABINET PARTS
REFRIGERATOR
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
12−09 Litho In U.S.A. (mjb)(bay)
1
Part No. W10305562 Rev.A
CABINET PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10142143
W10251542
W10249206
W10249207
2225623 Modular Icemaker
Service &
Wiring Sheet
Energy Label
Use & Care Guide
Bilingual
Trilingual
Service Sheet
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
677969 Do−It−Yourself
Manual Ref./Frz.
2 2189410 Hinge (Top)
3 2166108 Roller, Front (2)
Illus. Part
No. No. DESCRIPTION
4 Cabinet (Not a
Serviceable Part)
5 489385 Clamp, Tube
(Water Supply Line)
6 489442 Screw
7 2179826 Rivet
8 3400504 Screw
9 549193 Clamp, Cord
10 489497 Screw
11 2254618 Hinge, Center
12 2183852 Shim, Hinge
Center
13 8281265 Screw
14 2254473 Hinge Butt
15 Fitting, Water Tube
(Not Serviced)
16 Hole Plug (6)
2201012 White
2183998 Black
2200924 Biscuit
Illus. Part
No. No. DESCRIPTION
17 Corner Filler (2)
W10283959
W10283960
2200926 Biscuit
18 Grille
2254313 White
2254315 Black
2254316 Biscuit
19 489341 Washer
20 487576 Washer
21 2189356 Clip, Grille (2)
22 Cover, Hinge
2213360 White
2213363 Black
2213364 Biscuit
23 Rail, Center
24 2254576 Cover, Unit
25 489427 Screw
White
Black
(Includes
Illus. 21)
(Not Serviced)
2
W10305562
DOOR PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
W10305562
3
DOOR PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes
Illus. 6 & 14)
2183920 White
2200714 Black
W10271883
2205284 Biscuit
2 Handle, Trim
2193143W White
2193143B Black
2193143T Biscuit
3 Handle,
2254533W White
2254533B Black
2254533T Biscuit
4 489357 Screw
5 8281146 Screw
6 Door Gasket,
2202875 Mist Beige
2202882 Black
Stainless Steel
Refrigerator
Magnetic
Illus. Part
No. No. DESCRIPTION
7 2195378 Trim
W10170766
8
9 2195947 Trim, Door Shelf
10 8281206 Screw
11 Freezer Door
2182489 White
2200711 Black
W10271885
2204686 Biscuit
12 Hole Plug,
2189000 White
2189009 Black
2200936 Biscuit
13 2188236 Shelf, Flip−Up
14 2314293 Thimble
15 Door Gasket,
2214967 Mist Beige
2214969 Black
Nameplate
(Includes
Illus. 14 & 15)
Stainless Steel
Handle
Magnetic
Illus. Part
No. No. DESCRIPTION
16 2204812 Bin, Door Shelf
17 2189202 Bracket,
Door Stop (2)
18 488921 Screw
19 Hole Plug
2212648 White
2212651 Black
2212649 Biscuit
20 2195916 Plug, Trim
21 2156006 Plug, Trim
22 2218118 Compartment Door
23 Handle,
Freezer
W10291249
W10292303
W10292304
24 2195948 Trim, Door
White
Black
Biscuit
4
W10305562
LINER PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
W10305562
5
LINER PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2197380 Grommet (2)
3 2254360 Gasket, Evaporator
Cover (2)
4 2304099 Defrost Timer
5 2212485 Thermostat Tube
Barrier
6 488208 Screw
7 2310057 Wire Assembly,
Control Box
8 2162085 Socket, Light
9 2179858 Damper, Air
W10208121
10
11 2163777 Fan Blade
12 2212982 Control Box
W10225856
13
14 8534009 Screw
15 2304099 Screw
16 2320194 Cover, Evaporator
17 527949 Light Bulb (2)
18 2200831 Weight, Thermal
19 1118894 Switch, Rocker Arm
20 2179859 Post, Damper
21 2176281 Cover, Air
22 2200863 Knob, Thermostat
23 2254354 Air Tower
24 2189452 Air Diffuser,
25 2321800 Defrost, BI−Metal
26 2204690 Air Separator
27 2254453 Bracket,
29 2204639 Shield, Heat
30 2254454 Bracket
31 2302536 Knob, Damper
32 2163810 Bracket,
33 2205079 Seal, Rear
34 2171931 Valve−Tube, Body
W10129803
35
Fan Motor
Thermostat Assy.
(Includes
Illus. 5 & 18)
Diffuser
Bottom
Assembly
Fan Motor
Evap. Fan, Rear
Damper Knob
Thermostat
Wire Assembly,
Freezer Compartment
(Includes
Illus. 25)
6
W10305562
UNIT PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
W10305562
7
UNIT PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
1 2320187 Plate, Unit
Mounting
2 2214857 Insulation
3
W10268878
4
W10140847
5 2254249 Evaporator Assy.
6 8533961 Screw
7 2254295 Drain Pan
8 2319835 Grommet−Cond−(4)
9 2176301 Bracket, Heater
10 2300638 Extension, Air
11
W10174384
12 2169104 Insulation
14 Grommet (4)
1100826 Production
4387558 Service
15
W10194431
16 2201185 Support Block
17 2150304 Roller (2)
Condenser
Heater, Defrost
Baffle
Strap
Start−Device
Combination
(Start Relay and
Overload for
Production
Compressor Only)
Illus. Part
No. No. DESCRIPTION
18 2221797 Rivet
19 2182338 Clip, Heater
20 489373 Screw
21 3400518 Screw
22 488500 Screw
W10164016
24
25 Drier
W10177049
26 2155774 Clamp
27 Capacitor
2264017 Production
1118576 Service
29 2315541 Air Baffle
30 2188874 Motor, Condenser
31 2187382 Wire Assembly,
32 2225834 Fan Blade
34
W10189806
35
W10274306
36 2254574 Tray, Evaporator
Compressor
(Includes
Illus. 14,25,27)
(Also Order 482801
Installation Kit
& 876765 Tube Kit)
Service
Unit
Tube, Suction
Tube, Process
Illus. Part
No. No. DESCRIPTION
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
4.00 Ozs.
(R134A)
8
W10305562
ICEMAKER PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
W10305562
9
ICEMAKER PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
1 488878 Clamp, Tube
3 2210495 Clip, Water Valve
4 2181939 Insert, Tube
5 628379 Clip, Fuse
6 2181943 Tube Water
7 2315576 Valve Solenoid
8 79191001 Cover
9 8281265 Screw
W10122527
10
11 628515 Cup, Water Fill
12 627843 Ejector
W10122563
13
14 2194712 Support
15 2315522 Retainer
16 628397 Thermostat (Also
17 8533917 Screw
18 489276 Screw
19 627792 Shut Off Arm
20 2187464 Harness, Wiring
21 628320 Bracket
W10223929
22
23 489478 Screw
24 489136 Screw,
25 488208 Screw
26 488886 Screw, 8−18 x 1/2
W10190952
100
Mold & Heater
Assembly (Also
Order 542638
Silicone Grease)
Ice Striper
Thermostat
Order 542369
Cement
Alumilastic)
Module Assembly
(Includes Item 24)
3−24 x 23/64
Icemaker,Complete
Assembly
10
W10305562
SHELF PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
1 2210522 Shelf, Ladder (2)
2 2300520 Shelf, Ladder
Center
3 2163762 Cup, Shelf Mtg.
4 2188691 Trim,Shelf Front
5 489478 Screw
6 2176222 Slide, Humidity
Control
7 2212446 Body, Humidity
Control
8 2314502 Crisper Cover
9 2201102E Shelf, Cantilever
10 2210573 Insert, Crisper
Cover
11 2201106 Pan, Shelf
Cantilever
12 2174694 Glass, Shelf
13 2188685 Trim, Shelf Front
14 2314478 Crisper Support
15 2189454 Shelf, Freezer
16 2218132K Pan, Meat
17 2188689 Trim, Shelf Rear
18 2254352 Bucket, Ice
19 2218130 Crisper Pan
(Includes
Illus. 6 & 7)
20 2188687 Trim, Shelf Rear
21 2174693 Glass, Shelf Full
22 2201104E Frame Assy
W10305562
11
OPTIONAL PARTS
For Models: M1TXEMMWW02, M1TXEMMWB02, M1TXEMMWS02, M1TXEMMWQ02
(White) (Black) (Stainless Steel) (Biscuit)
Illus. Part
No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Miscellaneous
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
x 2−5/8")
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4" x 108")
876305 Kit, Insulation
(14 Pcs.
3" x 24" x 48")
876370 Kit, Insulation
(2 Pcs.
3" x 24 " x 48")
876029 Kit, Foam Slab
(30" x 32−1/2" x
1−1/2")
505587 Sealer, Mastic
(1 Qt.)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
799832 Kit, Porcelain
Repair (White)
503695 Cork Sealer
(1/4 Pound)
Illus. Part
No. No. DESCRIPTION
Customer Touch−Up Material
350942 Primer, White
(12 Oz. Spray Can)
350939 Enamel, Black
(12 Oz. Spray Can)
350930 Enamel, White
(12 Oz. Spray Can)
4392901 Enamel, Biscuit
(12 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−Up Kit
(Black)
4392899 Brush Touch−Up Kit
(Biscuit)
Refinishing Material
799344 Enamel, White
(1 Qt. Uncut)
4392900 Enamel, Biscuit
(1 Qt. Uncut)
786032 Enamel, Black
(1 Qt. Uncut)
833938 Kit, Terminal
Connector
Important:
not to be used where the paint
may make contact with the door
gaskets.
The spray paint is
Illus. Part
No. No. DESCRIPTION
TORX SCREW WRENCH
1117510 Torx Key
12
W10305562
