www.maytag.co.uk
Cylinder Cleaner
How do you clean
your space?
Add wings to your cleaning with
the new Maytag cylinder cleaner.
The cleaner you have purchased
is more than just a vacuum. You
have purchased a new way to
clean your space, simplify your
life, and complement your home
décor.
The Maytag cylinder cleaner’s
powerful motor, ingenious design
and impeccable style complement
all of your cleaning needs.
Important safeguards . . . . . . 2
Carton contents . . . . . . . . . . . 3
How to use . . . . . . . . . . . . . 4-6
Cleaner description . . . . . . 4
Cleaning tools . . . . . . . . . . 5
Cleaning stairs . . . . . . . . . 6
Storage. . . . . . . . . . . . . . . . 6
Maintenance . . . . . . . . . . . . 6-7
Filter bag . . . . . . . . . . . . . . . 6
Filter. . . . . . . . . . . . . . . . . . . 7
Lubrication . . . . . . . . . . . . . . 7
Clearing blockages . . . . . . . . 8
If you have a problem . . . . . . 8
Service . . . . . . . . . . . . . . . . . . 9
Guarantee. . . . . . . . . . . . . . . . 9
Contents
To contact us:
• www.maytag.co.uk
• 01737 231000 - our Consumer
Response Centre (9 AM to 5 PM
Monday - Friday)
• ukservice@maytag.com
When using an electrical appliance, always follow basic precautions, including the following:
READ ALL INSTRUCTIONS BEFORE USING APPLIANCE.
WARNING:
To reduce the risk of fire, electric shock, or injury:
• Do not use outdoors or on wet surfaces.
• Close supervision is necessary when any appliance is used near children. Do not allow vacuum
cleaner to be used as a toy or to run unattended at
any time.
• This appliance is not intended for use by children
or infirm persons without supervision.
• Keep hair, loose clothing, fingers, feet and all parts
of body away from openings, rotating agitators and
other moving parts. Do not operate cleaner in bare
feet or when wearing open toe shoes or sandals.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not use to pick up flammable or combustible
liquids or fine sawdust or use in areas where they
may be present.
• Avoid picking up hard, sharp objects with the
cleaner. They may damage the cleaner.
• Always turn off this appliance before connecting or
disconnecting hose.
• Do not use without filter bag or filter in place.
Change bag frequently when picking up very fine
materials such as powder.
• Use extra care when cleaning on stairs.
• Always fully unwind the cable before using the
cleaner.
• Do not put any object into openings. Do not use
with any opening blocked; keep free of dust, lint, hair,
and anything that may reduce air flow.
• Do not pull or carry by cable, use cable as a handle, close door on cable or pull cable around sharp
edges or corners. Do not run appliance over cable.
Keep cable away from heated surfaces.
• Always disconnect cable from electrical source before
servicing the cleaner.
• Turn cleaner off and unplug when not in use.
• Do not unplug by pulling on cable. To unplug,
grasp the plug, not the cable. Never handle plug or
appliance with wet hands.
• The use of an extension cable is not recommended.
• Do not use with damaged cable or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, contact the Consumer Response Centre.
• Use vacuum cleaner only for its intended use as
described in the instructions.
• Use only attachments recommended by Maytag;
others may cause hazards.
• Do not pull/drag the cleaner across hard floor surfaces when the cleaner is turned off.
Important Safeguards
Save these instructions
www.maytag.co.uk
Maytag Int’l, Inc.
Schaumburg, IL 60173
2
A. Cleaner - Your Maytag cylinder cleaner uses a unique prin-
ciple called “air lift” which allows the cleaner to glide across
your rugs without any pulling or tugging. That’s right, this cylinder acts
just like it would in space, floating over your floors and not touching the
ground. Not only is this great because it doesn’t have wheels to
scratch and mark your floors, but it pulls along with you intuitively-creating an effortless and weightless cleaning experience.
B. Hose and Hand Grip - The flexible hose is super-light, flexible and
easy to use. It stretches out easily for that extra length you need, and
then quickly contracts to its original length when the job is done. You’ll
find it’s light in your hands, never kinks, and is easy to control-- so that
you can easily clean your space from top to bottom.
The Maytag cylinder cleaner gives you cleaning attachments for
every job...
C. Soft Touch™ Floor Brush Nozzle - There is no better way to clean
your hard surface spaces than to use the Soft Touch™ straight air floor
nozzle. It is wide enough to cut down on cleaning time and delicate
enough not to scratch your floors.
D. Turbine Nozzle - If your space is lined with carpet, then the air-
driven nozzle is for you. The cylinder cleaner’s suction power will drive
the brush-roll located on the underside of this nozzle to get down into
the fibers of your carpet, sucking up dirt and particles leaving with you
a clean space.
E. Combination Tool - With this new combination tool, you can easily
clean upholstered furniture, curtains, and mattresses. You’ll find it ideal
for cleaning the interior of your car.
F. Crevice Tool - The crevice tool is designed for cleaning even the
most cramped spaces. Get between furniture cushions, around skirting, under furniture and all those hard to get to places.
G. Dusting Brush - A dusting brush that is great for use on tables,
lamp shades, carved furniture, venetian blinds, shelves, and more.
Used properly, it won’t scratch surfaces, and it will save you time dusting around the house. Why use chemicals for your dusting, when you
can get that space squeaky-clean with the cylinder cleaner’s dusting
brush.
H. Telescoping Extension Wand - Used with the flexible clear hose
and any tool you can clean your ceiling, floors, or stairs in one easy
step. Adjust the wand to the desired length, release latch and you are
ready to go. Because the extension wand is light and easy to use,
you’ll tire less--making all of your above-floor cleaning a breeze.
I. Tool Holder - Tools are easily accessible and ready to use for all
your cleaning needs.
J. Extra Filter Bag - (one installed in cleaner) The Maytag cylinder
cleaner doesn’t stop at effortless cleaning; it also uses a HEPA filtration
waste-bag so that the air coming out of your cylinder cleaner is cleaner
than the air it’s sucking in. The HEPA filtration bag traps dirt, dust mites
and other small particles leaving you with a cleaner space.
3
IMPORTANT
Electricity Supply
This cleaner must be connected to an alternating
current (AC) supply at the voltage shown on the
rating plate. This is a double-insulated appliance,
and must not be earthed.
Switch off and remove power plug from electrical
outlet-socket before inspecting or servicing
cleaner.
Carton contents
1. Unpacking
1-1
(Cont’d
)
→
B
G
H
C
A
D
J
IMPORTANT
E
F
I
Use the following to identify the parts and
features of the cleaner:
1. Turbine nozzle
2. Bag lid
3. Bag lid latch (on rear of cleaner)
4. Wand storage/tool storage slot (at rear of
carrying handle)
5. Combination tool
6. Crevice tool
7. Dusting brush
8. Wand/tool storage holder: fits into storage
slot on rear of carry handle
9. Hand grip
10. Hose
11. Spring latch
12. Carrying handle
13. Hose connector
14. ON/OFF switch
15. Telescoping extension wand: used with
turbine nozzle, floor brush or tools.
Adjusts to desired length.
Operate cleaner only at voltage specified
on data plate on underside of the cleaner.
This cleaner is intended for household use.
4
B
C
1
2
3
4
8
6
7
5
9
10
11
12
13
14
15
A
Attach hose
Insert hose connector (A) into opening (B) in bag lid, aligning tabs on hose connector with slots in opening. Twist
counterclockwise to latch.
To remove hose, twist hose connector clockwise and pull
up.
Attach wand
To attach wand to hose, push wand firmly onto hose; twist
wand to tighten.
To adjust the telescoping wand, push spring latch (C) and
pull down on lower portion of wand. Adjust wand to
desired length. Release latch to lock the wand in
position.
Attach tools and nozzle
To attach tool to the hose or wand, firmly push tool onto
hose or wand. Twist tool slightly to tighten or loosen connection.
To attach either nozzle to the wand, push the nozzle firmly
onto the wand. Twist nozzle slightly to tighten or loosen
connection.
1-3
1-4
2-1
1-2
Attach hose, wand, tools and nozzle
Cleaner description
2. How to use
C
C
D
A
E
F
G
I
H
J
B
ON/OFF switch
To turn cleaner ON, push the ON/OFF switch (A) down. To
turn cleaner OFF, push the switch up.
2-2
5
Wand/tool storage holder
The wand/tool storage holder (B) fits into the slot
(C) at the rear of the carry handle. Tools may be
positioned on the tool holder attached to the wand for
convenient storage.
Cleaning tool storage
The tools may also be stored on the tool holder
(D). Fit the tool holder into the slot (C) at the rear
of the carry handle.
The cleaning tools have many uses. Select the tool best
suited for the cleaning task from the following descriptions.
2-3
2-4
Select the proper tool
E. Crevice tool may be used in tight spaces, cor-
ners, and along edges in such places as dresser
drawers, upholstered furniture, and stairs.
F. Dusting brush may be used for carved furniture, table
tops, books, lamps, lighting fixtures, and venetian blinds.
G. Combination tool use with brush attached for carved
furniture, table tops, books, lamps, lighting fixtures, and
venetian blinds. Remove brush to clean upholstered furniture, curtains, mattresses, car upholstery, and carpeted
stairs.
H. Soft Touch™ floor brush use on hard surface floors.
I. Turbine nozzle use on carpeted surfaces and rugs.
Automatically adjusts to different carpet pile heights.
J. Telescoping wand may be used to give extra length to
the hose. It can be used with any of the above tools. The
wand can be extended by pushing the spring latch and
pulling down on lower portion of wand. Adjust wand to
desired length. Release latch to lock the wand in
position.
2-5
Attaching tools
The tools and the floor nozzles are attached to the hose or the wand in the same manner. Push tool firmly onto hose;
twist tool slightly to tighten or loosen connection.
Cleaning tools
2-6
(Cont’d)
→
Combination tool
Slide brush to remove.
To replace brushes, align brush with grooves on tool. Slide brush into place.
2-7
Familiarize yourself with these home maintenance tasks as proper use and care of your cleaner will ensure continued cleaning
effectiveness.
Filter bag
When to replace
Check bag from time to time. When bag is filled with dirt, the cleaner will not operate efficiently. Discard used bag.
CAUTION: Very fine materials may reduce airflow through the bag even though it is only partially full of dirt. When the
cleaner is used to remove material of this nature, change the bag often.
What bags to buy
It is important to use only Genuine MAYTAG® HEPA Filtration Type CB disposable bags in order to maintain the origi-
nal cleaning effectiveness of your cleaner.
MAYTAG bags can be identified by these trademarks --
®®
Storing the cleaner
Unplug the cable and wrap it around the
base of the cleaner. Disconnect tool or
wand from hose, wrap hose around base and
insert hook on hand grip into slot at the back of
the carry handle.
Position tools on the tool storage holder attached
to the wand.
2-8
Replacing the filter bag
Disconnect cleaner from electrical source.
The bag lid latch (A) is located on the back side of
the cleaner. Unlatch and open bag lid.
3-1
Remove bag from bag holder (B) by pulling up on
bag collar (C). Discard used bag.
3-2
Slide new bag collar all the way down into bag
holder.
3-3
A
B
C
Cleaning stairs
Simply leave the Maytag cylinder cleaner at the foot of the stairs and work your way up, cleaning the stairs as you go. Used
with the extension wand, the clear hose will stretch to the length you need, as you need it without any strain on you or the
cleaner. Use either the Soft Touch™ floor brush or turbine nozzle for stairs--whichever is most convenient for you.
Where to buy bags
Filter bags may be purchased from your local Maytag retailer. When ordering filter bags, be sure to give the
model number of your cleaner. Ask for Maytag part number 401011CB.
3. Maintenance
6
7
Close bag lid, making sure bag is completely
inside bag compartment.
Close and latch bag lid.
3-4
Secondary filter
Disconnect cleaner from electrical outlet.
The secondary filter, located in the bag compartment, protects the motor from dirt particles.
To replace the filter when it becomes dirty, remove the disposable bag, following Figs. 3-1 and 3-2.
Grasp the centre of the filter retainer (A) and pull
up to remove. DO NOT DISCARD filter retainer.
3-5
Remove the used secondary filter (B) and discard.
Replace with a new filter. Put the filter retainer back
into position and press in place.
Replace the disposable bag (Figs. 3-3 and 3-4), close bag
lid and latch.
Do not operate cleaner without secondary filter and disposable bag in place.
It is recommended that the secondary filter be replaced after
every 2 bag changes. Disposable bags and filters may be
purchased from your local Maytag retailer. When ordering,
be sure to give the model number of your cleaner. Ask for
Maytag part number 401011CB.
3-6
Lubrication
The motor is equipped with sufficient lubrication for the life of the motor. The addition of lubricant could cause
damage.
Therefore, do not add lubricant to the motor.
A
B
(Cont’d)
→
8
Clearing blockages
If a minor problem occurs, it usually can be solved quite easily when the cause is found by
using the check list below. Turn cleaner off and disconnect cable from electrical source-
outlet before performing any maintenance tasks.
It won’t turn on Not firmly plugged in.
✓
Be sure cleaner is firmly plugged into an
active electrical outlet with the correct voltage/
wattage needs.
I sucked up something, and I need it back!
Don’t worry. If you have sucked up something
valuable, you can simply retrieve it from the
throw-away vacuum bag. Simply turn it off,
unplug power cord and remove bag and
empty.
It’s making a bad noise
There may be an internal fault, or something
stuck inside. We recommend you turn the
unit off, unplug and bring to an authorised
service centre. To locate an authorised
service centre near you, call 01737 231000
(9 AM to 5 PM, Monday - Friday);
email us at ukservice@maytag.com.
I need a new bag
New bags can be purchased at your local
Maytag cleaner retailer.
Alternatively, you can buy more bags from
Maytag directly by calling 01737 231000.
What’s the problem? What does it mean? What should I do?
What’s the problem? What does it mean? What should I do?
What’s the problem? What does it mean? What should I do?
What’s the problem? What does it mean? What should I do?
4. What’s wrong with my cylinder cleaner? HELP!
Low suction or pick up may be due to a blockage in the system. Refer to the following steps to check for blockages, continuing with each step until the blockage is found.
1. Turn cleaner OFF and disconnect from electrical source; then disconnect the wand from the hand grip.
2. Plug cleaner in, turn on, and check hose end for suction. Remove any obstructions.
3. Remove nozzle from wand and attach wand to hose. Check for suction and remove any blockages.
9
The two year guarantee on your MAYTAG cleaner becomes effective from your date of purchase. We
suggest you record the model and serial number from the information plate on your cleaner and retain it
with your original proof of purchase.
This guarantee covers all materials and manufacturer assembly of your cleaner.
All repairs must be authorised in advance by our Consumer Response Centre and subsequently completed by an authorised agent. Any repair completed under guarantee will not extend the original period
of your product guarantee.
This guarantee applies to normal domestic use only.
This guarantee does not cover normal wear and tear, negligence, misuse, accidental damage, blockages or consumable items.
This guarantee does not cover any consequential loss.
These guarantee benefits are in addition to your statutory rights.
Servicing your cleaner
GUARANTEE
To contact us:
• www.maytag.co.uk
• 01737 231000 - our Consumer Response Centre (9 AM to 5 PM Monday Friday)
• ukservice@maytag.com
IMPORTANT
Cable Replacement
This MAYTAG appliance is supplied complete with a plug.
If the supply cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
For your records, enter the model number and serial numbers in the spaces provided. These
numbers are located on the data label on the underside of the cleaner.
Model No. ____________________________
Serial No. _____________________________
Save your sales receipt and attach it to this manual. Proof of date of purchase may be
required for warranty service of your cleaner.
Fill in and Save
10
11
R2 12-05 S3340001 Printed in PRC 59138285
MAYTAG and are registered trademarks
Loading...
