Precision Touch Control 500
Electric Smoothtop
®
Use & Care Guide
Table of Contents
Safety.......................................... 1-4
Surface Cooking ...................... 5-8
Controls
Smoothtop Surface
Oven Cooking ......................... 9-18
Baking
Cook & Hold
Delay
Keep Warm
Broiling
Oven Racks
Care & Cleaning ...................19-22
Self-Clean Oven
Cleaning Procedures
Maintenance ............................... 23
Oven Window
Oven Light
Troubleshooting ...................24-25
Warranty & Service .................... 27
Form No. A/06/03 Part No. 8113P395-60 ©2003 Maytag Appliances Sales Co. Litho U.S.A .
Installer: Please leave this manual with this appliance.
Consumer: Please read and keep this manual for future
reference. Keep sales receipt and/or canceled check as proof
of purchase.
Model Number __________________________________
Serial Number __________________________________
Date of Purchase ________________________________
If you have questions, call:
Maytag Customer Assistance
1-800-688-9900 USA
1-800-688-2002 Canada
1-800-688-2080 ( U.S. TTY for hearing or speech impaired)
(Mon.-Fri., 8 am-8 pm Eastern Time)
Internet: http://www.maytag.com
In our continuing effort to improve the quality and performance
of our cooking products, it may be necessary to make changes
to the appliance without revising this guide.
For service information, see page 23.
Safety
IMPORTANT SAFETY
INSTRUCTIONS
Warning and Important Safety Instructions appearing in
this guide are not meant to cover all possible conditions
and situations that may occur. Common sense, caution,
and care must be exercised when installing, maintaining,
or operating the appliance.
Always contact your dealer, distributor, service agent, or
manufacturer about problems or conditions you do not
understand.
Recognize Safety Symbols, Words, Labels
To ensure proper and safe operation: Appliance must
be properly installed and grounded by a qualified technician. Do not attempt to adjust, repair, service, or replace
any part of your appliance unless it is specifically recommended in this guide. All other servicing should be
referred to a qualified servicer.
Always disconnect power to appliance before servicing.
WARNING
• ALL RANGES CAN TIP AND
CAUSE INJURIES TO PERSONS
• INSTALL ANTI-TIP DEVICE
PACKED WITH RANGE
• FOLLOW ALL INSTALLATION
INSTRUCTIONS
WARNING: To reduce risk of
tipping of the appliance from
abnormal usage or by excessive
loading of the oven door, the appliance must
be secure by a properly installed anti-tip device.
To check if device is properly installed, look underneath
range with a flashlight to make sure one of the rear
leveling legs is properly engaged in the bracket slot. The
anti-tip device secures the rear leveling leg to the floor
when properly engaged. You should check this anytime
the range has been moved.
To Prevent Fire or Smoke
Damage
• Be sure all packing materials are removed from the
appliance before operating it.
• Keep area around appliance clear and free from com-
bustible materials. Flammable materials should not be
stored in an oven.
WARNING
WARNING – Hazards or unsafe practices which
COULD result in severe personal injury or death.
CAUTION
CAUTION – Hazards or unsafe practices which
COULD result in minor personal injury.
Read and follow all instructions before using this
appliance to prevent the potential risk of fire, electric
shock, personal injury or damage to the appliance as a
result of improper usage of the appliance. Use appliance
only for its intended purpose as described in this guide.
• Many plastics are vulnerable to heat. Keep plastics away
from parts of the appliance that may become warm or
hot.
• To prevent grease fires, do not let cooking grease or
other flammable materials accumulate in or near the
appliance.
In Case of Fire
Use dry chemical or foam-type extinguisher or baking
soda to smother fire or flame. Never use water on a
grease fire.
1. Turn off appliance to avoid spreading the flame.
2. NEVER pick up or move a flaming pan.
3. Smother fire or flame by closing the oven door.
1
Safety
Child Safety
CAUTION
NEVER store items of interest to children in cabinets
above an appliance. Children climbing on the appliance
or on the appliance door to reach items could be
seriously injured.
• NEVER leave children alone or unsupervised near the
appliance when it is in use or is still hot. Children should
never be allowed to sit or stand on any part of the
appliance as they could be injured or burned.
• Children must be taught that the appliance and utensils
in it can be hot. Let hot utensils cool in a safe place, out
of reach of small children. Children should be taught
that an appliance is not a toy. Children should not be
allowed to play with controls or other parts of the
appliance.
About Your Appliance
CAUTION
NEVER use an appliance as a step to reach cabinets
above. Misuse of appliance doors, such as stepping,
leaning or sitting on the door, may result in possible
tipping of the appliance, breakage of door, and serious
injuries.
• To prevent potential hazard to the user and damage to
the appliance, do not use appliance as a space heater to
heat or warm a room. Also, do not use the oven as a
storage area for food or cooking utensils.
• Do not obstruct the flow of air by blocking the oven vent.
• DO NOT TOUCH HEATING ELEMENTS OR INTERIOR
SURFACES OF OVEN. Heating elements may be hot
even though they are dark in color. Interior surfaces of
any oven become hot enough to cause burns. During
and after use, do not touch, or let clothing or other
flammable materials contact heating elements or interior
surfaces of oven until they have had sufficient time to
cool. Other surfaces of the appliance may become hot
enough to cause burns – among these surfaces are:
oven vent openings and surfaces near these openings,
oven doors, windows of oven doors.
• Do not touch a hot oven light bulb with a damp cloth as
the bulb could break. Should the bulb break, disconnect
power to the appliance before removing bulb to avoid
electrical shock.
• NEVER use aluminum foil to cover an oven rack or oven
bottom. Misuse could result in risk of electric shock, fire,
or damage to the appliance. Use foil only as directed in
this guide.
Cooking Safety
• Never heat an unopened food container in the oven.
Pressure build-up may cause container to burst resulting
in serious personal injury or damage to the appliance.
• Use dry, sturdy potholders. Damp potholders may cause
burns from steam. Dish towels or other substitutes
should never be used as potholders because they can
trail across hot elements and ignite or get caught on
appliance parts.
• Wear proper apparel. Loose fitting or long hanging-
sleeved apparel should not be worn while cooking.
Clothing may ignite and cause burns if garment comes in
contact with heating elements.
• Always place oven racks in the desired positions while
oven is cool. Slide oven rack out to add or remove food,
using dry, sturdy potholders. Always avoid reaching into
the oven to add or remove food. If a rack must be moved
while hot, use a dry potholder. Do not let potholder
contact hot element in oven.
• Use racks only in the oven in which they were shipped/
purchased.
• Use care when opening the oven door. Let hot air or
steam escape before removing or replacing food.
• PREPARED FOOD WARNING: Follow food
manufacturer’s instructions. If a plastic frozen food
container and/or its cover distorts, warps, or is otherwise
damaged during cooking, immediately discard the food
and its container. The food could be contaminated.
• Do not allow aluminum foil or meat probe to contact
heating element.
• Always turn off all controls when cooking is completed.
Utensil Safety
• Follow the manufacturer’s directions when using oven
cooking bags.
• This appliance has been tested for safe performance
using conventional cookware. Do not use any devices or
accessories that are not specifically recommended in this
guide. Do not use add-on oven convection systems. The
use of devices or accessories that are not expressly
recommended in this guide can create serious safety
2
Safety
hazards, result in performance problems, and reduce the
life of the components of the appliance.
• If pan is smaller than element, a portion of the element
will be exposed to direct contact and could ignite
clothing or potholder.
• Only certain types of glass, glass/ceramic, ceramic,
earthenware, or other glazed utensils are suitable for
cooktop or oven service without breaking due to the
sudden change in temperature. Follow utensil manufacturer’s instructions when using glass.
• Turn pan handle toward center of cooktop, not out into
the room or over another surface element. This reduces
the risk of burns, ignition of flammable materials, or
spillage if pan is accidently bumped or reached by small
children.
Cooktop
• NEVER leave surface units unattended especially when
using high heat. An unattended boilover could cause
smoking and a greasy spillover can cause a fire.
• This appliance is equipped with different size surface
elements. Select pans with flat bottoms large enough to
cover element. Fitting pan size to element will improve
cooking efficiency.
• GLASS-CERAMIC SURFACE: NEVER cook on broken
cooktop. If cooktop should break, cleaning solutions
and spillovers may penetrate the broken cooktop and
create a risk of electric shock. Contact a qualified
technician immediately.
cleaning. Clean with caution. Use care to avoid steam
burns if a wet sponge or cloth is used to wipe spills on a
hot surface. Some cleaners can produce noxious fumes
if applied to a hot surface.
• Clean only parts listed in this guide.
Self-Clean Oven
CAUTION
Do not leave racks, broiling pan, food or cooking
utensils, etc. in the oven during the self-clean cycle.
• Do not clean door gasket. The door gasket is essential
for a good seal. Care should be taken not to rub, damage, or move the gasket.
• Do not use oven cleaners or oven liners of any kind in or
around any part of the self-clean oven.
• Before self-cleaning the oven, remove broiler pan, oven
racks and other utensils, and wipe off excessive
spillovers to prevent excessive smoke or flare ups.
Important Safety Notice and
Warning
The California Safe Drinking Water and Toxic Enforcement
Act of 1986 (Proposition 65) requires the Governor of
California to publish a list of substances known to the
State of California to cause cancer or reproductive harm,
and requires businesses to warn customers of potential
exposures to such substances.
Deep Fat Fryers
Use extreme caution when moving the grease pan or
disposing of hot grease. Allow grease to cool before
attempting to move pan.
Ventilating Hoods
• Clean range hood and filters frequently to prevent
grease or other flammable materials from accumulating
on hood or filter and to avoid grease fires.
• When flaming foods under the hood, turn the fan on.
Cleaning Safety
• Clean cooktop with caution. Turn off all controls and
wait for appliance parts to cool before touching or
Save These Instructions for Future Reference
Users of this appliance are hereby warned that when the
oven is engaged in the self-clean cycle, there may be
some low-level exposure to some of the listed substances,
including carbon monoxide. Exposure to these substances
can be minimized by properly venting the oven to the
outdoors by opening the windows and/or door in the room
where the appliance is located during the self-clean cycle.
IMPORTANT NOTICE REGARDING PET BIRDS: Never
keep pet birds in the kitchen or in rooms where the fumes
from the kitchen could reach. Birds have a very sensitive
respiratory system. Fumes released during an oven selfcleaning cycle may be harmful or fatal to birds. Fumes
released due to overheated cooking oil, fat, margarine and
overheated non-stick cookware may be equally harmful.
3
Surface Cooking
Surface Controls
Use to turn on the surface elements. An infinite choice of
heat settings is available from Low to High. The knobs can
be set on or between any of the settings.
Setting the Controls
1. Place pan on surface element.
2. Push in and turn the knob in either direction to the desired
heat setting.
• The control panel is marked to identify which
element the knob controls. For example, the
graphic at right indicates left front element.
3. There is an element indicator light on the control panel.
When any surface control knob is turned on, the light will
turn on. The light will turn off when all the surface elements are turned off.
4. After cooking, turn knob to Off. Remove pan.
Dual Elements (select models)
The cooking surface has dual elements
located in the right front and/or left
front positions on the smoothtop. This
allows you to change the size of these
elements.
Press the switch to the left to use the
large element or to the right to use the
small element.
Suggested Heat Settings
The size, type of cookware and cooking operation will affect the
heat setting. For information on cookware and other factors
affecting heat settings, refer to Cookware Recommendations on
page 7 and “Cooking Made Simple” booklet.
Low (2): Use to keep foods
warm and melt chocolate
and butter.
Med. Low (3-4):
Use to continue
cooking covered
foods or steam
foods.
Medium (5-7): Use to
maintain slow boil for
large amounts of liquids
and for most frying
operations.
Control style varies by model.
High (10): Use to bring
liquid to a boil. Always
reduce setting to a lower
heat when liquids begin to
boil or foods begin to cook.
Med. High (8-9): Use
to brown meat, heat oil
for deep fat frying or
sauteing. Maintain fast
boil for large amounts
of liquids.
BEFORE COOKING
• Always place a pan on the surface unit before you turn it
on. To prevent damage to range, never operate surface
unit without a pan in place.
• NEVER use the cooktop as a storage area for food or
cookware.
DURING COOKING
• Be sure you know which knob controls which surface
unit. Make sure you turned on the correct surface unit.
• Begin cooking on a higher heat setting then reduce to a
lower setting to complete the operation. Never use a
high heat setting for extended cooking.
• NEVER allow a pan to boil dry. This could damage the
pan and the appliance.
• NEVER touch cooktop until it has cooled. Expect some
parts of the cooktop, especially around the surface units,
to become warm or hot during cooking. Use potholders
to protect hands.
CAUTION
AFTER COOKING
• Make sure surface unit is turned off.
• Clean up messy spills as soon as possible.
OTHER TIPS
• If cabinet storage is provided directly above cooking
surface, limit it to items that are infrequently used and can
be safely stored in an area subjected to heat. Temperatures may be unsafe for items such as volatile liquids,
cleaners or aerosol sprays.
• NEVER leave any items, especially plastic items, on the
cooktop. The hot air from the vent may ignite flammable
items, melt or soften plastics, or increase pressure in
closed containers causing them to burst.
• NEVER allow aluminum foil, meat probes or any other
metal object, other than a pan on a surface element, to
contact heating elements.
• NEVER store heavy items above the cooktop that could fall
and damage it.
4
Surface Cooking
Smoothtop Surface
Smoothtop Surface Notes:
• Cooktop may emit light smoke and odor the first few
times the cooktop is used. This is normal.
• Smoothtop cooktops retain heat for a period of time
after the element is turned off. Turn the elements off
a few minutes before food is completely cooked and use
the retained heat to complete cooking. When the hot
surface light turns off, the cooking area will be cool
enough to touch. Because of the way they retain heat, the
smoothtop elements will not respond to changes in
settings as quickly as coil elements.
• In the event of a potential boilover, remove the pan from
the cooking surface.
• Never attempt to lift the cooktop.
• The smoothtop surface may appear discolored when it is
hot. This is normal and will disappear when the surface
cools.
FlexChoice Element (select models)
The FlexChoice element is a fully
functioning element that provides
an ultra low (Warm) heat setting
for holding delicate sauces and
keeping cooked foods warm. It is
located in the right rear position.
The Warm setting is located
between Low and OFF on the
control. Heat settings outside of this
area function as a normal element, with
Low to High settings.
Control style varies by model.
Note: When using the normal element settings for preparing foods, it may take a few minutes for the cooking area to
cool to the Warm heat setting.
Tips to Protect the
Smoothtop Surface
Cooking Areas
The cooking areas on your range are identified by permanent
circles on the smoothtop surface. For most efficient cooking,
fit the pan size to the element size.
Pans should not extend more than 1/2 to 1-inch beyond
the cooking area.
When a control is turned on, a glow can be seen through the
smoothtop surface. The element will cycle on and off to
maintain the preset heat setting, even on Hi.
For more information on cookware, refer to Cookware
Recommendations on page 6 and “Cooking Made Simple”
booklet included with your range.
SINGLE
ELEMENT
DUAL ELEMENT
(SELECT MODELS)
FLEXCHOICE ELEMENT
(SELECT MODELS)
Hot Surface Light
The Hot Surface indicator light is located on
the control panel. The light will be illuminated
when any cooking area is hot. It will remain
on, even after the control is turned off, until the area has
cooled.
Cleaning (see page 18 for more information)
• Before first use, clean the cooktop.
• Clean your cooktop daily or after each use. This will keep
your cooktop looking good and can prevent damage.
• If a spillover occurs while cooking, immediately clean the
spill from the cooking area while it is hot to prevent a tough
cleaning chore later. Using extreme care, wipe spill with a
clean dry towel.
• Do not allow spills to remain on the cooking area or the
cooktop trim for a long period of time.
• Never use abrasive cleansing powders or scouring pads
which will scratch the cooktop.
• Never use chlorine bleach, ammonia or other cleansers not
specifically recommended for use on glass-ceramic.
To Prevent Marks & Scratches
• Do not use glass pans. They may scratch the surface.
• Never place a trivet or wok ring between the surface and
pan. These items can mark or etch the top.
• Do not slide aluminum pans across a hot surface. The pans
may leave marks which need to be removed promptly. (See
Cleaning, page 18.)
cont.
5
Surface Cooking
• Make sure the surface and the pan bottom are clean before
turning on to prevent scratches.
• To prevent scratching or damage to the glass-ceramic top,
do not leave sugar, salt or fats on the cooking area. Wipe
the cooktop surface with a clean cloth or paper towel
before using.
• Never slide heavy metal pans across the surface since
these may scratch.
To Prevent Stains
• Never use a soiled dish cloth or sponge to clean the
cooktop surface. A film will remain which may cause stains
on the cooking surface after the area is heated.
• Continuously cooking on a soiled surface may/will result in
a permanent stain.
To Prevent Other Damage
• Do not allow plastic, sugar or foods with high sugar content
to melt onto the hot cooktop. Should this happen, clean
immediately. (See Cleaning, page 18.)
• Never let a pan boil dry as this will damage the surface and
pan.
• Never use cooktop as a work surface or cutting board.
• Never cook food directly on the surface.
• Do not use a small pan on a large element. Not only does
this waste energy, but it can also result in spillovers burning
onto the cooking area which requires extra cleaning.
• Do not use non-flat specialty items that are oversized or
uneven such as round bottom woks, rippled bottom and/or
oversized canners and griddles.
• Do not use foil or foil-type containers. Foil may melt onto
the glass. If metal melts on the cooktop, do not use. Call an
authorized Maytag Servicer.
Cookware Recommendations
Using the right cookware can prevent many problems, such
as food taking longer to cook or achieving inconsistent
results. Proper pans will reduce cooking times, use less
energy, and cook food more evenly.
Flat Pan Tests
See if your pans are flat.
The Ruler Test:
1. Place a ruler across the bottom of the pan.
2. Hold it up to the light.
3. Little or no light should be visible under the ruler.
The Bubble Test:
1. Put 1 inch of water in the pan. Place on cooktop and turn
control to High.
2. Watch the formation of the bubbles as the water heats.
Uniform bubbles mean good performance, and uneven
bubbles indicate hot spots and uneven cooking.
See “Cooking Made Simple” booklet for more information.
Select Avoid
Flat, smooth-bottom Pans with grooved or warped bottoms.
pans. Pans with uneven bottoms do not cook
efficiently and sometimes may not
boil liquid.
Heavy-gauge pans. Very thin-gauge metal or glass pans.
Pans that are the Pans smaller or larger than the
same size as the element by 1 inch.
element.
Secure handles. Cookware with loose or broken handles.
Heavy handles that tilt the pan.
Tight-fitting lids. Loose-fitting lids.
Flat bottom woks. Woks with a ring-stand bottom.
Canning and Oversize
Cookware
All canners and large pots must have flat bottoms and
must be made from heavy-gauge materials. This is critical
on smoothtop surfaces. The base must not be more than
1 inch larger than the element.
When canners and pots do not meet these standards, cooking
times may be longer, and cooktops may be damaged.
Some canners are designed with smaller bases for use on
smoothtop surfaces.
When canning, use the High heat setting only until the
water comes to a boil or pressure is reached in the canner.
Reduce to the lowest heat setting that maintains the boil or
pressure. If the heat is not turned down, the cooktop may be
damaged.
See “Cooking Made Simple” booklet for more information.
6
Oven Cooking
Control Panel
A B C D
E F G H I J
The control panel is designed for ease in programming. The display window on the control shows time of day, timer and oven functions.
Control panel shown includes model specific features. (Styling may vary depending on model.)
A Broil Use for broiling and top browning.
B Bake Use for baking and roasting.
C More+ or Enters or changes time, oven
Less- temperature. Sets HI or LO broil.
D Timer Sets Timer.
E Cook & Hold Bakes for a preset time, then holds food
warm for 1 hour.
F Clean Use to set self-clean cycle.
G Delay Programs the oven to start baking at
a later time.
H Clock Use to set time of day clock.
I Keep Warm Use to keep cooked food warm in oven.
J CANCEL Cancels all operations except Timer
and Clock.
Using the Touchpads
• Press the desired pad.
• Press the More+ or Less- pad to enter time or temperature.
•A beep will sound when any pad is touched.
•A double beep will sound if a programming error occurs.
Note: Four seconds after pressing the More+ or Lesspad, the time or temperature will automatically be entered.
If more than 30 seconds elapse between touching a
function pad and the More+ or Less- pad, the function will
be canceled and the display will return to the previous
display.
Clock
The clock can be set to display time in a 12-hour or 24-hour
format. The clock is set at the factory for the 12-hour format.
To change the clock to
24-hour format:
1. Press and hold the CANCEL and Delay
pads for three seconds.
2. Set the time of day following the
directions below.
To set the Clock:
1. Press the Clock pad.
• Time of day and the colon flash in the
display.
2. Press the More+ or Less- pad to set the
time of day.
• Colon continues flashing.
3. Press the Clock pad again or wait four
seconds.
When electrical power is supplied or after a power interruption, the last clock time before power was interrupted will
flash.
To recall the time of day when another time function is
showing, press the Clock pad.
Clock time cannot be changed when the oven has been
programmed for cook or clean Delay or Cook & Hold.
7
Oven Cooking
To cancel the Clock display:
If you do not want the time of day to display:
Press and hold the CANCEL and Clock pads for three seconds. The time of day will disappear from the display
When the clock display is canceled, press the Clock pad to
briefly display the time of day.
To restore the Clock display:
Press and hold the CANCEL and Clock
pads for three seconds. The time of day
will reappear in the display.
Timer
The timer can be set from one minute (00:01) up to 99 hours
and 59 minutes (99:59).
The timer can be used independently of any other oven
activity. It can also be set while another oven function is
operating.
The Timer does not control the oven. It only controls a
beeper.
To set the Timer:
1. Press the Timer pad.
• 00:00 lights in the display.
• The colon flashes in the display.
2. Press the More+ or Less- pad until the
correct time appears in the display.
• The colon will continue to flash.
3. Press Timer pad again or wait four seconds.
• The colon continues flashing and the time begins
counting down.
• The last minute of the timer countdown will be displayed
as seconds.
4. At the end of the set time, one long beep will sound.
To cancel the Timer:
1. Press and hold the Timer pad for three seconds.
OR
2. Press the Timer pad and set the time to 00:00.
Locking the Control
and Oven Door
The touch pad controls and oven door can be locked for
safety, cleaning, or to prevent unwanted use. They will not
function when locked.
If the oven is currently in use, the controls and door cannot be
locked.
The current time of day will remain in the display when the
controls are locked.
To lock:
Press and hold the CANCEL and Cook &
Hold pads for three seconds.
• LOCK flashes in the display.
To unlock:
Press and hold the CANCEL and Cook & Hold pads for three
seconds.
• LOCK disappears from the display.
Fault Codes
BAKE or LOCK may flash rapidly in the display to alert you if
there is an error or a problem. If BAKE or LOCK flash in the
display, press CANCEL pad. If BAKE or LOCK continue to
flash, disconnect power to the appliance. Wait a few minutes,
and then reconnect power. If the flashing still continues,
disconnect power to the appliance and call an authorized
servicer.
CAUTION
• Food preparation warning: Follow food manufac-
turer’s instructions. If a plastic frozen-food container
and/or its cover distorts, warps, or is otherwise damaged
during cooking, immediately discard the food and its
container. The food could be contaminated.
• When using oven-cooking bags follow the manufacturer’s
directions.
• Do not use oven for storing food or cookware.
• Be sure all packing material is removed from oven before
turning on.
• Never change the oven rack position when the oven is
hot.
8
Oven Cooking
Baking
Operating the Controls for Routine Baking:
1. Press the Bake pad.
• “BAKE” will flash.
• 000 will light in the display.
2. Select the oven temperature. The oven temperature can be set from 170° to 550°. Press or press
and hold the More+ or Less- pads.
• 350° will light when either pad is first pressed.
• Press the More+ pad to increase the temperature.
• Press the Less- pad pad to decrease the temperature.
3. Press Bake pad again or wait four seconds.
• BAKE will stop flashing and light in the display.
• 100° or the actual oven temperature will display. The
temperature will rise in 5° increments until the preset
temperature is reached.
4. Allow the oven to preheat for 8-15 minutes.
• When the set oven temperature is reached, one long
beep will sound.
• To recall the set temperature during preheat, press the
Bake pad.
5. Place food in the oven.
6. Check cooking progress at the minimum cooking time.
Cook longer if needed.
7. When cooking is finished, press CANCEL.
8. Remove food from the oven.
Baking Notes:
Baking Differences Between Your Old
and New Oven
It is normal to notice some baking time differences between a
new oven and an old one. See “Adjusting the Oven Temperature”
on page 12.
Cook & Hold
Cook & Hold allows you to bake for a preset amount of time,
followed by a one-hour Keep Warm cycle.
To set Cook & Hold:
1. Press the Cook & Hold pad.
• “BAKE” and “HOLD” flash.
• 000 lights in the display.
2. Select the oven temperature. The oven temperature can be set from 170° to 550°. Press or press
and hold the More+ or Less- pads.
• Press the More+ pad to increase the temperature.
• Press the Less- pad to decrease the temperature.
3. Press Cook & Hold again OR wait four seconds.
• “HOLD” flashes.
• 00:00 flashes in the display.
4. Enter the amount of time you want to bake by pressing the
More+ or Less- pads. Bake time can be set from ten
minutes (00:10) to (11:59).
• “BAKE” and “HOLD” light in the display.
• The baking time will light in the display.
• The baking time will start counting down.
When the cooking time has elapsed:
• Four beeps will sound.
• “BAKE” will turn off.
• “HOLD” and “WARM” will light.
• 170° will display.
• To change the oven temperature during cooking, press
the More+ or Less- pad until you reach the desired
temperature.
• If you forget to turn off the oven, it will automatically turn
off at the end of 12 hours. If you wish to deactivate this
feature, see page 12.
• For additional baking and roasting tips, see “Cooking
Made Simple” booklet.
After one hour in HOLD WARM:
• “End” will display.
• The time of day reappears in the display.
To cancel Cook & Hold at any time:
Press the CANCEL pad. Remove food from oven.
9
Oven Cooking
Delay Bake
CAUTION
Do not use delayed baking for highly perishable foods such
as dairy products, pork, poultry, or seafood.
When using Delay, the oven begins to cook later in the day.
Set the amount of time that you want to delay before the oven
turns on and how long you want to cook. The oven begins to
heat at the selected time and cooks for the specified length of
time.
Delay time can be set from 10 minutes (00:10) to 11 hours, 59
minutes (11:59).
To set a Delayed Baking cycle:
1. Press the Delay pad.
• “DELAY” flashes.
• 00:00 flashes in the display.
2. Press the More+ or Less- pad to set the
delay time.
While “DELAY” is still flashing:
3. Press the Cook & Hold pad.
• 000 lights in the display.
• “BAKE” and “HOLD” flash.
4. Press More+ pad to set the baking temperature.
• 00:00 and “HOLD” flash.
• “BAKE” stays lit.
5. Press More+ pad to set the baking time.
• The Delay time, “DELAY”, “BAKE” and “HOLD” light in
the display.
When the Delay time has expired:
• “DELAY” will turn off.
• Baking time is displayed.
• “BAKE” and “HOLD” are displayed.
To set a Delay when Cook & Hold has already
been programmed:
1. Press the Delay pad.
• “DELAY” flashes.
• 00:00 appears in the display.
2. Press the More+ or Less- pad to set the
delay time.
• After four seconds, the DELAY icon will
stay lit to remind you that a delayed
cooking cycle has been set.
When the Delay time has expired and the oven
starts:
• The baking time will be displayed.
• “DELAY” will turn off.
• BAKE will remain lit.
To cancel:
Press the CANCEL pad.
• All timed and untimed cooking functions will be
canceled.
• The time of day will reappear in the display.
Note: Do not use Delayed Baking for items that require a
preheated oven, such as cakes, cookies, and breads.
10
Oven Cooking
Keep Warm
For safely keeping foods warm or for warming breads and
plates.
To set Keep Warm:
1. Press the Keep Warm pad.
• “WARM” flashes.
• 000 appears in the display.
2. Select the Keep Warm temperature. The Keep
Warm temperature can be set from 145° to
190°. Press or press and hold the More+ or
Less- pads.
• 170° will light when either pad is first pressed.
• Press the More+ pad to increase the temperature.
• Press the Less- pad to decrease the temperature.
WARM and the temperature will be displayed while Keep
Warm is active.
Keep Warm Notes:
• For optimal food quality, oven cooked foods should be kept
warm for no longer than 1 to 2 hours.
• For optimal food quality and color, foods cooked on the
range top should be kept warm for an hour or less.
• To keep foods from drying, cover loosely with foil or a lid.
• To warm dinner rolls:
- cover rolls loosely with foil and place in oven.
- press Keep Warm and More+ pad to set 170° F.
- warm for 12-15 minutes.
• To warm plates:
- place 2 stacks of up to four plates each in the oven.
- press Keep Warm and More+ pad to set 170° F.
- warm for five minutes, turn off the oven and leave plates
in the oven for 15 minutes more.
- use only oven-safe plates, check with the manufacturer.
- do not set warm dishes on a cold surface as rapid
temperature changes could cause crazing.
To cancel Keep Warm:
1. Press the CANCEL pad.
2. Remove food from the oven.
11
Oven Cooking
Automatic Shut-Off/Sabbath
Mode
The oven will automatically turn off after 12 hours if you
accidentally leave it on. This safety feature can be turned off.
To cancel the 12-hour shut-off and run the
oven continuously for 72 hours:
1. Set the oven to bake (see page 9).
2. Press and hold the Clock pad for three seconds.
• SAb will be displayed and flash for five seconds.
• SAb will then be displayed continuously until turned off
or until the 72-hour time limit is reached.
• “BAKE” will also be displayed if a bake cycle is in use
while the oven is in Sabbath Mode.
All other functions EXCEPT BAKE (Timer, Keep Warm,
Clean, etc.) are locked out during the Sabbath Mode.
To cancel Bake when in Sabbath Mode:
Press CANCEL.
• “BAKE” will turn off in the display.
• No beeps will sound.
To cancel the Sabbath Mode:
1. Press the Clock pad for three seconds.
OR
2. After 72 hours, the Sabbath Mode will end.
• SAb will flash for 5 seconds.
• The time of day will return to the display.
Adjusting the Oven Temperature
Oven temperatures are carefully tested for accuracy at the
factory. It is normal to notice some baking differences
between a new oven and an old one. As ranges get older, the
oven temperature can shift.
You may adjust the oven temperature if you think the oven is
not baking or browning correctly. To decide how much to
change the temperature, set the temperature 25° higher or
lower than your recipe recommends, then bake. The results
of the “test” should give you an idea of how much to adjust
the temperature.
To adjust the oven temperature:
1. Press Bake.
2. Enter 550° by pressing the More+ pad.
3. Press and hold the Bake pad for several
seconds or until 0° appears in the display.
If the oven temperature was previously adjusted, the
change will be displayed. For example, if the oven temperature was reduced by 15° the display will show “-15°”.
4. Press the More+ or Less- pad to adjust the temperature.
Each time a pad is pressed, the temperature changes by
5°. The oven temperature can be increased or decreased
by 5° to 35°.
5. The time of day will automatically reappear in the display
You do not need to readjust the oven temperature if there
is a power failure or interruption. Broiling and cleaning
temperatures cannot be adjusted.
Sabbath Mode Notes:
• Sabbath Mode can be turned on at any time with or
without the oven on.
• Sabbath Mode cannot be turned on if the keypads are
locked out or when the door is locked.
• If the oven is baking when Sabbath Mode is set, the
BAKE icon will go out at the end of the baking cycle.
There will be no audible beeps.
• If the oven light is desired while in Sabbath Mode, it
must be turned on before the Sabbath Mode is started.
• When the Sabbath Mode is started, no preheat beep will
sound.
• All prompts, messages and beeps are deactivated when
Sabbath Mode is active.
• The automatic door lock does not operate during the
Sabbath Mode.
• Pressing CANCEL will cancel a Bake cycle, however the
control will stay in the Sabbath Mode.
12
Oven Cooking
Broiling
To set Broil:
1. Press the Broil pad.
• “BROIL” flashes.
• SEt is displayed.
2. Press the More+ pad to set HI broil or press the Less- pad
to set LO broil.
• HI or LO will be displayed.
• Select HI (550° F) broil for normal broiling. Select
LO (450° F) broil for low-temperature broiling of longer
cooking foods such as poultry.
3. After four seconds, the oven will start.
• “BROIL” will remain lit.
4. For optimum browning, preheat broil element for 3-4
minutes before adding food.
5. Place food in the oven. Leave oven door open about four
inches (the first stop).
6. Turn meat once about halfway through cooking.
7. When food is cooked, press the CANCEL
pad. Remove food and broiler pan from
the oven.
• The time of day will reappear in the display.
Broil Notes:
• For best results when broiling, use a pan designed for
broiling.
• Expect broil times to increase and browning to be
slightly lighter if appliance is installed on a 208-volt
circuit.
• For additional broiling tips, refer to the “Cooking Made
Simple” booklet.
Broiling Chart
RACK APPROX. TIME APPROX. TIME
FOODS POSITION FIRST SIDE SECOND SIDE
Beef
Steak, 1” thick, Medium 6 8 minutes 7 - 12 minutes
Well 6 10 minutes 8 - 14 minutes
Hamburgers, 3/4” thick, Well 6 or 7 9 minutes 6 - 9 minutes
Pork
Bacon 6 6 - 10 minutes (no turning)
Chops, 1” 6 10 - 11 minutes 12 - 14 minutes
Ham Slice 6 5 minutes 3 - 7 minutes
Poultry LO Broil LO Broil
Breast Halves 4 15 minutes 15 - 25 minutes
Seafood
Fish Steaks, buttered, 1” thick 6 10 - 15 minutes (no turning)
Lobster Tails, 3-4 oz. each 5 7 - 10 minutes (no turning)
Note: This chart is a suggested guide. The times may vary with the food being cooked.
13
Oven Cooking
Oven Vent
When the oven is in use the area near the vent may become
hot enough to cause burns. Never block the vent opening.
The oven vent is located below the backguard vent
shield on your range.
OVEN VENT
LOCATION
Do not place
plastics near the
vent opening as
heat from the vent
could distort or
melt the plastic.
Oven Light
Press the Oven Light switch on the control panel to
turn the oven light on and off.
Oven Bottom
Protect oven bottom against spillovers, especially acidic or
sugary spills, as they may discolor the porcelain enamel. Use
the correct pan size to avoid spillovers and boilovers. Do not
place utensils or aluminum foil directly on the oven
bottom.
Oven Racks
CAUTION
• Do not attempt to change the rack position when the oven
is hot.
• Do not use the oven for storing food or cookware.
The oven has two racks. All racks are designed with a lockstop edge.
To remove:
1. Pull rack straight out until it
stops at the lock-stop
position.
2. Lift up on the front of the
rack and pull out.
To replace:
1. Place rack on the rack support in the oven.
2. Tilt the front end up slightly. Slide rack back until it clears
the lock-stop position.
3. Lower front and slide back into the oven.
Never cover an entire rack with aluminum foil or place
foil on the oven bottom. Baking results will be affected
and damage may occur to the oven bottom.
Rack Positions
RACK 7 (highest position):
For toasting bread or broiling
thin, non-fatty foods.
RACK 6: Used for most
broiling.
RACK 5: For two rack
baking.
RACK 4: Used for most
baked goods on a cookie sheet or jelly roll pan, fruit pies, or
frozen convenience foods. Also use for broiling chicken
pieces.
RACK 3: For casseroles, baking loaves of bread, bundt cakes
or custard pies.
Two Rack Baking
cont.
7
6
5
4
3
2
1
Oven
Bottom
14
Oven Cooking
RACK 2: Used for roasting small cuts of meat, frozen pies,
dessert souffles or angel food cake. Also use for two rack
baking.
RACK 1: Used for roasting large cuts of meat and poultry.
Oven Bottom: Place oven rack on
raised sides of oven bottom. Use for
additional space when cooking large
oven meals.
MULTIPLE RACK COOKING: Two
rack: Use rack positions 2 and 5.
Baking Layer Cakes on Two Racks
For best results when baking cakes on two racks, use racks 2
and 4.
Place the cakes on the rack as shown.
15
Care & Cleaning
Self-Clean Oven
CAUTION
• It is normal for parts of the range to become hot during a
self-clean cycle.
• To prevent damage to oven door, do not attempt to open
the door when LOCK is displayed.
• Avoid touching cooktop, door, window or oven vent area
during a clean cycle.
• Do not use commercial oven cleaners on the oven finish
or around any part of the oven. They will damage the
finish or parts.
The self-clean cycle uses above-normal cooking temperatures
to automatically clean the oven interior.
It is normal for flare-ups, smoking, or flaming to occur during
cleaning if the oven is heavily soiled. It is better to clean the
oven regularly rather than to wait until there is a heavy buildup of soil in the oven.
During the cleaning process, the kitchen should be well
ventilated to get rid of normal odors associated with cleaning.
To set Self-Clean:
Note: Oven temperature must be below 400° F to program
a clean cycle.
1. Close the oven door.
2. Press the Clean pad.
• “CLEAN” flashes in the display.
If the door is not closed, beeps will sound and DOOR will
display. If the door is not closed within 45 seconds, the
self-cleaning operation will be canceled and the display
will return to the time of day.
3. Press the More+ or Less- pad.
• CL-M (Clean – Medium Soil) is displayed.
4. Press the More+ or Less- pad to scroll through
the self-cleaning settings.
CL-H (Clean – Heavy Soil, 4 hours)
CL-M (Clean – Medium Soil, 3 hours)
CL-L (Clean – Light Soil, 2 hours)
Choosing the soil level of the oven automatically programs
the self-cleaning time.
5. After four seconds, the oven will start cleaning.
Before Self-Cleaning
1. Turn off the oven light before cleaning. The light may burn
out during the clean cycle.
2. Remove broiler pan, all pans, and oven racks from the
oven. The oven racks will discolor and may not slide easily
after a self-clean cycle if they are not removed.
3. Clean oven frame, door frame (area outside of gasket, and
around the opening in the door gasket with a nonabrasive
cleaner such as Bon Ami* or detergent and water. The
self-cleaning process does not clean these areas. They
should be cleaned to prevent soil from baking on during
the clean cycle. (The gasket is the
seal around the oven door and
window).
4. To prevent damage, do not clean or
rub the gasket around the oven
door. The gasket is designed to
seal in heat during the clean cycle.
5. Wipe up excess grease or spillovers from the oven bottom.
This prevents excessive smoking, flare-ups or flaming
during the clean cycle. To make cleaning easier, the
heating element can be lifted slightly (1 inch).
6. Wipe up sugary and acidic spillovers such as sweet
potatoes, tomato, or milk-based sauces. Porcelain enamel
is acid-resistant, not acid-proof. The porcelain finish may
discolor if acidic spills are not wiped up before a self-clean
cycle.
* Brand names for cleaning products are registered trademarks of the respective manufacturers.
• The cleaning time will start counting down in the display.
• “LOCK” will appear in the display.
• “CLEAN” will appear in the display.
To Delay a Self-Clean Cycle:
1. Press the Delay pad.
• “DELAY” flashes.
• 00:00 will appear in the display.
2. Press the More+ or Less- pad to set
the amount of time you want to delay
the cycle.
3. Press the Clean pad.
• “CLEAN” will flash.
4. Press the More+ or Less- pad.
• CL-M (Clean – Medium Soil)
is displayed.
16
cont.
Care & Cleaning
5. Press the More+ or Less- pad to scroll through the selfcleaning settings.
CL-H (Clean – Heavy Soil, 4 hours)
CL-M (Clean – Medium Soil, 3 hours)
CL-L (Clean – Light Soil, 2 hours)
Choosing the soil level of the oven automatically programs
the self-cleaning time.
6. After four seconds, CLEAN, DELAY and LOCK will appear
in the display to show that the oven is set for a delayed
clean operation. The delay time is displayed.
If the oven has already been set for a clean
cycle and you wish to set a delay:
1. Press the Delay pad.
• “DELAY” flashes.
• 00:00 will appear in the display.
2. Press the More+ or Less- pad to set the
amount of time you want to delay the cycle.
After four seconds, CLEAN, DELAY and LOCK will appear
in the display to show that the oven is set for a delayed
clean operation. The delay time is displayed.
When the Self-Clean cycle starts:
• “DELAY” will turn off.
• The clean time will appear in the display.
To cancel the Self-Clean cycle:
Press the Cancel pad.
• All words disappear from the display.
• All functions are canceled.
• The time of day appears in the display.
During the Self-Clean Cycle
When LOCK shows in the display, the door cannot be opened.
To prevent damage to the door, do not force the door open
when LOCK is displayed.
Smoke and Smells
You may see some smoke and smell an odor the first few
times the oven is cleaned. This is normal and will lessen in
time.
Smoke may also occur if the oven is heavily soiled or if a
broiler pan was left in the oven.
Sounds
As the oven heats, you may hear sounds of metal parts
expanding and contracting. This is normal and will not
damage the oven.
After Self-Cleaning
About one hour after the end of the self-clean cycle, LOCK
will turn off. The door can then be opened.
Some soil may leave a light gray, powdery ash. Remove
it with a damp cloth. If soil remains after wiping, that means
the clean cycle was not long enough. The soil will be removed during the next clean cycle.
If oven racks were left in the oven and do not slide
smoothly after a clean cycle, wipe racks and rack supports
with a small amount of vegetable oil to make them easier to
move.
Fine lines may appear in the porcelain because it went
through heating and cooling. This is normal and will not
affect performance.
A white discoloration may appear after cleaning if acidic
or sugary foods were not wiped up before the self-clean
cycle. This discoloration is normal and will not affect perfor-
mance.
Notes:
• If the oven door is left open, “door” will flash in the
display and a signal will beep until the door is closed
and the Clean pad is pressed again.
• The oven door will be damaged if the oven door is
forced to open when LOCK is still displayed.
17
Care & Cleaning
Cleaning Procedures
CAUTION
• Be sure appliance is off and all parts are cool before handling
or cleaning. This is to avoid damage and possible burns.
• To prevent staining or discoloration, clean appliance after each use.
• If a part is removed, be sure it is correctly replaced.
PART PROCEDURE
Backguard and Porcelain enamel is glass fused on metal and may crack or chip with misuse. It is acid resistant, not acid
Cooktop – proof. All spillovers, especially acidic or sugary spillovers, should be wiped up immediately with a dry cloth.
Porcelain Enamel • When cool, wash with soapy water, rinse and dry.
• Never wipe off a warm or hot surface with a damp cloth. This may cause cracking or chipping.
• Never use oven cleaners, abrasive or caustic cleaning agents on exterior finish of range.
Broiler Pan and Never cover insert with aluminum foil as this prevents the fat from draining to the pan below.
Insert • Place soapy cloth over insert and pan; let soak to loosen soil.
• Wash in warm soapy water. Use scouring pad to remove stubborn soil.
• Broiler pan and insert can be cleaned in dishwasher.
* Brand names are registered trademarks of the
respective manufacturers.
** To order call 1-877-232-6771.
Clock and • To activate “Control Lock” for cleaning, see page 8.
Control Pad • Wipe with a damp cloth and dry.
Area • Glass cleaners may be used if sprayed on a cloth first. DO NOT spray directly on control pad and
display area.
Control Knobs • Remove knobs in the OFF position by pulling forward.
• Wash, rinse and dry. Do not use abrasive cleaning agents as they may scratch the finish.
• Turn on each element to be sure the knobs have been correctly replaced.
Cooktop – Never use oven cleaners, chlorine bleach, ammonia or glass cleaners with ammonia. NOTE: Call an authorized
Glass-Ceramic servicer if the glass-ceramic top should crack, break or if metal or aluminum foil should melt on the cooktop.
• Allow the cooktop to cool before cleaning.
• General – Clean cooktop after each use, or when needed, with a damp paper towel and Cooktop Cleaning
Creme* (Part No. 20000001)**. Then, buff with a clean dry cloth.
NOTE: Permanent stains will develop if soil is allowed to cook on by repeatedly using the cooktop when soiled.
• Heavy Soils or Metal Marks – Dampen a “scratchless” or “never scratch” scrubber sponge. Apply
Cooktop Cleaning Creme* (Part No. 20000001)** and scrub to remove as much soil as possible. Apply a
thin layer of the creme over the soil, cover with a damp paper towel and let stand 30 to 45 minutes (2-3
hours for very heavy soil). Keep moist by covering the paper towel with plastic wrap. Scrub again, then
buff with a clean dry cloth.
NOTE: Only use a CLEAN, DAMP “scratchless” pad that is safe for non-stick cookware. The pattern and glass
will be damaged if the pad is not damp, if the pad is soiled, or if another type of pad is used.
• Burned-on or Crusty Soils – Scrub with a “scratchless” or “never scratch” scouring pad and
Cooktop Cleaning Creme*.
NOTE: Hold a razor blade scraper at 30° angle and scrape any remaining soil. Then, clean as
described above. Do not use the razor blade for daily cleaning as it may wear the pattern on
the glass.
• Melted Sugar or Plastic – Immediately turn element to LOW and scrape sugar or
plastic from hot surface to a cool area. Then turn element OFF and allow to cool. Clean
residue with razor blade scraper and Cooktop Cleaning Creme*.
18
cont.
Care & Cleaning
PART PROCEDURE
Oven Window • Avoid using excessive amounts of water which may seep under or behind glass causing staining.
and Door – Glass • Wash with soap and water. Rinse with clear water and dry. Glass cleaner can be used if sprayed on a cloth
first.
• Do not use abrasive materials such as scouring pads, steel wool or powdered cleaners as they will scratch
glass.
Oven Interior • Follow instructions on pages 16-17 to set a self-clean cycle.
Oven Racks • Clean with soapy water.
• Remove stubborn soil with cleansing powder or soap-filled scouring pad. Rinse and dry.
• Racks will permanently discolor and may not slide smoothly if left in the oven during a self-clean operation.
If this occurs, wipe the rack edge and rack support with a small amount of vegetable oil to restore ease
of movement, then wipe off excess oil.
Stainless Steel • DO NOT USE ANY CLEANING PRODUCT CONTAINING CHLORINE BLEACH.
(select models) • DO NOT USE ABRASIVE OR ORANGE CLEANERS.
• ALWAYS WIPE WITH THE GRAIN WHEN CLEANING.
• Daily Cleaning/Light Soil –– Wipe with one of the following - soapy water, white vinegar/water solution,
Formula 409 Glass and Surface Cleaner* or a similar glass cleaner - using a sponge or soft cloth. Rinse
and dry. To polish and help prevent fingerprints, follow with Stainless Steel Magic Spray (Part No.
20000008)**.
• Moderate/Heavy Soil –– Wipe with one of the following - Bon Ami, Smart Cleanser, or Soft Scrub* using a damp sponge or soft cloth. Rinse and dry. Stubborn soils may be removed with a damp ScotchBrite* pad; rub evenly with the grain. Rinse and dry. To restore luster and remove streaks, follow with
Stainless Steel Magic Spray*.
• Discoloration –– Using a damp sponge or soft cloth, wipe with Cameo Stainless Steel Cleaner*. Rinse
immediately and dry. To remove streaks and restore luster, follow with Stainless Steel Magic Spray*.
Storage Drawer, • When cool, wash with warm soapy water, rinse and dry. Never wipe a warm or hot surface with a damp cloth
Door Handle, Side as this may damage the surface and may cause a steam burn.
Panels – Painted • For stubborn soil, use mildly abrasive cleaning agents such as baking soda paste or Bon Ami.* Do not use
Enamel abrasive, caustic or harsh cleaning agents such as steel wool pads or oven cleaners. These products will scratch
or permanently damage the surface.
NOTE: Use a dry towel or cloth to wipe up spills, especially acidic or sugary spills. Surface may discolor
or dull if soil is not immediately removed. This is especially important for white surfaces.
* Brand names for cleaning products are registered trademarks of the respective manufacturers.
** To order direct, call
1-877-232-6771.
19
T
Maintenance
Oven Door
CAUTION
Do not place excessive weight on or stand on an open
oven door. This could cause the range to tip over, break
the door, or injure the user.
Note: The oven door on a new range may feel “spongy”
when it is closed. This is normal and will decrease with use.
Oven Window
To protect the oven door window:
1. Do not use abrasive cleaning agents such as steel wool
scouring pads or powdered cleansers as they may scratch
the glass.
2. Do not hit the glass with pots, pans, furniture, toys, or other
objects.
3. Do not close the oven door until the oven racks are in
place.
To replace:
1. Fit the ends of the drawer glides into the rails in the range.
2. Lift up the front of the drawer and gently push in to the first
stop position.
3. Lift drawer up again and push until drawer is closed.
Leveling Legs
CAUTION
Be sure the anti-tip bracket secures one of the rear
leveling legs to the floor. This bracket prevents the range
from accidentally tipping.
The range should be leveled when installed. If
the range is not level, turn the plastic leveling
legs, located at each corner of the range, until
range is level.
ANTI-TIP BRACKE
ANTI-TIP BRACKET
LEVELING LEG
LEVELING LEG
Scratching, hitting, jarring or stressing the glass may weaken
its structure causing an increased risk of breakage at a later
date.
Storage Drawer
CAUTION
Do not store plastic, paper products, food or flammable
materials in this drawer. The drawer may become too warm
for these items when the oven is in use.
The storage drawer can be removed to allow you to clean under
the range.
To remove:
1. Empty drawer and pull out to the first stop position.
2. Lift up the front of the drawer.
3. Pull out to the second stop position.
4. Grasp sides and lift drawer top up and out.
Oven Light
CAUTION
• Disconnect power to range before replacing light bulb.
• Allow oven to cool before replacing light bulb.
• Make sure bulb cover and bulb are cool before touching.
To assure the proper replacement bulb is used, order bulb
from Maytag. Call 1-877-232-6771 and ask for part number
74004458 - halogen bulb.
To Replace Oven Light Bulb:
1. Disconnect power to the range.
2. When oven is cool, use fingertips to grasp edge of bulb cover.
Pull out and remove.
3. Carefully remove old bulb by pulling straight out of ceramic
base.
4. To avoid damaging or decreasing the life of the new bulb, do
not touch the bulb with bare hands or fingers. Hold with a
cloth or paper towel. Push new bulb prongs straight into
small holes of ceramic base.
5. Replace bulb cover by snapping into place.
6. Reconnect power to range. Reset clock.
20
Troubleshooting
PROBLEM SOLUTION
For most concerns, try these first. • Check if oven controls have been properly set.
• Check to be sure plug is securely inserted into receptacle.
• Check or re-set circuit breaker. Check or replace fuse.
• Check power supply.
Part or all of appliance does not • Check if surface and/or oven controls have been properly set. See pages 4 & 9.
work. • Check if oven door is unlocked after self-clean cycle. See pages 16-17.
• Check if oven is set for a delayed cook or clean program. See pages 10 & 16.
• Check if Control Lock is activated. See page 8.
• Check if control is in Sabbath Mode. See page 12.
Clock, indicator words, and/or • Oven may be set for a Cook & Hold or delay function.
lights operate but oven does • Control Lock may have been set. See page 8.
not heat.
Baking results are not as • Make sure the oven vent has not been blocked. See page 14 for location.
expected or differ from • Check to make sure range is level.
previous oven. • Temperatures often vary between a new oven and an old one. As ovens age, the oven
temperature often “drifts” and may become hotter or cooler. See page 12 for
instructions on adjusting the oven temperature. NOTE: It is not recommended to
adjust the temperature if only one or two recipes are in question.
• See “Cooking Made Simple” booklet for more information on bakeware and
baking.
Food is not broiling properly or • Check oven rack positions. Food may be too close to element.
smokes excessively. • Broil element was not preheated.
• Aluminum foil was incorrectly used. Never line the broiler insert with foil.
• Oven door was closed during broiling. Leave the door open to the first stop position
(about 4 inches).
• Trim excess fat from meat before broiling.
•A soiled broiler pan was used.
• Voltage in house may be low.
Oven will not self-clean. • Check to make sure the cycle is not set for a delayed start. See page 16.
• Check if door is closed.
• Check if control is in Sabbath Mode. See page 12.
• Oven may be over 400° F. Oven temperature must be below 400° F to program a
clean cycle.
Oven did not clean properly. • Longer cleaning time may be needed.
• Excessive spillovers, especially sugary and/or acidic foods, were not removed prior
to the self-clean cycle.
Oven door will not unlock after • Oven interior is still hot. Allow about one hour for the oven to cool after the
self-clean cycle. completion of a self-clean cycle. The door can be opened when LOCK
is not displayed.
• The control and door may be locked. See page 8.
21
Troubleshooting
PROBLEM SOLUTION
Smoothtop surface shows 1. Tiny scratches or abrasions.
wear. • Make sure cooktop and pan bottom are clean. Do not slide glass or metal pans
across top. Make sure pan bottom is not rough. Use the recommended
cleaning agents. See page 18.
2. Metal marks.
• Do not slide metal pans across top. When cool, clean with Cooktop
Cleaning Creme. See page 18.
3. Brown streaks and specks.
• Remove spills promptly. Never wipe with a soiled cloth or sponge. Make sure
cooktop and pan bottom are clean.
4. Areas with a metallic sheen.
• Mineral deposits from water and food. Use recommended cleaning agents.
See page 18.
5. Pitting or flaking.
• Remove sugary boilovers promptly. See page 18.
Moisture collects on oven • This is normal when cooking foods high in moisture.
window or steam comes from • Excessive moisture was used when cleaning the window.
oven vent.
There is a strong odor or light • This is normal for a new range and will disappear after a few uses. Initiating a clean
smoke when oven is turned on. cycle will “burn off” the odors more quickly.
• Turning on a ventilation fan will help remove the smoke and/or odor.
• Excessive food soils on the oven bottom. Use a self-clean cycle.
Fault Codes • BAKE or LOCK may flash rapidly in the display to alert you if there is an error
or a problem. If BAKE or LOCK appear in the display, press CANCEL pad.
If BAKE or LOCK continue to flash, disconnect power to the appliance.
Wait a few minutes, and then reconnect power. If the flashing still continues,
disconnect power to the appliance and call an authorized servicer.
• If the oven is heavily soiled, excessive flareups may result in a fault code during
cleaning. Press the CANCEL pad and allow the oven to cool completely, wipe out
excess soil, then reset the clean cycle. If the fault code reappears, contact an
authorized servicer.
Noises may be heard. • The oven makes several low level noises. You may hear the oven relays as they go on
and off. This is normal.
• As the oven heats and cools, you may hear sounds of metal parts expanding and
contracting. This is normal and will not damage your appliance.
There are no beeps and • Control may be in Sabbath Mode. See page 12.
no display.
22
Warranty & Service
Full One Year Warranty Parts and Labor
For one (1) year from the original retail
purchase date, any part which fails in
normal home use will be repaired or
replaced free of charge.
Limited Warranties - Parts Only
Second Through Fifth Year - From the
original purchase date, parts listed below
which fail in normal home use will be
repaired or replaced free of charge for
the part itself, with the owner paying all
other costs, including labor, mileage and
transportation, trip charge and diagnostic
charge, if required.
• Glass-ceramic Surface: Due to
thermal breakage, discoloration,
cracking of the rubber edge seal,
pattern wear.
• Electric Heating Elements: Radiant
surface elements on electric cooking
appliances.
Canadian Residents
The above warranties only cover an
appliance installed in Canada that has
been certified or listed by appropriate test
agencies for compliance to a National
Standard of Canada unless the appliance
was brought into Canada due to transfer
of residence from the United States to
Canada.
Limited Warranty Outside the
United States and Canada Parts Only
For one (1) year from the date of original
retail purchase, any part which fails in
normal home use will be repaired or
replaced free of charge for the part itself,
with the owner paying all other costs,
including labor, mileage and transportation, trip charge and diagnostic charge, if
required.
The specific warranties expressed above
are the ONLY warranties provided by the
manufacturer. These warranties give you
specific legal rights, and you may also have
other rights which vary from state to state.
What is Not Covered By These
Warranties:
1. Conditions and damages resulting from any of the following:
a. Improper installation, delivery, or maintenance.
b. Any repair, modification, alteration, or adjustment not authorized by
the manufacturer or an authorized servicer.
c. Misuse, abuse, accidents, or unreasonable use.
d. Incorrect electric current, voltage, or supply.
e. Improper setting of any control.
2 Warranties are void if the original serial numbers have been removed, altered,
or cannot be readily determined.
3. Light bulbs.
4. Products purchased for commercial or industrial use.
5. The cost of service or service call to:
a. Correct installation errors.
b. Instruct the user on the proper use of the product.
c. Transport the appliance to the servicer.
6. Damage to the glass cooktop caused by the use of cleaners other than the
recommended cleaning creams and pads.
7. Damage to the glass cooktop caused by hardened spills of sugary materials or
melted plastic that are not cleaned according to the directions in the use and
care guide.
8. Consequential or incidental damages sustained by any person as a result of
any breach of these warranties. Some states do not allow the exclusion or
limitation of consequential or incidental damages, so the above exclusion may
not apply.
If You Need Service
• Call the dealer from whom your appliance was purchased or call Maytag
ServicesSM, Maytag Customer Assistance at 1-800-688-9900 U.S.A. or
1-800-688-2002 Canada to locate an authorized servicer.
• Be sure to retain proof of purchase to verify warranty status. Refer to
WARRANTY for further information on owner’s responsibilities for warranty
service.
• If the dealer or service company cannot resolve the problem, write to Maytag
ServicesSM, Attn: CAIR® Center, P.O. Box 2370, Cleveland, TN 37320-2370, or
call 1-800-688-9900 U.S.A. or 1-800-688-2002 Canada.
U.S. customers using TTY for deaf, hearing impaired or speech impaired, call
1-800-688-2080.
• User’s guides, service manuals and parts information are available from
Maytag ServicesSM, Maytag Customer Assistance.
Notes:
When writing or calling about a service problem, please include:
a. Your name, address and telephone number;
b. Model number and serial number;
c. Name and address of your dealer or servicer;
d. A clear description of the problem you are having;
e. Proof of purchase (sales receipt).
Form No. A/06/03 Part No. 8113P395-60 ©2003 Maytag Appliances Sales Co. Litho U.S.A .
Loading...
