PARTS LIST
Medina Series
TM
96 Conference Table
Model No. MNCT96
Name Part
A
REALS001
Cam Lock
B
REALS405**
Cam Sticker/Silver
Spare
Qty.
Qty
HB
14 1 14 1
HB
14
1
C
PartName
REALS003
Cam Post
MNCT96HB
Qty.
HB
Spare
Qty
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N MNCT96 REV 2 04/14
www.mayline.com
Items with HB are in hardware box.
**Denotes Color Code
1
PARTS LIST
1
Insert Cams (A) into the Modesty Panel (K) and MNCB Legs (J). Install Cam Posts (C) into
threaded inserts in MNCB Legs (J). Attach Modesty Panel (K) to MNCB Legs (J) by turning
Cams (A).
Name Part
H
J
NOTE:
①
. 1 Top and 2
②. 2
Legs with Hardware
Qty.
1
MNCT96**
Top
2
MNCB**
Leg
Modesty Panels with Hardware
packed in one carton - MNCB
PartName
K
MNCT96K**
Modesty Panel
packed in one carton - MNCT96
Qty.
A
2
J
K
K
C
J
K
C
**Denotes Color Code
2
J
A
NOTE: The arrow on the face of the Cam (A) should
point towards the Cam Post (C) for proper alignment.
3
Install Cam Posts (C) into threaded inserts in underside of Top (H).
2
3
Place Top (H) onto Leg (J) and Modesty Panel (K) and lock in place by turning Cams (A). Apply
MNCB Cam Sticker onto Cams (A) of Legs (J). Apply Cam Stickers/Silver (B) onto Cams (A) of
Modesty Panel (K). Insert Grommets into Top holes.
A
MNCB Grommets
H
MNCB Cam Sticker
C
J
MNCB
Cam Sticker
K
J
K
B
H
C
J
A
NOTE: The arrow on the face of the Cam (A) should
point towards the Cam Post (C) for proper alignment.
4
5
