Mayfair YSQ1000 Specifications

RESIDENTIAL

PLASTIC TOILET SEAT

MODEL # COLOR #

170 _______

DESCRIPTION:

Closed front with cover, elongated, injection molded solid plastic toilet seat.
Features four molded-in bumpers, color-matched Top-Tite® hinges with
non-corrosive, top-tightening Hex-Tite™ bolts and wing nuts. This seat
complies with IAPMO/ANSI Z124.5-2013 Plastic Toilet Seats as a class
Commercial Heavy Duty.

SPECIFICATIONS:

Size: Elongated

Material: Plastic

Style: Closed Front with Cover

Bumpers: Four

Hinges: Plastic Top-Tite

Fastening System: Non-Corrosive Hex-Tite™ Bolts and Wing Nuts

®

TOP-TITE® HINGES

NON-CORROSIVE BOLTS

AND WING NUTS

FEATURES:

®

Top-Tite

Non-Corrosive Hex-Tite™ Bolts and Wing Nuts

DIMENSIONS:

Hinges

5-1/2"

83/16"

17-1/8"

18-7/16"

12-1/8"

1-9/16"

13-15/16"

Proudly Made in the USA

Bemis Manufacturing Co., Sheboygan Falls, WI 53085 Phone: [phone] Fax: [phone]
www.ToiletSeats.com

5/8"

3/4"
