Maxx Ice MIM70 Installation Manual
The Legacy Companies
Automatic Ice Maker
3355 Enterprise Ave, Suite 160
Ft Lauderdale, FL
Tel.: 1-877-368-2797
E-mail: sales@thelegacycompanies.com
User’s Manual
Models:
MIM70
MIM90
MIM120
1
TABLE OF CONTENTS
Page
ICE MAKER SAFETY............................................................................................................... 2
IMPORTANT SAFEGUARDS.................................................................................................. 3-5
TECHNICAL INFORMATION................................................................................................. 5
INTRODUCTION...................................................................................................................... 6
COMPONENT LOCATIONS.....................................................................................................7
ICE MAKER INSTALLATION................................................................................................. 8-16
Unpacking.................................................................................................................... 8
Location Requirements................................................................................................ 9
Electrical Requirements................................................................................................11-12
Leveling the Ice Maker................................................................................................ 12
Water Supply and Drain Connections.......................................................................... 13-14
Installation Types................................... ...... ................................................. ...... ...... ... 15-16
OPERATION.............................................................................................................................. 16-19
Final Checklist before Operation................................................................................. 16
Operating Method........................................................................................................ 17
How the Machine Makes Ice........................................................................................ 17-18
Normal Sounds............................................................................................................. 18-19
Preparing the Ice Maker for Long Storage....................................................................19
CLEANING AND MAINTENANCE........................................................................................ 19-27
Exterior Cleaning......................................................................................................... 20-21
Condenser Cleaning..................................................................................................... 21
Interior Cleaning.......................................................................................................... 22-24
Ice Making System Cleaning....................................................................................... 24-26
Control Box................................................................................................................. 26-27
Major function............................................................................................................. 27
TROUBLESHOOTING.............................................................................................................. 29-31
LIMITED WARRANTY ......... ............... ............ ............ ...... ............. .......................................... 32
MaxxIce reserves the right to make changes in specifications and design
without prior notic e .
2
ICE MAKER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your
appliance. Always read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to
potential hazards that can kill or injure you and others. All
safety messages will follow the Safety Alert Symbol and
either the words "DANGER", "WARNING" or
"CAUTION".
Danger means that failure to heed
this safety statement may result in
severe personal injury or death.
Warning means that failure to heed
this safety statement may result in
extensive product damage, serious
personal injury, or death.
Caution means that failure to heed
this safety statement may result in
minor or moderate personal injury, or
property or equipment damage.
All safety messages will alert you to what the potential hazard is, tell you how to
reduce the chance of injury, and let you know what can happen if the instructions
are not followed.
3
IMPORTANT SAFEGUARDS
Before the ice maker is used, it must be properly positioned and
installed as described in this manual, so read the manual carefully. To
reduce the risk of fire, electrical shock or injury when using the ice
maker, follow basic precautions, including the following:
Plug into a grounded 3-prong outlet; do not remove grounding prong, do not use
an adapter, and do not use an extension cord.
It is recommended that a separate circuit, serving only your ice maker, be
provided. Use receptacles that cannot be turned off by a switch or pull chain.
Do not connect or disconnect the electric plug when your hands are wet.
Never clean ice maker parts with flammable fluids. These fumes can create a fire
hazard or explosion. And do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance. The fumes can create a
fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the the
unit is disconnected and the water line is shut off. (EXCEPTION: ice maker is
in cleaning mode).
Replace all panels before operating after servicing or maintenance.
Unplug the ice maker or disconnect power before cleaning or servicing. Failure to
do so can result in electrical shock or death.
Do not attempt to repair or replace any part of your ice maker unless it is
specifically recommended in this manual. All other servicing should be referred
to a qualified technician.
When you disassemble the front cover, don’t overexert, or the leads connected
with the power switch can be torn from the switch.
Use two or more people to move and install ice maker. Failure to do so can result
in back or other serious injury.
To ensure proper ventilation for your ice maker, the front of the unit must be
completely unobstructed. Choose a well-ventilated area with temperatures above
55°F (13°C) and below 90°F (32°C). This unit MUST be installed in an area
protected from the elements, such as wind, rain, water spray or drips.
The ice maker should not be located next to ovens, grills or other sources of high
heat.
The ice maker must be installed with all electrical, water and drain connections in
accordance with state and local codes. A standard electrical supply (115 VAC only,
60 Hz, 15 A), properly grounded in accordance with the National Electrical Code
4
and local codes and ordinances is required.
Do not kink or pinch the power supply cord between the ice maker and cabinet.
The circuit breaker rating should be 15 amperes.
It is important for the ice maker to be leveled in order to work properly. You may
need to make several adjustments to level it.
All installations must be in accordance with local plumbing code requirements.
Make certain that the pipes are not pinched or kinked or damaged during
installation.
Check for leaks after water line and drain line connection.
Never allow children to operate, play with or crawl inside the ice maker.
Although the unit has been tested at the factory, due to long-term transit and
storage, the first batch of cubes must be discarded.
Never turn the water supply tap off when the ice maker is working.
If the ice maker will not be used for a long time, before the next use it must be
thoroughly cleaned. Carefully follow instructions as provided for cleaning or use
of sanitizing solution. Do not leave any solution inside the ice maker after
cleaning.
DO NOT touch the condenser fins. The condenser fins are sharp and can be easily
damaged.
DO NOT use solvent-based cleaning agents or abrasives on the interior. These
cleaners may transmit taste to the ice cubes, or damage or discolor the interior.
The ice machine cleaner contains acids. DO NOT use or mix with any other
solvent-based cleaner products. Use rubber gloves to protect hands and protective
eye wear. Carefully read the material safety instructions on the container of the
ice machine cleaner.
Do not use this apparatus for anything other than its intended purpose.
SAVE THESE INSTRUCTIONS
Electrical Connection
Do not, under any circumstances, cut or remove the third (ground) prong from the
power cord. For personal safety, this appliance must be properly grounded. The
power cord of this appliance is equipped with a 3-prong ( N E M A 5-15P) grounding
plug that mates with a standard 3-prong (NEMA 5 -15R) grounded wall receptical to
minimize the possibility of electric shock hazard from the appliance. Have the wall
receptical and circuit checked by a qualified electrician to make sure the it is
properly grounded. When a old style 2-prong wall receptical is encountered, it is
your responsibility and obligation to have it replaced with a properly grounded
3-prong receptical. The ice maker should always be plugged into its dedicated
outlet which has a voltage rating that matches the rating label on the appliance. This
provides the best performance and also prevents overloading wiring circuits which
can be a fire hazard from overheated wires. Never unplug your ice maker by pulling
on the power cord. Always grip the plug firmly and pull straight out from the
5
receptical. Rep air or replace i mmediately all po wer cords that have become fr ayed
or otherwise damaged. Do not use a cord that shows cracks or abrasion damage
along its length or at either end. When moving the ice maker, be careful not to
damage the power cord.
Extension Cord DO NOT use an extention cord with this appliance.
TECHNICAL INFORMATION
Model: MIM70 MIM90 MIM120
Rated power: 120VAC~60Hz 120VAC~60Hz 120VAC~60Hz
Ice-making rated current: 6.7A 7.3A 7.5A
Ice-harvest rated current: 11.2A 11.7A 11.8A
Refrigerant: R134a R134a R134a
6.88oz 8.96oz 9.92oz
195.04g 254.01g 281.23g
High Side Pressure: 320psi 320psi 320psi
22.5Kg/cm 22.5Kg/cm 22.5Kg/cm
Low Side Pressure: 120psi 120psi 120psi
8.44Kg/cm 8.44Kg/cm 8.44Kg/cm
The technical data and performance index listed above should be used for reference
only. They are subject to change.
*The actual quantity of ice produced per day can vary with room and water
conditions.
6
INTRODUCTION
The MaxxIce MIM series Ice Maker finds wide application in households, bars,
restaurants, hotels, supermarkets, etc. It produces crystal-clear, gourmet cube ice,
and offers convenience for homeowners and hotel guests. An insulated ice storage
bin is built into the ice maker.
This user's manual is intended as a resource for persons installing, using and
servicing the MIM series. It contains valuable information on safety and
maintenance. Maxx Ice strongly recommends that this manual be kept in a place
where it can be accessed when needed.
The MaxxIce ice maker is designed and manufactured according to the highest
standards of safety and performance. It meets or exceeds the safety standard of
UL563 and sanitation standard of NSF12.
The Legacy Companies assumes no liability or responsibility of any kind for
products manufactured by MaxxIce that have been altered in any way, including the
use of any parts and/o r other components not specifically approved by The Legacy
Companies. MaxxIce reserves the right to make design changes and/or
improvements at any time. Specifications and designs are subject to change without
notice.
7
IMPORTANT SAFETY INSTRUCTIONS
cover)
WARNING: To reduce the risk of fire, electric shock, or injury
when using your ice maker, follow these basic precautions:
Plug into a grounded 3-prong outlet.
Do not remove grounding prong.
Do not use an adapter.
Do not use an extension cord.
Disconnect power before cleaning.
Disconnect power before servicing.
SAVE THESE INSTRUCTION
COMPONENT LOCATIONS
Door
Ice cube full sensor
Front cover
Ventilation
louvers
Replace all panels before
operating.
Use two or more people to move
and install ice maker.
Top cover
Right side cover
Ice-storage bin
Roller
Ice scoop
Control box
(behind Front
Power switch
8
ICE
ICE MAKER INSTALLATION
Unpacking
Excessive Weight Hazard
Use two or more people to move and install ice maker. Failure to
do so can result in back or other serious injury.
Remove packaging materials
NOTE: Do not remove any permanent instruction labels or the data label on your ice maker.
Remove tape and glue from your ice maker before using.
• To remove any remaining tape or glue, rub the area briskly with your thumb.
Tape or glue res idue can als o be eas il y remo ved b y rubbing a small amoun t of
liquid dish soap over the adhesive with your fingers. Wipe with warm water
and dry.
• Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These products can damage the surface of
your ice maker.
Cleaning before use
After you remove all of the packaging materials, clean the inside of your ice
maker before using it. See "Interior cleaning" in the Cleaning and Maintenance
section.
Location Re quirements
4”
To ensure proper ventilation for your ice maker, the front of the unit must be
completely unobstructed. Allow at least 4” (101mm) clearance at rear, and 0.6”
(15mm) at the top and sides for proper air circulation. The installation should
allow the ice maker to be pulled forward for servicing if necessary.
When installing the ice maker under a counter, follow the recommended spacing
dimensions shown. Place electrical and water supplies and drain fixtures in the
recommended locations as shown.
Choose a well-ventilated area with temperatures above 55°F (13°C) and below
90°F (32°C). This unit MUST be installed in an area protected from the elements,
such as wind, rain, water spray or drips.
The unit should not be located next to ovens, grills or other sources of high heat.
Installation of the ice maker requires a cold water supply inlet of 6.35mm (¼ in.)
soft copper tubing with a shut-off valve. A gravity-drain system provided with the
unit can be used.
NOTE: Runoff water can also be drained into a sink via a pump – not included – when a gravity
drain is not available.
The ice maker requires a continuous water supply with pressure between 14.5psi
and 72.5psi (0.1 MPa and 0.5 MPa). The temperature of the water feeding into the
ice maker should be between 41°F (5°C) and 77°F (25°C) for proper operation.
9
Loading...
