Assembly instructions
Turn on your T V set. Refer to ma nufact urers inst ructio ns to tune you r TV into the a vailable d igital/HD/3D
channels. Select a tuned-in channel. Next, carry out the following procedures:
1. Turn your aeri al to the LEF T until you los e the pictu re (if alone tu rn the volume up and tu rn until you hear a
reduction in sound quality).
2. Remembe r this positi on and turn your aeri al to the RIGH T until you lo se the pic ture/sound aga in.
3. Now point th e aerial in the centre of the se two points and you w ill receive op timum recept ion.
Digital & H D reception:
Reception of d igital terrestria l TV (DTT) sig nals is subject to:
1. Use with a DTT se t top box or inte grated TV w ith digital tuner/receiver
2. Satisfa ctory si gnal qual ity from DT T transmi tter
To receive terres trial HD ch annels you w ill require t he following:
1. An HD ready T V
2. Freeview HD re ceiver or TV with integ rated Freevi ew HD tuner/receiver
3. HD signals m ust be transmitte d in your loc al area. Visi t www.freev iew.co.uk for mor e informati on.
Safety warnings:
> Before sta rting in stallati on check st ructure i s sound and check for h idden ele ctrical w iring or plumbin g.
> When work ing on installatio ns outsid e, beware of overhead power l ines.
> Observ e safe worki ng practices, tread c arefully a nd ensure ad equate lig hting is avai lable in lof t/roof space.
> Always follow manufacturer’s operating and safety instructions before using tools and/or equipment.
> Ladder s afety - alway s read and follow the manu facture r’s instru ction lab el affixed to the ladde r.
> Ensure cab le is correc tly routed before fixin g into positi on, taki ng care not to over t ighten cab le clips.
> This prod uct may cont ain small pa rts - keep out of reach of ch ildren.
> After ins tallatio n make regula r maintenan ce checks.
> If in doubt co nsult a qua lified or prof essional a erial installer.
Contact:
Helplin e: +44 (0)1553 811000
Email: [email protected]
Web: w ww. max view. co.u k
Maxview re serve the right t o change specific ations withou t prior notice
9111314 I ss 2
MXR0034 TV Aerial - 14 Element
Model:
Aligning your aerial
Note model i s slightly
differen t to one shown he re
Page 2
1.
Pack contents check
Join the 2 pi eces of boom to gether using the
joining p late, M5 x 20mm s crews M5 nut s and
5mm Shake Proo f Washers.
2.
3.
4.
Assembly
A. Rear Boo m x 1
B. Front Boo m x 1
C. Reflect or x 1
G. Joinin g Plate x 2
H. Shake Proof W asher x 2
I. Nut x 2
J. M5 Screw x 2
K. 6½ Screw x 1
D. Mast Clam p x 1
E. Dipole C ap x 1
F. Dipole x 1
Screw on firm ly the Dipole to the Bo om.
Slide on an d firmly pus h down the Refle ctor onto
the groove of the Reflector Bung.
Attach ae rial to a suit able mast u sing the
supplie d Mast Clam p. (Note: Mast n ot supplie d).
B
A
D
E
F
G
H
I
J
C
Connecting Coaxial Cable (not supplied)
1.
Thread coaxial cable through Dipole Cap. Strip
away 25mm of oute r insulato r. Gather outer b raid
strands a nd twist together. Remo ve 10mm of
inner insulation around inner core.
Loosen th e screws on the 2 te rminals in the
Dipole. F eed the inn er core to one of the
terminal s and the tw isted brai d into the othe r.
Tighten sc rews and clos e Dipole Cap.
Polarisation
Tip: Look at o utdoor aerials
in your area to s ee which
directi on to point you r
aerial for best reception.
Note model
shown different.
For example only.
Vertical mounting
recommended for
Relay TV transmitters.
Inner
core
25mm
10mm
Outer
braid
Outer
insulator
Inner
insulator
Foil
2.
Horizontal mounting
recommended for
Main TV transmitters.
K
