High Performance
K56Plus/V.34+/V.42bis
56K BPS
Plug & Play Internal
Voice/FAX/Data/SVD
Modem
With Advanced
Speakerphone functions
User's Manual
Contents
Section One - Introduction .......................... 1
Section Two - Installation............................. 1
Section Three - A T Command Set............... 7
Section Four - S Registers........................ 14
Section Five - Result Codes......................1 5
Section Six - Troubleshooting.................... 15
Section Seven - Support and Service ....... 16
Appendix A - Specifications ..................... 16
Appendix B - Notices ................................ 17
Part #MAN128 Rev. 1.0 K56Plus-L/CPI-SVD
The information contained in this manual has been
validated at the time of this manual's production.
The manufacturer reserves the right to make any
changes and improvements in the product described in this manual at any time and without
notice. Consequently the manufacturer assumes
no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the product and the manual.
All registered trademarks are the property of their
respective owners.
Copyright © 1997 All rights reserved. No reproduction
of this document in any form is permitted without prior
written authorization from the Manufacturer.
Section One - Introduction
This 56 Kbps* Plug and Play FAX/Voice/Data/
SVD Speakerphone Modem connects your computer
to all popular high speed modems available today. The
modem incorporates
to provide increased download speeds using regular
telephone lines. The modem incorporates Plug and
Play for ease of installation. It features speakerphone
capability for hands-free communication and full-duplex analog/digital simultaneous voice and data (SVD)
over a single telephone line.
This manual describes the hardware installation
procedures for your new modem. Additional information on AT commands and S-registers is provided so
that your system can be customized for a particular
operating environment.
“K56Plus” (56Kbps)
technology
*Note: K56Plus is capable of downloading at 56Kbps.
However, current FCC regulations limit its speeds to
53Kbps.
Section Two - Installation
This section will provide step by step instructions
on how to install your new 56 Kbps FAX/Voice/Data/
SVD modem. Installation of this modem product is a
three-step process consists of 1) actual hardware
installation, 2) plug and play configuration, and 3)
communication software installation and configuration.
2.1 Unpacking Your Modem
Be certain that you have all the items listed
below. This package contains:
• A modem • A telephone cable
• User's manual • Software for the modem
• Software user's manual
2.2 What You Need
You will need:
1. A phillips-head screw driver
2. A) A Plug and Play enabled Operating System
1
(e.g., Windows 95),
or
B) A Plug and Play Revision 1.0a compliant PC.
Proceed to Section 2.3 now if you have everything required.
If you have neither 2A or 2B above, youneed to
install Windows 95 to provide Plug and Play functionality to your PC.
2.3 Hardware Installation
Installation of this modem requires opening and
manipulating your PC. Exercise caution at all times
when working with AC powered and static-sensitive
equipment. Turn off and unplug your PC before installation. Discharge any static electricity from your body
by touching any bare metal surface of the PC system,
such as its power supply cover.
1. Turn off and unplug your computer from the AC
outlet.
2. Remove your computer's cover (refer to your
computer's owner's manual).
3. Select any available half-card slot, and then re-
move the slot cover (refer to Figure 2-1).
Figure 2-1 Expansion Slots
4. Carefully slide the internal modem into the slot
you have chosen, applying even pressure until
the modem is completely seated in the slot.
5. Fasten the retaining bracket with the screw from
the slot cover. Make sure the modem is properly
aligned. Store the slot cover for future use.
6. Replace the computer cover and plug in your
computer.
2
7. Connect the telephone cable from the modem's
LINE connector to the telephone wall jack.
8. Optionally, connect your telephone to the modem's
PHONE connector.
9. Turn your computer on. Your modem is now
installed.
2.4 Hardware Configuration (Plug and Play)
Your modem is configured using the Plug and
Play (PnP) capabilities of your computer. Plug and
Play is a set of specifications that define the ability for
the computer hardware and operating system to automatically configure all compliant devices that are installed, relieving the user of the need to determine
which addresses and interrupts to use for each device.
Consult your PC's owner's manual to determine if it is
PnP Revision 1.0a compliant. You most likely have a
Plug and Play Revision 1.0a compliant system if it was
purchased after June 1994 or if the BIOS is dated after
June 1994.
Proceed to one of the following sections, depending on your system's configuration:
• Section 2.4.1 if you are running Windows
95 (with or without a Plug and Play PC)
• Section 2.4.2 if you are running Windows
3.1x or DOS on a PnP-compliant PC.
2.4.1Configuring in Windows 95
The version of Windows 95 you have will determine which set of dialog boxes is presented to you
when installing the modem in Windows 95. Proceed to
one of the following sections, depending on your
Windows 95's diaglog box:
• Section 2.4.1.1 when Windows 95 starts for
the first time after card installation, it
detects the modem and it displays the New
Hardware Found dialog box
• Section 2.4.1.2 when Windows 95 starts for
the first time after card installation, it
detects the modem and it displays the
Update Device Driver Wizard.
3
2.4.1.1 Windows 95 Release 4.00.950
When Windows 95 starts for the first time after
card installation, it detects the modem and displays the
New Hardware Found dialog box.
Under New Hardware Found, when asked to
“Select which driver you want to install for your new
hardware,” click on “Driver from disk provided by
hardware manufacturer.” Click “OK.”
The Install From Disk dialog box now instructs
you to “Insert the manufacturer's installation disk into
the drive selected, and then click OK.” Insert the
modem's driver diskette into the disk drive and type A:\
(or B:\ if inserted in drive B) in the “Copy manufacturer's
files from:” box. Click “OK.”
Windows 95 may request its own installation
disks or CD-ROM for some files. Insert the Windows
95 disks or CD-ROM as required. When all necessary
files are copied, the modem is configured. Windows 95
will assign the modem a COM port and IRQ line.
Proceed to Section 2.5.
2.4.1.2 Windows 95 Release 4.00.950 B
When Windows 95 starts for the first time after
card installation, it detects the modem and displays the
Update Device Driver Wizard.
Insert the driver disk into the disk drive and click
“Next.” Windows will find the driver on the driver disk.
Click “Finish. Windows 95 may request its own installation disks or CD for some files. Insert the Windows 95
disks or CD as required.
Windows will now find a second device on the
modem. Make sure that the driver disk is still in the disk
drive and click “Next.” Windows will find the second
driver. Click “Finish” to complete the installation.
When all necessary files are copied, the modem
is configured. Windows 95 will assign the modem a
COM port and IRQ line. Proceed to Section 2.5.
4
2.4.2Configuring in a Plug and Play System with-
out Windows 95
When this modem is installed in a Plug and Play
system without Windows 95, the computer's BIOS will
assign a COM port and IRQ line to the modem.
Proceed to Section 2.5, Software Installation/
Configuration.
2.5 Software Installation and Configuration
You are now ready to install and configure the
communication software. Refer to your software manual
for installation procedures.
We suggest the following communication parameters when you first use your data communication
software. Consult the software manual for information
on using these and other parameters/features.
57,600 bps; 8 data bits; no parity; 1 stop bit;
RTS/CTS flow control set to “on;” initialization
string: AT&F
We suggest that a “Generic Class 1” or “Generic Class 2” modem type should be selected in your
fax software, and a “Lucent” modem type should be
selected in your Voice software.
Note that your software must be configured to
communicate with the modem on the same COM port
and IRQ line used by the modem.
2.6 Using the Fax, Voice, SVD, and
Speakerphone Capabilities of the
Modem
Your modem has built-in advanced FAX, Voice,
SVD, and Full Duplex Speakerphone functions. Please
consult your FAX/Voice/SVD/Speakerphone software
manual about procedures on using these features.
Speakerphone functions require a correctly configured sound card with attached microphone and
speaker.
Voice functions include recording and playback
of voice prompts (files). You may record or playback
voice with your modem by attaching a telephone to the
5
RJ-11 jack marked “PHONE” or by attaching a microphone to the MIC jack and a speaker to the SPK jack
of your sound card. Follow instructions in the FAX/
Voice/Speakerphone software on recording and playback of voice prompts.
2.7 Testing Your Modem After Installation
In order to test your modem you should be
familiar with your communication software. Load and
set up your communication software and enter into
“terminal mode.” Make sure that the COM Port and
IRQ settings of the modem match the software. Type
AT on your terminal screen and press ENTER. You
may see “AT”, “AATT” or nothing on the screen. In any
case, the modem should respond with an OK or 0. If it
does not, either the modem may not have been installed properly or the software has not been properly
configured. Review Sections 2.2-2.5 and be certain
that the modem and the software have been properly
installed. If required, refer to Section 6 for additional
troubleshooting information.
2.8 Using Your Modem
The communication software included with your
modem product provides a user friendly interface to
access the fax, voice and data functions of your
modem.
your communication needs
when you need to access the modem manually via
modem commands. Read Section 3 for a summary
description of the modem command set before manually accessing the modem. You may want to read the
software manual first, however, as the software may
already provide a user friendly method of accessing
the functions you need (i.e. dialing or answering calls).
This software should be sufficient for all of
. There may be times
2.9 Where To Go From Here
You should familiarize yourself with the functions
available from the included software by reading its
manual. You will be accessing most, if not all, of the
modem's functions from this software. You may also
use any other commercially available communication
software with the modem. Read Section 3 only if you
6
are interested in accessing the modem manually, and
not through the included software. Section 4 and 5
contain reference material, and can be skipped. If you
have difficulties getting your modem to work, read
Section 6 - Troubleshooting to find answers to commonly asked questions and problems.
Section Three - AT Command Set
3.1 Executing Commands
Commands are accepted by the modem while it
is in Command Mode. Your modem is automatically in
Command Mode until you dial a number and establish
a connection. Commands may be sent to your modem
from a PC running communication software or any
other terminal devices.
Your modem is capable of data communication
at rates of: 300, 1200, 2400, 4800, 9600, 14400,
19200, 28800, 38400, 57600, and 115200 bps. Make
sure your COM port baud rate settings in your communications software is set to one of the above speeds.
3.2 Command Structure
All commands sent to the modem must begin
with AT and end with ENTER. All commands may be
typed in either upper or lower case, but not mixed. To
make the command line more readable, spaces may
be inserted between commands. If you omit a parameter from a command that requires one, it is just like
specifying a parameter of 0. Example:
ATH [ENTER]
This command causes your modem to hang up.
3.3 Basic AT Commands
In the following listings, all default settings are
printed in bold text.
Command Function
A Manually answer incoming call.
A/ Repeat last command executed. Do not
B_ B0 CCITT mode
precede A/ with AT or follow with ENTER.
7
B1 Bell mode
B2 V.23 originate mode @ 75 bps transmit/
1200 bps receive
B3 V.23 originate mode @ 1200 bps
transmit/75 bps receive
B15 Selects V.21 at 300 bps
B16 Selects Bell 103 at 300 bps
D_ 0 - 9, A-D, # and *
DS=n Dial one of the four telephone numbers
E_ E0 Commands are not echoed
+++ Escape Characters - Switch from Data
H_ H0 Force modem on-hook (hang up)
I_ I0 Default speed and controller version
L_ L0 Low speaker volume
M_ M0 Internal speaker off
N_ N0 Disable Autoscan mode
L last number redial
P pulse dialing
T touch-tone dialing
W wait for second dial tone
, pause
@ wait for five seconds of silence
! flash
; return to Command Mode after dialing
(n=0-3) stored in the modem’s non-
volatile memory.
E1 Commands are echoed
Mode to Command Mode
H1 Force modem off-hook (make busy)
I1 Display factory ROM checksum
I2 Internal memory test
I3 Default speed and controller version
I4 Datapump firmware version
I9 Country code
L1 Low speaker volume
L2 Medium speaker volume
L3 High speaker volume
M1 Internal speaker on until carrier
detected
M2 Internal speaker always on
M3 Internal speaker on until carrier detected
and off while dialing
N1 Enable Autoscan mode
8
O_ O0 Return to Data Mode
P Set Pulse dial as default
Q_ Q0 Modem sends responses
Sr? Read and display value in register r.
Sr=n Set register r to value n (n = 0-255).
T Set Tone Dial as default
V_ V0 Numeric responses
W_ W0 Report DTE speed only
X_ X0 Hayes Smartmodem 300 compatible
Y_ Y0 Modem does not send or respond to
Z_ Z0 Reset and retrieve active profile 0
O1 Return to Data Mode and initiate an
equalizer retrain
Q1 Modem does not send responses
V1 Word responses
W1 Report line speed, error correction
protocol, and DTE speed.
W2 Report DCE speed only
responses/blind dialing
X1 Display connect message according to
AT\V, blind dial, and ignore busy tone.
X2 Same as X1 plus dial tone detection
X3 Same as X1 plus busy detection/blind
dialing
X4 All responses and dial tone and busy
signal detection
X5 Same as X4
X6 Same as X4
X7 Same as X0 plus dial tone and busy
signal detection
break signals
Y1 Modem sends break signal for four
seconds before disconnecting
Z1 Reset and retrieve active profile 1
3.4 Extended AT Commands
&C_ &C0 Force Carrier Detect Signal High (ON)
&D_ &D0 Modem ignores the DTR signal
&C1 Turn on CD when remote carrier is
present
&D1 Modem returns to Command Mode after
9
DTR toggle
&D2 Modem hangs up, returns to the
Command Mode after DTR toggle
&D3 Resets modem after DTR toggle
&F_ &F Recall factory default configuration
&G_ &G0 Guard tone disabled
&K_ &K0 Disable flow control
&L_ &L0 Modem is set up for dial-up operation
&M_ &M0 Asynchronous operation
&S_ &S0 Force DSR Signal High (ON)
&T_ &T0 Ends test in progress
&V &V0 Displays Active Profile
&W_ &W0 Stores the active profile as Profile 0
&Y_ &Y0 Configuration Profile 0 active upon
&Zn=xn=0-3 Store phone number x into non-volatile
%E_ %E0 Disable auto-retrain
%X_ %X0 Disable re--dialing suppression
#CID=n n=0 Disable Caller ID
#CID? Displays current Caller ID mode
#CID=? Returns Caller ID capabilities of modem.
&G1 550 Hz guard tone
&G2 1800 Hz guard tone
&K3 Enable RTS/CTS hardware flow
control
&K4 Enable XON/XOFF software flow control
&S1 DSR off in command mode, on in on-line
mode
&T1 Perform Local Analog Loopback Test
&T3 Perform Local Digital Loopback Test
&T6 Perform a Remote Digital Loopback Test
&W1 Stores the active profile as Profile 1
Power on or reset
RAM
%E1 Enable auto-retrain
%X1 Enables re-dialing suppression
n=1 Enables Caller ID with formatting (date,
time, number, name)
n=2 Enables Caller ID without formatting
3.5 MNP/V.42/V.42bis Commands
%C_ %C0 Disable MNP Class 5 and V.42bis data
10
compression
%C1 Enable MNP Class 5 data compression
only
&Q_ &Q0 Direct data link only (same as \N1)
\A_ \A0 64-character maximum MNP block size
\Bn Send a 1/10 second line break to the modem,
\J_ \J0 DTE speed is independent of modem
\Kn Set break control, where n= 0 to 5. The effect of
\N_ \N0 Normal data-link only
\Q_ \Q0 Disable flow control
\T
\V_ \V0 Disable error correction protocol result
\X_ \X0 If XON/XOFF flow control is enabled,
&Q5 V.42 data link with fallback options
&Q6 Normal data link only (same as \N0)
\A1 128-character maximum MNP block
size
\A2 192-character maximum MNP block size
\A3 256-character maximum MNP block size
where n = 1 to 9. At normal connect, the default
is 3
connect speed
\J1 DTE speed matches the modem connect
speed
this command depends on the modem’s
operating condition. Default is 5.
\N1 Direct data-link only
\N2 MNP data link only
\N3 V.42/MNP/Normal data link
\N4 V.42 data link only
\N5 V.42/MNP/Normal data link
\N7 V.42/MNP/Normal data link
\Q1 XON\XOFF flow control
\Q3 RTS\CTS flow control
n
Inactivity timer (n=0-255 minutes)
code
\V1 Enable error correction protocol result
code
\V2 Enable error correction protocol result
code
do not pass XON/XOFF to remote
modem or local DTE
\X1 If XON/XOFF flow control is enabled,
11
pass XON/XOFF to remote modem or
local DTE
-C_ -C0 Data calling tone disabled
-C1 Data calling tone enabled
3.6 Fax Class 1 Commands
+FCLASS? Service class indication
+FCLASS=? Service class capabilities
+FCLASS=n Service class selection
+FMI=? Manufacturer identification
+FMM=? Product Identification
+FMR=? Version/Revision information
+FRH=n Receive data with HDLC framing
+FRH=? Receive HDLC data modulation
+FRM=n Receive data
+FRM=? Receive FAX modulation
+FRS=n Receive silence
+FTH=n Transmit data with HDLC framing
+FTH=? Transmit HDLC data modulation
+FTM=n Transmit data
+FTM=? Transmit FAX modulation
+FTS=n Stop transmission and wait
3.7 Fax Class 2 Commands
+FAA=n Adaptive Answer
+FAXERR Fax Error Value
+FBOR Phase C Data Bit Order
+FBUF? Buffer Size
+FCFR Indicate Confirmation to Receive
+FCLASS= Service Class
+FCON Facsimile Connection Response
+FCIG Set the polled station identification
+FCIG: Report the polled station identification
+FCR Capability to Receive
+FCR= Capability to Receive
+FCSI: Report the Called Station ID
+FDCC= DCE Capabilities Parameters
+FDCS: Report Current Session
+FDCS= Current Session Results
+FDIS: Report Remote Identification
+FDIS= Current Sessions Parameters
+FDR Begin or Continue Phase C Receive
+FDT Data Transmission
Data
12
+FDTC: Report the polled station capabilities
+FET: Post Page Message Response
+FET=n Transmit Page Punctuation
+FHNG Call Terminations with Status
+FK Session Termination
+FLID= Local ID String
+FLPL Document for polling
+FMDL? Identify Model
+FMFR? Identify Manufacturer
+FPHCTO Phase C Time Out
+FPOLL Indicates polling request
+FPTS: Page Transfer Status
+FPTS= Page Transfer Status
+FREV? Identify Revision
+FSPL Enable polling
+FTSI: Report the Transmit Station ID
3.8 SVD Commands
-SAC Accept Data mode request
-SCD= Capabilities data
-SDA Start modem data mode
-SDT Date
-SEM Erase message
-SER? Error reporting
-SFA Facsimile data mode event message
-SFX Start facsimile data mode
-SIC Reset capabilities data to default settings
-SIP Initialize Voice View parameters
-SMD Modem data mode event message
-SMS=X,Y,Z,T Select ASVD/DSVD Mode. The X
-SMT Telephone handset mute control
-SNO Notification timer
-SOR Reject or overflow system messages
-SQQ Start capabilities query
-SQR=n Capabilities query response control
-SQS=X,Y Select ASVD modulation. Parameter X
parameter selects data, ASVD, DSVD or
automatic mode where 0=Data mode;
1=DSVD mode; 2=ASVD mode;
3=automatic mode select (default). Y,Z,T
are optional parameters to control
connection speeds.
selects the modulation mode where
0=V.61; 1=ML144; 2=ML288. The Y
parameter enables/disables ASVD
automatic modulation
13
-SRM Retrieve message
-SSE=n n=0 Disable DSVD
n=1 Enable DSVD
-SSP Set transmission speeds
-SSR Start sequence response control
-SSV Data mode event message
-STM Time
-STT Telephone handset transaction tone
control
-SVV Start Voice View data mode
Section Four - S Registers
Your modem has 28 registers, designated S0
through S92. Table 4-1 shows the registers, their
functions, and their default values. Some registers can
have their values changed by commands. If you use a
command to change a register value, the command
remains in effect until you turn off or reset your modem.
Your modem then reverts to the operating characteristics specified in its non-volatile memory. Refer to
Section 3 for information on how to use the AT commands to manipulate the S registers.
Table 4-1 S - Registers
Register Function Range/units Default
S0 Auto-answer Ring 0-255 /rings 0
S1 Ring counter 0-255 /rings 0
S2 Escape code character 0-127 /ASCII 43
S3 Carriage return character 0-127 /ASCII 13
S4 Line feed character 0-127 /ASCII 10
S5 Backspace character 0-32, 127 /ASCII 8
S6 Dial tone wait time 2-255 /seconds 2
S7 Remote carrier wait time 1-255 /seconds 50
S8 Comma pause time 0-255 /seconds 2
S10 Carrier loss time 1-255 /0.1 second 14
S11 Touch-tone dialing speed 50-255 /milliseconds 95
S12 Escape character guard time0-255 /0.02 second 50
S14 Result codes, pulse dial Bit mapped 8
S21 DTR, DCD Bit mapped 48
S22 Result codes, pulse dial Bit mapped 112
S24 Sleep mode timer 0,5-255/seconds 10
S28 V.34 modulation enable 0-255 1
S30 Inactivity timer 0-255/minutes 0
S32 Synthetic ring volume - dB 10
S33 Synthetic ring frequency 0-5 0
S35 Data calling tone enable 0, 1 0
S36 Negotiation failure fallback 0-7 7
14
S37 Connection speed 0-19 0
S38 56K dial line rate 0-16 1
S42-43 Reserved
S48 LAPM negotiation 7, 128 7
S89 Sleep mode timer 0, 5-255 seconds 10
S90 Local phone status 0=on hook, 1=off hook
S92 Transmit level 6-15/dB 15
Section Five - Result Codes
OK 0 CONNECT 1
RING 2 NO CARRIER 3
ERROR 4 CONNECT 1200 5
NO DIALTONE 6 BUSY 7
NO ANSWER 8 CONNECT 300 EC* 40
CONNECT 2400 EC* 10 CONNECT 4800 EC* 11
CONNECT 9600 EC* 12 CONNECT 7200 EC* 24
CONNECT 12000 EC* 25 CONNECT 14400 EC* 13
CONNECT 16800 EC* 86 CONNECT 19200 EC* 14
CONNECT 31200 EC* 83 CONNECT 21600 EC* 55
CONNECT 24000 EC* 56 CONNECT 26400 EC* 57
CONNECT 28800 EC* 58 CONNECT 31200 EC* 59
CONNECT 32000 EC* 70 CONNECT 33600 EC* 60
CONNECT 34000 EC* 71 CONNECT 36000 EC* 72
CONNECT 38400 EC* 28 CONNECT 38000 EC* 73
CONNECT 40000 EC* 74 CONNECT 42000 EC* 75
CONNECT 44000 EC* 76 CONNECT 46000 EC* 77
CONNECT 48000 EC* 78 CONNECT 50000 EC* 79
CONNECT 52000 EC* 80 CONNECT 54000 EC* 81
CONNECT 56000 EC* 82 CONNECT 57600 EC* 18
CONNECT 58000 EC* 83 CONNECT 60000 EC* 84
CONNECT 115200 EC* 87
* EC denotes one of the following extensions depending on the
error control method used when extended result codes are
enabled.
V42bis - V.42 error correction and B.42bis data compression
V42 - V.42 error correction only
MNP 5 - MNP Class 4 error correction and MNP Class 5 data
compression
MNP 4 - MNP Class 4 error correction only
NoEC - Error correction is off
Section Six - Troubleshooting
This section describes some of the common
problems you may encounter while using your modem.
If you can not resolve your difficulty after reading this
chapter, contact your dealer or vendor for assistance.
Modem does not respond to commands.
1. Make sure the communication software is configured
15
to “talk” to the modem on the correct COM port and IRQ setting (same COM port and IRQ setting as the modem). Your communication software must know which address your modem is using in the system in order to pass data to it. Similarly, IRQ settings must be set correctly to receive data from the modem.
2.Make sure that your modem is initialized correctly. Your modem may have been initialized to not display responses. You may factory-reset the modem by issuing AT&F and press ENTER. The factory default allows the modem to display responses after a command has been executed.
Modem does not dial.
1.Make sure the modem is connected to a working phone line. Replace the modem with a working phone to ensure that the phone line is working.
2.Make sure the phone line is connected to the jack marked “LINE.” Incorrect connection prevents the modem from operating properly. Refer to Section 2.3 for modem connection instructions.
Modem dials but does not connect.
1.Make sure the IRQ setting is identical on both the modem and the software. Modem and software must be configured identically.
2.Make sure the phone line is working properly. Replace the modem with a regular phone and dial the number. If the line sounds noisy, you may have difficulty connecting to the remote device.
Modem makes a connection but no data appears on your screen.
1.Make sure the correct data format (data bits, stop bits, and parity bits) and flow control (RTS/CTS) are being used.
2.Make sure the correct terminal emulation mode is being used (see communication software manual).
High pitch tone is heard whenever you answer the phone.
1.Make sure Auto-Answer is turned off. Your modem is factory configured to NOT auto-answer. Issue AT&F to factory reset your modem.
Modem experiences errors while communicating with a remote modem.
1.Make sure the DTE speed is the same as the modem connection speed when in Direct Mode.
2.Make sure the remote system and your modem use the same communication parameters (speed, parity, etc.).
3.Make sure RTS/CTS hardware flow control is enabled and XON/XOFF software flow control is disabled in the communication software.
4.Make sure the data speed is not faster than your computer's capability. Most IBM compatibles are capable of 19,200 bps under DOS and Windows 3.X. Operating at higher speeds under Windows requires a 486 or faster CPU or Windows 95.
Modem experiences bursts of errors or suddenly disconnects while communicating with a remote modem.
1.Make sure Call Waiting is turned off.
2. Make sure the phone line does not exhibit excess
noise.
Section Seven - Support and Service
In the unlikely event you experience difficulty in
the use of this product, we suggest you: (1) consult the
Troubleshooting section of this guide and (2) consult
with your dealer. To obtain service for this product,
follow the Return Merchandise Authorization Procedure as outlined in the Warranty card.
Appendix A - Specifications
Communication Std. K56Plus (56Kbps), V.34,
Data Compression: V.42bis/MNP5
Error Correction: V.42/MNP2-4
Host Interface: 16 bit PC bus
V.32bis, V.32, V.29, V.27ter,
V.22bis, V.23, V.22, V.21, V.17,
Bell212/103
16
COM ports:1, 2, 3, 4
IRQ lines: 3, 4, 5, 7, 9, 10, 11, 12, 15
FAX Group: Group III Send/Receive
Standard
FAX Command set: EIA/TIA-578 Service Class 1,
EIA/TIA-SP2388 Service Class
2
Transmit level: -11 dBm +/- 1 dB
Receiver Sensitivity: -39 dBm (V.34); -43 dBm (all
other protocols)
UART: 16550 compatible
Data format: 300-115200 bps
Power: 0.75 W
Temperature:0 to 55 degrees C (Operating)
Caller ID: Y es
PnP: Revision 1.0a
Speakerphone: Full-duplex with DSP echo
cancellation
Appendix B - Notices
FCC Compliance
This equipment complies with Part 68 of the FCC Rules. On
this equipment is a label that contains, among other information, the FCC registration number and Ringer Equivalence
Number (REN) for this equipment. You must, upon request,
provide this information to your telephone company.
If your telephone equipment causes harm to the telephone
network, the Telephone Company may discontinue your
service temporarily. If possible, they will notify in advance.
But, if advance notice is not practical, you will be notified as
soon as possible. You will be informed of your right to file a
complaint with the FCC.
Your telephone company may make changes in its facilities,
equipment, operations, or procedures that could affect proper
operation of your equipment. If they do, you will be notified in
advance to give you an opportunity to maintain uninterrupted
telephone service.
The FCC prohibits this equipment to be connected to party
lines or coin-telephone service.
In the event that this equipment should fail to operate
properly, disconnect the equipment from the phone line to
determine if it is causing the problem. If the problem is with the
equipment, discontinue use and contact your dealer or vendor.
17
The FCC also requires the transmitter of a FAX transmission be properly identified (per FCC Rules Part 68, Sec. 68.381 (c) (3)).
FCC Class B Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the
receiver
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
• Consult the dealer or an experienced radio / TV technician
for help
Notice: 1) Shielded cables, if any, must be used in order to
comply with the emission limits. 2) Any change or modification not expressly approved by the Grantee of the equipment
authorization could void the user’s authority to operate the
equipment.
DOC Compliance Information
NOTICE: The Canadian Department of Communications
label identifies certified equipment. This certification means
that the equipment meets certain telecommunications network protective, operational and safety requirements. The
Department does not guarantee the equipment will operate to
the user’s satisfaction.
Before installing this equipment, users ensure that it is
permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be
installed using an acceptable method of connection. The
customer should be aware that compliance with the above
conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to
disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines
and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly
important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric
inspection authority, or electrician, as appropriate.
18
NOTICE: The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device, to prevent overloading. The termination on a loop may consist of any combination of devices subject only to the requirement that the sum of the Load Numbers of all the devices does not exceed 100.
UL Notice
Caution: This internal modem adapter is to be installed in UL Listed computers only, Always disconnect the modem adapter from the telephone system during installation or when the cover is removed from the computer.
First EditionGZ/DR - Version 1.0
19
20
21
Loading...
