Metered Outlet - MMP
MMP Series
MODULAR METERED POWER (OUTLET MONITORED)
Going Green!!!
Power Factor is Real and now it’s Real-Time with the MMP Power Solution
Reach operational efficiency and conform to new Green Energy standards with the MMP outlet monitoring solutions.
Additional Unique Features
All Circuit Breakers Monitored
Most metered power solu­tions only monitor input power. BayTech monitors all circuit breakers and re­ports via SNMP when thresholds met.
BayTech’s metered outlet modules report Amps, Voltage, VA, Watts, and power fac­tor per receptacle.
Through our secure SNMP engine thresh­olds can be set to help identify equipment that is running inefficient.
Standard Features
Single Phase and Three Phase
20,30,50,60 Amp Support
On, Off, Reboot option
HTTPS,SSH,SSL Access
Radius, TACACS Authentication
Tool less Mounting
Unique Features
Modular Design
All Receptacles Monitored
Outlet Metering with Power Factor
Monitor individual outlets and receive current, watts, and volt-amps. Continu­ously monitoring equip­ment for power factor.
Locking C13 Receptacle Optional
Reliable integrated locking clips assure power cord retention. Unique to the industry and does away with nuisance wire clips.
Reliable PCB Power Distribution
ISD’s (Insulation Displace­ment) connectors are faulty and un-reliable! All Bay­Tech power solutions use reliable PCB power distri­bution.
Power Factor per Outlet
kW Hour Meter per Outlet
Current, Voltage and VA and Watts
Reliable PCB Power Distribution
Fail Functional Design
Integrated Sensor Inputs
Eliminate the need for ex­tra environmental monitor­ing devices. All BayTech power solutions offer two ports for external tempera­ture and humidity probes.
230 Yuma St., Denver, CO 80223 / Tel (800) 576-3966 / Fax (800) 577-4096 / www.maxpowercorp.com
©2012 MaxPower Corporaon. All rights reserved. (04/13/12)
MMP
(Modular Metered Power)
MMP Series
MODULAR METERED POWER (OUTLET MONITORED)
Suggested MMP Configurations for Outlet Control and Metered Outlet. Please note that many other configurations can be made with the modular design
Outlet Control; Metered Outlets; Metered CKT Load; LCD
120V (Single Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L5-20P 8 8 - - MMP26.01.230-04 $604.00 MMP26.02.230-04 $748.00 29.75
10 10 - - MMP16.01.228-04 $637.00 MMP16.02.228-04 $781.00 31.5
16 16 - - MMP24.01.430-04 $860.00 MMP24.02.430-04 $1,000.00 43.75
20 20 - - MMP14.01.428-04 $923.00 MMP14.02.428-04 $1,060.00 47.25
30A NEMA L5-30P 8 8 - - MMP26.01.230-05 $633.00 MMP26.02.230-05 $777.00 29.75
10 10 - - MMP16.01.228-05 $666.00 MMP16.02.228-05 $810.00 31.5
16 16 - - MMP24.01.430-05 $889.00 MMP24.02.430-05 $1,030.00 43.75
20 20 - - MMP14.01.428-05 $952.00 MMP14.02.428-05 $1,090.00 47.25
24 24 - - MMP27.01.630-05 $1,140.00 MMP27.02.630-05 $1,290.00 57.75
30 30 - - MMP17.01.628-05 $1,240.00 MMP17.02.628-05 $1,380.00 57.0
Dimension
W-1.97” D-3.15”
Length
208V (Single Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA 6-20P 8 - 6 2 MMP26.01.226B-07 $628.00 MMP26.02.226B-07 $772.00 29.75
8 - 8 - MMP26.01.226A-07 $620.00 MMP26.02.226A-07 $764.00 29.75
10 - 8 2 MMP16.01.224B-07 $666.00 MMP16.02.224B-07 $810.00 31.5
10 - 10 - MMP16.01.224A-07 $658.00 MMP16.02.224A-07 $802.00 31.5
16 - 12 4 MMP24.01.426B-07 $894.00 MMP24.02.426B-07 $1,030.00 43.75
16 - 16 - MMP24.01.426A-07 $878.00 MMP24.02.426A-07 $1,020.00 43.75
20 - 16 4 MMP14.01.424B-07 $967.00 MMP14.02.424B-07 $1,110.00 47.25
20 - 20 - MMP14.01.424A-07 $950.00 MMP14.02.424A-07 $1,090.00 47.25
24 - 18 6 MMP27.01.626B-07 $1,160.00 MMP27.02.626B-07 $1,300.00 57.75
24 - 24 - MMP27.01.626A-07 $1,130.00 MMP27.02.626A-07 $1,280.00 57.75
30 - 24 6 MMP17.01.624B-07 $1,270.00 MMP17.02.624B-07 $1,410.00 57.0
30 - 30 - MMP17.01.624A-07 $1,240.00 MMP17.02.624A-07 $1,390.00 57.0
30A NEMA L6-30P 8 - 4 4 MMP26.01.226C-08 $650.00 MMP26.02.226C-08 $794.00 29.75
8 - 6 2 MMP26.01.226B-08 $642.00 MMP26.02.226B-08 $786.00 29.75
8 - 8 - MMP26.01.226A-08 $634.00 MMP26.02.226A-08 $778.00 29.75
10 - 8 2 MMP16.01.224B-08 $681.00 MMP16.02.224B-08 $825.00 31.5
10 - 10 - MMP16.01.224A-08 $673.00 MMP16.02.224A-08 $817.00 31.5
16 - 12 4 MMP24.01.426B-08 $909.00 MMP24.02.426B-08 $1,050.00 43.75
Dimension
W-1.97” D-3.15”
Length
230 Yuma St., Denver, CO 80223 / Tel (800) 576-3966 / Fax (800) 577-4096 / www.maxpowercorp.com
©2012 MaxPower Corporaon. All rights reserved. (04/13/12)
MMP
(Modular Metered Power)
Suggested MMP Configurations for Outlet Control and Metered Outlet. Please note that many other configurations
MMP Series
MODULAR METERED POWER (OUTLET MONITORED)
can be made with the modular design
Outlet Control; Metered Outlets; Metered CKT Load; LCD
208V (Single Phase) continued
RECEPTACLES COMMUNICATIONS INTERFACE
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
30A NEMA L6-30P 16 - 16 - MMP24.01.426A-08 $893.00 MMP24.02.426A-08 $1,030.00 43.75
20 - 16 4 MMP14.01.424B-08 $981.00 MMP14.02.424B-08 $1,120.00 47.25
20 - 20 - MMP14.01.424A-08 $965.00 MMP14.02.424A-08 $1,100.00 47.25
24 - 18 6 MMP27.01.626B-08 $1,170.00 MMP27.02.626B-08 $1,310.00 57.75
24 - 24 - MMP27.01.626A-08 $1,150.00 MMP27.02.626A-08 $1,290.00 57.75
30 - 24 6 MMP17.01.624B-08 $1,280.00 MMP17.02.624B-08 $1,420.00 57.0
30 - 30 - MMP17.01.624A-08 $1,260.00 MMP17.02.624A-08 $1,400.00 57.0
RECEPTACLES
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L14-20P 16 4 9 3 MMP24.01.130.326B-29 $939.00 MMP24.02.130.326B-29 $1,080.00 43.75
20 5 12 3 MMP14.01.128.324B-29 $1,000.00 MMP14.02.128.324B-29 $1,150.00 47.25
20 5 15 - MMP14.01.128.324A-29 $997.00 MMP14.02.128.324A-29 $1,140.00 47.25
24 4 15 5 MMP27.01.130.526B-29 $1,200.00 MMP27.02.130.526B-29 $1,340.00 57.75
24 4 20 - MMP27.01.130.526A-29 $1,180.00 MMP27.02.130.526A-29 $1,320.00 57.75
30 5 20 5 MMP17.01.128.524B-29 $1,310.00 MMP17.02.128.524B-29 $1,450.00 57.0
30 5 25 - MMP17.01.128.524A-29 $1,290.00 MMP17.02.128.524A-29 $1,430.00 57.0
30A NEMA L14-30P 16 4 9 3 MMP24.01.130.326B-25 $948.00 MMP24.02.130.326B-25 $1,090.00 43.75
20 5 12 3 MMP14.01.128.324B-25 $1,010.00 MMP14.02.128.324B-25 $1,160.00 47.25
20 5 15 - MMP14.01.128.324A-25 $1,000.00 MMP14.02.128.324A-25 $1,150.00 47.25
24 4 15 5 MMP27.01.130.526B-25 $1,210.00 MMP27.02.130.526B-25 $1,350.00 57.75
24 4 20 - MMP27.01.130.526A-25 $1,190.00 MMP27.02.130.526A-25 $1,330.00 57.75
30 5 20 5 MMP17.01.128.524B-25 $1,320.00 MMP17.02.128.524B-25 $1,460.00 57.0
30 5 25 - MMP17.01.128.524A-25 $1,300.00 MMP17.02.128.524A-25 $1,440.00 57.0
120/208V (2 Phase)
COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-3.15”
Length
Dimension
W-1.97” D-3.15”
Length
230 Yuma St., Denver, CO 80223 / Tel (800) 576-3966 / Fax (800) 577-4096 / www.maxpowercorp.com
©2012 MaxPower Corporaon. All rights reserved. (04/13/12)
MMP
(Modular Metered Power)
MMP Series
MODULAR METERED POWER (OUTLET MONITORED)
Suggested MMP Configurations for Outlet Control and Metered Outlet. Please note that many other configurations can be made with the modular design
Outlet Control; Metered Outlets; Metered Input; Metered CKT Load; LCD
120V 3ØY (3 Phase)
RECEPTACLES
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L21-20P 24 - - - MMP21.01.630-13 $1,240.00 MMP21.02.630-13 $1,380.00 59.5
30A NEMA L21-30P 24 - - - MMP21.01.630-14 $1,250.00 MMP21.02.630-14 $1,400.00 59.5
30 - - - MMP11.01.628-14 $1,340.00 MMP11.02.628-14 $1,480.00 66.5
60A IEC60309P (60A) 24 - - - MMP20.01.630-28 $1,720.00 MMP20.02.630-28 $1,870.00 59.5
30 - - - MMP10.01.628-28 $1,800.00 MMP10.02.628-28 $1,950.00 70.0
COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-3.15”
Length
208V 3ØY (3 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L21-20P 24 - 18 6 MMP21.01.626B-13 $1,270.00 MMP21.02.626B-13 $1,410.00 59.5
30 - 24 6 MMP11.01.624B-13 $1,370.00 MMP11.02.624B-13 $1,510.00 66.5
30A NEMA L21-30P 24 - 12 12 MMP21.01.626C-14 $1,310.00 MMP21.02.626C-14 $1,450.00 59.5
24 - 18 6 MMP21.01.626B-14 $1,280.00 MMP21.02.626B-14 $1,430.00 59.5
24 - 24 - MMP21.01.626A-14 $1,260.00 MMP21.02.626A-14 $1,400.00 59.5
30 - 24 6 MMP11.01.624B-14 $1,380.00 MMP11.02.624B-14 $1,530.00 66.5
30 - 30 - MMP11.01.624A-14 $1,360.00 MMP11.02.624A-14 $1,500.00 66.5
30A NEMA L21-30P 24 - 24 - MMP21.01.626A-14 $1,260.00 MMP21.02.626A-14 $1,400.00 59.5
30 - 30 - MMP11.01.624A-14 $1,360.00 MMP11.02.624A-14 $1,500.00 66.5
50A CS8365CP 24 - 18 6 MMP20.01.626B-18 $1,550.00 MMP20.02.626B-18 $1,690.00 65.0
24 - 24 - MMP20.01.626A-18 $1,520.00 MMP20.02.626A-18 $1,670.00 65.0
30 - 18 12 MMP10.01.624C-18 $1,670.00 MMP10.02.624C-18 $1,810.00 70.0
30 - 24 6 MMP10.01.624B-18 $1,640.00 MMP10.02.624B-18 $1,790.00 70.0
30 - 30 - MMP10.01.624A-18 $1,620.00 MMP10.02.624A-18 $1,760.00 70.0
60A IEC60309P (60A) 24 - 6 18 MMP20.01.626D-12 $1,710.00 MMP20.02.626D-12 $1,860.00 65.0
24 - 12 12 MMP20.01.626C-12 $1,690.00 MMP20.02.626C-12 $1,830.00 65.0
24 - 18 6 MMP20.01.626B-12 $1,670.00 MMP20.02.626B-12 $1,810.00 65.0
24 - 24 - MMP20.01.626A-12 $1,640.00 MMP20.02.626A-12 $1,790.00 65.0
24 - - 24 MMP20.01.626E-12 $1,740.00 MMP20.02.626E-12 $1,880.00 65.0
30 - 12 18 MMP10.01.624D-12 $1,810.00 MMP10.02.624D-12 $1,950.00 70.0
30 - 18 12 MMP10.01.624C-12 $1,780.00 MMP10.02.624C-12 $1,930.00 70.0
30 - 24 6 MMP10.01.624B-12 $1,760.00 MMP10.02.624B-12 $1,900.00 70.0
30 - 30 - MMP10.01.624A-12 $1,740.00 MMP10.02.624A-12 $1,880.00 70.0
Dimension
W-1.97” D-3.15”
Length
120/208V 3ØY (3 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE Dimension
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L21-20P 24 4 15 5 MMP21.01.128.526B-13 $1,140.00 MMP21.02.128.526B-13 $1,280.00 59.5
230 Yuma St., Denver, CO 80223 / Tel (800) 576-3966 / Fax (800) 577-4096 / www.maxpowercorp.com
©2012 MaxPower Corporaon. All rights reserved. (04/13/12)
W-1.97” D-3.15”
Length
MMP
(Modular Metered Power)
MMP Series
MODULAR METERED POWER (OUTLET MONITORED)
Suggested MMP Configurations for Metered Outlet. Please note that many other configurations can be made with the modular design
Outlet Control; Metered Outlets; Metered Input; Metered CKT Load; LCD
230/400V 3ØY (3 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
30A NEMA L22-30P 24 - 12 12 MMP21.01.626C-20 $1,470.00 MMP21.02.626C-20 $1,610.00 59.5
24 - 18 6 MMP21.01.626B-20 $1,440.00 MMP21.02.626B-20 $1,590.00 59.5
24 - 24 - MMP21.01.626A-20 $1,420.00 MMP21.02.626A-20 $1,560.00 59.5
30 - 18 12 MMP11.01.624C-20 $1,560.00 MMP11.02.624C-20 $1,700.00 65.0
30 - 24 6 MMP11.01.624B-20 $1,540.00 MMP11.02.624B-20 $1,680.00 65.0
30 - 30 - MMP11.01.624A-20 $1,510.00 MMP11.02.624A-20 $1,660.00 65.0
Dimension
W-1.97” D-3.15”
Length
230 Yuma St., Denver, CO 80223 / Tel (800) 576-3966 / Fax (800) 577-4096 / www.maxpowercorp.com
©2012 MaxPower Corporaon. All rights reserved. (04/13/12)
