TOSHIBA
INSTRUCTION MANUAL ADDENDUM
UNINTERRUPTIBLE POWER SYSTEM (UPS)
SINGLE PHASE - UE362L036C61TC1 (3.6-C1)
SPECIFICATIONS
April 2007 Document # 59759-000
Manufactured in the USA
© Copyright 2007 TOSHIBA International Corporation All rights reserved.
Introduction
This addendum to the 1600EP Series User Manual adds information to the existing Specifi cation sheet that is specifi c to the 3.6kVA-C1 (UE36L036C61TC1) UPS.
Purpose and Scope
This addendum to the 1600EP Series User Manual adds the specifi cations for the 3.6kVA-C1 (UE36L036C61TC1) UPS to the existing Specifi cation sheet.
The information in this addendum is to be used in conjunction with the Safety, Installation, and Operation information provided in the 1600EP Series Instruction Manual (55288-001).
Specifi cations for the 3.6 kVA-C1 UPS
Battery Low Voltage Tolerances
UPS Capacity 3.6 kVA-C1
Nominal Voltage (V Alarm Voltage (V Shutdown Voltage (V
) 144 VDC
NOM
) 130 VDC
LOW
) 114 VDC
MIN
Rated Battery Voltage
Model V
3.6 kVA-C1 163 114 1.0 A
Dimensions (ref. 1600EP Instruction Manual, “External Layout,” pg. 53)
MAX
V
MIN
I
CHARGE
Model A (Height) B (Width) C (Length) D (Body
3.6 kVA-C1 21 in. (533 mm)
Shipping Weight
10 in.
(2554 mm)
33 in.
(838 mm)
Model Pounds Kilograms
3.6 kVA-C1 325 147
height)
18.2 in.
(462 mm)
E (Unit fl oor
clearance)
2.8 in.
(72 mm)
2
1600EP Series Instruction Manual Addendum
UPS Specifi cations
STANDARD MODELS: 3.6 kVA-C1; 3.6 kVA; 6 kVA; 8 kVA
Unit (Capacity)
3.6 kVA-C1 (3.1 kW)
1
3.6 kVA (3.1 kW)
1
6 kVA (5.1 kW)
1
8 kVA (6.8 kW)
General Topology True On-line Certifi cations UL, CUL, ISO 9001, NEMA/PE1-1993 Input Characteristics Input Voltage Single-phase, 208/240 Vac, -30% – +10% Input Frequency 45 – 65 Hz (auto-sensing) Input Capacity 3.6 kVA 6.0 kVA 8.0 kVA Input Power Factor > 0.95 for all loads Current THD (linear load) < 5% total harmonic distortion Included AC Input Breaker
Rating
30 A/277 V 50 A/277 V 60 A/277 V
Battery Characteristics Battery Type Valve Regulated Lead Acid, Flame Retardant Backup time, fully charged
@ 0.7 power factor, 77 °F Backup time, fully charged
@ 0.85 power factor, 77 °F Recharge Time 24 hr. (full), 12 hr. (90%) for internal batteries only
8 min.
minimum
7 min.
minimum
2
minimum
2
10 min.
14 min.
2
minimum
2
7 min.
minimum
7 min.
minimum
2
2
3
Battery Voltage (Nominal) 144 Vdc 216 Vdc 216 Vdc 288 Vdc Output Characteristics Output Voltage Single-phase, 240/208/120 V Output Voltage Regulation ± 3% Output Frequency ±0.5 Hz/1 Hz/1.5 Hz (factory or authorized service center selectable only) AUTO/MAN Frequency Factory or authorized service center selectable only Voltage THD < 3% for linear load; < 6% for non-linear load Common-Mode Noise < 0.5Vrms Rated Load Power Factor 0.85 (0.6 – 1.0) lagging Effi ciency (ac-dc-ac) > than 83% (without battery charge) Voltage Transient < ±8% (Load of 0 – 100 %) Rated Output Current (rms) 15 A 25 A 33.3 A Max. Peak Output Current 45 A 75 A 100 A Inverter Overload Capacity 125% for 30 sec./150% for 10 sec. Bypass Overload Capacity 125% for 10 min./1000% for 1 cycle
1
1600EP Series Instruction Manual Addendum
3
STANDARD MODELS: 3.6 kVA-C1; 3.6 kVA; 6 kVA; 8 kVA (CONT’D)
Unit (Capacity)
3.6 kVA-C1
(3.1 kW)
1
3.6 kVA (3.1 kW)16 kVA (5.1 kW)
1
8 kVA (6.8 kW)
Environment Operating Temperature
59 – 77 °F (15 – 25 °C)
recommended
32 – 104 °F (0 – 40 °C) 32 – 91 °F (0 – 33 °C)
60 Hz 50 Hz
Storage Temperature -4 – 104 °F (-20 – 40 °C) Installation Area
To be installed in a well ventilated area free of airborne dust,
metal particles or fl ammable gas, allow at least 4 inches on all sides Operating Humidity 30 – 90% non-condensing Altitude < 3300 ft. (1000 m) above sea level
4
Acoustical Noise 50 dB (A) maximum @ 1 meter from front panel Operation Diagnosis Battery Check Performed on start up, by schedule, on-demand (user confi gurable) Input OV Protection Standard
Battery Lifetime
based upon battery ambient temperature (LCD display, LED and beeps)
UPS calculates battery replacement time
Internal Temperature UPS gives indication of internal temperature, alarm when high temp Event Data Storage 64 – Supply Mode, 32 – Backup, 16 – Faults Applications Switches Generator compatibility Bypass Switch Bypass Disable Static switch < ¼ cycle (50 Hz – 5 ms/60 Hz – 4.16 ms) Automatic Retransfer Factory or authorized service center selectable only User Interface Provided (can be disabled from front panel) Real Time Clock Schedule Operation Standard, Minimum 3 days memory backup during power loss RUN/STOP Disable Schedule ON/OFF operation of UPS using communication software Autostart UPS has option for UPS to start automatically when AC is applied Remote ON/OFF Standard, external terminal LED Display 4 LED’s indicating input/output condition, warning and battery operation LCD Screen 16 characters x 2 lines UPS Operation: 6 Keys Run/Stop, Set/Monitor, Shift/Select, Del/Page Down, Reset/Page Up Buzzer Volume Low, High, Mute; Selectable by keypad Power Connections Hard wire (Standard) Emergency Power Off Standard (Terminal contacts only) Remote Contacts Standard (INV, BYP, BATT, LB, AC, FLT) RS232 ASCII Interface Standard
1
4
1600EP Series Instruction Manual Addendum
STANDARD MODELS: 3.6 kVA-C1; 3.6 kVA; 6 kVA; 8 kVA (CONT’D)
Unit (Capacity)
3.6 kVA-C1 (3.1
1
kW)
3.6 kVA (3.1 kW)
1
6 kVA (5.1 kW)
1
8 kVA (6.8 kW)
Mechanical Design Enclosure Enclosure of unit made from sheet metal meeting NEMA1 and UL Type 1 Size (HxWxD) Inches (max) 21 x 10 x 33 27.5 x 10 x 33 28.25 x 13 x 33.5 Paint System Powder coating
Fan Panel
easy replacement of fans without turning off power to UPS
Panel mounted on back of UPS to allow for
Battery System Battery Replacement
Slide out battery packs accessible from front of UPS
(Factory or authorized service center serviceable only) Battery Packs Designed for battery acid leakage containment with (6) batteries per pack Battery Pack Size HxWxD)Inches(max) 5 x 7.3 x 18.2 Battery Pack Quantity 2 3 3 4 Battery Manufacturer Enersys Battery Type NPX-35 Toshiba’s Part Number for
Battery Pack
(1) Input/output fi gures rated for 240 volts. Output ratings given for 0.85 pF are only valid when the input voltage is
greater than 204 volts; otherwise, ratings given for 0.70 pF are applicable. (2) Battery backup time may vary depending on the operating conditions and ambient temperature at the installation site. (3) An initial charge time of 24 hrs. is necessary to obtain proper battery performance level before unit is placed in operation. (4) At 6600 ft (2000 m) above sea level, output capacity should be derated by 3%.
51896
1
1600EP Series Instruction Manual Addendum
5
TOSHIBA
TOSHIBA INTERNATIONAL CORPORATION Industrial Division
13131 West Little York Road Houston, Texas 77041-9990 TEL (713) 466-0277 FAX (713) 466-8773 USA Toll Free (800) 231-1412
Printed in the U.S.A.
