Maxon Telecom PMR446 User Manual
S5 PMR446
User Manual
User Manual S5
Table of Contents
Table of Contents .................................................................................................................1
Operating Instructions...........................................................................................................2
About Your S5 Radio ....................................................................................................2
S5 Specification ...........................................................................................................2
Safety Information................................................................................................................3
Unpacking Information..........................................................................................................4
S5 Features..........................................................................................................................5
Description of Radio Components...........................................................................................5
Installing and Removing the Battery Pack ...............................................................................7
Attaching and Removing the Belt Clip ..................................................................................... 8
Attaching and Removing the Jack Cover..................................................................................8
English
Battery Charging and Care.....................................................................................................9
Status Indicators and Audible Alert Tones.............................................................................10
Operation Mode..................................................................................................................11
Power Off Mode..................................................................................................................11
Power On Mode..................................................................................................................11
Cloning ..............................................................................................................................11
Password ...........................................................................................................................11
Scanning............................................................................................................................11
Fixed Key...........................................................................................................................12
PTT (Press to Talk) ....................................................................................................12
MONITOR..................................................................................................................12
EMG..........................................................................................................................12
Service Information.............................................................................................................12
CH-SL1000-02 Desktop Charger...........................................................................................14
Declaration of conformity…………………………………………………………...........................................15
Page 1
User Manual S5
Operating Instructions
About Your S5 Radio
Maxon's S5 radio features up to 8 channels. Operation and functions of these radios are outlined
in this manual.
We urge you to thoroughly read this manual before operating the radio
The application of some of the functions described in this manual is determined by the sytem you
use. Your Maxon Dealer will program your radio so that you have the greatest number of
functions possible relative to your needs.
S5 Specification
MODEL S5
EQUIPMENT TYPE PMR446
PERFORMANCE SPECIFICATIONS EN 300.296
BAND 446.00625~446.09375MHz
CHANNEL SPACING 12.5KHz
RF OUTPUT POWER 500Mw (ERP)
English
MODULATION TYPE F3E
AUDIO POWER 500Mw (EXT WITH 8 OHM)
1 W (INT WITH 4 OHM)
INTERMEDIATE FREQUENCIES 45.1MHz
455KHz
CHANNELS 8 Channels
FREQUENCY SOURCE SYNTHESIZER
POWER SUPPLY Li-ion(1500mA)
7.5VDC Nominal
+/- 10% VDC Extreme
Page 2
User Manual S5
Safety Information
WARNING
¾ DO NOT hold the radio in such a manner that the antenna is next to, or touching, exposed
parts of the body while transmitting.
¾ DO NOT allows children to operate transmitter-equipped radio equipment.
CAUTION
¾ DO NOT operate the radio near unshielded electrical blasting caps or in an explosive
atmosphere unless it is a type especially designed and qualified for such use.
¾ DO NOT press and hold the transmit switch (P-T-T) when not actually wishing to transmit.
¾ NEVER use the radio in an aircraft.
¾ NEVER use the radio near to sensitive medical equipment or in areas where instructed not to
do so, e.g. Petrol filling stations.
¾ When used in a vehicle, do not mount the radio unit on or near the Airbag or Airbag
activation device.
¾ The use of an accessory not recommended or supplied by Maxon may cause damage to
equipment or injury to personnel, and will invalidate warranty.
English
¾ When using any of the charging accessories, the mains socket-outlet must be installed near
the equipment.
¾ The outlet must not be obstructed and must be easily accessible at all times.
¾ Never attempt to disassemble, modify or repair the unit unless the work is carried out by a
Maxon approved Dealer.
Incorrect assembly, modification or repair may cause irreparable damage to your unit and will
invalidate warranty.
For service or repair always return your radio to an authorized Maxon Dealer.
Page 3
User Manual S5
Unpacking Information
Remove and carefully inspect the contents of your package(s) for the following items:
1. Radio
2. Battery Pack
3. Battery Charger
4. Spring Belt Clip
5. Jack Cover
6. Battery Charger Power Supp ly
7. User Manual
* If any items are missing, please contact your Dealer or Maxon
English
Page 4
User Manual S5
S5 Features
500mW output power
12.5KHz channel spacing
Full scanning
Password protect
Emergency call
CTCSS/DCS/tone signalling
Li-ion Battery
2-Tone Decode
Busy Channel lockout
Time-out timer
Priority Channel Edit
English
Description of Radio Components
(Please see drawing on page 6)
1. Fixed Antenna
2. Channel Selector Switch
3. On/Off – Volume Control
4. Emergency Button
5. Push-To- Talk (PTT)
6. Monitor Butto n
7. Option Button
8. Battery
9. RX/TX Indicator
10. Speaker
11. Microphone
12. Accessory Connector (EXT Jack)
13. Battery Latch
14. Belt Clip
15. Battery Charge Contacts
Page 5
