Maxnet WA7500-SG User Manual
108M
Wireless
Access Point
SkyNet WA7500-SG
LAN
WLAN
System
Power
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice Maxnet.
is a registered trademark of
Other brands and product names are trademarks or
registered trademarks of t
heir respective
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from MAXNET.
All rights reserved.
http://www.maxnet.pe
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient o r relocate the receiving antenna.
• Increase the separation be t w een the equipment and receiver.
• Connect t h e equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienceed radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1) This device may not cause h a rmful interference.
2) This device must accept a ny interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement
To comply with FCC RF exposure compliance requir ements, this grant is applicable to only Mobile
Configurations. The antennas used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
National Restrictions
2400.0-2483.5 MHz
Country Restriction Reason/remark
Bulgaria
General authorization required for outdoor use and
public service
France
Outdoor use limited to 10
mW e.i.r.p. within the band
2454-2483.5 MHz
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
Italy
If used outside of own premises, general authorization is
required
Luxembourg None
General authorization required for network and service
supply(not for spectrum)
Norway Implemented
This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Russian Federation Only for indoor applications
Note: Please don’t use the product outdoors in France.
CONTENTS
Package Contents .................................................................................................... 1
Chapter 1 Introduction........................................................................................... 2
1.1 Product Overview .............................................................................................. 2
1.2 Main Features ................................................................................................... 2
1.3 Conventions ...................................................................................................... 3
Chapter 2 Hardware Installation............................................................................ 3
2.1 The Front Panel................................................................................................. 3
2.1.1 LED Explanation.................................................................................................3
2.2 The Back Panel ................................................................................................. 4
2.3 System Requirements ....................................................................................... 4
2.4 Installation Environment Requirements............................................................. 4
2.5 Connecting the Device ...................................................................................... 5
2.6 Configure PC..................................................................................................... 5
Chapter 3 Software Configuration ........................................................................ 9
3.1 Login.................................................................................................................. 9
3.2 Status ..............................................................................................................10
3.3 Network ........................................................................................................... 11
3.4 Wireless........................................................................................................... 11
3.4.1 Basic Settings ...................................................................................................12
3.4.2 Wireless Mode ..................................................................................................13
3.4.3 Site Survey .......................................................................................................18
3.4.4 Security Settings...............................................................................................19
3.4.5 MAC Filtering ....................................................................................................21
3.4.6 Wireless Statistics.............................................................................................24
3.5 DHCP .............................................................................................................. 24
3.5.1 DHCP Settings..................................................................................................25
3.5.2 DHCP Clients List.............................................................................................26
3.5.3 Address Reservation ........................................................................................26
3.6 Wireless Settings............................................................................................. 27
3.7 System Tools ................................................................................................... 28
3.7.1 Firmware...........................................................................................................28
3.7.2 Factory Defaults................................................................................................29
3.7.3 Backup & Restore.............................................................................................30
3.7.4 Reboot ..............................................................................................................30
3.7.5 Passw ord ..........................................................................................................31
3.7.6 Syslog ...............................................................................................................31
Appendix A: Glossary......................................................................................... 33
Appendix B: Specifications................................................................................ 35
Appendix C: FAQ.................................................................................................... 36
Package Contents
The following items should be found in your package:
1 One WA7500-SG 1 08Mbps Wireless Access Point
2
One AC powe r Adapter for 108Mbps Wireless Access Point WA7500-SG
3 One Resourc e CD , which includes This User Guide
Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact with your distributor.
1
Chapter 1 Introduction
Thank you for choosing the WA7500-SGG 108Mbps Wireless Access Point.
1.1 Product Overview
This AP provides smooth connectivity between Ethernet wired networks and radio-equipped
wireless devices.
It adopts 108M Super G
™
WLAN Transmission Technology, which offers the highest throughput
performance available on the market today, and data rates of up to 108Mbps. In dynamic 108M
mode, the AP can attach IEEE 802.11b, 802.11g and 108Mbps Super G
™
devices at the same
time in an integrated environment.
It adopts 2x to 3x eXtended Range
™
WLAN transmission technology so that transmission
distance is 2-3 times of traditional IEEE 802.11g and IEEE 802.11b solutions, up to 855.36m
tested in China. The transmission range is extended to 4-9 times.
It is an easy, web-based setup for installation and management. Even though you may not be
familiar with the AP, this guide will make configuring the AP easy. Before installing the AP, please
look through this guide to get to know all the AP’s functions.
1.2 Main Features
Complies with IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u standards
Adopts 2x to 3x eXtended Range™ and 108M Super G™ wireless LAN transmission
technology.
Supports 108/54/48/36/24
/18/12/9/6Mbps or 11/
5.5/3/2/1Mbps wireless LAN data transfer
rates
Provides 64/1 2 8/152-bit WEP encryption security
Provides WPA/WPA 2 and WPA-PSK/WPA2-PSK authentication and TK
IP/AES encryption
security
Built-in DHCP s erver supporting dynamic IP address distributing
Supports MAC address f iltering
Supports multiple operating modes (Access Point, Client, Repeater, Point to Point, Point to
Multi-point)
Supports TCP/IP, DHCP
Supports Traffic s tatistics
Supports firmware upgrade
Supports Remote a nd Web management
2
108M Wireless Access Point User Guide
108M Wireless Access Point User Guide
MAXNET WA7500-SG
1.3 Conventions
The AP or WA7500-SG, or device mentioned in this User guide stands for WA7500-SG 108M
Wireless Access Point without any explanations.
Parameters provided in the pictures are just references for setting up the product, which may differ
from the actual situation.
You can set the parameters according to your demand.
Chapter 2 Hardware Installation
2.1 The Front Panel
Figure 2-1
The LED indicators displayed on the front panel, the status of these LED indicators represent the
device’s working circs. For details, please refer to 2.1.1 LED Explanation
2.1.1 LED Explanation
Name Status Description
Off No Power
Power
On Power on
Off The AP has a hardware error
On The AP is initialising
System
Flashing The AP is working properly
Off There is no device linked to the corresponding port
On There is a device linked to the corresponding port but no activity
LAN
Flashing There is an active device linked to the corresponding port
Off The Wireless Radio function is disabled
WLAN
Flashing The Wireless Radio function is enabled
3
108M Wireless Access Point User Guide
MAXNET WA7500-SG
SkyNet WA7500-SG
LAN WLANSystem
Power
Super G & eXtended Range
TMTM
108M Wireless Access Point
2.2 The Back Panel
Figure 2-2
Wireless antenna
Factory Default R eset button
There are t h ree ways to reset the AP's factory defaults:
• Use the Factory Defaults function on System Tools -> Factory Defaults page in the
AP's Web-based Utility.
• Use the Factory Default R eset button: Pr ess and hold the default Reset button for 5
seconds, and then the AP reboot after the System led flash 5 times.
• Use the Factory Reset button: First,Default turn off the AP's power. Second, press and
hold the default Reset button then turn on the AP's power, until the system LED lights up
(about 3 seconds). Last, release the reset button and wait for the AP to reboot.
Note:
Ensure the AP is powered on before it restarts completely.
One LAN 10/1 0 0Mbps RJ45 port for connecting the AP to hub or switch
AC power socket: Only u se the power adapter provided with the WA7500-SG 108Mbps
Wireless Access Point; Usage of a different adapter may result in product damage.
2.3 System Requirements
Broadba n d Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable M odem that has an RJ45 connector
A Ethernet broadband r o uter
TCP/IP protocol m ust be installed on each PC
Web brow ser, such as Microsoft Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later
802.11g or 802.11b-compliant devices, su ch as the WA7500-SG Wireless Adapter
2.4 Installation Environment Requirements
Not in direct sunlight or near a heater or heating vent
4
108M Wireless Access Point User Guide
MAXNET WA7500-SG
Not cluttered or crowded. There should be at least 2 inches (5 cm) of clear space on all sides
of the AP
Well ventilated (especially if it is in a closet)
Operating temperature: 0 ~40 (32 ~104 )
Operating Humidity: 10%~90%RH, Non-condensing
2.5 Connecting the Device
Figure 2-3 is an example of an infrastructure network incorporating the WA7500-SG. An
Infrastructure network contains an access point or a wireless router. For a typical connection of the
AP, please do the following:
1. You will need broadband Internet access (a Cable or DSL-subscriber line into your home or
office). Consult with your Cable or DSL provider for proper installation of the modem.
2. Connect the Cable or DSL modem to a Router. Quickly install the router.
3. Locate an optimun l o cation for the AP. The best pl
ace is usually near the
center of the area in
which your PC(s) will wirelessly connect. The place must accord with the Installation
Environment Requirements.
4. Adjust the direction of the antenna. Normally, upright is a good direction.
5. Conne c t the Ethernet Broadband Router to the AP. Power on the AP. WA7500-SG
6. If you are connecting a desktop PC o r laptop to your network, install the MAXNET Wireless
Adapter on the PC.
Figure 2-3 The Example of Infrastructure Network Incorporating the WA7500-SG
2.6 Configure PC
After connecting the AP into your netwWA7500-SG ork, you should confi gure it. The default IP
address of the 108Mbps Wireless WA7500-SG Access Point is 192.168.1.1, and the default
5
0:LUHOHVV$FFHVV3RLQW8VHU*XLGHMAXNET WA7500-SG
ćć
Subnet Mask is 255.255.255.0. These values can be seen from the LAN. They can be changed as
you desire, as an example we use the default values for description in this guide.
Connect the local PCs to the LAN ports on the AP and configure the IP address manually for your
PCs.
1. From the Start menu on your desktop, go to Settings, and then click on Network
Connections.
Figure 2-4
2. In the Network Connections window, right-click on LAN (Local Area Connection), then click
Properties.
Figure 2-5
3. In the General tab of Internet Protocol (TCP/IP) Properties menu, highlight Internet
Protocol (TCP/IP) under “This connection uses the following items:” by clicking on it once.
Click on the Properties button.
6
108M Wireless Access Point User Guide
MAXNET WA7500-SG
Figure 2-6
4. Configure the IP address manually. Click OK.
Figure 2-7
7
108M Wireless Access Point User Guide
MAXNET WA7500-SG
Loading...
