MAX15301 PMBus Command Set
User’s Guide
Rev 1; 10/14
Maxim Integrated canno t assume responsibility for use o f any circuitry other than circuit ry entirely embodied in a Maxi m Integrated product. No circuit patent licenses are implied. Maxim Integrated reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated 160 Rio Robles, San Jose, CA 95134 USA 1-408-601-1000
© 2014 Maxim Integrate d Pr od ucts, Inc. Maxim Integrat ed and the Maxim Integrated logo are trademarks of Maxim Integrat ed P ro ducts, Inc.
MAX15301 PMBus Command Set User’s Guide
Reference:
<”Standard” or “Maxim Specific”>
Lockable:
<yes/no>
Command Code:
<hex value>
Format:
<data format>
Data Bytes:
<byte count>
Units:
<unit of measure>
Transfer:
<SMBus transaction>
Factory Value:
<Maxim setting>
Description/Notes:
<Command definition if Maxim-specific, or notes on command functionality where it differs from the

Introduction

Maxim Integrated InTune™ digital power products utilize the PMBus™ command standard for configuration, control and telemetry.
This document lists and describes the PMBus commands implemented in the MAX15301 digital DC-DC controller. Standard commands from the PMBus specification are not described in detail unless there are deviations from the PMBus specification functionality. Maxim manufacturer-specific commands are fully described in this document.
References for this document are found on the PMBus and SMBus organization websites.
http://pmbus.org/specs.html http://smbus.org/specs/
The commands in this document are presented in the following format:
<COMMAND_NAME>
PMBus specification.>

Part Number Differences

The MAX15301 controller is available under different part numbers with some functional differences as follows.

MAX15301AA01

The MAX15301AA01 has the first production firmware, version 4018.

MAX15301AA02

The MA15301AA02 has improved firmware, version 4328, with the following improvements:
Changed to 2-point thermal measurement algorithm to improve the READ_TEMPERATURE_2 accuracy
Added support for v6 final test/trim scheme (improves READ_TEMPERATURE_1 accuracy)
Changed IC_DEVICE_ID length from 8 to 12 bytes
PMBUS_REVISION changed to 0x22
Changed EXT_TEMP_CAL defaults to improve READ_TEMPERATURE_2 accuracy
Added SMBus timeout support
Bug fix for interrupted PMBus read operations
Bug fix for operation with FREQUENCY_SWITCH <400kHz and temperature sense diode connected to TEMPX
Rev 1 Page 2 of 53
MAX15301 PMBus Command Set User’s Guide
Table of Contents
Introduction ................................................................................................................................................................................. 1
Part Number Differences ............................................................................................................................................................. 2
MAX15301AA01 ....................................................................................................................................................................... 2
MAX15301AA02 ....................................................................................................................................................................... 2
On, Off, and Margin Testing Related Commands ........................................................................................................................ 7
OPERATION .............................................................................................................................................................................. 7
ON_OFF_CONFIG ..................................................................................................................................................................... 7
VIN_ON .................................................................................................................................................................................... 8
VIN_OFF ................................................................................................................................................................................... 9
Output Voltage Related Commands .......................................................................................................................................... 10
VOUT_MODE ......................................................................................................................................................................... 10
VOUT_COMMAND ................................................................................................................................................................. 10
VOUT_TRIM ........................................................................................................................................................................... 10
VOUT_CAL_OFFSET ................................................................................................................................................................ 11
VOUT_MAX ............................................................................................................................................................................ 11
VOUT_MARGIN_HIGH ........................................................................................................................................................... 11
VOUT_MARGIN_LOW ............................................................................................................................................................ 12
VOUT_TRANSITION_RATE ...................................................................................................................................................... 13
VOUT_DROOP ........................................................................................................................................................................ 13
Switching Frequency and PWM Commands .............................................................................................................................. 15
FREQUENCY_SWITCH ............................................................................................................................................................. 15
INTERLEAVE ........................................................................................................................................................................... 15
Output Voltage Sequencing Commands .................................................................................................................................... 16
POWER_GOOD_ON ............................................................................................................................................................... 16
POWER_GOOD_OFF .............................................................................................................................................................. 17
TON_DELAY ............................................................................................................................................................................ 17
TON_RISE ............................................................................................................................................................................... 18
TOFF_DELAY ........................................................................................................................................................................... 18
TOFF_FALL.............................................................................................................................................................................. 19
Fault Related Commands ........................................................................................................................................................... 20
CLEAR_FAULTS ....................................................................................................................................................................... 20
VOUT_OV_FAULT_LIMIT ........................................................................................................................................................ 20
VOUT_OV_FAULT_RESPONSE ................................................................................................................................................ 21
Rev 1 Page 3 of 53
MAX15301 PMBus Command Set User’s Guide
VOUT_UV_FAULT_LIMIT ........................................................................................................................................................ 21
VOUT_UV_FAULT_RESPONSE ................................................................................................................................................ 22
IOUT_OC_FAULT_LIMIT ......................................................................................................................................................... 22
IOUT_OC_FAULT_RESPONSE ................................................................................................................................................. 23
OT_FAULT_LIMIT ................................................................................................................................................................... 23
OT_FAULT_RESPONSE ........................................................................................................................................................... 24
OT_WARN_LIMIT ................................................................................................................................................................... 25
VIN_OV_FAULT_LIMIT ........................................................................................................................................................... 25
VIN_OV_FAULT_RESPONSE ................................................................................................................................................... 25
VIN_UV_FAULT_LIMIT ........................................................................................................................................................... 26
VIN_UV_FAULT_RESPONSE ................................................................................................................................................... 26
Unit Status Commands .............................................................................................................................................................. 28
STATUS_BYTE ......................................................................................................................................................................... 28
STATUS_WORD ...................................................................................................................................................................... 28
STATUS_VOUT ....................................................................................................................................................................... 28
STATUS_IOUT ......................................................................................................................................................................... 28
STATUS_INPUT ....................................................................................................................................................................... 29
STATUS_TEMPERATURE......................................................................................................................................................... 29
STATUS_CML .......................................................................................................................................................................... 29
Telemetry Commands ................................................................................................................................................................ 30
READ_VIN............................................................................................................................................................................... 30
READ_VOUT ........................................................................................................................................................................... 30
READ_IOUT ............................................................................................................................................................................ 30
READ_TEMPERATURE_1 ........................................................................................................................................................ 31
READ_TEMPERATURE_2 ........................................................................................................................................................ 31
READ_DUTY_CYCLE ................................................................................................................................................................ 31
READ_FREQUENCY ................................................................................................................................................................. 32
PMB_VALUES ......................................................................................................................................................................... 32
Calibration Commands .............................................................................................................................................................. 34
IOUT_CAL_GAIN ..................................................................................................................................................................... 34
IOUT_CAL_OFFSET ................................................................................................................................................................. 34
EXT_TEMP_CAL (MAX15301AA01) ........................................................................................................................................ 34
EXT_TEMP_CAL (MAX15301AA02) ........................................................................................................................................ 35
Device Identification Commands ............................................................................................................................................... 36
Rev 1 Page 4 of 53
MAX15301 PMBus Command Set User’s Guide
CAPABILITY ............................................................................................................................................................................. 36
PMBUS_REVISION .................................................................................................................................................................. 36
MFR_ID .................................................................................................................................................................................. 36
MFR_MODEL .......................................................................................................................................................................... 37
MFR_REVISION ...................................................................................................................................................................... 37
MFR_LOCATION ..................................................................................................................................................................... 37
MFR_DATE ............................................................................................................................................................................. 37
MFR_SERIAL ........................................................................................................................................................................... 38
IC_DEVICE_ID (MAX15301AA01) ........................................................................................................................................... 38
IC_DEVICE_ID (MAX15301AA02) ........................................................................................................................................... 38
IC_DEVICE_REV ...................................................................................................................................................................... 38
Security Commands ................................................................................................................................................................... 39
WRITE_PROTECT .................................................................................................................................................................... 39
MANUF_CONF ....................................................................................................................................................................... 39
MANUF_LOCK ........................................................................................................................................................................ 40
MANUF_PASSWD ................................................................................................................................................................... 40
USER_CONF ............................................................................................................................................................................ 40
USER_LOCK ............................................................................................................................................................................ 41
USER_PASSWD ....................................................................................................................................................................... 41
SECURITY_LEVEL .................................................................................................................................................................... 42
Memory and Storage Commands .............................................................................................................................................. 43
STORE_DEFAULT_ALL ............................................................................................................................................................ 43
RESTORE_DEFAULT_ALL ........................................................................................................................................................ 44
STORE_USER_ALL ................................................................................................................................................................... 44
RESTORE_USER_ALL............................................................................................................................................................... 46
RESTORE_MAXIM_ALL ........................................................................................................................................................... 46
STRAP_DISABLE ...................................................................................................................................................................... 47
Control Loop Commands ........................................................................................................................................................... 48
ADAPTIVE_MODE ................................................................................................................................................................... 48
FEEDBACK_EFFORT ................................................................................................................................................................ 49
LOOP_CONFIG ........................................................................................................................................................................ 49
COMP_MODEL ....................................................................................................................................................................... 50
DEADTIME_GCTRL ................................................................................................................................................................. 50
ZETA_P ................................................................................................................................................................................... 52
Rev 1 Page 5 of 53
MAX15301 PMBus Command Set User’s Guide
Trademarks ................................................................................................................................................................................ 53
Revision History ......................................................................................................................................................................... 53
Rev 1 Page 6 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x01
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0x40 (see Description table)
Description/Notes:
See Section 12.1 of the PMBus Specification Part II.

On, Off, and Margin Testing Related Commands

OPERATION

If the values of VOUT_OV_FAULT_LIMIT or VOUT_UV_FAULT_LIMIT are set between the values of
VOUT_MARGIN_HIGH and VOUT_MARGIN_LOW, it is possible that a fault will be detected when
exiting the “Margin High/Low (Ignore Fault)” command states. This occurs when fault detection is re­enabled before the output has had time to return to the be avoided in most cases by increasing the value of VOUT_TRANSITION_RATE, thereby decreasing the amount of time required for the output to return to normal VOUT_COMMAND setpoint.
The value of the OPERATION command is maintained in volatile memory, and cannot be stored in the Default Store or User Store nonvolatile memory. This prevents inadvertent preservation of a margin-high or margin-low state. If it is desired to keep the output always enabled or always disabled upon power-up, this can be achieved by storing the appropriate value of the ON_OFF_CONFIG command.
MAX15301 PMBus Command Set User’s Guide
VOUT_COMMAND value. This condition can
Useful values for the OPERATION command: 0x00 Immediate-off, no sequencing: both DH and DL outputs low 0x40 Soft-off, with sequencing (factory setting) 0x80 Output enabled, if allowed by ON_OFF_CONFIG setting (note: same as 0x81-0x8F) 0x94 Margin low, ignore faults (note: same as 0x95-0x97) 0x98 Margin low, act on faults (note: same as 0x99-0x9B) 0xA4 Margin high, ignore faults (note: same as 0xA5-0xA7) 0xA8 Margin high, act on faults (note: same as 0xA9-0xAB)
Invalid values for the OPERATION command:
0x90-0x93 0x9C-0x9F 0xA0-0xA3 0xAC-0xFF
These invalid data bytes will trigger an “Invalid Or Unsupported Data” response per section 10.9.3 of the PMBus specification.
After writing the OPERATION command to enable the output, the PMBus master must either wait for a time equal to (TON_DELAY + TON_RISE + 50ms), or wait for PG to assert, before sending additional PMBus commands.
ON_OFF_CONFIG
a
An “immediate-off,” “hard-stop,” or “tri-state” shutdown means the MAX15301 will stop switching and keep both DH and
DL outputs low, allowing the output voltage to decay naturally according to load and output capacitance.
b
In this application note (and other InTune documents) a “soft-off,” “soft-stop,” or “ramp-down” shutdown means the MAX15301 actively controls the output voltage along a linear ramp to zero Volts, per the TOFF_DELAY and TOFF_FALL values.
a
b
(note: same as 0x41-0x7F)
(note: same as 0x01-0x3F)
Rev 1 Page 7 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x02
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0x16 (see Description table)
Description/Notes:
See Section 12.2 of the PMBus Specification Part II.
writing the ON_OFF_CONFIG command to enable the output, the PMBus master must either
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x35
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0xCB00 (6.0V)
Description/Notes:
See Section 14.5 of the PMBus Specification Part II.

ON_OFF_CONFIG

MAX15301 PMBus Command Set User’s Guide
Useful Values for the ON_OFF_CONFIG command: 0x00 Output always enabled (note: same as 0x01-0x0F) 0x10 Output always disabled (note: same as 0x11-0x13) 0x14 Ignore bit 7 of OPERATION 0x15 Ignore bit 7 of OPERATION, require EN low to run, immediate-off on loss of EN 0x16 Ignore bit 7 of OPERATION, require EN high to run, soft-off on loss of EN (factory setting) 0x17 Ignore bit 7 of OPERATION, require EN high to run, immediate-off on loss of EN 0x18 Require bit 7 of OPERATION to run, ignore EN (note: same as 0x19-0x1B) 0x1C Require bit 7 of OPERATION and EN low to run, soft-off on loss of EN 0x1D Require bit 7 of OPERATION and EN low to run, immediate-off on loss of EN 0x1E Require bit 7 of OPERATION and EN high to run, soft-off on loss of EN 0x1F Require bit 7 of OPERATION and EN high to run, immediate-off on loss of EN
, require EN low to run, soft-off on loss of EN
In general, odd values of ON_OFF_CONFIG that require a valid EN signal will have an immediate-off shutdown when EN is not valid. Even values that require EN will have a soft-off shutdown when EN is not valid.
After wait for a time equal to (TON_DELAY + TON_RISE + 50ms), or wait for PG to assert, before sending additional PMBus commands.

VIN_ON

The MAX15301 hardware has 8-bit resolution for the minimum input voltage required for regulation, to a maximum value of ≈14.75V.
The desired value of VIN_ON is retained in memory, regardless limitations imposed by the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
Rev 1 Page 8 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x36
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0xCAC0 (5.5V)
Description/Notes:
See Section 14.6 of the PMBus Specification Part II.

VIN_OFF

The MAX15301 hardware has 8-bit resolution for the minimum input voltage required for regulation, to a maximum value of ≈14.75V.
The desired value of VIN_OFF is retained in memory, regardless limitations imposed by the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
MAX15301 PMBus Command Set User’s Guide
Rev 1 Page 9 of 53
Reference:
Standard Command
Lockable:
No
Command Code:
0x20
Format:
Mixed: bit-field and 2’s complement
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
0x14 (Linear Mode, exponent -12)
Description/Notes:
See Section 8.2 of the PMBus Specification Part II.
supports Linear Mode values for output voltage related commands. The

VOUT_COMMAND

Reference:
Standard Command
Lockable:
Yes
Command Code:
0x21
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0001 (see Description)
Description/Notes:
See Section 8.2 of the PMBus Specification Part II.
In the MAX15301, there are seven possible output voltage ranges based on seven corresponding internal feedback divider taps. The value of VOUT_COMMAND is retained and read back from volatile
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x22
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0000 (0V)
Description/Notes:
See Section 13.3 of the PMBus Specification Part II.

Output Voltage Related Commands

VOUT_MODE

The MAX15301 only VOUT_MODE command is read-only and the value cannot be changed.
The 5-bit exponent for output voltage data is -12, or two’s-complement 10100. This means that voltage command data sent to and from the MAX15301 using either the 2-byte unsigned integer mantissa or Direct mantissa formats must be divided by 4096 to determine the actual voltage value.
MAX15301 PMBus Command Set User’s Guide
VOUT_COMMAND mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
The factory value of 0x0001 (0.244mV) will be overridden during initialization by the hardware (pin­strap) value determined by the resistance to ground detected at the SET pin, unless a specific value has been written to the User Store. The value of the SET pin resistance is measured only once during initialization (power-up).
memory, regardless of limitations imposed by the feedback divider range.
New values of VOUT_COMMAND can be written at any time, but large changes (specifically, those that require a different feedback divider selection;, see Table 7 of the MAX15301 data sheet) will require the output to be disabled for the feedback divider to change.
VOUT_TRIM
.
Rev 1 Page 10 of 53
In the MAX15301, the value of VOUT_TRIM is summed with the value of VOUT_COMMAND and
VOUT_CAL_OFFSET, and the result is sent to the control loop as the output voltage setpoint.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x23
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0000 (0V)
Description/Notes:
See Section 13.4 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x24
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0001 (see Description)
Description/Notes:
See Section 13.5 of the PMBus Specification Part II.
erridden during initialization to
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x25
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0001 (see Description)

VOUT_TRIM

The value of VOUT_TRIM is not subtracted from READ_VOUT, so nonzero VOUT_TRIM values will result in a difference between VOUT_COMMAND and READ_VOUT.
This command is intended to allow an end user of a PMBus device to tailor a specific supply to the performance requirements of a specific load device, while retaining use of a “nominal” voltage setpoint for all similar load devices.

VOUT_CAL_OFFSET

In the MAX15301, the value of VOUT_CAL_OFFSET is summed with the value of VOUT_COMMAND and VOUT_TRIM, and the result is sent to the control loop as the output voltage setpoint.
MAX15301 PMBus Command Set User’s Guide
The value of VOUT_CAL_OFFSET is subtracted from READ_VOUT, so VOUT_CAL_OFFSET values never result in a difference between VOUT_COMMAND and READ_VOUT.
This command is intended to allow a PMBus device manufacturer or an end user to calibrate the output voltage of a module (or other power-supply assembly) to match an external reference instrument during their final-test process.

VOUT_MAX

VOUT_MAX mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
The factory value of 0x0001 (0.244mV) will be ov
VOUT_COMMAND x 1.10, unless a specific value has been written to the User Store.
VOUT_MARGIN_HIGH
.
Rev 1 Page 11 of 53
Description/Notes:
See Section 13.6 of the PMBus Specification Part II.
In the MAX15301, there are seven possible output voltage ranges based on seven corresponding
high operation, the output will fall at a rate
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x26
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0001 (see Description)
Description/Notes:
See Section 13.7 of the PMBus Specification Part II.
V) will be overridden during initialization to
voltage ranges based on seven corresponding

VOUT_MARGIN_HIGH

VOUT_MARGIN_HIGH mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
The factory value of 0x0001 (0.244mV) will be overridden during initialization to
VOUT_COMMAND
internal feedback divider taps. The desired value of VOUT_MARGIN_HIGH is retained and read back from Operating Memory, regardless of hardware limitations imposed by the feedback divider range.
If the MAX15301 is set for margin-high operation prior to the output being enabled, the output will rise directly to VOUT_MARGIN_HIGH at the rate determined by VOUT_COMMAND/TON_RISE Likewise, if the output is disabled from margin­determined by -VOUT_COMMAND/TOFF_FALL.

VOUT_MARGIN_LOW

MAX15301 PMBus Command Set User’s Guide
.
x 1.05, unless a specific value has been written to the User Store.
.
VOUT_MARGIN_LOW mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
The factory value of 0x0001 (0.244
VOUT_COMMAND x 0.95, unless a specific value has been written to the User Store.
In the MAX15301, there are seven possible output internal feedback divider taps. The desired value of VOUT_MARGIN_LOW is retained and read back from Operating Memory, regardless of hardware limitations imposed by the feedback divider range.
If the MAX15301 is set for margin-low operation prior to the output being enabled, the output will rise directly to VOUT_MARGIN_LOW at the rate determined by VOUT_COMMAND/TON_RISE Likewise, if the output is disabled from margin-low operation, the output will fall at a rate determined by -VOUT_COMMAND/
.
.
TOFF_FALL.
Rev 1 Page 12 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x27
Format:
Linear
Data Bytes:
2
Units:
mV/μs (or V/ms, kV/s)
Transfer:
Read/Write Word
Factory Value:
0x9B33 (0.1V/ms, see Description)
Description/Notes:
See Section 13.8 of the PMBus Specification Part II.
Feedback
VOUT_TRANSITION_RATE, kV/s
Divider
Min
Max
0
≈ 0.005
≈ 1.171
1
≈ 0.005
≈ 1.323
2
≈ 0.006
≈ 1.519
3
≈ 0.007
≈ 1.782
4
≈ 0.008
≈ 2.16
5
≈ 0.011
≈ 2.736
6
≈ 0.015
≈ 3.725
7
≈ 0.023
≈ 5.862
based on actual
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x28
Format:
Linear
Data Bytes:
2
Units:
mΩ (or mV/A)
Transfer:
Read/Write Word
Factory Value:
0x0000 (0mΩ)
Description/Notes:
See Section 13.9 of the PMBus Specification Part II.
It is also important to calibrate READ_IOUT using IOUT_CAL_GAIN and IOUT_CAL_OFFSET to achieve

VOUT_TRANSITION_RATE

To achieve output voltage slew-rate control, the MAX15301 has an 8-bit timer with approximately 243ns resolution. When the timer expires, the 12-bit voltage setpoint is incremented or decremented until the setpoint reaches its final value. This limits the minimum and maximum possible slew-rates for each feedback divider range as follows:
MAX15301 PMBus Command Set User’s Guide
For each divider range, the minimum transition rate is also the resolution (minimum step size).
The desired value of VOUT_TRANSITION_RATE is retained in memory, regardless of hardware limitations imposed by the feedback divider range, but the read-back value is hardware register settings.
If a commanded value of VOUT_TRANSITION_RATE exceeds the maximum possible slew-rate for the feedback divider range, the MAX15301 sets the slew-rate control timer to zero, and the output voltage setpoint is updated to the new setpoint value immediately and without delay. In this case, VOUT_TRANSITION_RATE will read back as 0mV/μs to avoid a divide-by-zero operation.
VOUT_DROOP
The MAX15301 uses low-pass filtered inductor DCR current-sense information (i.e. the READ_IOUT signal) to establish the load-line characteristic according to the VOUT_DROOP value. Because of this low-pass filtering of the load current information, there will be some settling time in the output voltage positioning when VOUT_DROOP is non-zero.
Rev 1 Page 13 of 53
accurate adaptive voltage positioning results with the VOUT_DROOP command.
the VOUT_DROOP command before sending

VOUT_DROOP

Note that VOUT_DROOP can accept negative resistance values, allowing a user to compensation for resistive losses between the output voltage remote sense point and the load, if desired. (Setting VOUT_DROOP to a negative value will case output voltage to rise with increasing load.)
Wait at least 500μs for execution after sending
additional PMBus commands.
MAX15301 PMBus Command Set User’s Guide
Rev 1 Page 14 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x33
Format:
Linear
Data Bytes:
2
Units:
kHz
Transfer:
Read/Write Word
Factory Value:
0x0258 (see Description)
Description/Notes:
See Section 14.4 of the PMBus Specification Part II.
NC pin resistance is measured only once
applied after enabling the output, the PWM will synchronize to the external clock, but
If the external clock crosses the 475kHz boundary while regulating, unexpected results or output
INTERLEAVE
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x37
Format:
4 x 4-bit unsigned integer “nibbles”
Data Bytes:
2
Units:
N/A
Transfer:
Read/Write Word
Factory Value:
0x0000 (see Description)
Description/Notes:
See Section 14.7 of the PMBus Specification Part II.

Switching Frequency and PWM Commands

FREQUENCY_SWITCH

The factory value of 0x0258 (600kHz) will be overridden during initialization by the hardware (pin­strap) value determined by the resistance to ground detected at the SYNC pin, unless a specific value has been written to the User Store. The value of the SY during initialization (power-up).
The MAX15301 can also synchronize to an external clock at the SYNC input. If the external clock is present at or before power-up, the SYNC resistance reading will fail and FREQUENCY_SWITCH will be set to 300kHz.
The MAX15301 has two different PWM “speed modes” to support FREQUENCY_SWITCH values at or below 475kHz, and above 475kHz. It is important to ensure that FREQUENCY_SWITCH is set, either by PMBus command or by successful resistor pin-strap, to a value that is within ±10% of the expected external clock frequency.
MAX15301 PMBus Command Set User’s Guide
If the external clock is present at the time of output enable, the operating memory value of FREQUENCY_SWITCH will be updated to reflect the external clock frequency. If the external clock is
FREQUENCY_SWITCH will not be updated.
voltage transients may result.
The actual switching frequency can be obtained using the READ_FREQUENCY command.
Wait at least 10ms for execution after sending the FREQUENCY_SWITCH command before sending additional PMBus commands.
The INTERLEAVE command determines the phase delay of the MAX15301, measured from the rising edge of an external clock applied at SYNC to the center of the PWM positive pulse.
The factory value of 0x0000 (zero degrees phase shift) will be overridden during initialization by the hardware (pin-strap) value determined by the resistances to ground detected at the ADDR0 and
c
c
Because the MAX15301 has dual-edge modulation, the rising and falling edges of the PWM waveform both “move” relative to the center of the high-side switch on-time.
Rev 1 Page 15 of 53
ADDR1 pins, unless a non-zero value of INTERLEAVE has been written to the User Store. The value of
), the INTERLEAVE command will show unexpected
set a “Group ID Number.” Both nibbles of the high byte of INTERLEAVE can be used
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x5E
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x1135 (see Description)
Description/Notes:
See Section 15.32.1 of the PMBus Specification Part II.
POWER_GOOD_ON mantissa data sent to and from the MAX15301 must be divided by 4096 to
The factory value of 0x1135 (1.080V) will be overridden during initialization to

INTERLEAVE

the ADDR0 and ADDR1 pin resistance is measured only once during initialization (power-up).
Because the MAX15301 uses one of two different PWM “speed modes” depending on the switching frequency selected (see FREQUENCY_SWITCH results if switching frequency crosses the 475kHz speed-mode boundary after initialization.
The MAX15301 includes enhancements beyond the PMBus specification INTERLEAVE command functionality:
Setting the “Number In Group” to zero will be interpreted by the MAX15301 as 16 possible
phases. This allows phase-spreading in 22.5º increments.
The low nibble of the high byte of INTERLEAVE contains the “Group ID Number” per the
PMBus specification, but this is a value that has no function and no dependent parameters in either the MAX15301 device or in the PMBus specification. As a result, it is not necessary to
separately or together as “scratchpad” data, if desired.

Output Voltage Sequencing Commands

MAX15301 PMBus Command Set User’s Guide

POWER_GOOD_ON

determine the actual voltage value, according to the fixed value of VOUT_MODE.
In the MAX15301, there are seven possible output voltage ranges based on seven corresponding internal feedback divider taps. The MAX15301 hardware has 8-bit resolution for the power-good threshold within each of these seven ranges.
The desired value of POWER_GOOD_ON is retained in memory, regardless of limitations imposed by the feedback divider range and the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
VOUT_COMMAND x 0.95, unless a specific value has been written to the User Store.
Rev 1 Page 16 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x5F
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0F99 (see Description)
Description/Notes:
See Section 15.32.2 of the PMBus Specification Part II.
The factory value of 0x0F99 (0.980V) will be overridden during initialization to
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x60
Format:
Linear
Data Bytes:
2
Units:
ms
Transfer:
Read/Write Word
Factory Value:
0xCA80 (see Description)
Description/Notes:
See Section 16.1 of the PMBus Specification Part II.

POWER_GOOD_OFF

POWER_GOOD_OFF mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
In the MAX15301, there are seven possible output voltage ranges based on seven corresponding internal feedback divider taps. The MAX15301 hardware has 8-bit resolution for the power-good threshold within each of these seven ranges.
The desired value of POWER_GOOD_OFF is retained in memory, regardless of limitations imposed by the feedback divider range and the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
VOUT_COMMAND x 0.93, unless a specific value has been written to the User Store.
MAX15301 PMBus Command Set User’s Guide
.

TON_DELAY

The TON_DELAY command sets the delay time between a valid enable condition and the beginning of the output ramp to regulation at VOUT_COMMAND
An 8-bit timer with approximately 570μs resolution allows for delay times from ≈1ms to ≈145ms.
. The nominal factory value is 5ms.
Rev 1 Page 17 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x61
Format:
Linear
Data Bytes:
2
Units:
ms
Transfer:
Read/Write Word
Factory Value:
0xCA80 (see Description)
Description/Notes:
See Section 16.2 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x64
Format:
Linear
Data Bytes:
2
Units:
ms
Transfer:
Read/Write Word
Factory Value:
0xBA00 (see Description)
Description/Notes:
See Section 16.5 of the PMBus Specification Part II.

TON_RISE

MAX15301 PMBus Command Set User’s Guide
The TON_RISE command sets the ramp-up time from 0V to regulation at VOUT_COMMAND. The nominal factory value is 5ms.

TOFF_DELAY

The MAX15301 achieves startup dV
/dt control by incrementing the loop setpoint by one 12-bit
OUT
step every time a certain number of ramp-controller clock cycles have elapsed in an 8-bit counter. This results in a setpoint that increases at a controlled rate, in turn creating a constant dV
OUT
/dt
during startup.
Because the MAX15301 must calculate the ramp control timer setting based upon the value of VOUT_COMMAND, the possible range and resolution of TON_RISE will vary significantly.
The desired value of TON_RISE is retained in memory, regardless of ramp-timer limitations, but the read-back value is based on actual hardware register settings.
The TOFF_DELAY command sets the delay time between loss of enable condition and the beginning of the output ramp-down. The nominal factory value is 1ms.
An 8-bit timer with approximately 570μs resolution allows for delay times from 0ms to ≈145ms.
Rev 1 Page 18 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x65
Format:
Linear
Data Bytes:
2
Units:
ms
Transfer:
Read/Write Word
Factory Value:
0xCA80 (see Description)
Description/Notes:
See Section 16.6 of the PMBus Specification Part II.
ntrol timer setting based upon the value of

TOFF_FALL

MAX15301 PMBus Command Set User’s Guide
The TOFF_FALL command sets the ramp-down time from regulation at VOUT_COMMAND to 0V. The nominal factory value is 5ms.
The MAX15301 achieves shutdown dV step every time a certain number of ramp-controller clock cycles have elapsed in an 8-bit counter. This results in a setpoint that decreases at a controlled rate, in turn creating a constant dV during shutdown.
Because the MAX15301 must calculate the ramp co VOUT_COMMAND, the possible range and resolution of TOFF_FALL will vary significantly.
The desired value of TOFF_FALL is retained in memory, regardless of ramp-timer limitations, but the read-back value is based on actual hardware register settings.
/dt control by decrementing the loop setpoint by one 12-bit
OUT
OUT
/dt
Rev 1 Page 19 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x03
Format:
N/A
Data Bytes:
0
Units:
N/A
Transfer:
Send Byte
Factory Value:
N/A
Description/Notes:
See Section 15.1 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x40
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x0025 (see Description)
Description/Notes:
See Section 15.2 of the PMBus Specification Part II.
will be overridden during initialization to

Fault Related Commands

CLEAR_FAULTS

If the MAX15301 has latched off for a fault condition, sending the CLEAR_FAULTS command will cause a restart.

VOUT_OV_FAULT_LIMIT

MAX15301 PMBus Command Set User’s Guide
VOUT_OV_FAULT_LIMIT mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
In the MAX15301, there are seven possible output voltage ranges based on seven corresponding internal feedback divider taps. The MAX15301 hardware has 8-bit resolution for the overvoltage fault limit within each of these seven ranges.
The desired value of VOUT_OV_FAULT_LIMIT is retained in memory, regardless of limitations imposed by the feedback divider range and the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
The factory value of 0x0025 (9mV)
VOUT_COMMAND x 1.15, unless a specific value has been written to the User Store.
.
Rev 1 Page 20 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x41
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0x80 (Stop regulating and remain off)
Description/Notes:
See Sections 10.5.1 and 15.3 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x44
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0x019A (see Description)
Description/Notes:
See Section 15.6 of the PMBus Specification Part II.
f limitations
The factory value of 0x019A (0.100V) will be overridden during initialization to

VOUT_OV_FAULT_RESPONSE

Note that the MAX15301 does not support finite, non-zero restart-attempt counts. (Continuous restart attempts are supported.)
The VOUT_OV_FAULT_RESPONSE command data comprises three bit-fields:
Bits [7:6] determine the basic fault-response mode. The MAX15301 supports the following modes:
00 Ignore the fault condition. 01 Continue operating and wait for the fault to abate for time specified in bits [2:0]. If the fault does not abate, shutdown and attempt to restart according to bits [5:3]. 10 Stop regulating immediately, delay for the time specified in bits [2:0], then attempt to restart according to bits [5:3]. (Default setting) 11 Stop regulating immediately, and then restart as soon as possible after the fault condition abates.
MAX15301 PMBus Command Set User’s Guide
Bits [5:3] determine the number of retry attempts. The MAX15301 supports only a subset of the full PMBus functionality for this portion of the command:
000-110 No attempt is made to restart after a fault shutdown. (Default setting) 111 Attempt to restart continuously until commanded off, or until another fault condition causes the unit to shut down.
Bits [2:0] determine the fault-tolerance or retry-delay timing. Each binary value in bits [2:0] corresponds to a multiple of 100ms, up to a possible maximum of 111 will cause the MAX15301 to use the minimum possible timing value, typically about 30-40ms. (The default timing for overvoltage faults is 000
VOUT_UV_FAULT_LIMIT
VOUT_UV_FAULT_LIMIT mantissa data sent to and from the MAX15301 must be divided by 4096 to determine the actual voltage value, according to the fixed value of VOUT_MODE
In the MAX15301, there are seven possible output voltage ranges based on seven corresponding internal feedback divider taps. The MAX15301 hardware has 8-bit resolution for the undervoltage fault limit within each of these seven ranges.
The desired value of VOUT_UV_FAULT_LIMIT is retained in memory, regardless o imposed by the feedback divider range and the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
bin
= 700ms. A value of 000
bin
bin
.)
.
Rev 1 Page 21 of 53
VOUT_COMMAND x 0.85, unless a specific value has been written to the User Store.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x45
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0x00 (Ignore undervoltage faults)
Description/Notes:
See Sections 10.5.1 and 15.7 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x46
Format:
Linear
Data Bytes:
2
Units:
A
Transfer:
Read/Write Word
Factory Value:
0xDB20 (25A)
Description/Notes:
See Section 15.8 of the PMBus Specification Part II.

VOUT_UV_FAULT_LIMIT

VOUT_UV_FAULT_RESPONSE

Note that the MAX15301 does not support finite, non-zero restart-attempt counts. (Continuous restart attempts are supported.)
The VOUT_UV_FAULT_RESPONSE command data comprises three bit-fields:
Bits [7:6] determine the basic fault-response mode. The MAX15301 supports the following modes:
00 Ignore the fault condition. (Default setting) 01 Continue operating and wait for the fault to abate for time specified in bits [2:0]. If the fault does not abate, shutdown and attempt to restart according to bits [5:3]. 10 Stop regulating immediately, delay for the time specified in bits [2:0], then attempt to restart according to bits [5:3]. 11 Stop regulating immediately, and then restart as soon as possible after the fault condition abates.
MAX15301 PMBus Command Set User’s Guide
Bits [5:3] determine the number of retry attempts. The MAX15301 supports only a subset of the full PMBus functionality for this portion of the command:
000-110 No attempt is made to restart after a fault shutdown. (Default setting) 111 Attempt to restart continuously until commanded off, or until another fault condition causes the unit to shut down.
Bits [2:0] determine the fault-tolerance or retry-delay timing. Each binary value in bits [2:0] corresponds to a multiple of 100ms, up to a possible maximum of 111 will cause the MAX15301 to use the minimum possible timing value, typically about 30-40ms. (The default timing for undervoltage faults is 000

IOUT_OC_FAULT_LIMIT

The MAX15301 hardware has 8-bit resolution for the overcurrent fault limit within a 30A full-scale load current range.
The desired value of IOUT_OC_FAULT_LIMIT is retained in memory, regardless limitations imposed by the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
bin
= 700ms. A value of 000
bin
bin
.)
Rev 1 Page 22 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x47
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0xBF (Shut down, retry every 700ms)
Description/Notes:
See Sections 10.5.1 and 15.9 of the PMBus Specification Part II.
(sometimes referred to as
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x4F
Format:
Linear
Data Bytes:
2
Units:
°C
Transfer:
Read/Write Word
Factory Value:
0xEB98 (115°C)
Description/Notes:
See Section 15.17 of the PMBus Specification Part II.
The OT_FAULT_LIMIT applies to the external temperature signal, if a valid sensor is detected during
IT applies to the internal

IOUT_OC_FAULT_RESPONSE

For overcurrent faults, the MAX15301 implements the fault responses of PMBus Specification section
10.5.1, rather than the responses of section 10.5.2.
Note that…
MAX15301 does not support finite, non-zero restart-attempt counts. (Continuous restart
attempts are supported.)
MAX15301 also does not support the “delay before shutdown”
“wait for abate”) option for overcurrent faults.
The IOUT_OC_FAULT_RESPONSE command data comprises three bit-fields:
Bits [7:6] determine the basic fault-response mode. The MAX15301 supports the following modes:
MAX15301 PMBus Command Set User’s Guide
00 Ignore the fault condition. 01 Same as setting 10. 10 Stop regulating immediately, delay for the time specified in bits [2:0], then attempt to restart according to bits [5:3]. (Default setting) 11 Same as setting 10.
Bits [5:3] determine the number of retry attempts. The MAX15301 supports only a subset of the full PMBus functionality for this portion of the command:
000-110 No attempt is made to restart after a fault shutdown. 111 Attempt to restart continuously until commanded off, or until another fault condition causes the unit to shut down. (Default setting)
Bits [2:0] determine the retry-delay timing. Each binary value in bits [2:0] corresponds to a multiple of 100ms, up to a possible maximum of 111 use the minimum possible timing value, typically about 30-40ms. (The default timing for overcurrent
faults is 700ms.)
OT_FAULT_LIMIT
= 700ms. A value of 000
bin
will cause the MAX15301 to
bin
The MAX15301 has an internal temperature signal and can also measure temperature at an external location, using a diode junction.
initialization. If no external sensor is detected, the OT_FAULT_LIM
Rev 1 Page 23 of 53
temperature signal instead.
130°C that applies solely to the internal temperature signal to protect the flash memory of the
“fault cleared” threshold for OT_FAULT_LIMIT. For this reason, it is important to always set
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x50
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0xC0 (Shut down, restart when fault
Description/Notes:
See Sections 10.5.1 and 15.18 of the PMBus Specification Part II.

OT_FAULT_LIMIT

In addition to the PMBus-programmable OT_FAULT_LIMIT value, there is also a hard-coded limit of
MAX15301.
Overtemperature fault hysteresis is achieved in the MAX15301 by using the OT_WARN_LIMIT as the
OT_WARN_LIMIT below OT_FAULT_LIMIT.

OT_FAULT_RESPONSE

MAX15301 PMBus Command Set User’s Guide
abates)
Note that the MAX15301 does not support finite, non-zero restart-attempt counts. (Continuous restart attempts are supported.)
The OT_FAULT_RESPONSE command data comprises three bit-fields:
Bits [7:6] determine the basic fault-response mode. The MAX15301 supports the following modes:
00 Ignore the fault condition. 01 Continue operating and wait for the fault to abate for time specified in bits [2:0]. If the fault does not abate, shutdown and attempt to restart according to bits [5:3]. 10 Stop regulating immediately, delay for the time specified in bits [2:0], then attempt to restart according to bits [5:3]. 11 Stop regulating immediately, and then restart as soon as possible after the fault condition abates.
Bits [5:3] determine the number of retry attempts. The MAX15301 supports only a subset of the full PMBus functionality for this portion of the command:
000-110 No attempt is made to restart after a fault shutdown. (Default setting) 111 Attempt to restart continuously until commanded off, or until another fault condition causes the unit to shut down.
Bits [2:0] determine the fault-tolerance or retry-delay timing. Each binary value in bits [2:0] corresponds to a multiple of 100ms, up to a possible maximum of 111 will cause the MAX15301 to use the minimum possible timing value, typically about 30-40ms. (The default timing for overtemperature faults is 000
d
(Default setting)
bin
= 700ms. A value of 000
bin
bin
.)
d
An overtemperature fault (i.e. relevant temperature signal above OT_FAULT_LIMIT) is not considered to have abated until the temperature has fallen below the OT_WARN_LIMIT value.
Rev 1 Page 24 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x51
Format:
Linear
Data Bytes:
2
Units:
°C
Transfer:
Read/Write Word
Factory Value:
0xEAF8 (95°C)
Description/Notes:
See Section 15.19 of the PMBus Specification Part II.
_LIMIT applies to the internal
Overtemperature fault hysteresis is achieved in the MAX15301 by using the OT_WARN_LIMIT as the
reason, it is important to always set
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x55
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0xD380 (14V)
Description/Notes:
See Section 15.23 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x56
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0xC0 (Shut down, restart when fault
Description/Notes:
See Sections 10.5.1 and 15.24 of the PMBus Specification Part II.
fault does not abate, shutdown and attempt to restart according to bits [5:3].

OT_WARN_LIMIT

The MAX15301 has an internal temperature signal and can also measure temperature at an external location, using a diode junction.
The OT_WARN_LIMIT applies to the external temperature signal, if a valid sensor is detected during initialization. If no external sensor is detected, the OT_WARN temperature signal instead.
“fault cleared” threshold for OT_FAULT_LIMIT. For this OT_WARN_LIMIT below OT_FAULT_LIMIT.

VIN_OV_FAULT_LIMIT

MAX15301 PMBus Command Set User’s Guide
The MAX15301 hardware has 8-bit resolution for the input overvoltage fault limit, to a maximum value of ≈14.75V.
The desired value of VIN_OV_FAULT_LIMIT is retained in memory, regardless limitations imposed by the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
VIN_OV_FAULT_RESPONSE
Note that the MAX15301 does not support finite, non-zero restart-attempt counts. (Continuous restart attempts are supported.)
The VIN_OV_FAULT_RESPONSE command data comprises three bit-fields:
Bits [7:6] determine the basic fault-response mode. The MAX15301 supports the following modes:
00 Ignore the fault condition. 01 Continue operating and wait for the fault to abate for time specified in bits [2:0]. If the
abates)
Rev 1 Page 25 of 53
10 Stop regulating immediately, delay for the time specified in bits [2:0], then attempt to

VIN_UV_FAULT_LIMIT

Reference:
Standard Command
Lockable:
Yes
Command Code:
0x59
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read/Write Word
Factory Value:
0xCA1A (4.2V)
Description/Notes:
See Section 15.27 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x5A
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0xC0 (Shut down, restart when fault
Description/Notes:
See Sections 10.5.1 and 15.28 of the PMBus Specification Part II.

VIN_OV_FAULT_RESPONSE

restart according to bits [5:3]. 11 Stop regulating immediately, and then restart as soon as possible after the fault condition abates. (Default setting)
Bits [5:3] determine the number of retry attempts. The MAX15301 supports only a subset of the full PMBus functionality for this portion of the command:
000-110 No attempt is made to restart after a fault shutdown. (Default setting) 111 Attempt to restart continuously until commanded off, or until another fault condition causes the unit to shut down.
Bits [2:0] determine the fault-tolerance or retry-delay timing. Each binary value in bits [2:0] corresponds to a multiple of 100ms, up to a possible maximum of 111 will cause the MAX15301 to use the minimum possible timing value, typically about 30-40ms. (The default timing for input overvoltage faults is 000
MAX15301 PMBus Command Set User’s Guide
bin
= 700ms. A value of 000
bin
.)
bin
The MAX15301 hardware has 8-bit resolution for the input undervoltage fault limit, to a maximum value of ≈14.75V.
The desired value of VIN_UV_FAULT_LIMIT is retained in memory, regardless limitations imposed by the 8-bit fault limit resolution, but the read-back value is based on actual hardware register settings.
VIN_UV_FAULT_RESPONSE
Note that the MAX15301 does not support finite, non-zero restart-attempt counts. (Continuous restart attempts are supported.)
The VIN_UV_FAULT_RESPONSE command data comprises three bit-fields:
Bits [7:6] determine the basic fault-response mode. The MAX15301 supports the following modes:
00 Ignore the fault condition. 01 Continue operating and wait for the fault to abate for time specified in bits [2:0]. If the fault does not abate, shutdown and attempt to restart according to bits [5:3]. 10 Stop regulating immediately, delay for the time specified in bits [2:0], then attempt to
abates)
Rev 1 Page 26 of 53
restart according to bits [5:3].

VIN_UV_FAULT_RESPONSE

11 Stop regulating immediately, and then restart as soon as possible after the fault condition abates. (Default setting)
Bits [5:3] determine the number of retry attempts. The MAX15301 supports only a subset of the full PMBus functionality for this portion of the command:
000-110 No attempt is made to restart after a fault shutdown. (Default setting) 111 Attempt to restart continuously until commanded off, or until another fault condition causes the unit to shut down.
Bits [2:0] determine the fault-tolerance or retry-delay timing. Each binary value in bits [2:0] corresponds to a multiple of 100ms, up to a possible maximum of 111 will cause the MAX15301 to use the minimum possible timing value, typically about 30-40ms. (The default timing for input undervoltage faults is 000
MAX15301 PMBus Command Set User’s Guide
bin
.)
= 700ms. A value of 000
bin
bin
Rev 1 Page 27 of 53
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x78
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
N/A
Description/Notes:
See Section 17.1 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x79
Format:
Bit field
Data Bytes:
2
Units:
N/A
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 17.2 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x7A
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
N/A
Description/Notes:
See Section 17.3 of the PMBus Specification Part II.
Bits #5 and #6 of STATUS_VOUT are not implemented in the MAX15301 because the
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x7B
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
N/A
Description/Notes:
See Section 17.4 of the PMBus Specification Part II.
are not implemented in the MAX15301 because the corresponding fault

Unit Status Commands

STATUS_BYTE

STATUS_WORD

Bit #2 of the STATUS_WORD low byte is not implemented in the MAX15301 because there are no relevant fan-related commands.
MAX15301 PMBus Command Set User’s Guide

STATUS_VOUT

STATUS_IOUT

VOUT_UV_WARNING and VOUT_OV_WARNING commands are not supported.
Bit #1 is not implemented in the MAX15301 because the TOFF_MAX_WARNING is not supported.
Bits #6, #4, #2, #1, and #0 commands are not supported.
Rev 1 Page 28 of 53
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x7C
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
N/A
Description/Notes:
See Section 17.5 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x7D
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
N/A
Description/Notes:
See Section 17.6 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x7E
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
N/A
Description/Notes:
See Section 17.7 of the PMBus Specification Part II.

STATUS_INPUT

Bits #6, #5, #2, #1, and #0 are not implemented in the MAX15301 because the corresponding fault commands are not supported.

STATUS_TEMPERATURE

MAX15301 PMBus Command Set User’s Guide
Bits #5 and #4 are not implemented in the MAX15301 because the corresponding fault commands are not supported.

STATUS_CML

Rev 1 Page 29 of 53
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x88
Format:
Linear
Data Bytes:
2
Units:
V
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.1 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x8B
Format:
Unsigned integer mantissa
Data Bytes:
2
Units:
V
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.4 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x8C
Format:
Linear
Data Bytes:
2
Units:
A
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.5 of the PMBus Specification Part II.

Telemetry Commands

READ_VIN

The MAX15301 has 12-bit measurement resolution for input voltage to a maximum value of about
14.75V.

READ_VOUT

MAX15301 PMBus Command Set User’s Guide

READ_IOUT

The value of VOUT_TRIM is not subtracted from READ_VOUT, so non-zero VOUT_TRIM values will result in a difference between VOUT_COMMAND and READ_VOUT.
The value of VOUT_CAL_OFFSET is subtracted from READ_VOUT, so VOUT_CAL_OFFSET values never result in a difference between VOUT_COMMAND and READ_VOUT.
The MAX15301 has 8-bit measurement resolution for load current over a variable, symmetric bipolar range of inductor DCR voltage. READ_IOUT data is filtered and decimated, so reported load current may display greater than 8-bit resolution.
READ_IOUT must be calibrated by means of IOUT_CAL_GAIN and IOUT_CAL_OFFSET
to achieve
accurate results.
The value of READ_IOUT is temperature compensated for sense-element resistance change according to READ_TEMPERATURE_2
and the resistive temperature coefficient value in the third data byte of
EXT_TEMP_CAL.
Rev 1 Page 30 of 53
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x8D
Format:
Linear
Data Bytes:
2
Units:
°C
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.6 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x8E
Format:
Linear
Data Bytes:
2
Units:
°C
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.6 of the PMBus Specification Part II.
can be used to adjust the diode ideality factor to
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x94
Format:
Linear
Data Bytes:
2
Units:
%
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.9 of the PMBus Specification Part II.

READ_TEMPERATURE_1

The MAX15301 uses READ_TEMPERATURE_1 to report its internal (i.e. die) temperature.

READ_TEMPERATURE_2

The MAX15301 uses READ_TEMPERATURE_2 to report external temperature as measured by an external diode junction, typically placed near the power inductor to facilitate READ_IOUT temperature compensation.
MAX15301 PMBus Command Set User’s Guide
If no external diode junction is detected, READ_TEMPERATURE_2 returns a value of -273°C and is not used for temperature faults or READ_IOUT temperature compensation.
The Maxim-specific command EXT_TEMP_CAL match that of the actual diode junction used for external temperature sensing and to add or remove a fixed temperature offset for calibration purposes.

READ_DUTY_CYCLE

The READ_DUTY_CYCLE command returns an averaged measure of the pulse-width modulator output value in percent. The duty-cycle value is averaged over 256 PWM cycles.
Rev 1 Page 31 of 53
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x95
Format:
Linear
Data Bytes:
2
Units:
kHz
Transfer:
Read Word
Factory Value:
N/A
Description/Notes:
See Section 18.10 of the PMBus Specification Part II.
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xF5
Format:
See Description
Data Bytes:
215
Units:
See Description
Transfer:
Read/Write Block
Factory Value:
See Description
Description/Notes:
This command returns most PMBus command values from the device for ease of recording the device

READ_FREQUENCY

MAX15301 PMBus Command Set User’s Guide
The READ_FREQUENCY command returns the actual switching frequency in kilohertz.
The desired switching frequency is set using the FREQUENCY_SWITCH
PMB_VALUES
configuration. The command data returned is as follows:
<ON_OFF_CONFIG position="0" Type="U8" NumElem="1"/> <WRITE_PROTECT position="1" Type="U8" NumElem="1"/> <VOUT_COMMAND position="2" Type="Float" NumElem="1"/> <VOUT_TRIM position="3" Type="Float" NumElem="1"/> <VOUT_CAL_OFFSET position="4" Type="Float" NumElem="1"/> <VOUT_MAX position="5" Type="Float" NumElem="1"/> <VOUT_MARGIN_HIGH position="6" Type="Float" NumElem="1"/> <VOUT_MARGIN_LOW position="7" Type="Float" NumElem="1"/> <VOUT_TRANSITION_RATE position="8" Type="Float" NumElem="1"/> <VOUT_DROOP position="9" Type="Float" NumElem="1"/> <FREQUENCY_SWITCH position="10" Type="Float" NumElem="1"/> <VIN_ON position="11" Type="Float" NumElem="1"/> <VIN_OFF position="12" Type="Float" NumElem="1"/> <INTERLEAVE position="13" Type="U8" NumElem="2"/> <IOUT_CAL_GAIN position="14" Type="Float" NumElem="1"/> <IOUT_CAL_OFFSET position="15" Type="Float" NumElem="1"/> <VOUT_OV_FAULT_LIMIT position="16" Type="Float" NumElem="1"/> <VOUT_OV_FAULT_RESPONSE position="17" Type="U8" NumElem="1"/> <VOUT_UV_FAULT_LIMIT position="18" Type="Float" NumElem="1"/> <VOUT_UV_FAULT_RESPONSE position="19" Type="U8" NumElem="1"/> <IOUT_OC_FAULT_LIMIT position="20" Type="Float" NumElem="1"/> <IOUT_OC_FAULT_RESPONSE position="21" Type="U8" NumElem="1"/> <OT_FAULT_LIMIT position="22" Type="Float" NumElem="1"/> <OT_FAULT_RESPONSE position="23" Type="U8" NumElem="1"/> <OT_WARN_LIMIT position="24" Type="Float" NumElem="1"/> <VIN_OV_FAULT_LIMIT position="25" Type="Float" NumElem="1"/> <VIN_OV_FAULT_RESPONSE position="26" Type="U8" NumElem="1"/> <VIN_UV_FAULT_LIMIT position="27" Type="Float" NumElem="1"/> <VIN_UV_FAULT_RESPONSE position="28" Type="U8" NumElem="1"/> <POWER_GOOD_ON position="29" Type="Float" NumElem="1"/>
command.
Rev 1 Page 32 of 53
<POWER_GOOD_OFF position="30" Type="Float" NumElem="1"/>

PMB_VALUES

MAX15301 PMBus Command Set User’s Guide
<TON_DELAY position="31" Type="Float" NumElem="1"/> <TON_RISE position="32" Type="Float" NumElem="1"/> <TON_MAX_FAULT_LIMIT position="33" Type="U8" NumElem="2"/> <TON_MAX_FAULT_RESPONSE position="34" Type="U8" NumElem="1"/> <TOFF_DELAY position="35" Type="Float" NumElem="1"/> <TOFF_FALL position="36" Type="Float" NumElem="1"/> <MFR_ID position="37" Type="U8" NumElem="8"/> <MFR_MODEL position="38" Type="U8" NumElem="13"/> <MFR_REVISION position="39" Type="U8" NumElem="7"/> <MFR_LOCATION position="40" Type="U8" NumElem="8"/> <MFR_DATE position="41" Type="U8" NumElem="6"/> <MFR_SERIAL position="42" Type="U8" NumElem="13"/> <ADAPTIVE_MODE position="43" Type="U8" NumElem="2"/> <ADAPTIVE_MODE_FAULT_RESPONSE position="44" Type="U8" NumElem="1"/> <FEEDBACK_EFFORT position="45" Type="Float" NumElem="1"/> <LOOP_CONFIG position="46" Type="U8" NumElem="2"/> <ILOAD_CAL_GAIN position="47" Type="Float" NumElem="1"/> <COMP_MODEL position="48" Type="Float" NumElem="3"/> <STRAP_DISABLE position="49" Type="U8" NumElem="2"/> <MANUF_LOCK position="50" Type="U8" NumElem="2"/> <USER_LOCK position="51" Type="U8" NumElem="2"/> <ZETAP position="52" Type="Float" NumElem="1"/> <EXT_TEMP_CAL position="53" Type="Float" NumElem="2"/>
Rev 1 Page 33 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x38
Format:
Linear
Data Bytes:
2
Units:
mΩ
Transfer:
Read/Write Word
Factory Value:
0xB200 (see Description)
Description/Notes:
See Section 14.8 of the PMBus Specification Part II.
The differential voltage measured between the DCRP and DCRN pins is divided by the value of
is subtracted to provide a load current signal,
The value of IOUT_CAL_GAIN is internally temperature compensated according to
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x39
Format:
Linear
Data Bytes:
2
Units:
A
Transfer:
Read/Write Word
Factory Value:
0x0000 (0A)
Description/Notes:
See Section 14.9 of the PMBus Specification Part II.
The differential voltage measured between the DCRP and DCRN pins is divided by the value of
and the value of IOUT_CAL_OFFSET is subtracted to provide a load current signal,
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xF8
Format:
Linear
Data Bytes:
4
Units:
Scalar, °K
Transfer:
Read/Write Block
Factory Value:
0xBA02 (1.004363), 0x0000 (0°K)
Description/Notes:
The EXT_TEMP_CAL command allows the user to calibrate the READ_TEMPERATURE_2 data and to

Calibration Commands

IOUT_CAL_GAIN

IOUT_CAL_GAIN and the value of IOUT_CAL_OFFSET accessible through the READ_IOUT command.
The factory value of 0xB200 (0.5mΩ) will be overridden during initialization by the hardware (pin­strap) value determined by the resistances to ground detected at the ADDR1 pin, unless a specific value of IOUT_CAL_GAIN has been written to the User Store. The value of the ADDR1 pin resistance is measured only once during initialization (power-up).
READ_TEMPERATURE_2 and EXT_TEMP_CAL.
Wait at least 500μs for execution after sending the IOUT_CAL_GAIN command before sending
additional PMBus commands.
MAX15301 PMBus Command Set User’s Guide

IOUT_CAL_OFFSET

IOUT_CAL_GAIN
accessible through the READ_IOUT command.
Note that the MAX15301 implementation of IOUT_CAL_OFFSET differs from the PMBus specification because the sign of IOUT_CAL_OFFSET is inverted (i.e., IOUT_CAL_OFFSET is subtracted rather than added.)
EXT_TEMP_CAL (MAX15301AA01)
adjust for different temperature-sense diode junction ideality factors.
Rev 1 Page 34 of 53
Byte # Data Byte
Ideality Factor
Combined diode ideality factor and external temperature
1
Offset correction
°K
External temperature measurement offset correction
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xF8
Format:
Linear
Data Bytes:
4
Units:
Scalar, °K
Transfer:
Read/Write Block
Factory Value:
1.00391, -8°K
Description/Notes:
The EXT_TEMP_CAL command allows calibration of the external temperature sense signal. The two
Data Byte
Data Byte
Combined temperature gain correction and diode ideality
1
b
°K
Temperature offset correction

EXT_TEMP_CAL (MAX15301AA01)

MAX15301 PMBus Command Set User’s Guide
Name Units Description
0
and Gain Correction
The corrections are applied internal to the MAX15301 as follows:
READ_TEMPERATURE_2 = (Measured external temperature) / EXT_TEMP_CAL[0] + EXT_TEMP_CAL[1] - 273.15°K

EXT_TEMP_CAL (MAX15301AA02)

arguments of the EXT_TEMP_CAL signal are as follows:
Number
0 m None
None
gain correction scalar
Name Units Description
factor
Temperature Calibration
The default gain term is nominally set for use with a Fairchild MMBT3904 transistor diode junction. To correct the gain term for a different temperature sense transistor, do the following:
1. Read the existing value of EXT_TEMP_CAL from the device
2. Multiply the existing value of the gain correction term by the new transistor ideality factor
3. Divide the result by 1.0046
Send the final result back to the device
Rev 1 Page 35 of 53
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x19
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
0xA0
Description/Notes:
See Section 11.12 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0x98
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
0x42 (see Description)
Description/Notes:
See Section 22.1 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x99
Format:
ASCII string
Data Bytes:
8
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
Null string
Description/Notes:
See Section 22.2.1 of the PMBus Specification Part II.

Device Identification Commands

CAPABILITY

PMBUS_REVISION

Note that the Maxim interpretation of the specification is to omit bit #4, placing the Part I Revision level in bits [7:5] and the Part II Revision level in bits [3:0].
MAX15301 PMBus Command Set User’s Guide
Bits [7:5] describe the PMBus specification Part I revision level as follows:
000 Revision 1.0 001 Revision 1.1 010 Revision 1.2
Bit [4] is unused and is set to zero.
Bits [3:0] describe the PMBus specification Part II revision level as follows:
0000 Revision 1.0 0001 Revision 1.1 0010 Revision 1.2

MFR_ID

Note that the MAX15301 implements MFR_ID as a fixed-width string, not as part of a shared memory space.
Rev 1 Page 36 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x9A
Format:
ASCII string
Data Bytes:
13
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
Null string
Description/Notes:
See Section 22.2.2 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x9B
Format:
ASCII string
Data Bytes:
7
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
Null string
Description/Notes:
See Section 22.2.3 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x9C
Format:
ASCII string
Data Bytes:
8
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
Null string
Description/Notes:
See Section 22.2.4 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x9D
Format:
ASCII string
Data Bytes:
6
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
Null string
Description/Notes:
See Section 22.2.5 of the PMBus Specification Part II.

MFR_MODEL

MFR_REVISION

MAX15301 PMBus Command Set User’s Guide
Note that the MAX15301 implements MFR_MODEL as a fixed-width string, not as part of a shared memory space.

MFR_LOCATION

MFR_DATE

Note that the MAX15301 implements MFR_REVISION as a fixed-width string, not as part of a shared memory space.
Note that the MAX15301 implements MFR_LOCATION as a fixed-width string, not as part of a shared memory space.
Note that the MAX15301 implements MFR_DATE as a fixed-width string, not as part of a shared memory space.
The recommended format is YYMMDD where Y, M, and D are integer values from 0 to 9, inclusive.
Rev 1 Page 37 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x9E
Format:
ASCII string
Data Bytes:
13
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
Null string
Description/Notes:
See Section 22.2.6 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0xAD
Format:
ASCII string
Data Bytes:
8
Units:
N/A
Transfer:
Read Block
Factory Value:
MAX15301
Description/Notes:
See Section 22.2.7 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0xAD
Format:
ASCII string
Data Bytes:
12
Units:
N/A
Transfer:
Read Block
Factory Value:
MAX15301AA02
Description/Notes:
See Section 22.2.7 of the PMBus Specification Part II.
Reference:
Standard Command
Lockable:
N/A
Command Code:
0xAE
Format:
ASCII string
Data Bytes:
8
Units:
N/A
Transfer:
Read Block
Factory Value:
Firmware revision (see Description)
Description/Notes:
See Section 22.2.8 of the PMBus Specification Part II.
The Maxim PowerTool GUI uses this information to identify the supported command set for a

MFR_SERIAL

Note that the MAX15301 implements MFR_SERIAL as a fixed-width string, not as part of a shared memory space.

IC_DEVICE_ID (MAX15301AA01)

Note that the MAX15301 implements IC_DEVICE_ID as a fixed-width string, not as part of a shared memory space.
MAX15301 PMBus Command Set User’s Guide

IC_DEVICE_ID (MAX15301AA02)

Note that the MAX15301 implements IC_DEVICE_ID as a fixed-width string, not as part of a shared memory space.

IC_DEVICE_REV

Note that the MAX15301 implements IC_DEVICE_REV as a fixed-width string, not as part of a shared memory space.
The default value is the firmware revision number stored as an ASCII string, typically a 4-digit number.
particular slave device.
Rev 1 Page 38 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x10
Format:
Bit field
Data Bytes:
1
Units:
N/A
Transfer:
Read/Write Byte
Factory Value:
0x00
Description/Notes:
See Section 11.1 of the PMBus Specification Part II.
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE0
Format:
Bit field
Data Bytes:
32
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
0
Description/Notes:
To allow password-based write-protection on a per-command basis, the MANUF_CONF command has 32 data bytes, with one bit per possible PMBus command; the byte order is low to high. Each bit position within the 32 bytes correlates to a PMBus command number from 0x00 to 0xFF. For
at least 350ms for execution after sending the MANUF_CONF command before sending

Security Commands

WRITE_PROTECT

MANUF_CONF

MAX15301 PMBus Command Set User’s Guide
example:
Byte 0, bit 0: PAGE command Byte 0, bit 1: OPERATION command Byte 0, bit 2: ON_OFF_CONFIG command … Byte 6, bit 3: FREQUENCY_SWITCH command etc…
If the bit for a particular command is set in MANUF_CONF, and the read-only SECURITY_LEVEL command is not set to level 2 by successfully sending a value of MANUF_PASSWD that matches the working memory value of MANUF_LOCK, then the MAX15301 will ignore attempts to write data to that command.
Note that setting a bit for a read-only PMBus command or send-byte PMBus command has no effect, regardless of SECURITY_LEVEL. Likewise, read operations for any PMBus command are never blocked on the basis of MANUF_CONF and SECURITY_LEVEL.
The 32 data bytes for MANUF_CONF are saved in flash memory as a unique, single instance (i.e. not as part of the USER, DEFAULT, or MAXIM PMBus command stores.) The data is written to flash every time the MANUF_CONF command data is written to the MAX15301.
Wait additional PMBus commands.
Rev 1 Page 39 of 53
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE1
Format:
Direct
Data Bytes:
2
Units:
N/A
Transfer:
Write Word
Factory Value:
0x0000
Description/Notes:
The MANUF_LOCK command contains the password value for the “manufacturer” PMBus command
value is set to 2, and any PMBus commands flagged in
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE2
Format:
Direct
Data Bytes:
2
Units:
N/A
Transfer:
Read/Write Word
Factory Value:
N/A
Description/Notes:
The MANUF_PASSWD command is the “key” or password-attempt command used to unlock the
matches the
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE3
Format:
Bit field
Data Bytes:
32
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
0
Description/Notes:
To allow password-based write-protection on a per-command basis, the USER_CONF command has 32 data bytes, with one bit per possible PMBus command; the byte order is low to high. Each bit position within the 32 bytes correlates to a PMBus command number from 0x00 to 0xFF. For

MANUF_LOCK

MANUF_PASSWD

MAX15301 PMBus Command Set User’s Guide
security level. If the working-memory value of MANUF_PASSWD matches the working-memory value of MANUF_LOCK, the SECURITY_LEVEL
MANUF_CONF or USER_CONF are unlocked for write operations.
Note that SECURITY_LEVEL must be set to 2 before a new value can be written to MANUF_LOCK.
The value of MANUF_LOCK can be stored in both the USER and DEFAULT nonvolatile PMBus memory with separate and distinct values – this should be taken into account when setting up command security.
“manufacturer” security level. If the working-memory value of MANUF_PASSWD working-memory value of MANUF_LOCK, the SECURITY_LEVEL value is set to 2, and any PMBus commands flagged in MANUF_CONF or USER_CONF are unlocked for write operations.
The value of MANUF_PASSWD is only retained in working memory and cannot be stored.
USER_CONF
example:
Byte 0, bit 0: PAGE command Byte 0, bit 1: OPERATION command Byte 0, bit 2: ON_OFF_CONFIG command … Byte 6, bit 3: FREQUENCY_SWITCH command etc…
If the bit for a particular command is set in USER_CONF, and the read-only SECURITY_LEVEL is not set to level 1 by successfully sending a value of USER_PASSWD that matches the working
Rev 1 Page 40 of 53
command
memory value of USER_LOCK, then the MAX15301 will ignore attempts to write data to that
The 32 data bytes for USER_CONF are saved in flash memory as a unique, single instance (i.e. not as
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE4
Format:
Direct
Data Bytes:
2
Units:
N/A
Transfer:
Read Word
Factory Value:
0x0000
Description/Notes:
The USER_LOCK command contains the password value for the “user” PMBus command security
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE5
Format:
Direct
Data Bytes:
2
Units:
N/A
Transfer:
Read/Write Word
Factory Value:
N/A
Description/Notes:
The USER_PASSWD command is the “key” or password-attempt command used to unlock the “user”

USER_CONF

USER_LOCK

MAX15301 PMBus Command Set User’s Guide
command.
Note that setting a bit for a read-only PMBus command or send-byte PMBus command has no effect, regardless of SECURITY_LEVEL. Likewise, read operations for any PMBus command are never blocked on the basis of USER_CONF and SECURITY_LEVEL.
part of the USER, DEFAULT, or MAXIM PMBus command stores.) The data is written to flash every time the USER_CONF command data is written to the MAX15301.
Wait at least 350ms for execution after sending the USER_CONF command before sending additional PMBus commands.
level. If the working-memory value of USER_PASSWD matches the working-memory value of USER_LOCK, the SECURITY_LEVEL value is set to 1, and any PMBus commands flagged in USER_CONF are unlocked for write operations.
Note that SECURITY_LEVEL must be set to 1 before a new value can be written to USER_LOCK.
The value of USER_LOCK can be stored in both the USER and DEFAULT nonvolatile PMBus memory with separate and distinct values – this should be taken into account when setting up command security.

USER_PASSWD

security level. If the working-memory value of USER_PASSWD matches the working-memory value of
USER_LOCK, the SECURITY_LEVEL value is set to 1, and any PMBus commands flagged in USER_CONF
are unlocked for write operations.
The value of USER_PASSWD is only retained in working memory and cannot be stored.
Rev 1 Page 41 of 53
Reference:
Maxim Specific
Lockable:
N/A
Command Code:
0xE6
Format:
Direct
Data Bytes:
1
Units:
N/A
Transfer:
Read Byte
Factory Value:
0x00
Description/Notes:
The MAX15301 provides two levels of password protection for all writeable PMBus commands, on a

SECURITY_LEVEL

MAX15301 PMBus Command Set User’s Guide
per-command basis. The SECURITY_LEVEL command value shows the present security level as follows:
SECURITY_LEVEL Description 0x00 No write access to commands locked by USER_CONF or MANUF_CONF 0x01 Write access granted to commands locked by USER_CONF 0x02 Write access granted to commands locked by MANUF_CONF and USER_CONF
Note that SECURITY_LEVEL is 0 until a value is written to USER_PASSWD or MANUF_PASSWD that matches the working-memory value of USER_LOCK or MANUF_LOCK respectively.
When the working-memory value of USER_LOCK is written to USER_PASSWD, SECURITY_LEVEL is set to 1.
When the working-memory value of MANUF_LOCK is written to MANUF_PASSWD, SECURITY_LEVEL is set to 2.
Writing a “mismatched” (or wrong) value of USER_PASSWD or MANUF_PASSWD causes SECURITY_LEVEL to reset to 0.
The values of USER_LOCK and USER_CONF can only be changed when SECURITY_LEVEL is 1 or 2.
The values of MANUF_LOCK and MANUF_CONF can only be changed when SECURITY_LEVEL is 2.
Rev 1 Page 42 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x11
Format:
N/A
Data Bytes:
0
Units:
N/A
Transfer:
Send Byte
Factory Value:
N/A
Description/Notes:
See Section 11.2 of the PMBus Specification Part II.
In general, when the STORE_DEFAULT_ALL command is sent, the existing contents of the DEFAULT

Memory and Storage Commands

STORE_DEFAULT_ALL
The MAX15301 includes three banks of nonvolatile (flash memory) storage for most “writeable” PMBus command values, referred to as the USER, DEFAULT, and MAXIM stores. These stores are fully independent, but identical in structure.
The DEFAULT store is intended to function as a backup of an original equipment manufacturer (OEM) preferred device configuration. OEMs should save identical configurations to the USER store and the DEFAULT store, such that the USER store can be refreshed from the DEFAULT store if needed.
The contents of the DEFAULT store are never loaded into working memory unless the
RESTORE_DEFAULT_ALL
store are erased, and the contents of the working PMBus memory (volatile RAM) are written into the DEFAULT store. There are exceptions to this behavior, as follows:
MAX15301 PMBus Command Set User’s Guide
command is sent.
OPERATION The OPERATION command is not stored to prevent unintentional
enabling/disabling of the output.
TEST_MODE TEST_MODE is not stored to prevent unintentional operation in special
test modes.
COMP_MODEL The working memory COMP_MODEL data is only stored if the
command has been edited (as recorded by STRAP_DISABLE).
MANUF_CONF The manufacturer flags for password command locking are stored
independently in nonvolatile memory for security.
MANUF_PASSWD The manufacturer security password is always volatile for obvious
reasons.
USER_CONF The user flags for password command locking are stored
independently in nonvolatile memory for security.
USER_PASSWD The user security password is always volatile for obvious reasons.
DEADTIME_GCTRL This command is used to initiate a partial internal edit of the
nonvolatile “Config Page” special-purpose memory bank.
START_MEASUREMENT The Parameter Analyzer setup data is only stored in volatile memory.
CONFIG_PAGE This command is used to edit the nonvolatile “Config Page” special-
purpose memory bank.
CONFIG_STORE_NLSS This command is used to initiate a partial internal edit of the
nonvolatile “Config Page” special-purpose memory bank.
Rev 1 Page 43 of 53
INFO_PAGE This command is used to access the nonvolatile die trim information.
NLSS_ADDR This command is stored in volatile memory only.
NLSS_DATA This command is stored in volatile memory only.

RESTORE_DEFAULT_ALL

Reference:
Standard Command
Lockable:
Yes
Command Code:
0x12
Format:
N/A
Data Bytes:
0
Units:
N/A
Transfer:
Send Byte
Factory Value:
N/A
Description/Notes:
See Section 11.3 of the PMBus Specification Part II.
loaded into working memory when the
default to prevent unintended operational consequences following a RESTORE_DEFAULT_ALL
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x15
Format:
N/A
Data Bytes:
0
Units:
N/A
Transfer:
Send Byte
Factory Value:
N/A
Description/Notes:
See Section 11.6 of the PMBus Specification Part II.
identical configurations to the USER store and the
the MAX15301 device. The USER store can also be loaded to working memory at any time by sending

STORE_DEFAULT_ALL

Wait at least 450ms for execution after sending the STORE_DEFAULT_ALL command before sending additional PMBus commands.
The MAX15301 includes three banks of nonvolatile (flash memory) storage for most “writeable” PMBus command values, referred to as the USER, DEFAULT, and MAXIM stores. These stores are fully independent, but identical in structure.
The DEFAULT store is intended to function as a backup of an original equipment manufacturer (OEM) preferred device configuration.
MAX15301 PMBus Command Set User’s Guide
The contents of the DEFAULT store are only RESTORE_DEFAULT_ALL command is sent; there are no other conditions or actions that result in loading of the DEFAULT store to working memory.
Be aware that several commands in the DEFAULT store are set to zero (or other safe values) by
command.
Wait at least 10ms for execution after sending the RESTORE_DEFAULT_ALL command before sending additional PMBus commands.
Please see STORE_DEFAULT_ALL
STORE_USER_ALL
The MAX15301 includes three banks of nonvolatile (flash memory) storage for most “writeable” PMBus command values, referred to as the USER, DEFAULT, and MAXIM stores. These stores are fully independent, but identical in structure.
for exceptions to PMBus nonvolatile command storage.
The USER store functions as the primary nonvolatile storage of all PMBus command values. Original equipment manufacturers (OEMs) should save DEFAULT store, such that the USER store can be refreshed from the DEFAULT store if needed.
The contents of the USER store are loaded into working memory every time input power is applied to
Rev 1 Page 44 of 53
the RESTORE_USER_ALL command.

STORE_USER_ALL

MAX15301 PMBus Command Set User’s Guide
In general, when the STORE_USER_ALL command is sent, the existing contents of the USER store are erased, and the contents of the working PMBus memory (volatile RAM) are written into the USER store. There are exceptions to this behavior, as follows:
OPERATION
TEST_MODE TEST_MODE is not stored to prevent unintentional operation in special
COMP_MODEL The working memory COMP_MODEL data is only stored if the
MANUF_CONF The manufacturer flags for password command locking are stored
MANUF_PASSWD The manufacturer security password is always volatile for obvious
USER_CONF The user flags for password command locking are stored
USER_PASSWD The user security password is always volatile for obvious reasons.
DEADTIME_GCTRL This command is used to initiate a partial internal edit of the
START_MEASUREMENT The Parameter Analyzer setup data is only stored in volatile memory.
CONFIG_PAGE This command is used to edit the nonvolatile “Config Page” special-
CONFIG_STORE_NLSS This command is used to initiate a partial internal edit of the
The OPERATION command is not stored to prevent unintentional
enabling/disabling of the output.
test modes.
command has been edited (as recorded by STRAP_DISABLE).
independently in nonvolatile memory for security.
reasons.
independently in nonvolatile memory for security.
nonvolatile “Config Page” special-purpose memory bank.
purpose memory bank.
nonvolatile “Config Page” special-purpose memory bank.
INFO_PAGE This command is used to access the nonvolatile die trim information.
NLSS_ADDR This command is stored in volatile memory only.
NLSS_DATA This command is stored in volatile memory only.
Wait at least 450ms for execution after sending the STORE_USER_ALL command before sending additional PMBus commands.
Rev 1 Page 45 of 53
Reference:
Standard Command
Lockable:
Yes
Command Code:
0x16
Format:
N/A
Data Bytes:
0
Units:
N/A
Transfer:
Send Byte
Factory Value:
N/A
Description/Notes:
See Section 11.7 of the PMBus Specification Part II.
identical configurations to the USER store and the
the MAX15301 device. The USER store can also be loaded to working memory at any time by sending
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xEA
Format:
N/A
Data Bytes:
0
Units:
N/A
Transfer:
Send Byte
Factory Value:
N/A
Description/Notes:
The MAX15301 includes three banks of nonvolatile (flash memory) storage for most “writeable”
The contents of the MAXIM store are only loaded into working memory when the

RESTORE_USER_ALL

The MAX15301 includes three banks of nonvolatile (flash memory) storage for most “writeable” PMBus command values, referred to as the USER, DEFAULT, and MAXIM stores. These stores are fully independent, but identical in structure.
The USER store functions as the primary nonvolatile storage of all PMBus command values. Original equipment manufacturers (OEMs) should save DEFAULT store, such that the USER store can be refreshed from the DEFAULT store if needed.
The contents of the USER store are loaded into working memory every time input power is applied to
the RESTORE_USER_ALL command.
Be aware that several commands in the USER store are set to zero (or other safe values) by default to prevent unintended operational consequences following a RESTORE_DEFAULT_ALL command.
MAX15301 PMBus Command Set User’s Guide
Wait at least 10ms for execution after sending the RESTORE_USER_ALL command before sending additional PMBus commands.
Please see STORE_USER_ALL
for exceptions to PMBus nonvolatile command storage.

RESTORE_MAXIM_ALL

PMBus command values, referred to as the USER, DEFAULT, and MAXIM stores. These stores are fully independent, but identical in structure.
The MAXIM store functions as a backup of the firmware default configuration, and it cannot be edited.
RESTORE_MAXIM_ALL command is sent; there are no other conditions or actions that result in loading of the MAXIM store to working memory.
Be aware that several commands in the MAXIM store are set to zero (or other safe values) by default to prevent unintended operational consequences following a RESTORE_MAXIM_ALL command.
Wait at least 10ms for execution after sending the RESTORE_MAXIM_ALL command before sending additional PMBus commands.
Rev 1 Page 46 of 53
MAX15301 PMBus Command Set User’s Guide
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xDC
Format:
Bit field
Data Bytes:
2
Units:
N/A
Transfer:
Read/Write Word
Factory Value:
0x0000
Description/Notes:
Several commands in the MAX15301 can be set directly by resistor value connected to a device pin,
flag in
Bit
Command
Comments
Command set indirectly by the SMBus slave address, from
The FLC data is set automatically by the parametric extraction
13
VOUT_MAX
Command set indirectly according to VOUT_COMMAND x 110%
12
IOUT_CAL_GAIN
Command set by R
ADDR1
resistor value
11
FREQUENCY_SWITCH
Command set by R
SYNC
resistor value
10
<RESERVED>
9 IOUT_OC_FAULT_LIMIT
Command not set automatically; flag is for future sue
8
VOUT_MARGIN_LOW
Command set indirectly according to VOUT_COMMAND x 95%
7
VOUT_MARGIN_HIGH
Command set indirectly according to VOUT_COMMAND x 105%
6
POWER_GOOD_OFF
Command set indirectly according to VOUT_COMMAND x 85%
5
POWER_GOOD_ON
Command set indirectly according to VOUT_COMMAND x 90%
4
VOUT_UV_WARN_LIMIT
Undervoltage warning is not implemented
3
VOUT_UV_FAULT_LIMIT
Command set indirectly according to VOUT_COMMAND x 85%
2
VOUT_OV_WARN_LIMIT
Overvoltage warning is not implemented
1
VOUT_OV_FAULT_LIMIT
Command set indirectly according to VOUT_COMMAND x 115%
0
VOUT_COMMAND
Command set by R
SET
resistor value

STRAP_DISABLE

or are set indirectly according to the value of other pin-configurable commands. Of these “pin­configurable” commands, the STRAP_DISABLE command keeps track of those that have been directly altered by a user through the SMBus serial interface.
When one of the commands in the table below is edited, the corresponding bit­STRAP_DISABLE is set, and this flag prevents the device from automatically setting the value of that command in the future, preserving the user-set value instead.
Note that the STRAP_DISABLE command can be saved in the USER and DEFAULT nonvolatile stores. In order to disable pin-configuration of a command, the flag for that command must be 1, and a
STORE_USER_ALL
the flag set in the working-memory version of STRAP_DISABLE. (This process is handled automatically without need for special user interaction in most situations.)
To restore pin-configuration capability for a command, clear the corresponding bit in STRAP_DISABLE and send the STORE_USER_ALL command.
operation must have been performed, to ensure that the device powers up with
15 INTERLEAVE
14 COMP_MODEL
R
ADDR0
and R
resistor values. (Note that this STRAP_DISABLE
ADDR1
bit is not actually used in the INTERLEAVE pin-strapping decision; any non-zero value of INTERLEAVE cancels the determination of phase relationship based on the PMBus address.)
process
Rev 1 Page 47 of 53
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xD0
Format:
Bit field
Data Bytes:
2
Units:
N/A
Transfer:
Read/Write Word
Factory Value:
0x024B
Description/Notes:
The ADAPTIVE_MODE command configures the automatic tuning features of the MAX15301. Each bit
Bit
Name
Effect When True
15
<RESERVED>
14
<RESERVED>
13
<RESERVED>
12
FIRST_ENABLE_ONLY
Perform parametric extraction on first enable only
11
<RESERVED>
10
<RESERVED>
Perform parametric extraction after the startup ramp (set by
8
ADAPT_CONTINUOUS
Perform parametric extraction periodically while regulating
7
<RESERVED>
Update working memory LC double-pole frequency (FLC) after
Update working memory output capacitor ESR zero frequency (FZ)
Update working memory LC damping factor (ZLC) after parametric
Reset gain registers based on USER store values when output is
Execute STORE_USER_ALL after adaptive measurement (note that Calculate new NLSS “fast gain” register values based on
The control loop will switch to using the NLSS “fast gains”

Control Loop Commands

ADAPTIVE_MODE

in the two data bytes enables a particular function as follows:
MAX15301 PMBus Command Set User’s Guide
9 ADAPT_POST_RAMP
6 UPDATE_FLC
5 UPDATE_FZ
4 UPDATE_ZLC
3 RESET_GAINS
2 WRITEFLASH
default)
parametric extraction (set by default)
after parametric extraction
extraction
disabled (set by default)
this bit is cleared from the working memory copy of ADAPTIVE_MODE after execution)
1 GAIN_CALC
0 FAST_GAINS
COMP_MODEL parameters (set by default)
registers after ramp-up is complete (set by default)
Wait at least 500μs for execution after sending the ADAPTIVE_MODE command before sending additional PMBus commands.
Rev 1 Page 48 of 53
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xD3
Format:
Linear
Data Bytes:
2
Units:
Scalar
Transfer:
Read Byte
Factory Value:
0xB200 (0.5)
Description/Notes:
This command allows some user adjustment of the tradeoff between transient response, load regulation, and output noise. The default value is 0.5, which provides a good balance of transient
Higher values of FEEDBACK_EFFORT (up to 1.0) will provide improved transient response and load
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xD5
Format:
Bit field
Data Bytes:
2
Units:
N/A
Transfer:
Read/Write Word
Factory Value:
0x0100
Description/Notes:
The LOOP_CONFIG command configures miscellaneous control-loop features of the MAX15301. Each
Bit
Name
Effect When True
15
<RESERVED>
14
<RESERVED>
13
<RESERVED>
12
<RESERVED>
11
<RESERVED>
10
<RESERVED>
9 NOGAINCALC
The control loop will only use hard-coded NLSS gain values
8
PIDMODE
Enable integral term in the control loop (set by default)
7
<RESERVED>
6
GCTRLTABLEEN
Enable load-variable gate drive voltage lookup table
5
<RESERVED>
4
AGDEN
Enable adaptive gate-drive timing system (not supported)
3
NEGDUTYEN
Enable low-side body diode “braking” on load-release transient
2
<RESERVED>
1 <RESERVED>
0 <RESERVED>

FEEDBACK_EFFORT

response performance and output noise characteristics.
Lower values of FEEDBACK_EFFORT (as low as 0.0) will tend to provide lower output noise, at the expense of transient performance and slightly reduced load regulation accuracy.
regulation, at the expense of increased output noise and PWM waveform rising/falling edge “jitter.”
As a generalization, increasing FEEDBACK_EFFORT tends to increase effective control loop bandwidth, while decreasing FEDBACK_EFFORT reduces bandwidth.
Wait at least 500μs for execution after sending the FEEDBACK_EFFORT command before sending additional PMBus commands.
MAX15301 PMBus Command Set User’s Guide

LOOP_CONFIG

bit in the two data bytes enables a particular function as follows:
Wait at least 500μs for execution after sending the LOOP_CONFIG command before sending additional PMBus commands.
Rev 1 Page 49 of 53
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xDB
Format:
Linear
Data Bytes:
6 (see Description)
Units:
Scalar
Transfer:
Read/Write Block
Factory Value:
0.03167, 0.5, 0.5
Description/Notes:
The COMP_MODEL command provides access to key control loop tuning parameters. The three
Data Byte
Data Byte
Power stage LC double-pole frequency, as a fraction of the
parameter is determined by parametric extraction.
Output capacitor ESR zero frequency, as a fraction of the PWM
Power stage damping factor. Higher values indicate a more
y will reset to the USER store values whenever the output is disabled, unless bit 3 of
operation, unless the values have previously been set by a PMBus write to
This safety feature prevents inadvertent
DEADTIME_GCTRL
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE7
Format:
See Description
Data Bytes:
19
Units:
N/A
Transfer:
Read/Write Block
Factory Value:
See Description
Description/Notes:
The DEADTIME_GCTRL command allows configuration of the Adaptive Gate-Drive timing system (AGD),
Byte
Data
Default
0
fixedDTR (LSB)
Signed
1
fixedDTR (MSB)
2
fixedDTF (LSB)
Signed
3
fixedDTF (MSB)
4
TDR (LSB)
Signed
5
TDR (MSB)

COMP_MODEL

MAX15301 PMBus Command Set User’s Guide
arguments are as follows:
Number
0 FLC/FSW None
1 FZ/FSW None
2 ZLC None
Name Units Description
PWM fundamental frequency. In typical operation, this
fundamental frequency.
damped LC filter; lower values represent a less damped filter.
The values of COMP_MODEL can be altered by the parametric extraction function of the MAX15301. The
ADAPTIVE_MODE is cleared.
Note that the values in COMP_MODEL are not saved during a STORE_USER_ALL or
STORE_DEFAULT_ALL
COMP_MODEL, as indicated by bit 14 of STRAP_DISABLE. storage of parametric extraction results that could adversely affect the initial ramp control loop tuning.
Wait at least 500μs for execution after sending the COMP_MODEL command before sending additional
PMBus commands.
adjustment of static gate-drive timing, and adjustment of the variable gate-drive voltage system. The arguments for this command are as follows:
# Data Name
Type Description
Integer
Integer
Integer
Static rising-edge deadtime adjustment 20
Static falling-edge deadtime adjustment 20
AGD system rising edge deadtime target value 3
Rev 1 Page 50 of 53
Value
6
TDF (LSB)
Signed
7
TDF (MSB)
Unsigned
Byte
AGD system body-diode conduction comparator threshold DAC setting
Unsigned
Byte
Variable gate drive voltage DAC lookup table value, bin 0
Unsigned
Variable gate drive voltage DAC lookup table
Unsigned
Variable gate drive voltage DAC lookup table
Unsigned
Variable gate drive voltage DAC lookup table
Unsigned
Variable gate drive voltage DAC lookup table
Unsigned
Variable gate drive voltage DAC lookup table
Unsigned
Variable gate drive voltage DAC lookup table
Unsigned
Variable gate drive voltage DAC lookup table
17
GCTRLDAC (LSB)
18
GCTRLDAC (MSB)
timing when the AGD system is disabled, whereas the TDR and TDF values provide
The deadtime adjustment values are given in “vernier tick” units, such that each step results in a
LXDAC Setting
Comparator Threshold (mV)
1
-150
3
-300
7
-450
15
-600
31
-750
61
-900
127
-1000
DEADTIME_GCTRL
MAX15301 PMBus Command Set User’s Guide
Integer
8 LXDAC
9 GCTRL[0]
10 GCTRL[1]
11 GCTRL[2]
12 GCTRL[3]
13 GCTRL[4]
14 GCTRL[5]
15 GCTRL[6]
16 GCTRL[7]
Nonoverlap/Deadtime Adjustment
There are two sets of deadtime adjustment values: the fixedDTR and fixedDTF terms adjust the nonoverlap corresponding target values that are used when the AGD system is enabled.
Byte
Byte
Byte
Byte
Byte
Byte
Byte
Unsigned
Integer
AGD system falling edge deadtime target value 8
15
value, bin 1
value, bin 2
value, bin 3
value, bin 4
value, bin 5
value, bin 6
value, bin 7
Constant gate drive voltage DAC value 0
10
12
15
0
0
5
5
8
Note that the AGD system is disabled by default (bit 4 of the LOOP_CONFIG command) and operation of the AGD system is not recommended or supported by Maxim.
deadtime adjustment as follows:
Caution must be exercised when trimming the gate-drive nonoverlap timing; it is possible to set negative values and cause the high-side driver to enable before the low-side driver has disabled, and vice-versa.
Body-Diode Conduction Comparator
The LXDAC term is used to adjust the low-side MOSFET body-diode conduction detection comparator reference threshold as follows:
FREQUENCY_SWITCH ≤ 475kHz: 1 vernier tick = 1 / (FREQUENCY_SWITCH * 2048) FREQUENCY_SWITCH > 475kHz: 1 vernier tick = 1 / (FREQUENCY_SWITCH * 1024)
Rev 1 Page 51 of 53
255
-1200
GCTRLDAC
Setting
Typical
Gate Drive (V)
0
5.2
1
5.4 2 5.7 3 5.9
4
6.1 5 6.4 6 6.6 7 6.8 8 7.1 9 7.3
10
7.5
11
7.8
12
8
13
8.2
14
8.5
15
8.7
Reference:
Maxim Specific
Lockable:
Yes
Command Code:
0xE8
Format:
Linear
Data Bytes:
2
Units:
Scalar
Transfer:
Read/Write Byte
Factory Value:
0xBB00 (1.5)
Description/Notes:
The ZETA_P command sets the damping ratio for the closed-loop response. The value can be changed

DEADTIME_GCTRL

MAX15301 PMBus Command Set User’s Guide
Note: the default setting is LXDAC = 15 and this value should not be changed.
Variable Gate-Drive Voltage
The MAX15301 allows adjustment of the gate drive voltage from approximately 5.2V to 8.7V, as controlled by a 4-bit DAC. The DAC value to gate-drive voltage relationship is as follows:
ZETA_P
The variable gate drive system has two modes of operation, controlled by bit 6 of the LOOP_CONFIG command. When bit 6 is set to 1, the value of READ_IOUT is compared to determine which of “eighth” of the full load current range the device is operating in; e.g. 0 to IMAX/8, IMAX/8 to IMAX/4, etc. For each “bin” of the full load current range, there is a corresponding DAC setting in a lookup table. This table is populated by values sent in the GCTRL[0] to GCTRL[7] arguments of DEADTIME_GCTRL.
When bit 6 of LOOP_CONFIG is set to 0, the MAX15301 uses one setting for the gate-drive voltage, regardless of load current. This “fixed” setting is given by the GCTRLDAC argument of DEADTIME_GCTRL.
Wait at least 500ms for execution after sending the DEADTIME_GCTRL command before sending additional PMBus commands.
to improve performance when using nonceramic output capacitors with higher equivalent series resistance.
Rev 1 Page 52 of 53
Wait at least 500μs for execution after sending the ZETA_P command before sending additional
REVISION
NUMBER
REVISION
DATE
DESCRIPTION
PAGES
CHANGED
0
11/13
Initial release
Added information for new MAX15301AA02 part number
Data byte count for IC_DEVICE_ID increased to 12 in MAX15301AA02 firmware
2

ZETA_P

PMBus commands.

Trademarks

InTune is a trademark of Maxim Integrated Products, Inc.
PMBus is a trademark of SMIF, Inc.

Revision History

MAX15301 PMBus Command Set User’s Guide
1 10/14
Default value of VOUT_MAX corrected: VOUT_COMMAND x 1.10 Default values of EXT_TEMP_CAL changed in MAX15301AA02 firmware
11 35 38
Rev 1 Page 53 of 53
Loading...
