Maxima MPM 7 User Manual

Spangenberg International B.V. – Nijverheidsweg 19F – 3641 RP Mijdrecht – Holland – T. +31 (0) 297 253 969 – F. +31 (0) 297 256 445
info@spangenberg.nlwww.maximaholland.com
MAXIMA
MPM 7 PLANETARY MIXER
USER MANUAL
GEBRUIKERSHANDLEIDING
BEFORE USING THIS PRODUCT YOU SHOULD READ THIS USER MANUAL PROPERLY
VOOR GEBRUIK DIENT U DEZE GEBRUIKERSHANDLEIDING UITVOERIG TE LEZEN
Spangenberg International B.V. – Nijverheidsweg 19F – 3641 RP Mijdrecht – Holland – T. +31 (0) 297 253 969 – F. +31 (0) 297 256 445
info@spangenberg.nlwww.maximaholland.com
English
Introduction
Thank you for purchasing this Maxima product. In order to obtain the maximum benefit and use of this product, please read these instructions completely before attempting to install or use this product.
Your new Maxima product is manufactured with advanced production techniques. Every product is inspected before shipment and tested to ensure operator safety and product quality. All parameters have reached or exceeded the national standard.
The Maxima mixer range can be used for mixing food products as various types of dough or product fillings. The machines are safe, stable and easy-to-use. You can use different speeds and tools to meet different mixing requirements and satisfactory results. All parts in contact with food are made of stainless steel or food grade materials.
At Maxima we are very proud of our products and are completely committed to providing you with the best products and service possible. Your satisfaction is our number one priority.
We know you will enjoy using this product and Thank You for choosing our product. We hope you consider Maxima for your future equipment purchases.
Specifications
Model
Capacity
Speed
Colours
Dimensions
Packaging
Weight KG
Max.
Power
Connection
Maxima MPM 7
7 liter
100 - 938
RPM
White, Pink, Blue and
Green
403 x 244 x 438
mm
465 x 320 x 535
mm
N.W. 15 / G.W.
17
350 Watt
220V/50Hz/1Phase
Features
Certifications: All Maxima machines are CE certified.
Motors: All Maxima machine motors are designed specifically for heavy duty mixing applications.
Tools: All tools (Hook, Whisk and Beater) are made from 304 stainless steel
Transmission: All Maxima gears and shafts are made of quality steel which is precision machined.
Controls: All Maxima mixers have a separate start and stop button so that operators can easily stop the
machine in an emergency situation. The speed can be adjusted by a speed knob. IMPORTANT! In order to prolong the life of the motor and gearbox, it is required that the mixer is only used with speed 2-4 when mixing dough. When using the flat beater use speed 3-6.
Safety: This mixer is equipped with a protective guard so that moving parts cannot be accessed when the machine is running. Furthermore the tilting mechanism of the head is equipped with a safety switch so that the machine stops when the head is tilted. At last the machine is equipped with an overload switch.
Safety Regulations
The machine may only be used for the purpose for which it was intended and designed. The manufacturer is not liable for any damage caused by incorrect operation and improper use.
Keep the machine and electrical plug away from water and any other liquids. In the unlikely event that the machine should fall into water, immediately pull the plug out of the socket and have the machine checked by a certified technician. Not following these instructions could give rise to life-threatening
situations.
Never try to open the casing of the machine yourself.
Spangenberg International B.V. – Nijverheidsweg 19F – 3641 RP Mijdrecht – Holland – T. +31 (0) 297 253 969 – F. +31 (0) 297 256 445
info@spangenberg.nlwww.maximaholland.com
Do not insert any objects in the casing or openings of the machine.
Do not touch the plug with wet or damp hands.
Regularly check the plug and cord for any damage. When the plug or cord is damaged, you should have
it repaired by a certified repair company.
Do not use the machine after it has fallen or is damaged in any other way. Have it checked and repaired by a certified repair company.
Do not try to repair the machine yourself. This could give rise to life-threatening situations.
Make sure the cord does not come in contact with sharp or hot objects and keep it away from open fire.
To pull the plug out of the socket, always pull on the plug and not on the cord.
Make sure that no one can accidentally pull the cord loose or trip over the cord.
Always keep an eye on the machine when in use.
Never put your hands near the moving parts of the machine.
Never let children use professional machines.
Always pull the plug out of the socket when the machine is not being used and always before cleaning.
ATTENTION! As long as the plug is in the socket the machine is connected to the power source.
Turn off the machine before pulling the plug out of the socket.
Never try to move or carry the machine by the power cord.
This machine may only be used for its intended purpose: mixing food products.
Do not use any extra devices that are not supplied along with the machine.
Avoid overloading.
Turn off the machine after use by removing the plug from the socket.
The electrical installation must satisfy the applicable national and local regulations.
First Time Use
Unpack and inspect your machine immediately after receipt. If there are any latent defects or damage to the machine then immediately contact the freight carrier as well as your dealer. Save all packaging materials for inspection by the freight carrier.
Read this instruction manual completely before attempting to install and operate this product. All installations and set ups must be done by authorized service agents, your dealer, or Maxima representatives.
The machine must be positioned on a flat surface with sufficient space around the machine to allow for easy access to the machine, and for cleaning and ventilation.
If your machine is supplied with a factory fitted molded plug then you may plug the unit into a standard electrical outlet. Make sure that the voltage of the machine and the wall outlet are compatible. If your
