General Description

The MAX9360/MAX9361 are low-skew, single LVTTL/
TTL/CMOS-to-differential LVECL/ECL translators
designed for high-speed signal and clock driver appli­cations. For interfacing to LVTTL/TTL/CMOS input sig­nals, these devices operate over a 3.0V to 5.5V supply
range, allowing high-performance clock or data distrib­ution. For interfacing to differential LVECL/ECL output
signals, these devices operate from a -2.375V to -5.5V
supply.

The MAX9360 is a 3.3V LVTTL/CMOS-to-LVECL/ECL
translator that operates at a typical speed of 3GHz. The
MAX9361 is a 5V TTL/CMOS-to-LVECL/ECL translator
that operates at a typical speed of 1.3GHz. Both
devices can be used to drive either LVECL devices or
standard ECL devices with a negative supply range of

-2.375V to -5.5V.

The devices default to high if the input is disconnected,
and feature ultra-low propagation delay: 440ps for the
MAX9360, 810ps for the MAX9361.

Applications

Clock/Data-Level Translation

Features

o Output High with Input Open

o -2.375V to -5.5V LVECL/ECL Operation

o ESD Protection > 2kV (Human Body Model)

o 3.0V to 3.6V LVTTL/CMOS Operation (MAX9360)

Improved Second Source of the MC100EPT24
Low 13.8mA (typ) I

EE

Supply Current
440ps (typ) Propagation Delay
> 300mV Output at 1GHz

o 4.5V to 5.5V TTL Operation (MAX9361)

Improved Second Source of the MC100ELT24
Low 6.6mA (typ) I

EE

Supply Current
600ps (typ) Propagation Delay
> 300mV Output at 250MHz

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/

ECL Translators

________________________________________________________________

Maxim Integrated Products

1

Ordering Information

TOP VIEW

GNDN.C.

1

2

87V

CC

QD

N.C.

V

EE

SO

3

4

6

5

MAX9360/

MAX9361

Q

GND

N.C.

1

2

8

7

V

CC

Q

V

EE

N.C.

D

SOT23

3

4

6

5

MAX9360/

MAX9361

Q

Pin Configurations

19-2327; Rev 2; 12/08

EVALUATION KIT

AVAILABLE

PART TEMP RANGE

MAX9360EKA-T -40°C to +85°C 8 SOT23 AAJI

MAX9360ESA -40°C to +85°C 8 SO —

MAX9361EKA-T -40°C to +85°C 8 SOT23 AAJJ

MAX9361ESA -40°C to +85°C 8 SO —

PIN­PACKAGE

TOP

MARK

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/
ECL Translators

2 _______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

DC ELECTRICAL CHARACTERISTICS—MAX9360

(VCC= 3.0V to 3.6V, VEE= -2.375V to -5.5V, V

GND

= 0, outputs terminated with 50Ω ±1% to -2.0V. Typical values are at VCC= 3.3V,

V

IH

= 2.0V, VIL= 0.8V, unless otherwise noted.) (Notes 1, 2, 3)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

VCCto GND..............................................................-0.3V to +6V

V

EE

to GND...............................................................-6V to +0.3V

D to GND....................................................-0.3V to (V

CC

+ 0.3V)

Continuous Output Current ................................................50mA

Surge Output Current........................................................100mA

Junction-to-Ambient Thermal Resistance in Still Air

8-Pin SOT23.............................................................+112°C/W

8-Pin SO...................................................................+170°C/W

Junction-to-Ambient Thermal Resistance

with 500LFPM Airflow

8-Pin SOT23...............................................................+78°C/W

8-Pin SO.....................................................................+99°C/W

Junction-to-Case Thermal Resistance

8-Pin SOT23...............................................................+80°C/W

8-Pin SO..................................................................+40°C/mW

Continuous Power Dissipation (TA= +70°C)

8-Pin SOT23 (derate 8.9mW/°C above +70°C)............714mW

8-Pin SO (derate 5.9mW/°C above +70°C)..................470mW

Operating Temperature Range ...........................-40°C to +85°C

Junction Temperature......................................................+150°C

Storage Temperature Range .............................-60°C to +150°C

ESD Protection

Human Body Model (D, Q, Q)........................................> 2kV

Soldering Temperature (10s) ...........................................+300°C

PARAMETER SYMBOL CONDITIONS

LVTTL INPUT (D)

Input High Current I

Input Low Current I

Input Clamp
Voltage

Input High Voltage V

Input Low Voltage V

LVECL/ECL OUTPUTS (Q, Q)

Output High
Voltage

Output Low Voltage V

Differential Output
Swing (V

Power-Supply
Current

Internal Chip
Current

OH

- VOL)

IH

IL

V

V

OH

OL

V

OH

V

OL

I

CC

I

EE

VIN = 2.7V -20 +20 -20 +20 -20 +20

VIN = V

VIN = 0.5V -200 -51 -200 -60 -200 -67 µA

IIN = -18mA -1.2 -1.2 -1.2 V

IK

IH

IL

-

(Note 4) 4.3 7.0 5.0 7.0 5.6 7.0 mA

(Note 4) 12.3 20 13.8 20 15.2 20 mA

CC

0°C (SOT23)

MIN TYP MAX MIN TYP MAX MIN TYP MAX

-10 +10 -10 +10 -10 +10

2.0 2.0 2.0 V

-1.145 -0.885 -1.145 -0.885 -1.145 -0.885 V

-1.935 -1.625 -1.935 -1.625 -1.935 -1.625 V

550 550 550 mV

-40°C (SO)

0.8 0.8 0.8 V

+25°C +85°C

UNITS

µA

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/

ECL Translators

_______________________________________________________________________________________ 3

DC ELECTRICAL CHARACTERISTICS—MAX9361

(VCC= 4.5V to 5.5V, VEE= -2.375V to -5.5V, V

GND

= 0, outputs terminated with 50Ω ±1% to -2.0V. Typical values are at VCC= 5V,

V

IH

= 2.0V, VIL= 0.8V, unless otherwise noted.) (Notes 1, 2, 3)

PARAMETER SYMBOL CONDITIONS

TTL INPUT (D)

Input High Current I

Input Low Current I

Input Clamp
Voltage

Input High Voltage V

Input Low Voltage V

LVECL/ECL OUTPUTS (Q, Q)

Output High
Voltage

Output Low Voltage V

Differential Output
Swing (V

POWER SUPPLY

Power-Supply
Current

Internal Chip
Current

OH

- VOL)

IH

IL

V

V

OH

OL

V

OH

V

OL

I

CC

I

EE

VIN = 2.7V -30 +30 -30 +30 -30 +30

VIN = V

CC

VIN = 0.5V -200 -55 -200 -61 -200 -71 µA

IIN = -18mA -1.2 -1.2 -1.2 V

IK

IH

IL

-

(Note 4) 3.0 7.0 3.5 7.0 4.3 7.0 mA

(Note 4) 9 20 10 20 11 20 mA

-40°C (SO) +25°C +85°C

MIN TYP MAX MIN TYP MAX MIN TYP MAX

-10 +10 -10 +10 -10 +10

2.0 2.0 2.0 V

-1.055 -0.880 -1.055 -0.880 -1.025 -0.880 V

-1.875 -1.555 -1.810 -1.605 -1.810 -1.605 V

550 699 550 691 550 677 mV

UNITS

µA

0.8 0.8 0.8 V

Note 1: Measurements are made with the device in thermal equilibrium.
Note 2: Current into a pin is defined as positive. Current out of a pin is defined as negative.
Note 3: DC parameters are production tested at +25°C. DC limits are guaranteed by design and characterization over the full

operating temperature range.

Note 4: All pins are open except V

CC

, VEE, and GND.

Note 5: Guaranteed by design and characterization. Limits are set to ±6 sigma.
Note 6: Device jitter added to the input signal.

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/
ECL Translators

4 _______________________________________________________________________________________

AC ELECTRICAL CHARACTERISTICS—MAX9360

(VCC= 3.0V to 3.6V, VEE= -2.375V to -5.5V, V

GND

= 0, outputs terminated with 50Ω ±1% to -2.0V, input frequency = 1.0GHz, input

transition time = 125ps (20% to 80%). Typical values are at V

CC

= 3.3V, VIH= 2.0V, VIL= 0.8V, unless otherwise noted.) (Note 5)

(

)

(

)

AC ELECTRICAL CHARACTERISTICS—MAX9361

(VCC= 4.5V to 5.5V, VEE= -2.375V to -5.5V, V

GND

= 0, outputs terminated with 50Ω ±1% to -2.0V, input frequency = 100MHz, input

transition time = 125ps (20% to 80%). Typical values are at V

CC

= 5.0V, VIH= 2.0V, VIL= 0.8V, unless otherwise noted.) (Note 5)

(

)

(

)

PARAMETER SYMBOL CONDITIONS

Maximum Toggle
Frequency

Input-to-Output
Propagation Delay

Output Rise/Fall
Time

Added
Deterministic Jitter

f

MAX

t

PLHD

t

PHLD

t

R

t

DJ

, t

VOH - VOL ≥ 300mV 1.0 3.0 1.0 3.0 1.0 3.0

VOH - VOL ≥ 500mV 0.85 1.5 0.85 1.5 0.85 1.5

,

Figure 1 300 800 300 800 300 800 ps

Figure 1 70 97 150 80 105 150 100 122 150 ps

F

2Gbps

23

2

- 1 PRBS pattern

(Note 6)

0°C (SOT23)

-40°C (SO)

+25°C +85°C

MIN TYP MAX MIN TYP MAX MIN TYP MAX

43 70 43 70 43 70 ps

UNITS

GHz

P-P

Added Random
Jitter

t

RJ

1.0GHz clock
pattern (Note 6)

1.4 3.0 1.5 3.0 1.5 3.0 ps

PARAMETER SYMBOL CONDITIONS

Maximum Toggle
Frequency

Input-to-Output
Propagation Delay

Output Rise/Fall
Time

Added
Deterministic Jitter

Added Random
Jitter

f

MAX

t

PLHD

t

PHLD

, t

t

R

t

DJ

t

RJ

VOH - VOL ≥ 300mV 250 1300 250 1300 250 1300

VOH - VOL ≥ 500mV 150 500 150 500 150 500

,

Figure 1 300 561 900 300 583 900 300 607 900 ps

Figure 1 250 340 1000 250 342 1000 250 353 1000 ps

F

200Mbps

23

- 1 PRBS pattern

2
(Note 6)

100MHz clock
pattern (Note 6)

-40°C +25° C +85°C

MIN TYP MAX MIN TYP MAX MIN TYP MAX

81 150 83 150 85 150 ps

410 410 410ps

RMS

UNITS

MHz

P-P

RMS

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/

ECL Translators

_______________________________________________________________________________________

5

Typical Operating Characteristics

(MAX9360: VCC= 3.3V and VEE= -5V, VIH= 2.0V, VIL= 0.8V, TA= +25°C, outputs terminated with 50Ω to -2V, input frequency
= 1GHz, input transition time = 125ps (20% to 80%), unless otherwise noted.)

SUPPLY CURRENT vs. TEMPERATURE

20

16

12

8

SUPPLY CURRENT (mA)

4

0

-40 10-15 35 60 85

I

EE

I

CC

TEMPERATURE (°C)

TRANSITION TIME vs. TEMPERATURE

130

120

110

100

TRANSITION TIME (ps)

90

t

R

t

F

MAX9360 toc01

MAX9360 toc03

OUTPUT AMPLITUDE vs. FREQUENCY

800

750

700

650

600

550

500

450

OUTPUT AMPLITUDE (mV)

400

350

300

0 1000500 1500 2000 2500 3000

FREQUENCY (MHz)

PROPAGATION DELAY vs. TEMPERATURE

500

475

450

425

400

PROPAGATION DELAY (ps)

375

t

PLHD

t

PHLD

MAX9360 toc02

MAX9360 toc4

80

-40 10-15 35 60 85
TEMPERATURE (°C)

350

-40 10-15 35 60 85
TEMPERATURE (°C)

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/
ECL Translators

6 _______________________________________________________________________________________

Pin Description

Figure 1. Input-to-Output Propagation Delay and Transition Timing Diagram

PIN

SO SOT23

12V

2 1 D LVTTL/CMOS Input for MAX9360. TTL/CMOS input for MAX9361.

3, 4 3, 4 N.C. No Connect. Connect to GND.

5 8 GND Ground

67 Q Inverting Differential LVECL/ECL Output. Typically terminate with 50Ω resistor to -2V.

7 6 Q Noninverting Differential LVECL/ECL Output. Typically terminate with 50Ω resistor to -2V.

85V

NAME FUNCTION

Negative Supply Voltage. Bypass VEE to GND with 0.1µF and 0.01µF ceramic capacitors.

EE

Place the capacitors as close as possible to the device with the smaller value capacitor
closest to the device.

Positive Supply Voltage. Bypass VCC to GND with 0.1µF and 0.01µF ceramic capacitors.

CC

Place the capacitors as close as possible to the device with the smaller value capacitor
closest to the device.

50% 50%

D

Q

SINGLE-ENDED WAVEFORMS

Q

DIFFERENTIAL WAVEFORM

Q - Q

t

PLH

VOH - V

OL

80%

20% 20%

t

R

VOH - V

VOH - V

OL

OL

80%

t

PHL

0 (DIFFERENTIAL)

t

F

V

IH

V

IL

V

OH

V

OL

Detailed Description

The MAX9360/MAX9361 are low-skew, single LVTTL/
CMOS/TTL-to-differential LVECL/ECL translators
designed for high-speed signal and clock driver appli­cations. For interfacing to LVTTL/TTL/CMOS input sig­nals, these devices operate over a 3.0V to 5.5V supply
range, allowing high-performance clock or data distrib­ution in systems with a nominal 3.3V or 5.0V supply. For
interfacing to differential LVECL/ECL output signals,
these devices operate from a -2.375V to -5.5V supply.

The MAX9360 is a 3.3V LVTTL/CMOS-to-LVECL/ECL
translator that operates at typical speeds of 3GHz. The
MAX9361 is a 5V TTL/CMOS-to-LVECL/ECL translator that
operates at typical speeds of 1.3GHz. Both devices can
be used to drive either LVECL devices or standard ECL
devices with a negative supply range of -2.375V to -5.5V.

Input

The MAX9360/MAX9361 inputs accept standard LVTTL/
TTL/CMOS levels. The input has pullup circuitry that dri­ves the outputs to a differential high if the inputs are open.

Differential Output

Output levels are referenced to GND and are considered
ECL or LVECL, depending on the level of the VEEsupply.
With GND connected to zero and VEEat -4.2V to -5.5V,
the outputs are ECL. The outputs are LVECL when GND is
connected to zero and VEEis at -2.375V to -3.8V.

Applications Information

Supply Bypassing

Bypass VCCand VEEto ground with high-frequency
surface-mount ceramic 0.1µF and 0.01µF capacitors in
parallel as close as possible to the device, with the

0.01µF value capacitor closest to the device. Use multi­ple parallel vias for low inductance.

Traces

Input and output trace characteristics affect the perfor­mance of the MAX9360/MAX9361. Connect each signal
of a differential output to a 50Ω characteristic imped­ance trace. Minimize the number of vias to prevent
impedance discontinuities. Reduce reflections by main­taining the 50Ω characteristic impedance through con­nectors and across cables. Reduce skew within a
differential pair by matching the electrical length of the
traces.

On the MAX9360, if the input edge rate approaches the
electrical length of the interconnect, then controlled­impedance transmission lines should be used for the
input traces.

Output Termination

Terminate outputs through 50Ω to -2V or use an equiva­lent Thevenin termination. Terminate both outputs and
use the same termination on each for the lowest output­to-output skew. When a single-ended signal is taken
from a differential output, terminate both outputs. For
example, if Q is used as a single-ended output, termi­nate both Q and Q.

Ensure that the output currents do not exceed the con­tinuous safe output current limit or surge output current
limit as specified in the

Absolute Maximum Ratings

table. Under all operating conditions, the device’s total
thermal limits should be observed.

Chip Information

PROCESS: Bipolar

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/

ECL Translators

_______________________________________________________________________________________ 7

Package Information

For the latest package outline information and land patterns, go
to www.maxim-ic.com/packages

.

PACKAGE TYPE PACKAGE CODE DOCUMENT NO.

8 SOT23 K8-1

21-0078

8 SO S8-2

21-0041

MAX9360/MAX9361

LVTTL/TTL/CMOS-to-Differential LVECL/
ECL Translators

Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.

8

_____________________Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600

© 2008 Maxim Integrated Products is a registered trademark of Maxim Integrated Products, Inc.

Revision History

REVISION

NUMBER

0 1/02 Initial release —

1 7/02 — —

2 12/08 Removed incorrect temperature range specified in the data sheet. 1

REVISION

DATE

DESCRIPTION

PAGES

CHANGED
