General Description
The MAX9310 is a fast, low-skew 1:5 differential driver
with selectable LVPECL/HSTL inputs and LVDS outputs, designed for clock distribution applications. This
device features an ultra-low propagation delay of 345ps
with 45.5mA of supply current.
The MAX9310 operates from a 2.375V to 2.625V power
supply for use in 2.5V systems. A 2:1 input multiplexer
is used to select one of two differential inputs. The input
selection is controlled through the CLKSEL pin. This
device also features a synchronous enable function.
The MAX9310 is offered in a space-saving 20-pin
TSSOP package and operates over the extended temperature range from -40°C to +85°C.
Applications
Data and Clock Drivers and Buffers
Central-Office Backplane Clock Distribution
DSLAM
Base Stations
ATE
Features
♦ Guaranteed 1.0GHz Operating Frequency
♦ 8ps Output-to-Output Skew
♦ 345ps Propagation Delay
♦ Accepts LVPECL and Differential HSTL Inputs
♦ Synchronous Output Enable/Disable
♦ Two Selectable Differential Inputs
♦ 2.375V to 2.625V Supply Voltage
♦ ESD Protection: ±2kV (Human Body Model)
♦ Input Bias Resistors Drive Output Low for Open
Inputs
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
________________________________________________________________ Maxim Integrated Products 1
20
19
18
17
16
15
14
13
1
2
3
4
5
6
7
8
V
CC
EN
V
CC
CLK1Q1
Q1
QO
Q0
TOP VIEW
CLK1
I.C.
CLK0
CLK0Q3
Q3
Q2
Q2
12
11
9
10
CLKSEL
GNDQ4
Q4
MAX9310
TSSOP
Pin Configuration
Ordering Information
100Ω
MAX9310
ZO = 50Ω
Z
O
= 50Ω
RECEIVER
Q_
Q_
Typical Application Circuit
19-2541; Rev 0; 7/02
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
Functional diagram appears at end of data sheet.
PART TEMP RANGE PIN-PACKAGE
MAX9310EUP -40°C to +85°C 20 TSSOP
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(VCC- GND = 2.375V to 2.625V, outputs terminated with 100Ω±1%, unless otherwise noted. Typical values are at VCC- GND = 2.5V,
V
IHD
= VCC- 1.0V, V
ILD
= VCC- 1.5V, unless otherwise noted.) (Notes 1, 2, and 3)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
VCCto GND...........................................................-0.3V to +4.1V
EN, CLKSEL, CLK_, CLK_, to GND............-0.3V to (VCC+ 0.3V)
CLK_ to CLK_ ...........................................................|V
CC
- GND|
Continuous Output Current .................................................24mA
Surge Output Current..........................................................50mA
Continuous Power Dissipation (T
A
= +70°C)
Single-Layer PC Board
20-Pin TSSOP (derate 7.69mW/°C above +70°C) ......615mW
Multilayer PC Board
20-Pin TSSOP (derate 11mW/°C above +70°C) .........879mW
Junction-to-Ambient Thermal Resistance in Still Air
Single-Layer PC Board
20-Pin TSSOP .........................................................+130°C/W
Multilayer PC Board
20-Pin TSSOP ...........................................................+91°C/W
Junction-to-Ambient Thermal Resistance with 500LFPM
Airflow Single-Layer PC board
20-Pin TSSOP ...........................................................+96°C/W
Junction-to-Case Thermal Resistance
20-Pin TSSOP ...........................................................+20°C/W
Operating Temperature Range .......................... -40°C to +85°C
Junction Temperature......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
ESD Protection
Human Body Model (inputs and outputs) .......................±2kV
Lead Temperature (soldering, 10s) .................................+300°C
-40°C +25°C +85°C
PARAMETER
UNITS
SINGLE-ENDED INPUTS (CLKSEL, EN)
Input High
Voltage
V
IH
VCC -
VCC -
VCC -
VCC -
VCC -
VCC -
V
Input Low
Voltage
V
IL
VCC -
VCC -
VCC -
VCC -
VCC -
VCC -
V
Input Current I
IN
V
IH(MAX)
,
V
IL(MAX)
µA
DIFFERENTIAL INPUTS (CLK_, CLK_)
Differential Input
High Voltage
V
IHD
Figure 1
V
Differential Input
Low Voltage
V
ILD
Figure 1
VCC -
VCC -
VCC -
V
Differential Input
Voltage
V
ID
V
IHD
- V
ILD
V
Input Current
CLK_, or CLK_ =
V
IHD
or V
ILD
µA
OUTPUTS (Q_, Q_)
Output High
Voltage
V
OH
Figure 1
1.6 V
Output Low
Voltage
V
OL
Figure 1
V
Differential
Output Voltage
V
OD
VOH - VOL,
Figure 1
mV
SYMBOL CONDITIONS
MIN TYP MAX MIN TYP MAX MIN TYP MAX
IIH, I
IL
1.165
1.81
-150 +50 -150 +50 -150 +50
1.2 V
GND
0.095 V
-60 +50 -60 +50 -60 +60
0.9 0.9 0.9
250 350 450 250 350 450 250 350 450
0.88
1.165
1.475
0.095
1.81
1.2 V
CC
CC
1.6 1.6
GND
0.095 V
0.88
1.475
CC
0.095
CC
1.165
1.81
1.2 V
GND
0.095 V
0.88
1.475
CC
0.095
CC
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
_______________________________________________________________________________________ 3
DC ELECTRICAL CHARACTERISTICS (continued)
(VCC- GND = 2.375V to 2.625V, outputs terminated with 100Ω±1%, unless otherwise noted. Typical values are at VCC- GND = 2.5V,
V
IHD
= VCC- 1.0V, V
ILD
= VCC- 1.5V, unless otherwise noted.) (Notes 1, 2, and 3)
AC ELECTRICAL CHARACTERISTICS
(VCC- GND = 2.375V to 2.625V, outputs terminated with 100Ω±1%, fIN≤ 1.0GHz, input transition time = 125ps (20% to 80%),
V
IHD
- V
ILD
= 0.15V to VCC, unless otherwise noted. Typical values are at VCC- GND = 2.5V, V
IHD
= VCC- 1.0V, V
ILD
= VCC- 1.5V,
unless otherwise noted.) (Notes 1 and 5)
-40°C +25°C +85°C
PARAMETER
SYMBOL
CONDITIONS
UNITS
Change in V
OD
Between
Complementary
Output States
∆V
OD
40 40 40
mV
Output Offset
Voltage
V
OS
mV
Change in V
OS
Between
Complementary
Output States
25 25 25
mV
12 12 12
Output ShortCircuit Current
I
OSC
Q_ or Q_ shorted
to GND
28 28 28
mA
POWER SUPPLY
Power-Supply
Current
I
CC
(Note 4)
75
75
75
mA
MIN TYP MAX MIN TYP MAX MIN TYP MAX
1.125 1.25 1.375 1.125 1.25 1.375 1.125 1.25 1.375
∆V
OCM
Q_ shorted to Q_
42
45.5
48.5
PARAMETER SYMBOL CONDITIONS
Propagation
Delay CLK_,
CLK_ to Q_, Q_
Output-toOutput Skew
Part-to-Part
Skew
Added Random
Jitter
Added
Deterministic
Jitter
-40°C +25°C +85°C
MIN TYP MAX MIN TYP MAX MIN TYP MAX
,
t
PHL
t
PLH
t
SKOO
t
SKPP
t
t
Figure 1 250 335 600 250 345 600 250 345 600 ps
(Note 6) 10 25 8 25 5 25 ps
(Note 7) 145 145 145 ps
fIN = 1.0GHz,
clock pattern
RJ
(Note 8)
fIN = 1.0Gsps,
23
- 1 PRBS
2
DJ
pattern (Note 8)
0.4 1.0 0.4 1.0 0.4 1.0
41 52 41 52 41 52
UNITS
ps
(RMS)
ps
(P-P)
SUPPLY CURRENT vs. TEMPERATURE
MAX9310 toc01
TEMPERATURE (°C)
SUPPLY CURRENT (mA)
603510-15
41
42
43
44
45
46
47
48
49
50
40
-40 85
ALL PINS ARE OPEN EXCEPT VCC
AND GND OUTPUTS LOADED WITH 100Ω
DIFFERENTIAL
DIFFERENTIAL OUTPUT VOLTAGE (VOH - VOL)
vs. FREQUENCY
MAX9310 toc02
FREQUENCY (GHz)
DIFFERENTIAL OUTPUT VOLTAGE (mV)
1.501.250.25 0.50 0.75 1.00
100
150
200
250
300
350
400
450
50
0 1.75
OUTPUT RISE/FALL vs. TEMPERATURE
MAX9310 toc03
TEMPERATURE (°C)
RISE/FALL TIME (ps)
603510-15
205
210
215
220
200
-40 85
t
F
t
R
fIN = 500MHz
Typical Operating Characteristics
(VCC- GND = 2.5V, outputs terminated with 100Ω±1%, fIN= 1.0GHz, input transition time = 125ps (20% to 80%),V
IHD
= VCC- 1.0V,
V
ILD
= VCC- 1.5V, unless otherwise noted.)
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
4 _______________________________________________________________________________________
AC ELECTRICAL CHARACTERISTICS (continued)
(VCC- GND = 2.375V to 2.625V, outputs terminated with 100Ω±1%, fIN≤ 1.0GHz, input transition time = 125ps (20% to 80%),
V
IHD
- V
ILD
= 0.15V to VCC, unless otherwise noted. Typical values are at VCC- GND = 2.5V, V
IHD
= VCC- 1.0V, V
ILD
= VCC- 1.5V,
unless otherwise noted.) (Notes 1 and 5)
-40°C +25°C +85°C
PARAMETER
SYMBOL
CONDITIONS
UNITS
Operating
Frequency
f
MAX
VOD ≥ 250mV
GHz
Differential
Output Rise/Fall
Time
t
R/tF
20% to 80%,
Figure 1
ps
Note 1: Measurements are made with the device in thermal equilibrium.
Note 2: Current into a pin is defined as positive. Current out of a pin is defined as negative.
Note 3: DC parameters are production tested at +25°C. DC limits are guaranteed by design and
characterized over the full operating temperature range.
Note 4: All pins are open except V
CC
and GND, all outputs are loaded with 100Ω differentially.
Note 5: Guaranteed by design and characterization. Limits are set to ±6 sigma.
Note 6: Measured between outputs of the same part at the signal crossing points for a same-edge
transition.
Note 7: Measured between outputs of different parts at the signal crossing points under identical conditions
for a same-edge transition.
Note 8: Device jitter added to the input signal.
MIN TYP MAX MIN TYP MAX MIN TYP MAX
1.0 1.0 1.0
140 205 300 140 205 300 140 205 300
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
_______________________________________________________________________________________ 5
Typical Operating Characteristics (continued)
(VCC- GND = 2.5V, outputs terminated with 100Ω±1%, fIN= 1.0GHz, input transition time = 125ps (20% to 80%),V
IHD
= VCC- 1.0V,
V
ILD
= VCC- 1.5V, unless otherwise noted.)
PROPAGATION DELAY vs. HIGH VOLTAGE
OF DIFFERENTIAL INPUT (V
IHD
)
MAX9310 toc04
V
IHD
(V)
PROPAGATION DELAY (ps)
3.02.72.42.11.81.5
310
330
350
370
390
290
1.2 3.3
PROPAGATION DELAY vs. TEMPERATURE
MAX9310 toc05
TEMPERATURE (°C)
PROPAGATION DELAY (ps)
603510-15
320
340
360
380
400
300
-40 85
Pin Description
PIN NAME FUNCTION
1 Q0 Noninverting Differential Output 0. Typically terminated with 100Ω to Q0.
2 Q0 Inverting Differential Output 0. Typically terminated with 100Ω to Q0.
3 Q1 Noninverting Differential Output 1. Typically terminated with 100Ω to Q1.
4 Q1 Inverting Differential Output 1. Typically terminated with 100Ω to Q1.
5 Q2 Noninverting Differential Output 2. Typically terminated with 100Ω to Q2.
6 Q2 Inverting Differential Output 2. Typically terminated with 100Ω to Q2.
7 Q3 Noninverting Differential Output 3. Typically terminated with 100Ω to Q3.
8 Q3 Inverting Differential Output 3. Typically terminated with 100Ω to Q3.
9 Q4 Noninverting Differential Output 4. Typically terminated with 100Ω to Q4.
10 Q4 Inverting Differential Output 4. Typically terminated with 100Ω to Q4.
11 GND Ground
12 CLKSEL
Clock Select Input. Drive low to select the CLK0, CLK0 input. Drive high to select the CLK1,
CLK1 input. Internal 60kΩ pulldown to GND.
13 CLK0 Noninverting Differential Clock Input 0. Internal 75kΩ pulldown to GND.
14 CLK0 Inverting Differential Clock Input 0. Internal 75kΩ pullup to VCC and 75kΩ pulldown to GND.
15 I.C. Internally Connect. Do not connect externally.
16 CLK1 Noninverting Differential Input 1. Internal 75kΩ pulldown to GND.
17 CLK1 Inverting Differential Input 1. Internal 75kΩ pullup to VCC and 75kΩ pulldown to GND.
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
6 _______________________________________________________________________________________
CLK
CLK
Q_
Q_
t
PLHD
t
PHLD
VOH - V
OL
V
IHD
- V
ILD
V
IHD
V
ILD
Q_ - Q_
0V (DIFFERENTIAL) 0V (DIFFERENTIAL)
20%
80%
20%
80%
t
R
t
F
V
OL
V
OH
Figure 1. MAX9310 Timing Diagram
t
S
t
H
t
S
t
PLHD
OUTPUTS ARE LOW OUTPUTS STAY LOW
EN
CLK
CLK
Q_
Q_
t
H
tS = SETUP TIME
t
H
= HOLD TIME
Figure 2. MAX9310 ENTiming Diagram
Pin Description (continued)
PIN NAME FUNCTION
18, 20 V
CC
Positive Supply Voltage. Bypass each VCC to GND with 0.1µF and 0.01µF ceramic capacitors.
Place the capacitors as close to the device as possible with the smaller value capacitor closest
to the device.
19 EN
Output Enable Input. Outputs are synchronously enabled on the falling edge of the selected
clock input when EN is low. Outputs are synchronously driven to a differential low state on the
falling edge of the selected clock input when EN is high. Internal 60kΩ pulldown to GND
(Figure 2).
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
_______________________________________________________________________________________ 7
Detailed Description
The MAX9310 is a low-skew 1:5 differential driver with
two selectable LVPECL inputs and LVDS outputs,
designed for clock distribution applications. The selected clock accepts a differential input signal and reproduces it on five separate differential LVDS outputs. The
inputs are biased with internal resistors such that the
output is differential low when inputs are open. The output drivers are guaranteed to operate at frequencies up
to 1.0GHz with LVDS output levels conforming to the
EIA/TIA-644 standard.
The MAX9310 is designed for 2.375V to 2.625V operation in systems with a nominal 2.5V supply.
Differential LVPECL Input
The MAX9310 has two input differential pairs that
accept differential LVPECL/HSTL inputs. Each differential input pair has to be independently terminated. A
select pin (CLKSEL) is used to activate the desired
input. The maximum magnitude of the differential signal
applied to the input is VCC. Specifications for the high
and low voltages of a differential input (V
IHD
and V
ILD
)
and the differential input voltage (V
IHD
- V
ILD
) apply
simultaneously.
Synchronous Enable
The MAX9310 is synchronously enabled and disabled
with outputs in a differential low state to eliminate shortened clock pulses. EN is connected to the input of an
edge-triggered D flip-flop. After power-up, drive EN low
and toggle the selected clock input to enable the outputs. The outputs are enabled on the falling edge of the
selected clock input after EN goes low. The outputs are
set to a differential low state on the falling edge of the
selected clock input after EN goes high (Figure 2).
Input Bias Resistors
Internal biasing resistors ensure a (differential) output
low condition in the event that the inputs are not connected. The inverting input (CLK_) is biased with a
75kΩ pulldown to GND and a 75kΩ pullup to VCC. The
noninverting input (CLK_) is biased with a 75kΩ pull-
down to GND.
Differential LVDS Output
The LVDS outputs must be terminated with 100Ω
across Q_ and Q_, as shown in the Typical Application
Circuit. The outputs are short-circuit protected.
Applications Information
Supply Bypassing
Bypass each V
CC
to GND with high-frequency surfacemount ceramic 0.1µF and 0.01µF capacitors in parallel
as close to the device as possible, with the 0.01µF
capacitor closest to the device. Use multiple parallel
vias to minimize parasitic inductance and reduce
power-supply bounce with high-current transients.
Controlled-Impedance Traces
Input and output trace characteristics affect the performance of the MAX9310. Connect high-frequency input
and output signals to 50Ω characteristic impedance
traces. Minimize the number of vias to prevent impedance discontinuities. Reduce reflections by maintaining
the 50Ω characteristic impedance through cables and
connectors. Reduce skew within a differential pair by
matching the electrical length of the traces.
Output Termination
Terminate the outputs with 100Ω across Q_ and Q_, as
shown in the Typical Application Circuit.
Chip Information
TRANSISTOR COUNT: 716
PROCESS: Bipolar
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
8 _______________________________________________________________________________________
Functional Diagram
MAX9310
CLK0
CLK0
CLK1
CLKSEL
EN
I.C.
V
CC
GND GND
GND
GND
GND
GND
0
1
Q
D
75kΩ
75kΩ
75kΩ
60kΩ
60kΩ
Q0
Q0
Q1
Q1
Q2
Q2
Q3
Q3
Q4
Q4
75kΩ
75kΩ
75kΩ
V
CC
CLK1
MAX9310
1:5 Clock Driver with Selectable
LVPECL Inputs and LVDS Outputs
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 _____________________ 9
© 2002 Maxim Integrated Products Printed USA is a registered trademark of Maxim Integrated Products.
Package Information
(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information,
go to www.maxim-ic.com/packages.)
TSSOP,NO PADS.EPS
Loading...
