MAXIM MAX6613 Technical data

General Description
The MAX6613 is a low-power precision analog output temperature sensor in a tiny 5-pin SC70 package. The MAX6613 operates over a 1.8V to 5.5V supply voltage range, with a typical current consumption of only 7.5µA. It is particularly well suited for portable applications where minimizing battery cost and maximizing useful battery life are crucial.
The MAX6613 provides an analog voltage output pro­portional to temperature. Accuracy is ±4.0°C (max) over a range of T
A
= 0°C to +50°C and ±4.4°C (max) from TA= -20°C to +80°C. Self-heating effects are neg­ligible due to the low current consumption of the part.
Unlike many analog temperature sensors, the MAX6613 is stable with any capacitive load from 0pF to 1000pF, providing broad flexibility in board-level design.
The operating temperature range varies with the volt­age supply. The MAX6613 can be used over a -55°C to +130°C range with a 2.5V to 5.5V supply voltage. For applications with a supply voltage of 1.8V, the MAX6613 can be used over a +25°C to +130°C tem­perature range.
Applications
Features
1.8V to 5.5V Supply Voltage
4.0°C Accuracy
Low Supply Consumption, 7.5µA (typ)
-55°C to +130°C Temperature Range
SC70 Package
Pin Compatible to LM20
MAX6613
Low-Voltage Analog Temperature
Sensor in an SC70 Package
________________________________________________________________
Maxim Integrated Products
1
19-2477; Rev 3; 12/10
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
Ordering Information
Typical Application Circuit
Pin Configuration
Cellular Phones
GPS Equipment
Medical Instruments
Battery Management
Appliances
Disk Drives
Printers
Fax Machines
HVAC
+
Denotes a lead(Pb)-free/RoHS-compliant package.
/V denotes an automotive qualified part.
PART TEMP RANGE
MAX6613MXK+T -55°C to +130°C 5 SC70-5 ADJ
MAX6613MXK/V+T -55°C to +130°C 5 SC70-5 ADJ
PIN­PACKAGE
MARK
TOP
V
CC
V
CC
V
CC
VOUT
0.1μF
MAX6613
GND
GND
MICROCONTROLLER
ADC IN
100pF
GND
TOP VIEW
15GNDN.C.
2
GND
OUT
34
+
MAX6613
V
CC
SC70
MAX6613
Low-Voltage Analog Temperature Sensor in an SC70 Package
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Note 1: All parameters tested at room temperature. Values through temperature limits are guaranteed by design. Note 2: V
OUT
= -0.0000022 ✕T2- 0.01105 ✕T + 1.8455 (T = temperature in degrees Celsius).
Note 3: Guaranteed by design to 3 sigma. Note 4: Guaranteed by design.
(All voltages referenced to GND, unless otherwise noted.) V
CC
to GND..............................................................-0.3V to +6V
All Other Pins to GND.................................-0.3V to (V
CC
+ 0.3V)
OUT Short to GND......................................................Continuous
Output Current ....................................................-1mA to +50mA
ESD Protection (Human Body Model)................................2000V
Continuous Power Dissipation (T
A
= +70°C)
5-Pin SC70 (derate 3.1mW/°C above +70°C)...........246.9mW
Operating Temperature Range .........................-55°C to +130°C
Junction Temperature......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering 10s) ..................................+300°C
Soldering Temperature (reflow) .......................................+260°C
DC ELECTRICAL CHARACTERISTICS
(VCC= 1.8V to 5.5V, TA= -55°C to +130°C. Typical values are at TA= +25°C, unless otherwise noted.) (Note 1)
Temperature-to-Voltage Error (Notes 2, 3)
Output Voltage TA = 0°C 1.8455 V
Nonlinearity TA = -55°C to +100°C ±0.4 %
Sensor Gain (Temperature Sensitivity or Average Slope)
Maximum Output Impedance
Load Regulation
Quiescent Current I
Capacitive Load
Long-Term Stability TA = room temperature for 1000hr (Note 4) 0.1 °C
Temperature Coefficient of Supply Current
Power-Down Supply Current VCC < 0.8V 0.1 µA
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
VCC = 2.7V, TA = 0°C to +50°C -4 +4
VCC = 2.7V, TA = -20°C to +85°C -4.4 +4.4
VCC = 2.7V, TA = -55°C to +100°C -4.5 +4.5
VCC = 2.7V, TA = +100°C to +125°C -4.7 +4.7
= 2.7V, TA = +125°C to +130°C -5 +5
V
CC
= -20°C to +100°C (Note 3) -10.98 -11.23 -11.47 mV/°C
T
A
0 < IL < 16µA, TA = -55°C to +125°C 160
< 16µA, TA = +125°C to +130°C 300
0 < I
L
0 < IL < 16µA, TA = -55°C to +125°C -2.5
0 < I
< 16µA, TA = 125°C to 130°C -4.8
L
TA = -20°C to +130°C, VCC 5.5V 1 3.3
TA = -55°C to -20°C, VCC 4.5V 1 4.7Supply Sensitivity (Note 3)
T
= -55°C to -20°C, VCC 5.5V 1
A
No load 7.5 13 µA
Q
No sustained oscillations for capacitive loads in this range (Note 4)
0 1000 pF
15 nA/°C
°C
Ω
mV
mV/V
