Maxim MAX6382XR29D6-T Datasheet

General Description

The MAX6381–MAX6390 microprocessor (µP) supervisory
circuits monitor power supply voltages from +1.8V to
+5.0V while consuming only 3µA of supply current at
+1.8V. Whenever VCCfalls below the factory-set reset
thresholds, the reset output asserts and remains assert­ed for a minimum reset timeout period after VCCrises
above the reset threshold. Reset thresholds are available
from +1.58V to +4.63V, in approximately 100mV incre­ments. Seven minimum reset timeout delays ranging
from 1ms to 1200ms are available.

The MAX6381/MAX6384/MAX6387 have a push-pull
active-low reset output. The MAX6382/MAX6385/
MAX6388 have a push-pull active-high reset output,
and the MAX6383/MAX6386/MAX6389/MAX6390
have an open-drain active-low reset output. The
MAX6384/MAX6385/MAX6386 also feature a
debounced manual reset input (with internal pullup
resistor). The MAX6387/MAX6388/MAX6389 have an
auxiliary input for monitoring a second voltage. The
MAX6390 offers a manual reset input with a longer V

CC

reset timeout period (1120ms or 1200ms) and a shorter
manual reset timeout (140ms or 150ms).

The MAX6381/MAX6382/MAX6383 are available in 3-pin
SC70 packages and the MAX6384–MAX6390 are avail­able in 4-pin SC70 packages.

________________________Applications

Computers

Controllers

Intelligent Instruments

Critical µP and µC Power Monitoring

Portable/Battery-Powered Equipment

Dual Voltage Systems

Features

♦ Factory-Set Reset Threshold Voltages Ranging

from +1.58V to +4.63V in Approximately 100mV
Increments

♦ ±2.5% Reset Threshold Accuracy Over

Temperature (-40°C to +125°C)

♦ Seven Reset Timeout Periods Available: 1ms,

20ms, 140ms, 280ms, 560ms, 1120ms,
1200ms (min)

♦ 3 Reset Output Options

Active-Low Push-Pull
Active-High Push-Pull
Active-Low Open-Drain

♦ Reset Output State Guaranteed Valid

Down to V

CC

= 1V

♦ Manual Reset Input (MAX6384/MAX6385/MAX6386)

♦ Auxiliary RESET IN

(MAX6387/MAX6388/MAX6389)

♦ V

CC

Reset Timeout (1120ms or 1200ms)/Manual

Reset Timeout (140ms or 150ms) (MAX6390)

♦ Negative-Going V

CC

Transient Immunity

♦ Low Power Consumption of 6µA at +3.6V

and 3µA at +1.8V

♦ Pin Compatible with

MAX809/MAX810/MAX803/MAX6326/MAX6327/
MAX6328/MAX6346/MAX6347/MAX6348,
and MAX6711/MAX6712/MAX6713

♦ Tiny 3-Pin SC70 and 4-Pin SC70 Packages

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,

Low-Power µP Reset Circuits

________________________________________________________________ Maxim Integrated Products 1

RESET

(RESET)

1

3 V

CC

GND

MAX6381
MAX6382
MAX6383

TOP VIEW

2

SC70

( ) IS FOR MAX6382

PART TEMP. RANGE PIN-PACKAGE

MAX6381XR_ _D_-T -40°C to +125°C 3 SC70-3

MAX6382XR_ _D_-T -40°C to +125°C 3 SC70-3

MAX6383XR_ _D_-T -40°C to +125°C 3 SC70-3

Pin Configurations

19-1839; Rev 1; 04/01

Ordering Information

Pin Configurations continued at end of data sheet.

Ordering Information continued at end of data sheet.
Typical Operating Circuit appears at end of data sheet.
Selector Guide appears at end of data sheet.

Note: Insert reset threshold suffix (see Reset Threshold table)

after "XR" or "XS". Insert reset timeout delay (see Reset Timeout
Delay table) after "D" to complete the part number. Sample
stock is generally held on standard versions only (see
Standard Versions table). Standard versions have an order
increment requirement of 2500 pieces. Nonstandard versions
have an order increment requirement of 10,000 pieces.
Contact factory for availability of nonstandard versions.

*MAX6390 is available with D4 or D7 timing only.

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,
Low-Power µP Reset Circuits

2 _______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(VCC= full range, TA= -40°C to +125°C, unless otherwise specified. Typical values are at TA= +25°C.) (Note 1)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

V

CC

to GND ..........................................................-0.3V to +6.0V

RESET Open-Drain Output....................................-0.3V to +6.0V

RESET, RESET (Push-Pull Output) .............-0.3V to (V

CC

+ 0.3V)

MR, RESET IN.............................................-0.3V to (V

CC

+ 0.3V)

Input Current (V

CC

).............................................................20mA

Output Current (All Pins) .....................................................20mA

Continuous Power Dissipation (T

A

= +70°C)

3-Pin SC70 (derate 2.9mW/°C above +70°C)........235mW

4-Pin SC70 (derate 3.1mW/°C above +70°C)........245mW

Operating Temperature Range .........................-40°C to +125°C

Storage Temperature Range .............................-65°C to +150°C

Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS

Operating Voltage Range V

CC

1.0 5.5 V

VCC = 5.5V, no load 7 13

VCC = 3.6V, no load 6 11

VCC = 2.5V, no load 4 7

VCC Supply Current I

CC

VCC = 1.8V, no load 3 6

µA

TA = +25°C

V

TH

-

1.5%

V

TH

V

TH

+

1.5%

V

CC

Reset Threshold

(See Reset Thresholds table)

V

TH

TA = -40°C to +125°C

V

TH

-

2.5%

V

TH

V

TH

+

2.5%

V

Reset Threshold Tempco ∆VTH/°C 60 ppm/°C

VCC to Reset Delay

V

CC

falling at 10mV/µs from V

TH

+ 100mV

to V

TH

- 100mV

35 µs

D1 1 2

D2 20 40

D3 140 280

D5 280 560

D6 560 1120

D4 1120 2240

Reset Timeout Period
MAX6381–MAX6389
(See Reset Timeout table)

t

RP

D7 1200 2400

ms

D4 140 280

MR timeout period

D7 150 300

D4 1120 2240

Reset Timeout Period
MAX6390

t

RP

VCC timeout period

D7 1200 2400

ms

V

IL

0.3

✕

V

CC

V

IH

VTH < 4V

0.7

✕

V

CC

V

IL

0.8

MR Input Voltage

V

IH

VTH > 4V

2.4

V

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,

Low-Power µP Reset Circuits

_______________________________________________________________________________________ 3

ELECTRICAL CHARACTERISTICS (continued)

(VCC= full range, TA= -40°C to +125°C, unless otherwise specified. Typical values are at TA= +25°C.) (Note 1)

Note 1: Specifications over temperature are guaranteed by design, not production tested.

PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS

MR Minimum Input Pulse Width 1 µs
MR Glitch Rejection 100 ns
MR to Reset Delay 200 ns

MAX6381–MAX6389 32 63 100 kΩ

MR Internal Pullup Resistance

MAX6390 800 1350 2300 Ω

TA = +25°C 1.245 1.27 1.295

TA = 0°C to +85°C 1.232 1.308

Reset IN Input Threshold V

THRST

TA = -40°C to +125°C 1.219 1.321

V

RESET IN to RESET Delay

V

RESETIN

falling at 4mV/µs from

V

THRST

+ 40mV to V

THRST

- 40mV

4.5 µs

RESET IN Input Leakage Current I

RESET

IN

-50 ±1 +50 nA

VCC ≥ 4.5V, I

SINK

= 3.2mA, reset asserted 0.4

VCC ≥ 2.5V, I

SINK

= 1.2mA, reset asserted 0.3

Open-Drain RESET Output
Voltage

V

OL

VCC ≥ 1.0V, I

SINK

= 80µA, reset asserted 0.3

V

Open-Drain RESET Output
Leakage Current

I

LKG

VCC > VTH, RESET not asserted 1.0 µA

VCC ≥ 4.5V, I

SINK

= 3.2mA, reset asserted 0.4

VCC ≥ 2.5V, I

SINK

= 1.2mA, reset asserted 0.3

V

OL

VCC ≥ 1.0V, I

SINK

= 80µA, reset asserted 0.3

VCC ≥ 4.5V, I

SOURCE

= 800µA, reset not

asserted

0.8

✕

V

CC

Push-Pull RESET Output Voltage

V

OH

VCC ≥ 2.5V, I

SOURCE

= 500µA, reset not

asserted

0.8

✕

V

CC

V

VCC ≥ 4.5V, I

SOURCE

= 800µA, reset asserted

0.8

✕

V

CC

VCC ≥ 2.5V, I

SOURCE

= 500µA, reset asserted

0.8

✕

V

CC

VCC ≥ 1.8V, I

SOURCE

= 150µA, reset asserted

0.8

✕

V

CC

V

OH

VCC ≥ 1.0V, I

SOURCE

= 1µA, reset asserted

0.8

✕

V

CC

VCC ≥ 4.5V, I

SINK

= 3.2mA, reset not

asserted

0.4

Push-Pull RESET Output Voltage

V

OL

VCC ≥ 2.5V, I

SINK

= 1.2mA, reset not

asserted

0.3

V

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,
Low-Power µP Reset Circuits

4 ______________________________________________________________________________________

Typical Operating Characteristics

(TA = +25°C, unless otherwise noted.)

0

2

1

5

4

3

6

7

8

9

-40 -10 5-25 20 35 50 65 80 95 110 125

SUPPLY CURRENT vs. TEMPERATURE

(NO LOAD)

MAX6381/90 toc01

TEMPERATURE (°C)

SUPPLY CURRENT (µA)

VCC = +5.5V

VCC = +3.6V

VCC = +1.8V

V

CC

= +2.5V

25

29

27

35

33

31

37

39

41

43

-40 -10 5-25 20 35 50 65 80 95 110 125

POWER-DOWN RESET DELAY

vs. TEMPERATURE

MAX6381/90 toc02

TEMPERATURE (°C)

POWER-DOWN RESET DELAY (µs)

VCC = +3.0V

VCC = +1.8V

0.94

0.98

0.96

1.02

1.00

1.06

1.04

1.08

-40 -10 5 20-25 35 50 65 80 95 110 125

NORMALIZED POWER-UP RESET TIMEOUT

vs. TEMPERATURE

MAX6381/90 toc03

TEMPERATURE (°C)

NORMALIZED RESET TIMEOUT PERIOD

0.990

0.985

1.015

0.995

0.990

1.000

1.005

1.010

1.020

-40 -10 5 20-25 35 50 9580 11065 125

MAX6381/90 toc04

TEMPERATURE (°C)

NORMALIZED RESET THRESHOLD

NORMALIZED RESET THRESHOLD

vs. TEMPERATURE

0

0.4

0.2

0.8

0.6

1.0

1.2

063912

OUTPUT VOLTAGE LOW

vs. SINK CURRENT

MAX6381/90 toc05

I

SINK

(mA)

V

OL

(V)

VCC = +3.0V

VCC = +4.5V

0

1.0

0.5

2.0

1.5

2.5

3.0

0 500 750250 1000 1250 1500

OUTPUT VOLTAGE HIGH

vs. SOURCE CURRENT

MAX6381/90 toc06

I

SOURCE

(µA)

V

OH

(V)

VCC = +2.5V

VCC = +1.8V

450

0

1 100010010

MAXIMUM TRANSIENT DURATION

vs. RESET COMPARATOR OVERDRIVE

150

50

350

250

500

200

100

400

300

MAX6381/90 toc07

RESET COMPARATOR OVERDRIVE, VTH - VCC (mV)

MAXIMUM TRANSIENT DURATION (µs)

RESET ASSERTED
ABOVE THIS LINE

3.5

3.9

3.7

4.5

4.3

4.1

4.7

4.9

5.3

5.1

5.5

-40 -10 5-25 20 35 50 65 80 95 110 125

RESET IN TO RESET DELAY

vs. TEMPERATURE

MAX6381/90 toc08

TEMPERATURE (°C)

RESET IN DELAY (µs)

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,

Low-Power µP Reset Circuits

_______________________________________________________________________________________ 5

Pin Description

PIN

MAX6381/

MAX6383

MAX6382

MAX6384/
MAX6386/

MAX6390

MAX6385

MAX6387/

MAX6389

MAX6388

NAME FUNCTION

1 1 1 1 1 1 GND Ground

— 2 — 2 — 2 RESET

Active-High Push-Pull Reset Output. RESET
changes from low to high when any
monitored voltage (V

CC

or V

RESETIN

) drops

below the reset threshold or MR is pulled low.
RESET remains high for the reset timeout
period after monitored voltages exceed the
reset thresholds or MR is released.

2 — 2 — 2 — RESET

Active-Low Open-Drain/Push-Pull Reset
Output. RESET changes from high to low when
any monitored voltage (V

CC

or V

RESETIN

)

drops below the reset threshold or MR is
pulled low.

RESET

remains low for the reset

timeout period after the monitored voltages
exceed the reset thresholds or MR is released.
Open-drain requires an external pullup
resistor.

—— 33——MR

Active-Low Manual Reset Input. Drive low to
force a reset. Reset remains active as long
as MR is low and for the reset timeout period
after MR is released. Leave unconnected or
connect to V

CC

if unused. MR has an internal

63kΩ (1.35kΩ for MAX6390) pullup resistor to
V

CC

.

———— 33

RESET

IN

Auxiliary Reset Input. High-impedance input
to the auxiliary reset comparator. Connect
RESET IN to the center point of an external
resistor voltage-divider network to set the
reset threshold voltage. Reset asserts when
either V

CC

or RESET IN falls below its

threshold voltage.

334444V

CC

Supply Voltage for the device and input for
fixed V

CC

reset threshold monitor.

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,
Low-Power µP Reset Circuits

6 _______________________________________________________________________________________

Detailed Description

RESET Output

A µP reset input starts the µP in a known state. These
µP supervisory circuits assert reset to prevent code
execution errors during power-up, power-down, or
brownout conditions.

Reset asserts when VCCis below the reset threshold;
once VCCexceeds the reset threshold, an internal timer
keeps the reset output asserted for the reset timeout
period. After this interval, reset output deasserts. Reset
output is guaranteed to be in the correct logic state for
VCC≥ 1V.

Manual Reset Input (MAX6384/

MAX6385/MAX6386/MAX6390)

Many µP-based products require manual reset capabil­ity, allowing the operator, a test technician, or external
logic circuitry to initiate a reset. A logic low on MR
asserts reset. Reset remains asserted while MR is low,
and for the reset active timeout period (tRP) after MR
returns high. This input has an internal 63kΩ pullup
resistor (1.35kΩ for MAX6390), so it can be left uncon­nected if it is not used. MR can be driven with TTL or
CMOS logic levels, or with open-drain/collector outputs.
Connect a normally open momentary switch from MR to
GND to create a manual-reset function; external
debounce circuitry is not required. If MR is driven from
long cables or if the device is used in a noisy environ­ment, connecting a 0.1µF capacitor from MR to GND
provides additional noise immunity.

RESET IN Comparator

(MAX6387/MAX6388/MAX6389)

RESET IN is compared to an internal +1.27V reference.
If the voltage at RESET IN is less than 1.27V, reset
asserts. Use the RESET IN comparator as a user­adjustable reset detector or as a secondary power-sup­ply monitor by implementing a resistor-divider at RESET
IN (shown in Figure 1). Reset asserts when either V

CC

or RESET IN falls below its respective threshold volt­age. Use the following equation to set the threshold:

V

INTH

= V

THRST

(R1/R2 + 1)

where V

THRST

= +1.27V. To simplify the resistor selec-

tion, choose a value of R2 and calculate R1:

R1 = R2 [(V

INTH/VTHRST

) - 1]

Since the input current at RESET IN is 50nA (max),
large values can be used for R2 with no significant loss
in accuracy.

___________Applications Information

Negative-Going VCCTransients

In addition to issuing a reset to the µP during power-up,
power-down, and brownout conditions, the
MAX6381–MAX6390 are relatively immune to short dura­tion negative-going VCCtransients (glitches).

The Typical Operating Characteristics section shows the
Maximum Transient Durations vs. Reset Comparator
Overdrive, for which the MAX6381–MAX6390 do not
generate a reset pulse. This graph was generated using

Reset Thresholds (-40°C to +125°C)

SUFFIX VTH (min) VTH (nom) VTH (max)

46 4.51 4.63 4.74

45 4.39 4.50 4.61

44 4.27 4.38 4.48

43 4.19 4.30 4.41

42 4.10 4.20 4.31

41 4.00 4.10 4.20

40 3.90 4.00 4.10

39 3.80 3.90 4.00

38 3.71 3.80 3.90

37 3.61 3.70 3.79

36 3.51 3.60 3.69

35 3.41 3.50 3.59

34 3.32 3.40 3.49

33 3.22 3.30 3.38

32 3.12 3.20 3.28

31 3.00 3.08 3.15

30 2.93 3.00 3.08

29 2.85 2.93 3.00

28 2.73 2.80 2.87

27 2.63 2.70 2.77

26 2.56 2.63 2.69

25 2.44 2.50 2.56

24 2.34 2.40 2.46

23 2.26 2.31 2.37

22 2.13 2.19 2.24

21 2.05 2.10 2.15

20 1.95 2.00 2.05

19 1.85 1.90 1.95

18 1.76 1.80 1.85

17 1.62 1.67 1.71

16 1.54 1.58 1.61

a negative-going pulse applied to VCC, starting above the
actual reset threshold and ending below it by the magni­tude indicated (reset comparator overdrive). The graph
indicates the typical maximum pulse width a negative­going V

CC

transient may have without causing a reset
pulse to be issued. As the magnitude of the transient
increases (goes farther below the reset threshold), the
maximum allowable pulse width decreases. A 0.1µF
capacitor mounted as close as possible to VCCprovides
additional transient immunity.

Ensuring a Valid RESET

Output Down to V

CC

= 0

The MAX6381–MAX6390 are guaranteed to operate
properly down to VCC= 1V. In applications that require
valid reset levels down to VCC= 0, a pulldown resistor to
active-low outputs (push/pull only, Figure 2) and a

pullup resistor to active-high outputs (push/pull only) will
ensure that the reset line is valid while the reset output
can no longer sink or source current. This scheme does

not work with the open-drain outputs of the
MAX6383/MAX6386/MAX6389/MAX6390. The resistor
value used is not critical, but it must be small enough
not to load the reset output when V

CC

is above the reset

threshold. For most applications, 100kΩ is adequate.

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,

Low-Power µP Reset Circuits

_______________________________________________________________________________________ 7

MAX6387
MAX6388
MAX6389

RESET IN

( ) IS FOR MAX6388

R1

R2

RESET

(RESET)

GND

V

CC

V

IN

MAX6381
MAX6384
MAX6387

V

CC

R1
100k

RESET

GND

Figure 1. RESET IN Configuration

Figure 2. RESET Valid to V

CC

= Ground Circuit

PART

RESET

THRESHOLD

RESET TIMEOUT

46

44

31

29

26

23

22

17

MAX638_

16

D3

46

44

31

29

26

23

22

17

MAX6390

16

D4

Standard Versions

Reset Timeout Delay

SUFFIX MIN

D1 1ms

D2 20ms

D3 140ms

D5 280ms

D6 560ms

D4 1120ms

D7 1200ms

MAX6390XSD4 1120/140ms *

MAX6390XSD7 1200/150ms *

* The MAX6390 has a 1120ms or 1200ms

RESET

timeout and a

140ms or 150ms manual reset timeout

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,
Low-Power µP Reset Circuits

8 _______________________________________________________________________________________

Selector Guide

PART NUMBER

PUSH-PULL

ACTIVE-LOW

PUSH-PULL

ACTIVE-HIGH

OPEN-DRAIN
ACTIVE-LOW

MANUAL RESET

INPUT MR

RESET IN

MAX6381 X

MAX6382 X

MAX6383 X

MAX6384 X X

MAX6385 X X

MAX6386 X X

MAX6390* X X

MAX6387 X X

MAX6388 X X

MAX6389 X X

*The MAX6390 offers a VCCreset timeout of 1120ms or 1200ms (min) and a manual reset timeout of 140ms or 150ms (min).

MAX6381–MAX6390

V

CC

µP

MR *

PUSHBUTTON SWITCH

RESET

(RESET)

RESET
INPUT

GND

GND

RESET IN **

V

CORE

R1

I/O

VOLTAGE

I/O SUPPLY

CORE

VOLTAGE

R1

Chip Information

TRANSISTOR COUNT: 647

PROCESS: BiCMOS

*MRis for MAX6384/MAX6385/MAX6386/MAX6390
** RESET IN is for MAX6387/MAX6388/MAX6389

( ) are for MAX6382/MAX6385/MAX6388

( ) IS FOR MAX6388

SC70

TOP VIEW

1

2

4

3

V

CC

RESET

(RESET)

GND

MAX6387
MAX6388
MAX6389

1

2

4

3

V

CC

MR

RESET

(RESET)

GND

MAX6384
MAX6385
MAX6386
MAX6390

( ) IS FOR MAX6385

SC70

RESET IN

Pin Configurations (continued)

Typical Operating Circuit

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,

Low-Power µP Reset Circuits

_______________________________________________________________________________________ 9

PART TEMP. RANGE PIN-PACKAGE

MAX6384XS_ _D_-T -40°C to +125°C 4 SC70-4

MAX6385XS_ _D_-T -40°C to +125°C 4 SC70-4

MAX6386XS_ _D_-T -40°C to +125°C 4 SC70-4

MAX6387XS_ _D_-T -40°C to +125°C 4 SC70-4

MAX6388XS_ _D_-T -40°C to +125°C 4 SC70-4

MAX6389XS_ _D_-T -40°C to +125°C 4 SC70-4

MAX6390XS_ _D_-T* -40°C to +125°C 4 SC70-4

Ordering Information

(continued)

Note: Insert reset threshold suffix (see Reset Threshold table)
after "XR" or "XS". Insert reset timeout delay (see Reset Timeout
Delay table) after "D" to complete the part number. Sample
stock is generally held on standard versions only (see
Standard Versions table). Standard versions have an order
increment requirement of 2500 pieces. Nonstandard versions
have an order increment requirement of 10,000 pieces.
Contact factory for availability of nonstandard versions.

*MAX6390 is available with D4 or D7 timing only.

MAX6381–MAX6390

SC70, Single/Dual Low-Voltage,
Low-Power µP Reset Circuits

10 ______________________________________________________________________________________

Package Information

SC70, 4L.EPS

SC70, Single/Dual Low-Voltage,

Low-Power µP Reset Circuits

Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.

Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________ 11

© 2001 Maxim Integrated Products Printed USA is a registered trademark of Maxim Integrated Products.

MAX6381–MAX6390

Package Information (continued)

SC70, 3L.EPS
