MAXIM MAX5877 Technical data

General Description

The MAX5877 is an advanced 14-bit, 250Msps, dual
digital-to-analog converter (DAC). This DAC meets the
demanding performance requirements of signal synthesis
applications found in wireless base stations and other
communications applications. Operating from +3.3V and
+1.8V supplies, this dual DAC offers exceptional dynamic
performance such as 75dBc spurious-free dynamic range
(SFDR) at f

OUT

= 16MHz and supports update rates of

250Msps, with a power dissipation of only 287mW.
The MAX5877 utilizes a current-steering architecture

that supports a 2mA to 20mA full-scale output current
range, and allows a 0.1V

P-P

to 1V

P-P

differential output
voltage swing. The device features an integrated +1.2V
bandgap reference and control amplifier to ensure
high-accuracy and low-noise performance. A separate
reference input (REFIO) allows for the use of an exter­nal reference source for optimum flexibility and
improved gain accuracy.

The clock inputs of the MAX5877 accept both LVDS
and LVPECL-compatible voltage levels. The device fea­tures an interleaved data input that allows a single
LVDS bus to support both DACs. The MAX5877 is avail­able in a 68-pin QFN package with an exposed pad
(EP) and is specified for the extended temperature
range (-40°C to +85°C).

Refer to the MAX5876 and MAX5878 data sheets for
pin-compatible 12-bit and 16-bit versions of the
MAX5877, respectively. Refer to the MAX5874 data
sheet for a CMOS-compatible version of the MAX5877.

Applications

Base Stations: Single/Multicarrier UMTS, CDMA, GSM
Communications: Fixed Broadband Wireless Access,

Point-to-Point Microwave
Direct Digital Synthesis (DDS)
Cable Modem Termination Systems (CMTS)
Automated Test Equipment (ATE)
Instrumentation

Features

♦ 250Msps Output Update Rate
♦ Noise Spectral Density = -160dBFS/Hz

at f

OUT

= 16MHz

♦ Excellent SFDR and IMD Performance

SFDR = 75dBc at f

OUT

= 16MHz (to Nyquist)

SFDR = 71dBc at f

OUT

= 80MHz (to Nyquist)

IMD = -87dBc at f

OUT

= 10MHz

IMD = -73dBc at f

OUT

= 80MHz

♦ ACLR = 75dB at f

OUT

= 61MHz

♦ 2mA to 20mA Full-Scale Output Current
♦ LVDS-Compatible Digital and Clock Inputs
♦ On-Chip +1.20V Bandgap Reference
♦ Low 287mW Power Dissipation
♦ Compact 68-Pin QFN-EP Package (10mm x 10mm)
♦ Evaluation Kit Available (MAX5878EVKIT)

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

________________________________________________________________ Maxim Integrated Products 1

Pin Configuration

Ordering Information

19-3632; Rev 2; 3/07

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

*EP = Exposed pad.
+ = Lead-free package. D = Dry pack.

EVALUATION KIT

AVAILABLE

PART

TEMP RANGE

PIN-

PKG

CODE

MAX5877EGK-D

G6800-4

MAX5877EGK+D

G6800-4

Selector Guide

PART

RESOLUTION

(BITS)

UPDATE

LOGIC

INPUTS

MAX5873 12 200 CMOS

MAX5874 14 200 CMOS

MAX5875 16 200 CMOS

MAX5876 12 250 LVDS

MAX5877 14 250 LVDS

MAX5878 16 250 LVDS

5859606162 5455565763

38

39

40

41

42

43

44

45

46

47

DV

DD3.3

AV

DD1.8

B5N

QFN

TOP VIEW

B5P

DV

DD1.8

B6N

B6P

B7N

B7P

B8N

B8P

B9N

5253

B9P

B10N

DACREF

AV

DD3.3

GND

GND

AV

DD3.3

OUTQP

OUTQN

GND

GND

OUTIP

OUTIN

AV

DD3.3

GND

AV

DD3.3

B12P

B13N

B13P

SELIQN

SELIQP

XORP

XORN

PD

TORB

CLKP

35

36

37 CLKN

GND

AV

CLK

GND

N.C.

N.C.

N.C.

N.C.

REFIO

GND

AV

DD3.3

GND

GND

B0N

B0P

B1N

B1P

48 B12N

B2N

64

B4P

656667

B3N

B3P

B4N

68

B2P

2322212019 2726252418 2928 323130

GND

AV

DD1.8

3433

49

50

B11N

B11P

51 B10P

11

10

9

8

7

6

5

4

3

2

16

15

14

13

12

1

FSADJ 17

MAX5877

PACKAGE

-40°C to +85°C 68 QFN-EP*

-40°C to +85°C 68 QFN-EP*

RATE (Msps)

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

2 _______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

AV

DD1.8

, DV

DD1.8

to GND, DACREF...................-0.3V to +2.16V

AV

DD3.3

, DV

DD3.3

, AV

CLK

to GND, DACREF........-0.3V to +3.9V

REFIO, FSADJ to

GND, DACREF..................................-0.3V to (AV

DD3.3

+ 0.3V)

OUTIP, OUTIN, OUTQP,

OUTQN to GND, DACREF...................-1V to (AV

DD3.3

+ 0.3V)

CLKP, CLKN to GND, DACREF..............-0.3V to (AV

CLK

+ 0.3V)

B13P/B13N–B0P/B0N, XORN, XORP, SELIQN,

SELIQP to GND, DACREF ...................-0.3V to (DV

DD1.8

+ 0.3V)

TORB, PD to GND, DACREF ...............-0.3V to (DV

DD3.3

+ 0.3V)

Continuous Power Dissipation (T

A

= +70°C)
68-Pin QFN-EP

(derate 41.7mW/°C above +70°C) (Note 1)............3333.3mW

Thermal Resistance

θJA(Note 1)...................................+24°C/W

Operating Temperature Range ......................... -40°C to +85°C

Junction Temperature .................................................... +150°C

Storage Temperature Range ........................... -60°C to +150°C

Lead Temperature (soldering, 10s) ............................... +300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

STATIC PERFORMANCE

Resolution 14 Bits

Integral Nonlinearity INL Measured differentially

LSB

Differential Nonlinearity DNL Measured differentially

LSB

Offset Error OS

%FS

Offset-Drift Tempco

ppm/°C

Full-Scale Gain Error GE

FS

External reference

%FS

Internal reference

Gain-Drift Tempco

External reference

ppm/°C

Full-Scale Output Current

(Note 3) 2 20 mA

Output Compliance Single-ended

V

Output Resistance R

OUT

1MΩ

Output Capacitance C

OUT

5pF

DYNAMIC PERFORMANCE

Clock Frequency f

CLK

2

MHz

Output Update Rate f

DACfDAC

= f

CLK

/ 2 1

Msps

f

DAC

= 150MHz f

OUT

= 16MHz, -12dBFS

Noise Spectral Density

f

DAC

= 250MHz f

OUT

= 80MHz, -12dBFS

dBFS/

Hz

ELECTRICAL CHARACTERISTICS

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, GND = 0, f

CLK

= 2 x f

DAC

, external reference V

REFIO

= +1.25V, out-

put load 50Ω double-terminated, transformer-coupled output, I

OUTFS

= 20mA, TA = T

MIN

to T

MAX

, unless otherwise noted. Typical values

are at T

A

= +25°C.) (Note 2)

Note 1: Thermal resistance based on a multilayer board with 4 x 4 via array in exposed paddle area.

±0.5

±0.2

-0.025 ±0.001 +0.025

±10

-4.6 -0.6 +4.6

±100

±50

I

OUTFS

-0.5 +1.1

-160

-157

500

250

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

_______________________________________________________________________________________ 3

ELECTRICAL CHARACTERISTICS (continued)

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, GND = 0, f

CLK

= 2 x f

DAC

, external reference V

REFIO

= +1.25V, out-

put load 50Ω double-terminated, transformer-coupled output, I

OUTFS

= 20mA, TA = T

MIN

to T

MAX

, unless otherwise noted. Typical values

are at T

A

= +25°C.) (Note 2)

PARAMETER

CONDITIONS

UNITS

f

OUT

= 1MHz, 0dBFS 98

f

OUT

= 1MHz, -6dBFS 86

f

OUT

= 1MHz, -12dBFS 78

f

OUT

= 10MHz, -12dBFS 77

f

DAC

= 100MHz

f

OUT

= 30MHz, -12dBFS 78

f

OUT

= 10MHz, -12dBFS 75

f

OUT

= 16MHz, -12dBFS 66 75

f

OUT

= 50MHz, -12dBFS 74

f

DAC

= 200MHz

f

OUT

= 80MHz, -12dBFS 71

f

OUT

= 10MHz, -12dBFS 74

f

OUT

= 50MHz, -12dBFS 72

f

OUT

= 80MHz, -12dBFS 71

Spurious-Free Dynamic Range
to Nyquist

SFDR

f

DAC

= 250MHz

68

dBc

Spurious-Free Dynamic Range,
25MHz Bandwidth

SFDR f

DAC

= 150MHz f

OUT

= 16MHz, -12dBFS 80

dBc

f

DAC

= 100MHz

f

OUT1

= 9MHz, -7dBFS;

f

OUT2

= 10MHz, -7dBFS

-87

Two-Tone IMD

f

DAC

= 200MHz

f

OUT1

= 79MHz, -7dBFS;

f

OUT2

= 80MHz, -7dBFS

-73

dBc

Four-Tone IMD, 1MHz

Frequency Spacing, GSM Model

f

DAC

= 150MHz f

OUT

= 16MHz, -12dBFS -94

dBc

Adjacent Channel Leakage Power
Ratio 3.84MHz Bandwidth,
W-CDMA Model

ACLR

f

DAC

=

184.32MHz

f

OUT

= 61.44MHz 75 dB

Output Bandwidth

(Note 4)

MHz

INTER-DAC CHARACTERISTICS

f

OUT

= DC - 80MHz

Gain Matching

f

OUT

= DC

dB

Gain-Matching Tempco

ppm/°C

Phase Matching

f

OUT

= 60MHz

D egr ees

Phase-Matching Tempco

f

OUT

= 60MHz

D eg r ees/

°C

Channel-to-Channel Crosstalk f

DAC

= 200Msps, f

OUT

= 50MHz, 0dBFS 90 dB

REFERENCE

Internal Reference Voltage Range

1.2

V

SYMBOL

MIN TYP MAX

TTIMD

FTIMD

f

= 100MHz, -12dBFS

OUT

BW

-1dB

∆Gain

∆Gain/°C ±20

-0.25 +0.01 +0.25

∆Phase

∆Phase/°C

V

REFIO

1.14

240

±0.2

±0.25

±0.002

1.26

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

4 _______________________________________________________________________________________

ELECTRICAL CHARACTERISTICS (continued)

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, GND = 0, f

CLK

= 2 x f

DAC

, external reference V

REFIO

= +1.25V, out-

put load 50Ω double-terminated, transformer-coupled output, I

OUTFS

= 20mA, TA = T

MIN

to T

MAX

, unless otherwise noted. Typical values

are at T

A

= +25°C.) (Note 2)

PARAMETER

CONDITIONS

UNITS

Reference Input Compliance
Range

V

Reference Input Resistance

10 kΩ

Reference Voltage Drift

ppm/°C

ANALOG OUTPUT TIMING (See Figure 4)

Output Fall Time t

FALL

90% to 10% (Note 5) 0.7 ns

Output Rise Time t

RISE

10% to 90% (Note 5) 0.7 ns

Output-Voltage Settling Time

Output settles to 0.025% FS (Note 5) 14 ns

Output Propagation Delay t

PD

Excluding data latency (Note 5) 1.1 ns

Glitch Impulse Measured differentially 1

pV•s

I

OUTFS

= 2mA 30

Output Noise n

OUT

I

OUTFS

= 20mA 30

pA/√Hz

TIMING CHARACTERISTICS

Data to Clock Setup Time

Referenced to rising edge of clock (Note 6)

ns

Data to Clock Hold Time

Referenced to rising edge of clock (Note 6) 2.0 ns

Latency to I output 9

Data Latency

Latency to Q output 8

Clock

Cycles

Minimum Clock Pulse-Width High

t

CH

CLKP, CLKN 0.9 ns

Minimum Clock Pulse-Width Low

t

CL

CLKP, CLKN 0.9 ns

LVDS LOGIC INPUTS (B13P/B13N–B0P/B0N, XORN, XORP, SELIQN, SELIQP)

Differential Input-Logic High V

IH

mV

Differential Input-Logic Low V

IL

mV

Common-Mode Voltage Range V

CMR

V

Differential Input Resistance R

IN

(Note 7)

Ω

Input Capacitance C

IN

2.5 pF

CMOS LOGIC INPUTS (PD, TORB)

Input-Logic High V

IH

0.7 x
V

Input-Logic Low V

IL

0.3 x
V

Input Leakage Current I

IN

-20 1

µA

PD, TORB Internal Pulldown
Resistance

V

PD

= V

TORB

= 3.3V 1.5 MΩ

Input Capacitance C

IN

2.5 pF

CLOCK INPUTS (CLKP, CLKN)

Sine wave

Differential Input
Voltage Swing

Square wave

V

P-P

SYMBOL

MIN TYP MAX

V

REFIOCR

R

REFIO

TCO

t

SETTLE

REF

t

SETUP

t

HOLD

0.125 1.260

±25

-1.2

-100

1.125 1.375

110

DV

DD3.3

> 1.5

> 0.5

100

DV

DD3.3

+20

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

_______________________________________________________________________________________ 5

ELECTRICAL CHARACTERISTICS (continued)

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, GND = 0, f

CLK

= 2 x f

DAC

, external reference V

REFIO

= +1.25V, out-

put load 50Ω double-terminated, transformer-coupled output, I

OUTFS

= 20mA, TA = T

MIN

to T

MAX

, unless otherwise noted. Typical values

are at T

A

= +25°C.) (Note 2)

Note 2: Specifications at T

A

≥ +25°C are guaranteed by production testing. Specifications at TA< +25°C are guaranteed by design.

Note 3: Nominal full-scale current I

OUTFS

= 32 x I

REF

.

Note 4: This parameter does not include update-rate-dependent effects of sin(x)/x filtering inherent in the MAX5877.
Note 5: Parameter measured single-ended into a 50Ω termination resistor.
Note 6: Not production tested. Guaranteed by design.
Note 7: No termination resistance between XORP and XORN.
Note 8: A differential clock input slew rate of > 100V/µs is required to achieve the specified dynamic performance.
Note 9: Parameter defined as the change in midscale output caused by a ±5% variation in the nominal supply voltage.

PARAMETER

CONDITIONS

UNITS

Differential Input Slew Rate

(Note 8)

V/µs

External Common-Mode Voltage
Range

V

COM

±0.3

V

Input Resistance R

CLK

5kΩ

Input Capacitance C

CLK

2.5 pF

POWER SUPPLIES

3.3

Analog Supply Voltage Range

1.8

V

3.3

Digital Supply Voltage Range

1.8

V

Clock Supply Voltage Range

3.3

V

f

DAC

= 250Msps, f

OUT

= 16MHz 52 58 mA

Power-down 1 µA

f

DAC

= 250Msps, f

OUT

= 16MHz 30 36 mA

Analog Supply Current

Power-down 1 µA

f

DAC

= 250Msps, f

OUT

= 16MHz 0.2 1 mA

Power-down 1 µA

f

DAC

= 250Msps, f

OUT

= 16MHz 34 40 mA

Digital Supply Current

Power-down 4 µA

f

DAC

= 250Msps, f

OUT

= 16MHz

mW

Power Dissipation P

DISS

Power-down 16 µW

Power-Supply Rejection Ratio PSRR

AV

DD3.3

= AV

CLK

= DV

DD3.3

= +3.3V ±5%

(Notes 8, 9)

%FS/V

SYMBOL

SR

CLK

AV

DD3.3

AV

DD1.8

DV

DD3.3

DV

DD1.8

AV

CLK

I

AVDD3.3

+ I

AVCLK

I

AVDD1.8

I

DVDD3.3

MIN TYP MAX

>100

AV

CLK

3.135

1.710

3.135

1.710

3.135

/ 2

3.465

1.890

3.465

1.890

3.465

I

DVDD1.8

287 331

-0.1 +0.1

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

6 _______________________________________________________________________________________

SINGLE-TONE SFDR vs. OUTPUT

FREQUENCY (f

DAC

= 50Msps)

MAX5877 toc01

f

OUT

(MHz)

SFDR (dBc)

2015105

20

40

60

80

100

0

025

-12dBFS

-6dBFS

0dBFS

SINGLE-TONE SFDR vs. OUTPUT

FREQUENCY (f

DAC

= 100Msps)

MAX5877 toc02

f

OUT

(MHz)

SFDR (dBc)

40302010

20

40

60

80

100

0

050

-12dBFS

-6dBFS

0dBFS

SINGLE-TONE SFDR vs. OUTPUT

FREQUENCY (f

DAC

= 150Msps)

MAX5877 toc03

f

OUT

(MHz)

SFDR (dBc)

60453015

20

40

60

80

100

0

075

-12dBFS

-6dBFS

0dBFS

Typical Operating Characteristics

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, external reference, V

REFIO

= +1.25V, RL = 50Ω double-terminated,

I

OUTFS

= 20mA, TA= +25°C, unless otherwise noted.)

SINGLE-TONE SFDR vs. OUTPUT

FREQUENCY (f

DAC

= 200Msps)

MAX5877 toc04

f

OUT

(MHz)

SFDR (dBc)

80604020

20

40

60

80

100

0

0100

-12dBFS

-6dBFS

0dBFS

SINGLE-TONE SFDR vs. OUTPUT

FREQUENCY (f

DAC

= 250Msps)

MAX5877 toc05

f

OUT

(MHz)

SFDR (dBc)

100755025

20

40

60

80

100

0

0125

-12dBFS

-6dBFS

0dBFS

TWO-TONE IMD vs. OUTPUT FREQUENCY

(1MHz CARRIER SPACING, f

DAC

= 100Msps)

MAX5877 toc06

f

OUT

(MHz)

TWO-TONE IMD (dBc)

353025201510

-90

-85

-100

-80

-95

540

-12dBFS

-6dBFS

TWO-TONE INTERMODULATION

DISTORTION (f

DAC

= 100Msps)

MAX5877 toc07

f

OUT

(MHz)

OUTPUT POWER (dBFS)

3432302826

-80

-60

-40

-20

0

-100
24 36

BW = 12MHz

2 x fT1 - f

T2

2 x fT2 - f

T1

f

T1

f

T2

fT1 = 28.9795MHz
f

T2

= 30.0049MHz

TWO-TONE IMD vs. OUTPUT FREQUENCY

(1MHz CARRIER SPACING, f

DAC

= 200Msps)

MAX5877 toc08

f

OUT

(MHz)

TWO-TONE IMD (dBc)

70605040302010

-95

-90

-85

-80

-75

-70

-65

-60

-100
080

-12dBFS

-6dBFS

SFDR vs. FULL-SCALE OUTPUT CURRENT

(f

DAC

= 250Msps)

MAX5877 toc09

f

OUT

(MHz)

SFDR (dBc)

100755025

20

40

60

80

100

0

0125

A

OUT

= -6dBFS

10mA

5mA

20mA

SFDR vs. TEMPERATURE

(f

DAC

= 250Msps)

MAX5877 toc10

f

OUT

(MHz)

SFDR (dBc)

100755025

75

80

85

90

70

0125

A

OUT

= -6dBFS

TA = +85°C

TA = +25°C

TA = -40°C

INTEGRAL NONLINEARITY

vs. DIGITAL INPUT CODE

MAX5877 toc11

DIGITAL INPUT CODE

INL (LSB)

12,28881924096

-0.5

0

0.5

1.0

0 16,384

-1.0

DIFFERENTIAL NONLINEARITY

vs. DIGITAL INPUT CODE

MAX5877 toc12

DIGITAL INPUT CODE

DNL (LSB)

12,28881924096

-0.3

-0.2

-0.1

0

0.1

0.2

0.3

0.4

-0.4
016,384

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

_______________________________________________________________________________________ 7

Typical Operating Characteristics (continued)

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, external reference, V

REFIO

= +1.25V, RL = 50Ω double-terminated,

I

OUTFS

= 20mA, TA= +25°C, unless otherwise noted.)

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

8 _______________________________________________________________________________________

Typical Operating Characteristics (continued)

(AV

DD3.3

= DV

DD3.3

= AV

CLK

= +3.3V, AV

DD1.8

= DV

DD1.8

= +1.8V, external reference, V

REFIO

= +1.25V, RL = 50Ω double-terminated,

I

OUTFS

= 20mA, TA= +25°C, unless otherwise noted.)

POWER DISSIPATION vs. DAC

UPDATE RATE (f

OUT

= 10MHz)

MAX5877 toc13

f

DAC

(Msps)

POWER DISSIPATION (mW)

200 25015010050

200

220

240

280

260

300

180

0

A

OUT

= 0dBFS

POWER DISSIPATION vs. SUPPLY VOLTAGE

(f

DAC

= 100Msps, f

OUT

= 10MHz)

MAX5877 toc14

SUPPLY VOLTAGE (V)

POWER DISSIPATION (mW)

3.465

3.300

210

220

225

205

3.135

A

OUT

= 0dBFS

EXTERNAL REFERENCE

INTERNAL REFERENCE

215

FOUR-TONE POWER RATIO PLOT

(f

DAC

= 150MHz)

MAX5877 toc15

f

OUT

(MHz)

OUTPUT POWER (dBFS)

3634323028

-80

-60

-40

-20

0

-100
26 38

BW = 12MHz

f

T1

fT2f

T3

f

T4

fT1 = 29.6997MHz
f

T2

= 30.7251MHz

f

T3

= 31.6040MHz

f

T4

= 32.4829MHz

ACLR FOR WCDMA MODULATION,

SINGLE-CARRIER ACLR

MAX5877 toc16

9.216MHz/div

ANALOG OUTPUT POWER (dBm)

-110

-100

-90

-80

-70

-60

-50

-40

-30

1MHz 92.16MHz

f

DAC

= 184.32Mbps

f

CARRIER

= 30.72MHz

ACLR = +80dB

-20

ACLR FOR WCDMA MODULATION

TWO-CARRIER ACLR

MAX5877 toc17

3.05MHz/div

ANALOG OUTPUT POWER (dBm)

-110

-120

-100

-90

-80

-70

-60

-50

-40

-30

f

DAC

= 245.76Msps

f

CENTER

= 30.72MHz

ACLR = +77dB

ACLR FOR WCDMA MODULATION

TWO-CARRIER ACLR

MAX5877 toc18

3.05MHz/div

ANALOG OUTPUT POWER (dBm)

-110

-100

-90

-80

-70

-60

-50

-30

-120

f

DAC

= 184.32Msps

f

CENTER

= 30.72MHz

ACLR = +77dB

-40

WCDMA BASEBAND ACLR

(f

DAC

= 245.76Msps)

MAX5877 toc19

NUMBER OF CHANNELS

ACLR (dB)

4321

76

77

79

81

82

75

81.4

80.2

80.9

79.5

79.5

78.9

77.2

77.2

ALTERNATE

ADJACENT

78

80

79.0

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

_______________________________________________________________________________________ 9

Pin Description

PIN NAME FUNCTION

1 B2N Complementary Data Bit 2

2 B1P Data Bit 1

3 B1N Complementary Data Bit 1

4 B0P Data Bit 0 (LSB)

5 B0N Complementary Data Bit 0 (LSB)

6–9 N.C. No Connection. Leave floating or connect to GND.

10, 12, 13, 15,
20, 23, 26, 27,

30, 33, 36

GND Ground

11 DV

DD3.3

Digital Supply Voltage. Accepts a 3.135V to 3.465V supply voltage range. Bypass with a 0.1µF
capacitor to GND.

14, 21, 22, 31,

32

AV

DD3.3

Analog Supply Voltage. Accepts a 3.135V to 3.465V supply voltage range. Bypass each pin with
a 0.1µF capacitor to GND.

16 REFIO

Reference I/O. Output of the internal 1.2V precision bandgap reference. Bypass with a 1µF
capacitor to GND. REFIO can be driven with an external reference source. See Table 1.

17 FSADJ

Full-Scale Adjust Input. This input sets the full-scale output current of the DAC. For a 20mA full­scale output current, connect a 2kΩ resistor between FSADJ and DACREF. See Table 1.

18 DACREF

Current-Set Resistor Return Path. Internally connected to GND. Do not use as an external

ground connection.

19, 34 AV

DD1.8

Analog Supply Voltage. Accepts a 1.71V to 1.89V supply voltage range. Bypass each pin with a

0.1µF capacitor to GND.

24 OUTQN Complementary Q-DAC Output. Negative terminal for current output.

25 OUTQP Q-DAC Output. Positive terminal for current output.

28 OUTIN Complementary I-DAC Output. Negative terminal for current output.

29 OUTIP I-DAC Output. Positive terminal for current output.

35 AV

CLK

Clock Supply Voltage. Accepts a 3.135V to 3.465V supply voltage range. Bypass with a 0.1µF
capacitor to GND.

37 CLKN

Complementary Converter Clock Input. Negative input terminal for LVDS/LVPECL-compatible
differential converter clock. Internally biased to AV

CLK

/ 2.

38 CLKP

Converter Clock Input. Positive input terminal for LVDS/LVPECL-compatible differential converter
clock. Internally biased to AV

CLK

/ 2.

39 TORB

Two’s-Complement/Binary Select Input. Set TORB to a CMOS-logic-high level to indicate a two’s­complement input format. Set TORB to a CMOS-logic-low level to indicate an offset binary input
format. TORB has an internal pulldown resistor.

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

10 ______________________________________________________________________________________

Pin Description (continued)

PIN NAME FUNCTION

40 PD

Power-Down Input. Set PD to a CMOS-logic-high level to force the DAC into power-down mode.
Set PD to a CMOS-logic-low level for normal operation. PD has an internal pulldown resistor.

41 XORN

Complementary LVDS DAC Exclusive-OR Select Input. Set XORN high and XORP low to allow
the data stream to pass unchanged to the DAC input. Set XORN low and XORP high to invert the
DAC input data. If unused, connect XORN to DV

DD1.8

.

42 XORP

LVDS DAC Exclusive-OR Select Input. Set XORN high and XORP low to allow the data stream to
pass unchanged to the DAC input. Set XORN low and XORP high to invert the DAC input data. If
unused, connect XORP to GND.

43 SELIQP

LVDS DAC Select Input. Set SELIQN low and SELIQP high to direct data to the I-DAC outputs.
Set SELIQP low and SELIQN high to direct data to the Q-DAC outputs.

44 SELIQN

Complementary LVDS DAC Select Input. Set SELIQN low and SELIQP high to direct data to the
I-DAC outputs. Set SELIQP low and SELIQN high to direct data to the Q-DAC outputs.

45 B13P Data Bit 13 (MSB)

46 B13N Complementary Data Bit 13 (MSB)

47 B12P Data Bit 12

48 B12N Complementary Data Bit 12

49 B11P Data Bit 11

50 B11N Complementary Data Bit 11

51 B10P Data Bit 10

52 B10N Complementary Data Bit 10

53 B9P Data Bit 9

54 B9N Complementary Data Bit 9

55 B8P Data Bit 8

56 B8N Complementary Data Bit 8

57 B7P Data Bit 7

58 B7N Complementary Data Bit 7

59 B6P Data Bit 6

60 B6N Complementary Data Bit 6

61 DV

DD1.8

Digital Supply Voltage. Accepts a 1.71V to 1.89V supply voltage range. Bypass with a 0.1µF
capacitor to GND.

62 B5P Data Bit 5

63 B5N Complementary Data Bit 5

64 B4P Data Bit 4

65 B4N Complementary Data Bit 4

66 B3P Data Bit 3

67 B3N Complementary Data Bit 3

68 B2P Data Bit 2

—EPExposed Pad. Must be connected to GND through a low-impedance path.

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

______________________________________________________________________________________ 11

LATCH

XOR/

DECODE

LATCH

LVDS

RECEIVER

LATCH

LATCH DAC

OUTIP

OUTIN

LATCH

XOR/

DECODE

LATCH LATCH DAC

OUTQP

OUTQN

FSADJ

TORB

SELIQN

XORP

XORN

AV

CLK

CLKN

CLKP

CLK

INTERFACE

DATA13–

DATA0

+1.2V

REFERENCE

POWER-DOWN

BLOCK

REFIO

DACREF

PD GND

DV

DD1.8

DV

DD3.3

AV

DD1.8

AV

DD3.3

SELIQP

MAX5877

Figure 1. MAX5877 High-Performance, 14-Bit, Dual Current-Steering DAC

Detailed Description

Architecture

The MAX5877 high-performance, 14-bit, dual current­steering DAC (Figure 1) operates with DAC update rates
up to 250Msps. The converter consists of input registers
and a demultiplexer for single-port operation, followed by
a current-steering array. During operation, the input data
registers demultiplex the single-port data bus. The cur­rent-steering array generates differential full-scale cur­rents in the 2mA to 20mA range. An internal
current-switching network, in combination with external
50Ω termination resistors, converts the differential output
currents into dual differential output voltages with a 0.1V
to 1V peak-to-peak output voltage range. An integrated

+1.2V bandgap reference, control amplifier, and user­selectable external resistor determine the data convert­er’s full-scale output range.

Reference Architecture and Operation

The MAX5877 supports operation with the internal
+1.2V bandgap reference or an external reference volt­age source. REFIO serves as the input for an external,
low-impedance reference source. REFIO also serves as
a reference output when the DAC operates in internal
reference mode. For stable operation with the internal
reference, decouple REFIO to GND with a 1µF capaci­tor. Due to its limited output drive capability, buffer
REFIO with an external amplifier when driving large
external loads.

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

12 ______________________________________________________________________________________

The MAX5877’s reference circuit (Figure 2) employs a
control amplifier to regulate the full-scale current
I

OUTFS

for the differential current outputs of the DAC.

Calculate the full-scale output current as follows:

where I

OUTFS

is the full-scale output current of the

DAC. R

SET

(located between FSADJ and DACREF)
determines the amplifier’s full-scale output current for
the DAC. See Table 1 for a matrix of different I

OUTFS

and R

SET

selections.

Analog Outputs (OUTIP, OUTIN, OUTQP,

OUTQN)

Each MAX5877 DAC outputs two complementary cur­rents (OUTIP/N, OUTQP/N) that operate in a single­ended or differential configuration. A load resistor
converts these two output currents into complementary
single-ended output voltages. A transformer or a differ­ential amplifier configuration converts the differential
voltage existing between OUTIP (OUTQP) and OUTIN
(OUTQN) to a single-ended voltage. If not using a
transformer, the recommended termination from the
output is a 25Ω termination resistor to ground and a
50Ω resistor between the outputs.

To generate a single-ended output, select OUTIP (or
OUTQP) as the output and connect OUTIN (or OUTQN)
to GND. SFDR degrades with single-ended operation
or increased output swing. Figure 3 displays a simpli­fied diagram of the internal output structure of the
MAX5877.

Clock Inputs (CLKP, CLKN)

The MAX5877 features flexible differential clock inputs
(CLKP, CLKN) operating from a separate supply
(AV

CLK

) to achieve optimum jitter performance. Drive
the differential clock inputs from a single-ended or a
differential clock source. For single-ended operation,
drive CLKP with a logic source and bypass CLKN to
GND with a 0.1µF capacitor.

CLKP and CLKN are internally biased to AV

CLK

/ 2. This
facilitates the AC-coupling of clock sources directly to
the device without external resistors to define the DC
level. The dynamic input resistance from CLKP and
CLKN to ground is 5kΩ.

I

V

R

OUTFS

REFIO

SET

=× ×













−32 1

1

2

14

Table 1. I

OUTFS

and R

SET

Selection
Matrix Based on a Typical +1.200V
Reference Voltage

R

SET

(kΩ)

FULL-SCALE

CURRENT I

OUTFS

(mA)

1% EIA STD

2 19.2 19.1

5 7.68 7.5

10 3.84 3.83

15 2.56 2.55

20 1.92 1.91

Figure 2. Reference Architecture, Internal Reference
Configuration

I

OUT

I

OUT

OUTIN OUTIP

CURRENT

SOURCES

CURRENT

SWITCHES

AV

DD

Figure 3. Simplified Analog Output Structure

CALCULATED

+1.2V

REFERENCE

Ω

10k

REFIO

1µF

I

REF

I

= V

REF

REFIO

FSADJ

R

SET

DACREF

/ R

SET

GND

CURRENT-SOURCE

OUTIP

ARRAY DAC

OUTIN

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

______________________________________________________________________________________ 13

SELIQP

CLKP-CLKN

DATA

IN

I0 Q2I2Q1I1 I3 Q3Q0

t

S

t

H

OUTI

OUTQ

t

PD

I0 - 5

I0 - 4 I0 - 2

I0 - 3

I0 - 6

Q0 - 6

Q0 - 5

Q0 - 4

Q0 - 3 Q0 - 2

SELIQN

Figure 4. Timing Diagram

Data Timing Relationship

Figure 4 displays the timing relationship between digital
LVDS data, clock, and output signals. The MAX5877
features a 2.0ns hold, a -1.2ns setup, and a 1.1ns prop­agation delay time. A nine (eight)-clock-cycle latency
exists between CLKP/CLKN and OUTIP/OUTIN
(OUTQP/OUTQN).

LVDS-Compatible Digital Inputs

(B13P/B13N–B0P/B0N, XORP, XORN,

SELIQP, SELIQN)

The MAX5877 latches B13P/N–B0P/N, XORP/N, and
SELIQP/N data on the rising edge of the clock. A logic­high signal on SELIQP and a logic-low signal on
SELIQN directs data onto the I-DAC inputs. A logic-low
signal on SELIQP and a logic-high signal on SELIQN
directs data onto the Q-DAC inputs.

The MAX5877 features LVDS receivers on the bus input
interface with internal 110Ω termination resistors. See

Figure 5. XORP and XORN are not internally terminated.
These LVDS inputs (B13P/N–B0P/N) allow for a low differ­ential voltage swing with low constant power consump­tion. A 1.25V common-mode level and 250mV differential
input swing can be applied to the B13P/N–B0P/N,
XORP/N, and SELIQP/N inputs.

The MAX5877 includes LVDS-compatible exclusive-OR
inputs (XORP, XORN). Input data (all bits) is compared
with the bits applied to XORP and XORN through exclu­sive-OR gates. Setting XORP high and XORN low inverts
the input data. Setting XORP low and XORN high leaves
the input data noninverted. By applying a previously
encoded pseudo-random bit stream to the data input
and applying decoding to XORP/XORN, the digital input
data can be decorrelated from the DAC output, allowing
for the troubleshooting of possible spurious or harmonic
distortion degradation due to digital feedthrough on the
printed circuit board (PCB). If XOR functionality is not
required, connect XORP to GND and XORN to DV

DD1.8

.

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

14 ______________________________________________________________________________________

CMOS-Compatible Digital Inputs

Input Data Format Select (TORB)

The TORB input selects between two’s-complement or
offset binary digital input data. Set TORB to a CMOS­logic-high level to indicate a two’s-complement input
format. Set TORB to a CMOS-logic-low level to indicate
an offset binary input format.

Power-Down Operation (PD)

The MAX5877 also features an active-high power-down
mode that reduces the DAC’s digital current consump­tion from 34mA to less than 5µA and the analog current
consumption from 82mA to less than 2µA. Set PD high
to power down the MAX5877. Set PD low for normal
operation.

When powered down, the MAX5877 reduces the overall
power consumption to less than 16µW. The MAX5877
requires 10ms to wake up from power-down and enter
a fully operational state. The PD integrated pulldown
resistor activates the MAX5877 if PD is left floating.

Applications Information

CLK Interface

The MAX5877 features a flexible differential clock input
(CLKP, CLKN) with a separate supply (AV

CLK

) to
achieve optimum jitter performance. Use an ultra-low
jitter clock to achieve the required noise density. Clock
jitter must be less than 0.5ps

RMS

for meeting the speci­fied noise density. For that reason, the CLKP/CLKN
input source must be designed carefully. The differen­tial clock (CLKN and CLKP) input can be driven from a
single-ended or a differential clock source. Differential
clock drive is required to achieve the best dynamic
performance from the DAC. For single-ended opera­tion, drive CLKP with a low noise source and bypass
CLKN to GND with a 0.1µF capacitor.

Figure 6 shows a convenient and quick way to apply a
differential signal created from a single-ended source
(e.g., HP 8662A signal generator) and a wideband trans­former. Alternatively, these inputs can be driven from a
CMOS-compatible clock source; however, it is recom­mended to use sinewave or AC-coupled differential
ECL/PECL or LVDS drive for best dynamic performance.

110Ω

TO
DECODE
LOGIC

D

D

Q

Q

B13P–B0P,

SELIQP

B13N–B0N,

SELIQN

CLOCK

MAX5877

Figure 5. Simplified LVDS-Compatible Digital Input Structure

DIGITAL INPUT CODE

OFFSET BINARY TWO’S COMPLEMENT

OUT_P OUT_N

00 0000 0000 0000 10 0000 0000 0000 0 I

OUTFS

01 1111 1111 1111 00 0000 0000 0000 I

OUTFS

/ 2 I

OUTFS

/ 2

11 1111 1111 1111 01 1111 1111 1111 I

OUTFS

0

Table 2. DAC Output Code Table

WIDEBAND RF TRANSFORMER

PERFORMS SINGLE-ENDED-TO-

DIFFERENTIAL CONVERSION

SINGLE-ENDED
CLOCK SOURCE
(e.g., HP 8662A)

GND

1:1

25Ω

25Ω

CLKP

CLKN

TO DAC

0.1µF

0.1µF

Figure 6. Differential Clock-Signal Generation

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

______________________________________________________________________________________ 15

Differential-to-Single-Ended Conversion

Using a Wideband RF Transformer

Use a pair of transformers (Figure 7) or a differential
amplifier configuration to convert the differential voltage
existing between OUTIP/OUTQP and OUTIN/OUTQN to
a single-ended voltage. Optimize the dynamic perfor­mance by using a differential transformer-coupled out­put and limit the output power to < 0dBm full scale. Pay
close attention to the transformer core saturation char­acteristics when selecting a transformer for the
MAX5877. Transformer core saturation can introduce
strong 2nd-order harmonic distortion especially at low
output frequencies and high signal amplitudes. For best
results, center tap the transformer to ground. When not
using a transformer, terminate each DAC output to
ground with a 25Ω resistor. Additionally, place a 50Ω
resistor between the outputs (Figure 8).

For a single-ended unipolar output, select OUTIP
(OUTQP) as the output and ground OUTIN (OUTQN).
Driving the MAX5877 single-ended is not recommend­ed since additional noise and distortion will be added.

The distortion performance of the DAC depends on the
load impedance. The MAX5877 is optimized for 50Ω
differential double termination. It can be used with a
transformer output as shown in Figure 7 or just one 25Ω
resistor from each output to ground and one 50Ω resis-
tor between the outputs (Figure 8). This produces a full­scale output power of up to -2dBm, depending on the
output current setting. Higher termination impedance
can be used at the cost of degraded distortion perfor­mance and increased output noise voltage.

Grounding, Bypassing, and Power-

Supply Considerations

Grounding and power-supply decoupling can strongly
influence the MAX5877 performance. Unwanted digital
crosstalk couples through the input, reference, power
supply, and ground connections, and affects dynamic
performance. High-speed, high-frequency applications
require closely followed proper grounding and power­supply decoupling. These techniques reduce EMI and
internal crosstalk that can significantly affect the
MAX5877 dynamic performance.

Use a multilayer PCB with separate ground and power­supply planes. Run high-speed signals on lines directly
above the ground plane. Keep digital signals as far away
from sensitive analog inputs and outputs, reference input
sense lines, and clock inputs as practical. Use a con­trolled-impedance, symmetric, differential design of data
input, clock input, and the analog output lines to minimize
2nd-order harmonic distortion and noise components,
thus optimizing the DAC’s dynamic performance. Keep
digital signal paths short and run lengths matched to
avoid propagation delay and data skew mismatches.

The MAX5877 requires five separate power-supply inputs
for analog (AV

DD1.8

and AV

DD3.3

), digital (DV

DD1.8

and

DV

DD3.3

), and clock (AV

CLK

) circuitry. All power-supply
pins must be connected to their proper supply. Decouple
each AVDD, DVDD, and AV

CLK

input pin with a separate

0.1µF capacitor as close to the device as possible with
the shortest possible connection to the ground plane
(Figure 9). Minimize the analog and digital load capaci­tances for optimized operation. Decouple all three
power-supply voltages at the point they enter the PCB
with tantalum or electrolytic capacitors. Ferrite beads with
additional decoupling capacitors forming a pi-network
could also improve performance.

MAX5877

14

OUTIP/OUTQP

OUTIN/OUTQN

DATA13–DATA0

WIDEBAND RF TRANSFORMER T2 PERFORMS THE
DIFFERENTIAL-TO-SINGLE-ENDED CONVERSION

T1, 1:1

T2, 1:1

GND

50Ω

100Ω

50Ω

V

OUT

, SINGLE-ENDED

Figure 7. Differential-to-Single-Ended Conversion Using a Wideband RF Transformer

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

16 ______________________________________________________________________________________

The analog and digital power-supply inputs AV

DD3.3

,

AV

CLK

, and DV

DD3.3

allow a +3.135V to +3.465V sup­ply voltage range. The analog and digital power-supply
inputs AV

DD1.8

and DV

DD1.8

allow a +1.71V to +1.89V

supply voltage range.

The MAX5877 is packaged in a 68-pin QFN-EP pack­age, providing greater design flexibility and optimized
DAC AC performance. The EP enables the use of nec­essary grounding techniques to ensure highest perfor­mance operation. Thermal efficiency is not the key
factor, since the MAX5877 features low-power opera­tion. The exposed pad ensures a minimum inductance
ground connection between the DAC and the PCB’s
ground layer.

The data converter die attaches to an EP lead frame
with the back of this frame exposed at the package bot­tom surface, facing the PCB side of the package. This
allows for a solid attachment of the package to the PCB
with standard infrared reflow (IR) soldering techniques.
A specially created land pattern on the PCB, matching
the size of the EP (6mm x 6mm), ensures the proper
attachment and grounding of the DAC (refer to the
MAX5878 EV kit). Designing vias into the land area and
implementing large ground planes in the PCB design
allow for the highest performance operation of the DAC.
Use an array of at least 4 x 4 vias (≤ 0.3mm diameter
per via hole and 1.2mm pitch between via holes) for this
68-pin QFN-EP package. Connect the MAX5877
exposed paddle to GND. Vias connect the land pattern
to internal or external copper planes to spread heat. Use
as many vias as possible to the ground plane to mini­mize inductance.

Static Performance Parameter Definitions

Integral Nonlinearity (INL)

Integral nonlinearity is the deviation of the values on an
actual transfer function from either a best straight-line fit
(closest approximation to the actual transfer curve) or
a line drawn between the end points of the transfer
function, once offset and gain errors have been
nullified. For a DAC, the deviations are measured at
every individual step.

Differential Nonlinearity (DNL)

Differential nonlinearity is the difference between an actu­al step height and the ideal value of 1 LSB. A DNL error
specification of less than 1 LSB guarantees a monotonic
transfer function.

Offset Error

The offset error is the difference between the ideal and
the actual offset current. For a DAC, the offset point is the
average value at the output for the two midscale digital
input codes with respect to the full scale of the DAC. This
error affects all codes by the same amount.

Gain Error

A gain error is the difference between the ideal and the
actual full-scale output voltage on the transfer curve, after
nullifying the offset error. This error alters the slope of the
transfer function and corresponds to the same percent­age error in each step.

MAX5877

14

OUTIP/OUTQP

OUTIN/OUTQN

DATA13–DATA0

GND

25

Ω

50

Ω

25

Ω

OUTP

OUTN

Figure 8. Differential Output Configuration

MAX5877

14

OUTIP/OUTQP

OUTIN/OUTQN

DATA13–DATA0

0.1µF

AV

DD1.8

DV

DD1.8

0.1µF

0.1µF 0.1µF

AV

DD3.3

DV

DD3.3

0.1µF

AV

CLK

BYPASSING—DAC LEVEL

*BYPASS EACH POWER-SUPPLY PIN INDIVIDUALLY.

Figure 9. Recommended Power-Supply Decoupling and
Bypassing Circuitry

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

______________________________________________________________________________________ 17

Dynamic Performance Parameter Definitions

Signal-to-Noise Ratio (SNR)

For a waveform perfectly reconstructed from digital sam­ples, the theoretical maximum SNR is the ratio of the full­scale analog output (RMS value) to the RMS quantization
error (residual error). The ideal, theoretical minimum can
be derived from the DAC’s resolution (N bits):

SNR

dB

= 6.02dBx N + 1.76

dB

However, noise sources such as thermal noise, reference
noise, clock jitter, etc., affect the ideal reading; therefore,
SNR is computed by taking the ratio of the RMS signal to
the RMS noise, which includes all spectral components
minus the fundamental, the first four harmonics, and the
DC offset.

Noise Spectral Density

The DAC output noise floor is the sum of the quantiza­tion noise and the output amplifier noise (thermal and
shot noise). Noise spectral density is the noise power in
1Hz bandwidth, specified in dBFS/Hz.

Spurious-Free Dynamic Range (SFDR)

SFDR is the ratio of RMS amplitude of the carrier fre­quency (maximum signal components) to the RMS
value of their next-largest distortion component. SFDR
is usually measured in dBc and with respect to the car­rier frequency amplitude or in dBFS with respect to the
DAC’s full-scale range. Depending on its test condition,
SFDR is observed within a predefined window or to
Nyquist.

Two-/Four-Tone Intermodulation Distortion (IMD)

The two-tone IMD is the ratio expressed in dBc (or dBFS)
of the worst 3rd-order (or higher) IMD product(s) to either
output tone.

Adjacent Channel Leakage Power Ratio (ACLR)

Commonly used in combination with wideband code­division multiple-access (W-CDMA), ACLR reflects the
leakage power ratio in dB between the measured
power within a channel relative to its adjacent channel.
ACLR provides a quantifiable method of determining
out-of-band spectral energy and its influence on an
adjacent channel when a bandwidth-limited RF signal
passes through a nonlinear device.

Settling Time

The settling time is the amount of time required from the
start of a transition until the DAC output settles its new
output value to within the converter’s specified accuracy.

Glitch Impulse

A glitch is generated when a DAC switches between
two codes. The largest glitch is usually generated
around the midscale transition, when the input pattern
transitions from 011...111 to 100...000. The glitch
impulse is found by integrating the voltage of the glitch
at the midscale transition over time. The glitch impulse
is usually specified in pV•s.

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,
Dual DAC with LVDS Inputs

18 ______________________________________________________________________________________

Package Information

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information
go to www.maxim-ic.com/packages

.)

68L QFN.EPS

C

1

2

21-0122

PACKAGE OUTLINE, 68L QFN, 10x10x0.9 MM

MAX5877

14-Bit, 250Msps, High-Dynamic-Performance,

Dual DAC with LVDS Inputs

Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.

Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ___________________ 19

© 2007 Maxim Integrated Products is a registered trademark of Maxim Integrated Products, Inc.

C

1

2

21-0122

PACKAGE OUTLINE, 68L QFN, 10x10x0.9 MM

Package Information (continued)

(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information
go to www.maxim-ic.com/packages

.)

Revision History

Pages changed at Rev 2: 1, 2, 3, 5, 13, 15, 16, 18
