MAX3690
+3.3V, 622Mbps, SDH/SONET 8:1 Serializer
with Clock Synthesis and TTL Inputs
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(VCC= +3.0V to +3.6V, PECL loads = 50Ω ±1% to (VCC- 2V), TA= -40°C to +85°C, unless otherwise noted. Typical values are at
V
CC
= +3.3V, TA= +25°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Note 1: AC characteristics guaranteed by design and characterization.
Note 2: All TTL thresholds set to V
CC
/ 2.
Terminal Voltage (with respect to GND)
V
CC
.......................................................................-0.5V to +5V
All Inputs, FIL-, FIL+, PCLKO .................-0.5V to (V
CC
+ 0.5V)
Output Current
PECL Outputs (SD±).......................................................50mA
Continuous Power Dissipation (T
A
= +85°C)
TQFP (derate 10.2mW/°C above +85°C).....................663mW
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-60°C to +160°C
Lead Temperature (soldering, 10sec) .............................+300°C
T
A
= 0°C to +85°C
PECL outputs unterminated
IOL= -400µA
IOH= 400µA
VIN= 0
VIN= V
CC
TA= 0°C to +85°C
CONDITIONS
VCC- 1.025 VCC- 0.88
mA60 100I
CC
Supply Current
V0.44V
OL
Output Low Voltage
V2.4V
OH
Output High Voltage
µA-10 10I
IL
Input Low Current
µA-10 10I
IH
Input High Current
VCC- 1.81 VCC- 1.62
V2.0V
IH
Input High Voltage
V0.8V
IL
Input Low Voltage
UNITSMIN TYP MAXSYMBOLPARAMETER
C
LOAD
= 15pF, V
OUT
= 0.8V to 2.0V
C
LOAD
= 15pF, V
OUT
= 0.8V to 2.0V
CONDITIONS
ps1000t
H
Parallel Data Hold Time
ps1200t
SU
MHz622.08f
SCLK
Serial Clock Rate
Parallel Data Setup Time
ns550t
F
TTL Output Fall Time
ns650t
R
TTL Output Rise Time
ns0 5.0t
SKEW
Allowable Parallel Clock Output
to Parallel Clock Input Delay
ps
RMS
11
Φ
0
Output Random Jitter
UNITSMIN TYP MAXSYMBOLPARAMETER
AC ELECTRICAL CHARACTERISTICS
(VCC= +3.0V to +3.6V, PECL loads = 50Ω ±1% to (VCC- 2V), all TTL thresholds set to VCC/2, TA= -40°C to +85°C, unless otherwise
noted. Typical values are at V
CC
= +3.3V, TA= +25°C.) (Note 1)
CKSET = 0 or V
CC
µA500I
CKSET
CKSET Input Current
TA= -40°C
V
VCC- 1.085 VCC- 0.88
V
OH
Output High Voltage
TA= -40°C
V
VCC- 1.83 VCC- 1.555
V
OL
Output Low Voltage
PECL OUTPUTS (SD±)
TTL INPUTS AND OUTPUTS (PCLKI, RCLK, PCLKO, PD_)
20% to 80% ps200t
R, tF
PECL Differential Output
Rise/Fall Time
