MAXIM MAX14535E, MAX14539E User Manual

General Description
The MAX14535E–MAX14539E are low on-resistance and high ESD-protected DPDT switches that multiplex analog signals, such as AC-coupled audio or video. These devices combine the low on-capacitance (C
ON
) and low on-resistance (RON) necessary for high-perfor­mance switching applications in portable electronics, and include an internal negative supply to pass audio signals that swing below ground (down to -1.5V).
The MAX14535E/MAX14537E/MAX14539E feature inter­nal shunt resistors on the normally open path (and nor­mally closed path, (MAX14539E)) to reduce clicks and pops heard at the output. The MAX14535E– MAX14539E have an enable input (EN) to reduce sup­ply current and set all channels to high-impedance when driven low. When EN is driven low, the MAX14537E/MAX14538E have the lowest possible cur­rent consumption, but cannot withstand negative rail signals. The MAX14535E/MAX14536E/MAX14539E can still withstand a negative signal to NC_, NO_, or COM_ from -1.5V to min (VCC, 3V.)
The MAX14535E–MAX14539E operate from a +2.4V to +5.5V supply. These devices can be powered from the typical analog supply voltage in a cell phone (+2.5V to +2.8V) or a lithium-ion (Li+) battery (about 4.3V max). The MAX14535E–MAX14539E have high ESD protec­tion, up to ±15kV on COM_, and the NC_, NO_, and COM_ voltage can go up to 3.6V when V
CC
= 0 without
damaging the devices.
All devices are offered in a space-saving, 10-pin,
1.4mm x 1.8mm UTQFN package, and operate over the
-40°C to +85°C extended temperature range.
Applications
Features
o Low 0.135(typ) On-Resistance
o Low 0.3m(typ) R
ON
Flatness
o Single +2.4V to +5.5V Supply Voltage
o Pass Audio Signal Between -1.5V and min (V
CC
,
3V)
o Internal Shunt Resistors for Click-and-Pop
Reduction (MAX14535E/MAX14537E/MAX14539E)
o Withstand 3.6V (max) Applied to NC_, NO_, and
COM_ when V
CC
= 0V
o High ESD Protection: Up to ±15kV on COM_
o 10-Pin UTQFN (1.4mm x 1.8mm) Package
o -40°C to +85°C Operating Temperature Range
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
________________________________________________________________
Maxim Integrated Products
1
Ordering Information/Selector Guide
Pin Configuration
19-4461; Rev 1; 4/09
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
PART
PIN-PACKAGE
TOP MARK
SHUNT RESISTORS
SHUTDOWN MODE
(EN = LOW)
SIGNAL RANGE
MAX14535EEVB+ 10 UTQFN AAS NO1, NO2 Terminals -1.5V to min (VCC, 3V)
MAX14536EEVB+ 10 UTQFN AAT -1.5V to min (VCC, 3V)
MAX14537EEVB+* 10 UTQFN AAU NO1, NO2 Terminals 0 to V
CC
MAX14538EEVB+* 10 UTQFN AAV 0 to V
CC
MAX14539EEVB+* 10 UTQFN AAW NO_ and NC_ Terminals -1.5V to min (VCC, 3V)
Note: All devices are specified over the -40°C to +85°C temperature range.
+
Denotes a lead(Pb)-free package/RoHS-compliant package.
*
Future product—contact factory for availability.
Typical Operating Circuits appear at end of data sheet.
Cell Phones
MP3 Players
Notebook Computers
PDAs
TOP VIEW
CC
V
GND
7
8NC1
9COM1
MAX14535E–
10NO1
+
6
MAX14539E
1
2
CB
UTQFN
5 NC2
4 COM2
3 NO2
EN
MAX14535E–MAX14539E
Low-Resistance DPDT Switches with Negative Rail
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(VCC= +2.4V to +5.5V, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.0V, TA= +25°C.) (Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7 using a four-
layer board. For detailed information on package thermal considerations, refer to www.maxim-ic/thermal-tutorial
.
(Voltages referenced to GND.) V
CC
, CB, EN ..........................................................-0.3V to +6.0V
NO_, NC_, COM_ (V
CC
> 2.4V, MAX14535E/
MAX14536E/MAX14539E).................................-1.8V to +3.6V
NO_, NC_, COM_ (V
CC
< 2.4V, MAX14535E/
MAX14536E/MAX14539E).................................-0.3V to +3.6V
NO_, NC_, COM_ (V
EN
< VIL, MAX14537E/
MAX14538E)......................................................-0.3V to +6.0V
NO_, NC_, COM_ (V
EN
> VIL, VCC> 2.4V,
MAX14537E/MAX14538E).................................-1.8V to +3.6V
NO_, NC_, COM_ (V
EN
< VIL, VCC< 2.4V,
MAX14537E/MAX14538E).................................-0.3V to +3.6V
Continuous Current into NO_, NC_, COM_ Terminals....±300mA
Peak Current into NO_, NC_,
COM_ Terminals (50% duty cycle).............................±500mA
Continuous Power Dissipation (T
A
= +70°C)
10-Pin UTQFN (derate 6.9mW/°C above +70°C).........559mW
Junction-to-Ambient Thermal Resistance (
θ
JA
) (Note 1)..143.1°C/W
Junction-to-Case Thermal Resistance (
θ
JC
) (Note 1)...20.1°C/W
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature Range ............................-40°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
)
Power-Supply Range V
Supply Current I
Supply Current Increase with Logic Level
Analog Signal Range
On-Resistance R
On-Resistance Match Between Channels
On-Resistance Flatness R
Shunt Switch Resistance R
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
CC
MAX14537E/MAX14538E,
VCC =
3.0V
V
MAX14535E/MAX14536E/ M AX 14539E , V
CC
VCC =
5.5V
MAX14537E/MAX14538E, V
MAX14535E/MAX14536E/ M AX 14539E , V
V
= 0.4V or 1.4V, VCB = 0.4V or 1.4V 5 µA
EN
MAX14537E/MAX14538E, V
< V
EN
IL
MAX14537E/MAX14538E, V
> V
EN
IH
MAX14535E/MAX14536E/MAX14539E -1.5
ON
R
ON
FLAT(ON
SH
VCC = 3.0V, V I
= 100mA or I
NO_
VCC = 3.0V, V (Note 3)
VCC = 3.0V, I V
= -1.5V to +3.0V (Note 4)
COM_
I
or I
NO_
NC_
2.4 5.5 V
EN
EN
= 0
= 0
E N
E N
= 0, V
= 0, V
E N
E N
= V
= V
C C
C C
815
12 25
0V
1
1
CC
Min
-1.5
(3.0V,
V
CC
)
Min
(3.0V,
)
V
CC
= -1.5V, 3.0V;
COM_
COM_
COM_
= 100mA
NC_
= 0; I
= 100mA;
COM_
= 100mA
0.135 0.35
0.05
0.3 1 m
= 1mA 500 1000
µA
V
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
_______________________________________________________________________________________ 3
Note 2: Devices are production tested at TA= +25°C. Specifications over temperature limits are guaranteed by design. Note 3: R
ON(MAX)
= |R
ON(CH1)
- R
ON(CH2)
|
Note 4: Flatness is defined as the difference between the maximum and minimum value of on-resistance, as measured over speci-
fied analog signal ranges. These values are guraranteed by design.
Note 5: Between two switches.
)
)
)
)
ELECTRICAL CHARACTERISTICS (continued)
(VCC= +2.4V to +5.5V, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.0V, TA= +25°C.) (Note 2)
NC_ or NO_ Off-Leakage Current I
COM_ Off-Leakage Current I
COM_ On-Leakage Current I
AC CHARACTERISTICS
Turn-On Time t
Turn-Off Time t
Break-Before-Make Time Delay t
Off-Isolation V
Crosstalk V
NC_ -3dB Bandwidth BW
NO_ -3dB Bandwidth BW
Power-Supply Rejection Ratio PSRR
Total Harmonic Distortion THD
COM_ On-Capacitance C
NC_, NO_ Off-Capacitance C
LOGIC INPUT
Input Logic-High V
Input Logic-Low V
Input Leakage Current I
ESD PROTECTION
All Pins Human Body Model ±2 kV
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
N C _ ,N O_( OFF)
COM_(OFF
COM_(ON
ON
OFF
Switch open, VEN = VCC, V 0 or 2.5V, V
COM_
= 0V or 2.5V
VEN = 0, VCC = 3.0V, V V
= V
NC_
VCC = 0, V
NO_
COM_
= 0
= 3.6V, V
unconnected
V
= 3.0V , V
C C
or V
= - 1.5V , 2.5V or unconnected
N O_
VCC = 3.0V, V
= 50Ω , C L = 100p F, ( V
R
L
(V
= VCC and VCB transitions), Figure 1
EN
VCC = 3.0V, V
= 100p F, (VEN = V
50, C
L
= - 1.5V or + 2.5V , V
C OM _
or V
NC_
NC_
or V
NO_
NO_
NO_
= 3.0V,
COM_
NC_
= 1.5V, = 0 to V
E N
= 1.5V, RL =
CC
or V
NC_
= V
NO_
C C
to 0) or (V
=
N C _
) or
=
-10 +10 nA
-10 +10 nA
-1.5 +1.5 mA
-100 +100 nA
40 90 µs
EN
18 40 µs
= VCC and VCB transitions), Figure 1
D
ISO
CT
NC_
NO_
COM_(ON
NC _,N O_( OFF
IH
IL
IN
= V
NC_
f = 100kHz, V Figure 3
f = 100kHz, V Figure 3 (Note 5)
RS = RL = 50Ω , V
RS = RL = 50Ω , V
f = 10kHz, V R
COM_
f = 20Hz to 20kHz, V DC bias = 0, R
f = 1MHz, V
f = 1MHz, V
VCB = 0 or VCC, VEN = 0V or V
= 1.5V, RL = 50, Figure 2 28 µs
NO_
= 0dBm, RL = 50Ω,
= 50
COM_
= 0dBm, RL = 50Ω,
COM_
= 0d Bm , Fi g ur e 3a–3d 100 MHz
N O_
= 0d Bm , Fi g ur e 3a–3d 100 MHz
N O_
= 3V ± 0.3V,
CC
COM_
= 32
L
= 0.5V
COM_
= 0.5V
COM_
= 0.5V
, DC bias = 0 15 pF
P-P
, DC bias = 0 30 pF
P-P
P-P
,
-70 dB
-80 dB
90 dB
0.003 %
1.4 V
CC
-1 +1 µA
0.4 V
V
Human Body Model ±15
IEC 61000 Air-Gap Discharge ±15COM1, COM2
IEC 61000 Contact Discharge ±8
kV
MAX14535E–MAX14539E
Low-Resistance DPDT Switches with Negative Rail
4 _______________________________________________________________________________________
Figure 1. Switching Time
Figure 2. On-Loss, Off-Isolation, and Crosstalk
COM_
R
L
L
)
ON
V
OUT
C
L
LOGIC INPUT
NO_
V
IN
or NC_
CB
MAX14535E–MAX14539E
CL INCLUDES FIXTURE AND STRAY CAPACITANCE.
V
OUT
RL + R
= V
IN_ (
R
V
IN
V
OUT
MEAS REF
50
NC1
COM1
MAX14535E–
MAX14539E
NO1*
V
LOGIC INPUT
SWITCH OUTPUT
NETWORK
ANALYZER
50
50 50
IH
V
0V
50
IL
tR < 5ns t
< 5ns
t
OFF
F
0.1 x V
V
V
OUT
V
OUT
V
IN
OUT
V
IN
OUT
V
IN
50%
V
OUT
0.9 x V
0UT
t
ON
CONTROL DEPENDS ON SWITCH CONFIGURATION; INPUT POLARITY DETERMINED BY SENSE OF SWITCH.
OFF-ISOLATION = 20log
ON-LOSS = 20log
CROSSTALK = 20log
OFF-ISOLATION IS MEASURED BETWEEN COM_ AND "OFF" NO_ OR NC_ TERMINAL ON EACH SWITCH. ON-LOSS IS MEASURED BETWEEN COM_ AND "ON" NO_ OR NC_ TERMINAL ON EACH SWITCH. CROSSTALK IS MEASURED FROM ONE CHANNEL TO THE OTHER CHANNEL.
*FOR CROSSTALK THIS PIN IS NO2. NC2 AND COM2 ARE OPEN.
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
_______________________________________________________________________________________ 5
Typical Operating Characteristics
(TA = +25°C, V
CC
= +3.0V, unless otherwise noted.)
NORMALIZED ON-RESISTANCE
1.05
1.04
1.03
1.02
1.01
1.00
0.99
0.98
NORMALIZED ON-RESISTANCE
0.97
0.96
0.95
-1.5 3.0
NC_ TURN-ON/NO_ TURN-OFF TIME
100
90
80
70
60
50
TIME (µs)
40
30
20
10
0
2.5 3.5 5.04.0 4.53.0
2.0 5.5
vs. COM VOLTAGE
VCC = +3V
VCC = +5V
0.50-0.5 2.0-1.0 1.51.0 2.5
COM VOLTAGE (V)
vs. SUPPLY VOLTAGE
NC_ TURN-ON TIME
NO_ TURN-OFF TIME
SUPPLY VOLTAGE (V)
2.0 VCC = +3V
1.8
1.6
MAX14535E-9E toc01
1.4
1.2
1.0
0.8
0.6
NORMALIZED ON-RESISTANCE
0.4
0.2
0.0
-1.5 3.0
NO_ TURN-ON/NC_ TURN-OFF TIME
100
90
80
MAX14535E-9E toc04
70
60
50
TIME (µs)
40
30
20
10
0
2.0 5.5
NORMALIZED ON-RESISTANCE
vs. COM VOLTAGE
TA = +85°C
TA = +25°C
TA = -40°C
0.50-0.5 2.0-1.0 1.51.0 2.5
COM VOLTAGE (V)
vs. SUPPLY VOLTAGE
NO_ TURN-ON TIME
NC_ TURN-OFF TIME
2.5 3.5 5.04.0 4.53.0 SUPPLY VOLTAGE (V)
2.0 VCC = +5V
1.8
1.6
MAX14535E-9E toc02
1.4
1.2
1.0
0.8
0.6
NORMALIZED ON-RESISTANCE
0.4
0.2
0.0
-1.5 3.0
NC_ TURN-ON/NO_ TURN-OFF TIME
80
70
60
MAX14535E-9E toc05
50
40
TIME (µs)
30
20
10
0
-40 85
NORMALIZED ON-RESISTANCE
vs. COM VOLTAGE
TA = +85°C
TA = +25°C
TA = -40°C
0.50-0.5 2.0-1.0 1.51.0 2.5
COM VOLTAGE (V)
vs. TEMPERATURE
NC_ TURN-ON TIME
NO_ TURN-OFF TIME
3510 60-15
TEMPERATURE (°C)
MAX14535E-9E toc03
MAX14535E-9E toc06
NO_ TURN-ON/NC_ TURN-OFF TIME
vs. TEMPERATURE
80
70
60
50
40
TIME (µs)
30
20
10
0
-40 85
NO_ TURN-ON TIME
NC_ TURN-OFF TIME
3510 60-15
TEMPERATURE (°C)
MAX14535E-9E toc07
1.2
1.0
0.8
CB LOGIC THRESHOLD (V)
0.6
0.4
2.0 5.5
CB LOGIC THRESHOLD vs. SUPPLY VOLTAGE
VCB RISING
MAX14535E-9E toc08
VCB FALLING
2.5 3.5 5.04.0 4.53.0 SUPPLY VOLTAGE (V)
MAX14535E–MAX14539E
Low-Resistance DPDT Switches with Negative Rail
6 _______________________________________________________________________________________
Typical Operating Characteristics (continued)
(TA = +25°C, V
CC
= +3.0V, unless otherwise noted.)
TOTAL HARMONIC DISTORTION
vs. FREQUENCY
MAX14535E-9E toc15
FREQUENCY (kHz)
THD (%)
1100.1
0.1
0.01
1
0.001
0.01 100
POWER-SUPPLY REJECTION RATIO
vs. FREQUENCY
MAX14535E-9E toc16
PSRR (dB)
0.1 1
60
30
100
0
70
40
10
80
90
50
20
0.01 10
SUPPLY CURRENT
vs. CB LOGIC INPUT VOLTAGE
50
45
40
35
30
25
20
SUPPLY CURRENT (µA)
15
10
5
03.0 CB LOGIC INPUT VOLTAGE (V)
2.00.5 1.51.0 2.5
80
70
60
MAX14535E-9E toc09
50
40
30
20
ON-LEAKAGE CURRENT (nA)
10
0
FREQUENCY RESPONSE
0
-1
-2
-3
-4
ON-LOSS (dB)
-5
-6
-7
-8
0.1 10 1001
0.01 1000 FREQUENCY (MHz)
MAX14535E-9E toc12
0
-10
-20
-30
-40
-50
-60
OFF-ISOLATION (dB)
-70
-80
-90
-100
ON-LEAKAGE CURRENT
vs. TEMPERATURE
-40 85
-15 35 6010 TEMPERATURE (°C)
OFF-ISOLATION vs. FREQUENCY
0.01 100 FREQUENCY (MHz)
OFF-LEAKAGE CURRENT
vs. TEMPERATURE
1.0
0.9
0.8
MAX14535E-9E toc10
0.7
0.6
0.5
0.4
0.3
OFF-LEAKAGE CURRENT (nA)
0.2
0.1
0
-40 85
-15 35 6010 TEMPERATURE (°C)
MAX14535E-9E toc11
CROSSTALK vs. FREQUENCY
-40 RL = 32
-50
MAX14535E-9E toc13
-60
-70
CROSSTALK (dB)
-80
-90
-100
1100.1
0.01 100
1100.1
FREQUENCY (MHz)
MAX14535E-9E toc14
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
_______________________________________________________________________________________ 7
Pin Description
Detailed Description
The MAX14535E–MAX14539E are low on-resistance and high ESD-protected single DPDT switches that operate from a +2.4V to +5.5V supply and are designed to multiplex AC-coupled analog signals. These switches combine the low on-capacitance (CON) and low on-resistance (RON) necessary for high-perfor­mance switching applications. The negative signal capability of the analog channel allows signals below ground to pass through without distortion.
Analog Signal Levels
The MAX14535EMAX14539E are bidirectional, allow­ing NO_, NC_, and COM_ to be configured as either inputs or outputs. Note that NC_ and NO_ are only pro­tected against ESD up to ±2kV (Human Body Model) and may require additional ESD protection if used as outputs. These devices feature a charge pump that generates a negative supply to allow analog signals as low as -1.5V to pass through NO_, NC_, or COM_. This allows AC-coupled signals that drop below ground to pass even when operating from a 3.0V to 5.5V supply. For the MAX14537E/MAX14538E, the negative charge pump is controlled by the enable input and is active when EN is high. When EN is driven low, the negative charge pump is disabled, which puts the devices in the lowest possible current consumption, and the signal range is 0 to VCC. The negative charge pump is always active for the MAX14535E/MAX14536E/MAX14539E, therefore, a negative signal (at most -1.5V) can be applied through NC_, NO_, or COM_, even when EN is driven low. A negative rail signal (signal voltage < 0) must not be applied to the switch unless the negative charge pump is active.
Digital Control Input
The MAX14535EMAX14539E provide a single-bit con­trol logic input, CB. CB controls the switch position as shown in the
Functional Diagrams
. Drive CB rail-to-rail
to minimize power consumption.
Enable Input
The MAX14535EMAX14539E feature a shutdown mode that reduces the supply current (less than 1µA for MAX14537E/MAX14538E) and places the switches in high impedance. Drive EN low to place the device in shutdown mode. Drive EN high for normal operation.
Shunt Resistors
(MAX14535E/MAX14537E/MAX14539E)
When EN is high, the shunt resistors are controlled by CB. When CB is low, NC_ is connected to COM_ and NO_ is connected to shunt resistors. When CB is high, NO_ is connected to COM_ and NC_ is connected to shunt resistors (MAX14539E). When EN is low, all the switches are open and all the shunt resistors are active.
Click-and-Pop Suppression
The 500shunt resistors on the MAX14535E/ MAX14537E/MAX14539E automatically discharge any capacitance at the NO_ terminals (or NC_ terminals, MAX14539E) when they are unconnected from COM_. This reduces audio click-and-pop sounds that may occur when switching between capacitively coupled audio sources.
PIN NAME FUNCTION
1 CB Digital Control Input. Drive CB low to connect COM_ to NC_. Drive CB high to connect COM_ to NO_.
2EN
3 NO2 Normally Open Terminal for Switch 2
4 COM2 Common Terminal for Switch 2
5 NC2 Normally Close Terminal for Switch 2
6 GND Ground
7V
8 NC1 Normally Close Terminal for Switch 1
9 COM1 Common Terminal for Switch 1
10 NO1 Normally Open Terminal for Switch 1
CC
Active-High Enable Input. Drive EN high for normal operation. Drive EN low to put switches in high impedance. Do not apply negative signals to NO_ or NC_ when EN is low (MAX14537E/MAX14538E).
Positive Supply Voltage Input. Bypass VCC to GND with a 0.1µF capacitor as close as possible to the device.
MAX14535E–MAX14539E
Low-Resistance DPDT Switches with Negative Rail
8 _______________________________________________________________________________________
Figure 3a. Human Body ESD Test Model
Figure 3b. Human Body Current Waveform
Applications Information
Extended ESD Protection
ESD protection structures are incorporated on all pins to protect against electrostatic discharges up to ±2kV (HBM) encountered during handling and assembly. COM1 and COM2 are further protected against ESD up to ±15kV (HBM) without damage. The ESD struc­tures withstand high ESD both in normal operation and when the device is powered down. After an ESD event, the MAX14535EMAX14539E continue to function with­out latchup.
ESD Test Conditions
ESD performance depends on a variety of conditions. Contact Maxim for a reliability report that documents test setup, test methodology, and test results.
Human Body Model
Figure 3a shows the Human Body Model. Figure 3b shows the current waveform it generates when discharged into a low impedance. This model consists of a 100pF capaci­tor charged to the ESD voltage of interest that is then discharged into the device through a 1.5kresistor.
IEC 61000-4-2
The main difference between tests done using the Human Body Model and IEC 61000-4-2 is higher peak current in the IEC 61000-4-2. Because series resistance is lower in the IEC 61000-4-2 ESD test model (Figure 3c) the ESD withstand voltage measured using the Human Body Model. Figure 3d shows the current wave­form for the ±8kV IEC 61000-4-2 Level 4 ESD Contact Discharge test.
The Air-Gap Discharge test involves approaching the device with a charged probe. The Contact Discharge method connects the probe to the device before the probe is energized.
Figure 3c. IEC 61000-4-2 ESD Test Model
Figure 3d. IEC 61000-4-2 ESD Generator Current Waveform
R
1M
C
R
D
1.5k
DISCHARGE
RESISTANCE
STORAGE
s
CAPACITOR
DEVICE UNDER
TEST
HIGH-
VOLTAGE
DC
SOURCE
CHARGE-CURRENT-
LIMIT RESISTOR
C
100pF
PEAK-TO-PEAK RINGING
I
r
(NOT DRAWN TO SCALE)
AMPERES
IP 100%
90%
36.8%
10%
0
0
t
RL
TIME
t
DL
CURRENT WAVEFORM
R
D
330
DISCHARGE
RESISTANCE
STORAGE CAPACITOR
HIGH-
VOLTAGE
DC
SOURCE
R
C
50M to 100M
CHARGE-CURRENT-
LIMIT RESISTOR
C
s
150pF
DEVICE UNDER
TEST
I
100%
90%
PEAK
I
10%
t
= 0.7ns to 1ns
R
30ns
60ns
t
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
_______________________________________________________________________________________ 9
Power-Supply Sequencing
Caution: Do not exceed the absolute maximum rat­ings because stresses beyond the listed ratings may cause permanent damage to the device.
Proper power-supply sequencing is recommended for all devices. Apply V
CC
before applying analog signals,
especially if the analog signal is not current limited.
Functional Diagrams
NC1
NC2
NO1
NO2
MAX14535E/
MAX14537E
COM1
COM2
EN
GND
CB
MAX14535E–MAX14539E
Low-Resistance DPDT Switches with Negative Rail
10 ______________________________________________________________________________________
Functional Diagrams (continued)
MAX14536E/
MAX14538E
NC1
COM1
NC2
NO1
NO2
EN
GND
NC1
NC2
NO1
COM2
CB
MAX14539E
COM1
COM2
NO2
EN
GND
CB
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
______________________________________________________________________________________ 11
Typical Operating Circuits
DirectDrive is a registered trademark of Maxim Integrated Products, Inc.
DirectDrive
AUDIO
AMPLIFIER
AUDIO
AMPLIFIER
3.0V
0.1µF
V
CC
MAX14535E/
®
NC1
NC2
NO1
NO2
EN
MAX14537E
COM1
AUDIO
CONNECTOR
COM2
GND
CB
MAX14535E–MAX14539E
Low-Resistance DPDT Switches with Negative Rail
12 ______________________________________________________________________________________
Typical Operating Circuits (continued)
Chip Information
PROCESS: BiCMOS
Package Information
For the latest package outline information and land patterns, go to www.maxim-ic.com/packages
.
PACKAGE TYPE PACKAGE CODE DOCUMENT NO.
10 UTQFN V101A1CN+1
21-0028
3.0V
0.1µF
V
CC
MAX14536E/
DirectDrive
AUDIO
AMPLIFIER
NC1
NC2
MAX14538E
COM1
AUDIO
CONNECTOR
COM2
DirectDrive
AUDIO
AMPLIFIER
NO1
NO2
EN
GND
CB
MAX14535E–MAX14539E
Low-Resistance DPDT Switches
with Negative Rail
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________
13
© 2009 Maxim Integrated Products Maxim is a registered trademark of Maxim Integrated Products, Inc.
Revision History
REVISION
NUMBER
0 2/09 Initial release
1 4/09
REVISION
DATE
DESCRIPTION
Removed future product asterisk for MAX14536E and updated Electrical Characteristics table.
PAGES
CHANGED
1
Loading...
