MAXIM MAX14531E, MAX14534E Technical data

General Description

The MAX14531E–MAX14534E high ESD-protected
DP3T switches multiplex Hi-Speed (480 Mbps) USB
signals, low/full-speed USB signals, and analog sig­nals such as AC-coupled audio or video through any
of three channels. These devices combine the low on­capacitance (C

ON

) and low on-resistance (RON) nec­essary for high-performance switching applications in
portable electronics, and include an internal negative
supply to pass AC-coupled audio signals that swing
below ground (down to -2.0V). The MAX14531E–
MAX14534E operate from a +2.7V to +5.5V supply.

The MAX14531E–MAX14534E have a shutdown func­tion to reduce supply current and set all channels to
high impedance. The MAX14531E–MAX14534E feature
a VBUS detection function through the CB0 input to
automatically switch to the default USB signal path
upon detection of a valid VBUS signal. The
MAX14532E/MAX14534E feature internal shunt resis­tors on audio channels to reduce clicks and pops
heard at the output.

The MAX14531E–MAX14534E are available in a space­saving, 12-bump, 1.5mm x 2.0mm WLP package and
operate over the -40°C to +85°C temperature range.

Applications

Cell Phones

MP3 Players

PDAs

Notebook Computers

Features

♦ Single +2.7V to +5.5V Supply Voltage

♦ Low 10µA (typ) Supply Current

♦ -3dB Bandwidth: 800MHz (typ)

♦ Low 2Ω (typ) On-Resistance

♦ 0.05% THD+N

♦ Internal Shunt Resistor for Click-and-Pop

Reduction (MAX14532E/MAX14534E)

♦ VBUS Detection for Automatic Switch Path

Selection

+28V Maximum Rated VBUS Detection Input
(CB0)

♦ Space-Saving, 12-Bump, 1.5mm x 2.0mm WLP

Package

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with

Negative Signal Capability and ±15kV ESD

________________________________________________________________

Maxim Integrated Products

1

19-4597; Rev 0; 4/09

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.

EVALUATION KIT

AVAILABLE

Note: All devices are specified over the -40°C to +85°C operating temperature range.

+

Denotes a lead(Pb)-free/RoHS-compliant package.

*

Future product—contact factory for availability.

PART PIN-PACKAGE

TOP MARK

MAX14531EEWC+ 12 WLP NONE No AAT

MAX14532EEWC+ 12 WLP UAZ_ Yes AAU

MAX14533EEWC+* 12 WLP NONE Yes AAV

MAX14534EEWC+* 12 WLP UAY_/UAZ_ Yes AAW

Ordering Information/Selector Guide

Pin Configuration

TOP VIEW
(BUMPS ON BOTTOM)

231

+

MAX14531E/MAX14532E/

MAX14533E/MAX14534E

A

B

CC

UAZ1 UAZ2CB0

UAX1 UAX2V

4

COM1

GND

C

UAY1

UAY2

WLP

SHUNT RESISTORS CB0 PULLDOWN RESISTOR

COM2CB1

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with
Negative Signal Capability and ±15kV ESD

2 _______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(VCC= +2.7V to +5.5V, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.0V, TA= +25°C, unless other­wise noted.) (Note 2)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-

layer board. For detailed information on package thermal considerations, refer to www.maxim-ic.com/thermal-tutorial

.

(Voltages referenced to GND.)
V

CC

, CB1...............................................................-0.3V to +6.0V

CB0......................................................................-0.3V to +28.0V

COM_ (CB0 or CB1 > V

IH

) ....................................-2.3V to +3.6V

COM_ (CB0 and CB1 < V

IL

)..................................-0.3V to +6.0V

UAX_, UAY_, UAZ_ (CB0 or CB1 > V

IH

) ...............-2.3V to +3.6V

UAX_, UAY_, UAZ_ (CB0 and CB1 < V

IL

).............-0.3V to +6.0V

Continuous Current into Any Terminal............................±150mA

50% Duty Cycle Current into Any Terminal ....................±250mA

Continuous Power Dissipation (T

A

= +70°C) (Note 1)

12-Bump WLP (derate 8.5mW/°C above +70°C).........678mW

Operating Temperature Range ...........................-40°C to +85°C

Junction Temperature Range ............................-40°C to +150°C

Storage Temperature Range .............................-65°C to +150°C

Lead Temperature (soldering, 10s) .................................+300°C

)

PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS

Power-Supply Range V

Supply Current I

Supply Current Increase ΔI

VBUS Detect Threshold V

Analog Signal Range

ANALOG SWITCH

UAX_, UAY_, UAZ_
On-Resistance

UAX_, UAY_, UAZ_
On-Resistance Match Between
Channels

UAX_, UAY_, UAZ_
On-Resistance Flatness
(Notes 4, 5)

CC

CC

CC

VBDET

V

UAX_

V

UAY_

V

UAZ_

V

COM_

R

ON ( U AX Y Z )

ΔR

ON

R

FLAT(UAXYZ

VCC = +3.3V

VCC = +5.0V

V

CB0

V

CB0

V

CB0

,

V

CB0

,
,

V

CB0

VCC = +3.0V, V
I

COM_

VCC = +3.0V, V
I

COM_

VCC = +3.0V, V

-2.0V or +3.0V, I

= V

CB1

rising V

falling, hysteresis 0.2

< VIL and V

> VIH or V

= 10mA

= 10mA (Note 3)

2.7 5.5 V

V

= V

CB0

(shutdown)

V

CB0

V

CB0

V

CB0

(shutdown)

V

CB0

V

CB0

= VIH or V

CB1

> V

CB1

UAX_

UAX_

UAX_

COM_

= 0

CB1

= VCC or V

CB1

= V

CC

20

= +5.0V 20

= V

= 0

CB1

= VCC or V

CB1

= V

CC

25

= +5.5V 25

IL

+ 0.2 V

C C

C C

+ 0.6

< VIL (shutdown) 0 V

IH

= V

UAY_

= V

UAY_

= V

UAY_

= 10mA

= V

= V

= V

UAZ_

UAZ_

UAZ_

= 0,

= 0,

=

-2.0

0.02 0.1 Ω

Min

(V

, 3.3V)

CC

23 Ω

0.2 Ω

1

1

2µA

CC

µA

V

V

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with

Negative Signal Capability and ±15kV ESD

_______________________________________________________________________________________ 3

ELECTRICAL CHARACTERISTICS (continued)

(VCC= +2.7V to +5.5V, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.0V, TA= +25°C, unless other­wise noted.) (Note 2)

)

)

)

)

)

Shunt Switch Resistance R

UAX_ Off-Leakage Current I

UAY_ Off-Leakage Current I

UAZ_ Off-Leakage Current I

COM_ Off-Leakage Current I

Enable Turn-On Time t

Enable Turn-Off Time t

Address Transition Time t

Transient to Shutdown Valid Time t

VBUS Detection Time t

Break-Before-Make Time Delay t

Output Skew Same Switch t

PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS

I

SH

= 10mA (MAX14532E) or I

UAZ_

= 10mA (MAX14534E)

I

UAZ_

UAY_

=

100 200 Ω

VCC = 3.0V, <CB1,CB0> = 10

UAX(OFF

(UAX_ open), V
V

= -1.5V or +2.5V

COM_

= +2.5V or 0,

UAX_

-10 +10 nA

(MAX14531E–MAX14533E) VCC = 3.0V,

UAY(OFF

UAZ(OFF

COM(ON

CB1 = GND, CB0 = V
V

= +2.5V or 0,

UAY_

= -1.5V or +2.5V

V

COM_

( M AX 14531E /M AX 14533E ) V
< C B1,C B0> = 01 ( U AZ _ op en) ,
V

= + 2.5V or 0, V

U AZ _

< C B1,C B0> = 01, V
V

VCC = +3.0V,
V

=

COM_

-1.5V or
+2.5V

unconnected

< C B1,C B0> = 10, V
V
unconnected

< C B1,C B0> = 11, V
V

(UAY_ open),

CC

C OM _

= 0, +2.5V, or

UAZ_

= 0, +2.5V, or

UAZ_

= 0, +2.5V, or

UAY_

= 3.0V ,

C C

= - 1.5V or + 2.5V

=

UAY_

=

UAX_

=

UAX_

-10 +10 nA

-10 +10 nA

-100 +100

-100 +100COM_ On-Leakage Current I

-100 +100

nA

unconnected

COM(OFF

VCC = +3.0V,
< C B1,C B0>
= 00,

VUAX

= V

_ =

UAY

_ = 0

V

UAZ

V

_= +3.6V -0.01 +2 µA

COM

_

V

_= 0 -10 +10 nA

COM

From shutdown to UAX_, UAY_, or UAZ_

ON

connected to COM_, V
+3.0V, R

= 50Ω, CL = 10pF (Figure 1)

L

= +3.0V, V

CC

UA_

=

250 µs

From UAX_, UAY_, or UAZ_ connected to

OFF

COM_ to shutdown, V
+3.0V, R

= 50Ω, CL = 10pF (Figure 1)

L

= +3.0V, V

CC

UA_

=

6µs

Switching from one active channel to

TRANS

T00

VBDET

another, V

= 50Ω, CL = 10pF

R

L

= +3.0V, V

CC

UA_

= +3.0V,

From UAX_, UAY_, or UAZ_ connected to
COM_ to shutdown, V

V

= + 3.0V , V

C C

= 10p F, V

U AX Y _

= + 3.0V , V

C B1

= +3.0V

CC

= + 3.0V , RL = 50Ω , C

= 0 to + 5.0V

C B0

20 100 µs

L

15 200 µs

250 µs

Time delay between one side of the switch

BBM

SK(P)

opening and the other side closing,
R

= 50Ω, CL = 10pF (Note 5)

L

t

INRISE

t

OUTFALL

, t

INFALL,

< 5ns, t

OUTRISE

< 5ns, Figure 2 (Note 5)

,

1µs

40 ps

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with
Negative Signal Capability and ±15kV ESD

4 _______________________________________________________________________________________

ELECTRICAL CHARACTERISTICS (continued)

(VCC= +2.7V to +5.5V, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.0V, TA= +25°C, unless other­wise noted.) (Note 2)

)

Note 2: All devices are 100% production tested at TA= +25°C. All temperature limits are guaranteed by design.
Note 3: ΔR

ON

= ABS(R

ON(CH1)

- R

ON(CH2)

)

Note 4: Flatness is defined as the difference between the maximum and minimum value of on-resistance, as measured over speci-

fied analog signal ranges.

Note 5: Guaranteed by design.

Output Skew Between Channels t

UAX_, UAY_, UAZ_
Off-Capacitance

COM_ On-Capacitance C

AC PERFORMANCE

-3dB Bandwidth BW

Off-Isolation V

Crosstalk V

Power-Supply Rejection Ratio PSRR f = 10kH z, V

Total Harmonic Distortion Plus
Noise

LOGIC INPUT

Input Logic-High V

Input Logic-Low V

Input Logic Hysteresis V

Input Leakage Current I

CB0 Pulldown Resistor R

ESD PROTECTION

All Pins Human Body Model ±2 kV

COM1, COM2 Human Body Model ±15 kV

PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS

t

SK(O)

C

C OM _( OFF)

COM_(ON

NO

ISO

CT

THD+N

IH

IL

HYST

IN

CB0

, t

INRISE

< 5ns, Figure 2 (Note 5)

f = 240MHz, V
(Note 5)

f = 240MHz, V
(Note 5)

V

= 0dBm, RL = 50Ω, RS = 50Ω

COM_

(Figure 3)

f = 100kHz, V
R

= 50Ω (Figure 3)

S

f = 100kHz, V
R

= 50Ω (Figure 3)

S

f = 20Hz to 20kHz, V
DC bias = 0, R

(Note 5) 100 mV

V

= VCC = +3.3V (MAX14531E) (Note 5) 4 µA

CB0

V

= 0, VCC = +5.5V -250 +250

CB0

V

= 0 or +5.5V -250 +250

CB1

MAX14532E/MAX14533E/MAX14534E 500 1000 1500 kΩ

< 5ns, t

INFALL

COM

COM

COM_

COM_

= + 3.0V ± 0.3V , R

C C

= 32Ω

L

OUTRISE

= 0.5V

= 0.5V

= 1V

= 1V

COM_

, DC bias = 0

P-P

, DC bias = 0

P-P

, RL = 50Ω,

RMS

, RL = 50Ω,

RMS

= 0.5V

, t

OUTFALL

=

40 ps

5pF

8pF

800 MHz

-65 dB

-70 dB

= 50Ω 60 dB

C OM _

,

P-P

0.05 %

1.4 V

0.4 V

nA

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with

Negative Signal Capability and ±15kV ESD

_______________________________________________________________________________________ 5

Test Circuits/Timing Diagrams

tR < 5ns
tF < 5ns

50%

V

IL

LOGIC
INPUT

R

L

COM_

GND

CB0, CB1

C

L

INCLUDES FIXTURE AND STRAY CAPACITANCE.

V

OUT

= V

N_ (

R

L

)

RL + R

ON

V

IN

V

IH

t

OFF

0

UAX_, UAY_,
UAZ_

0.9 x V

0UT

0.9 x V

OUT

t

ON

V

OUT

SWITCH

OUTPUT

LOGIC
INPUT

C

L

V

OUT

MAX14531E
MAX14532E
MAX14533E
MAX14534E

Figure 1. Switching Time

Figure 2. Output Skew

MAX14531E
MAX14532E
MAX14533E
MAX14534E

UAX1, UAY1,

R

S

UAX2, UAY2,

R

S

or UAZ1

or UAZ2

V

IN+

V

IN-

COM1

COM2

t

= t

OR t

PLH

PLHX

= |t
= |t

PHLX

PLHX
PLHX

OR t

- t

- t

PLHY

PHLY
PLHY
PHLX

| OR |t

| OR |t

PHLX
PLHY

- t

|

PHLY

- t

|

PHLY

V

OUT+

t

= t

PHL

t

R

L

R

L

SK(O)

t

SK(P)

V

OUT-

CB0, CB1

V

IN+

V

IN-

V

OUT+

V

OUT-

VIL TO V

IH

t

t

INRISE

V

CC

50%

50%

0

V

CC

50%

50%

90%

10% 10%

INFALL

90%

0

t

OUTRISE

t

V

PLHX

CC

50%

0

V

CC

50%

0

t

PHLY

t

t

PLHY

PHLX

90%

50%

10% 10%

50%

90%

t

OUTFALL

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with
Negative Signal Capability and ±15kV ESD

6 _______________________________________________________________________________________

Test Circuits/Timing Diagrams (continued)

Figure 3. On-Loss, Off-Isolation, and Crosstalk

V

OUT

V

IN

V

OUT

V

IN

V

OUT

V

IN

50Ω

UAX1,
UAY1,
OR UAZ1

UAX1, UAY1,

MAX14531E–

MAX14534E

OR UAZ1

*COM1

NETWORK
ANALYZER

V

IN

V

OUT

50Ω

MEAS REF

50Ω 50Ω

50Ω

OFF-ISOLATION = 20log

ON-LOSS = 20log

CROSSTALK = 20log

OFF-ISOLATION IS MEASURED BETWEEN COM_ AND "OFF" UAX_, UAY_, OR UAZ_ TERMINAL ON EACH SWITCH.
ON-LOSS IS MEASURED BETWEEN COM_ AND "ON" UAX_, UAY_, OR UAZ_ TERMINAL ON EACH SWITCH.
CROSSTALK IS MEASURED FROM ONE CHANNEL TO THE OTHER CHANNEL.

*FOR CROSSTALK, THIS PIN IS COM2.
UAX2, UAY2, AND UAZ2 ARE OPEN.

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with

Negative Signal Capability and ±15kV ESD

_______________________________________________________________________________________ 7

Typical Operating Characteristics

(VCC= +3.0V, TA= +25°C, unless otherwise noted.)

QUIESCENT SUPPLY CURRENT

vs. SUPPLY VOLTAGE

MAX14531E toc04

SUPPLY VOLTAGE (V)

QUIESCENT SUPPLY CURRENT (μA)

5.14.74.33.93.53.1

11

12

13

14

15

10

2.7 5.5

TA = +85°C

TA = +25°C

TA = -40°C

QUIESCENT SUPPLY CURRENT

vs. LOGIC LEVEL

MAX14531E toc05

LOGIC LEVEL (V)

QUIESCENT SUPPLY CURRENT (μA)

2.52.01.51.00.5

4

8

12

16

20

0

0 3.0

V

CB0

AND V

CB1

FALLING

V

CB0

AND V

CB1

RISING

1.90

ON-RESISTANCE vs. V

1.88

1.86

1.84

ON-RESISTANCE (Ω)

1.82

1.80

-2.0 3.3
V

COM

COM

MAX14531E toc01

ON-RESISTANCE (Ω)

2.41.50.6-0.2-1.1

(V)

3.0

ON-RESISTANCE vs. V

2.5

2.0

1.5

1.0

0.5

0

-2.0 3.3

TA = +85°C

TA = -40°C

V

COM

COM

TA = +25°C

2.41.50.6-0.2-1.1

(V)

COM_ LEAKAGE CURRENT vs. TEMPERATURE

60

V

COM_

50

MAX14531E toc02

40

30

20

10

COM_ LEAKAGE CURRENT (nA)

0

-10

-40 85

= 0

MAX14531E toc03

ON-LEAKAGE

OFF-LEAKAGE

603510-15

TEMPERATURE (°C)

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with
Negative Signal Capability and ±15kV ESD

8 _______________________________________________________________________________________

Typical Operating Characteristics (continued)

(VCC= +3.0V, TA= +25°C, unless otherwise noted.)

Pin Description

VBUS DETECTION THRESHOLD

450

400

350

300

250

200

150

100

VBUS DETECTION THRESHOLD (mV)

50

0

-40 85

vs. TEMPERATURE

V

RISING

CB0

V

FALLING

CB0

TEMPERATURE (°C)

MAX14531E toc06

603510-15

PIN NAME FUNCTION

A1 CB0 Control Input 0

A2 UAZ1 USB/Audio Input Z1

A3 UAZ2 USB/Audio Input Z2

A4 COM1 Common Terminal 1

B1 V

CC

B2 UAX1 USB/Audio Input X1

B3 UAX2 USB/Audio Input X2

B4 GND Ground

C1 CB1 Control Input 1

C2 UAY1 USB/Audio Input Y1

C3 UAY2 USB/Audio Input Y2

C4 COM2 Common Terminal 2

Positive Supply Voltage Input. Bypass VCC to GND with a 0.1µF ceramic capacitor as close as
possible to the device.

TOTAL HARMONIC DISTORTION PLUS NOISE

0.005
RL = 32Ω

0.004

0.003

THD+N (%)

0.002

0.001

0

0.01 100

vs. FREQUENCY

1010.1

FREQUENCY (MHz)

MAX14531E toc07

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with

Negative Signal Capability and ±15kV ESD

_______________________________________________________________________________________ 9

Functional Diagram/Truth Table

Typical Application Circuit

DirectDrive is a trademark of Maxim Integrated Products, Inc.

CB1

UAX1

UAY1
UAZ1

UAX2

UAY2
UAZ2

MAX14531E/MAX14512E/

MAX14533E/MAX14534E

MAX14534E
ONLY

CONTROL

LOGIC

MAX14532E
MAX14534E

ONLY

V

GND

CC

CB0

MAX14532E
MAX14533E
MAX14534E

ONLY

COM1

COM2

MAX14531E–MAX14534E

CB1 CB0 UAX_ UAY_ UAZ_

0 0 OFF OFF OFF

0 1 ON OFF OFF

1 0 OFF ON OFF

1

1 ( < V

) OFF OFF ON

VBDET

X

1 ( > V

VBDET

) ON OFF OFF

HI-SPEED USB

TRANSCEIVER

DC-COUPLED

DirectDrive

VIDEO

(MAX9516)

AUDIO

AMPLIFIER

®

UAX1

UAY1
UAZ1

UAX2

UAY2
UAZ2

MAX14532E

3.0V

V

CONTROL

LOGIC

GND

0.1μF

CC

COM1

D+

D-

COM2

CB0

CB1

VBUS

OPTIONAL VBUS

AND VIDEO CONNECTOR

COMBINATION USB, AUDIO

DETECTION

SYSTEM

CONTROLLER

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with
Negative Signal Capability and ±15kV ESD

10 ______________________________________________________________________________________

Detailed Description

The MAX14531E–MAX14534E are high ESD-protected
single DP3T switches that operate from a +2.7V to +5.5V
supply and are designed to multiplex USB 2.0 Hi-Speed
signals and AC-coupled analog signals. These switches
combine the low on-capacitance (CON) and low on-resis­tance (R

ON

) necessary for high-performance switching
applications. These devices also meet the requirements
for USB low-speed and full-speed signaling. The nega­tive signal capability of all three channels allows signals
below ground to pass through without distortion.

Analog Signal Levels

The MAX14531E–MAX14534E are bidirectional, allow­ing UAX_, UAY_, UAZ_, and COM_ to be configured as
either inputs or outputs. Note that UAX_, UAY_, and
UAZ_ are only protected against ESD up to ±2kV
(Human Body Model) and may require additional ESD
protection if used as outputs. These devices feature a
charge pump that generates a negative supply to allow
analog signals as low as -2.0V applied to UAX_, UAY_,
UAZ_, or COM_. The negative charge pump is only
active when the part is enabled (CB0 or CB1 = 1).
Connect negative signals to UAX_, UAY_, UAZ_, or
COM_ only when the device is enabled.

VBUS Detection

The MAX14531E–MAX14534E feature a VBUS detec­tion input (CB0) that connects COM_ to UAX_ when
V

CB0

exceeds the VBUS detection threshold (V

VBDET

)

(see the

Functional Diagram/Truth Table

). Note that the
MAX14531E requires an external pulldown resistor
when using this function.

Digital Control Inputs

The MAX14531E–MAX14534E provide control logic
inputs, CB0 and CB1, to control the switch position as
shown in the

Functional Diagram/Truth Table

. Drive

CB_ rail-to-rail to minimize power consumption.

Shutdown Mode

The MAX14531E–MAX14534E feature a shutdown
mode to reduce the supply current to less than 1µA and
place the switches in high impedance. Drive both CB0
and CB1 low to place the devices in shutdown mode
(see the

Functional Diagram/Truth Table

.)

Click-and-Pop Suppression

The switched 100Ω shunt resistors on the MAX14532E/
MAX14534E automatically discharge any capacitance
at the UAZ_ (MAX14532E) or UAY_ and UAZ_
(MAX14534E) inputs when they are unconnected from
COM_ (see the

Functional Diagram/Truth Table

). This
reduces audio click-and-pop sounds that may occur
when switching to audio sources.

Applications Information

Extended ESD Protection

ESD-protection structures are incorporated on all pins
to protect against electrostatic discharges up to ±2kV
(Human Body Model) encountered during handling and
assembly. COM1 and COM2 are further protected
against ESD up to ±15kV (Human Body Model) without
damage. The ESD structures withstand high ESD both
in normal operation and when the device is powered
down. After an ESD event, the MAX14531E–
MAX14534E continue to function without latchup.

ESD Test Conditions

ESD performance depends on a variety of conditions.
Contact Maxim for a reliability report that documents
test setup, test methodology, and test results.

Human Body Model

Figure 4 shows the Human Body Model, and Figure 5
shows the current waveform it generates when discharged
into a low impedance. This model consists of a 100pF
capacitor charged to the ESD voltage of interest that is
then discharged into the device through a 1.5kΩ resistor.

Figure 4. Human Body ESD Test Model

Figure 5. Human Body Current Waveform

R

C

1MΩ

CHARGE-CURRENT-

LIMIT RESISTOR

HIGH-

VOLTAGE

DC

SOURCE

100pF

C

s

R

D

1500Ω

DISCHARGE
RESISTANCE

STORAGE
CAPACITOR

DEVICE
UNDER

TEST

IP 100%

90%

AMPERES

36.8%

10%

0

0

t

RL

I

r

TIME

t

DL

CURRENT WAVEFORM

PEAK-TO-PEAK RINGING
(NOT DRAWN TO SCALE)

MAX14531E–MAX14534E

USB 2.0 Hi-Speed and Audio Switches with

Negative Signal Capability and ±15kV ESD

Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.

Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________

11

© 2009 Maxim Integrated Products Maxim is a registered trademark of Maxim Integrated Products, Inc.

Layout

USB Hi-Speed requires careful PCB layout with 45Ω
single-ended/90Ω differential controlled impedance
matched traces of equal lengths. Ensure that bypass
capacitors are as close as possible to the device. Use
large ground planes where possible.

Power-Supply Sequencing

Caution: Do not exceed the absolute maximum rat­ings because stresses beyond the listed ratings
may cause permanent damage to the device.

Proper power-supply sequencing is recommended for
all devices. Apply VCCbefore applying analog signals,
especially if the analog signal is not current limited.

Chip Information

PROCESS: BiCMOS

Package Information

For the latest package outline information and land patterns, go
to www.maxim-ic.com/packages

.

PACKAGE TYPE PACKAGE CODE DOCUMENT NO.

12 WLP W121A2-1

21-0009
