Page 1
HWP-24WH
Furrow Plow
Hilling Plow
Cultivator tine
High Wheel Walk Behind
Owner’s Manual MHWP-24WHA
Plow & Cultivator
800-621-2789 HWP-24WH Rev A Page 1
Page 2
HWP-24WH
⚠
READ ENTIRE MANUAL BEFORE ATTEMPTING TO USE THIS WALK BEHIND PLOW
Table of Contents
1 INTRODUCTION ........................................................................................................................................................ 3
1.1 ... Navigating This Manual ..................................................................................................................................................3
1.2 ... Warnings and Safety Precautions ..............................................................................................................................3
1.3 ... Owner Assistance ................................................................................................................................................................3
1.4 ... Further Assistance .............................................................................................................................................................4
2 SAFETY ......................................................................................................................................................................... 4
2.1 ... General Safety Rules ..........................................................................................................................................................4
3 UNPACKING AND ASSEMBLY OF PLOW ......................................................................................................... 5
3.1 ... Assembly .................................................................................................................................................................................5
3.2 ... Final Set-up ........................................................................................................................................................................ 10
4 PARTS BREAKDOWN ........................................................................................................................................... 10
4.1 ... Parts List .............................................................................................................................................................................. 11
5 WARRANTY & PRODUCT REGISTRATION .................................................................................................. 12
5.1 ... Warranty/Product Registration .............................................................................................................................. 12
WARNING
If incorrectly used, this machine can cause severe injury. Those who use this walk behind plow should
read the entire manual before attempting to set up, operate or adjust this plow.
Read and keep this manual for future reference. This manual contains important information on
SAFETY, ASSEMBLY & OPERATION. This information includes the SET UP MANUAL, REPLACEMENT
PARTS and the WARRANTIES.
800-621-2789 HWP-24WH Rev A Page 2
Page 3
HWP-24WH
1 INTRODUCTION
Maxim’s Walk Behind High Wheel Plow features a long wooden handle, making it an easy to
manually guide one of three easy to change garden tools through tilled soil. Switch out the garden
tools and use the cultivator tool for weeding, single plow for planning or the hilling plow to help
close soil around seeds or add soil around the root base of plants. That’s just a few of the benefits
of this walk behind high wheel plow and we’re certain you’ll find that it’s easy to use and will help
you to accurately weed and plant. It’s this simple, yet sturdy design that makes Maxim Walk
Behind Plow a low maintenance and easy to use tool.
Please read this entire manual before assembly and use. The manufacturer reserves the right
to change, alter or improve the product and this document at any time without prior notice.
1.1 Navigating This Manual
1. Use this manual to help familiarize yourself with safety, assembly, operation,
adjustments, and warranty information. It is very important that you read this manual
and follow the instructions to ensure safe operation of the plow.
2. Please visit www.maximmfg.com
for updated information.
1.2 Warnings and Safety Precautions
The safety of our customers and other’s well-being is very important to us. Accurate assembly and
safe use of the plow is the owner’s responsibility.
• Carefully follow all assembly instructions
1.3 Owner Assistance
Please complete the Warranty/Product Registration at the time of purchase. You will need to
complete the warranty/product registration form with your new unit, or you may visit our
website www.maximmfg.com
this information so we can keep you updated with any important information about your plow
and provide you with the best customer service possible.
The parts and components used on your Maxim plow have been specifically engineered for
Maxim and should only be replaced with Maxim parts. Contact your local Maxim Dealer for OEM
replacement parts or contact our customer service department for assistance in parts, locating
your local servicing dealer and more.
and complete our online product registration form. We require
800-621-2789 HWP-24WH Rev A Page 3
Page 4
HWP-24WH
1.4 Further Assistance
Your dealer and all of us at Maxim want you to be pleased with your plow. Should you require
further assistance or have questions regarding your plow, please contact your local dealer where
you purchased your plow. If you are unable to satisfy your needs by your local dealer, please
contact us at:
Maxim
20195 South Diamond Lake Road, STE 100
Rogers, MN 55374
800-621-2789
Email: sales@maximmfg.com
Website: www.maximmfg.com
Live Chat: Visit our website Monday – Friday, From 8 A.M. – 5 P.M. CST
2 SAFETY
2.1 General Safety Rules
• Use this equipment for its intended purpose only.
• Familiarize yourself with this plow and its attachments.
• Do not put hands or feet near or under plow or attachments.
• Do not allow children to operate this plow.
• Do not pull or tow this plow
• Wear appropriate clothing such as sturdy, rough-soled shoes (steel toe recommended)
and close fitting pants and shirt. Never wear sandals, sneakers or open shoes, and never
operate the plow with bare feet.
• Operate only in daylight.
• Do not operate the plow when fatigued or under the influence of alcohol, drugs or other
medication which can cause drowsiness or affect your ability to operate machine safely.
• Regularly inspect the plow. Make sure parts are not bent, damaged or loose.
• Keep all nuts and bolts tight.
800-621-2789 HWP-24WH Rev A Page 4
Page 5
HWP-24WH
¼” x 2.25”
2- ¼” Washers
¼” Nyloc nut
Right Tool
Left Tool
Left and Right
3 UNPACKING AND ASSEMBLY OF PLOW
Prior to opening your unit, ensure that you have a clear work area. Carefully open box and
remove contents. Then carefully set all parts to the side and follow set up and assemble
instructions found in this manual.
3.1 Assembly
Follow these steps when assembling your Maxim Plow:
1. Locate the Left tool support ref # 6 and Right tool support ref # 7
2. Using ref # 13- ¼” x 2.25” bolt connect the Left frame ref # 14 and Right frame ref # 15
together with the tool support arms as shown below, using 2 ref #25- ¼” washers as
spacers, then thread on ref# 24 - ¼” Nyloc nut tighten only at a snug fit. Do not tighten
nut at this time.
Support
Frame
Support
800-621-2789 HWP-24WH Rev A Page 5
Page 6
HWP-24WH
A C B D E
F
A
3/8-16 Nyloc nut
B
3/8-16 x 2 Carriage Bolt
C
Fix Plate
D
Tool Union
E
5/16-18 x 1.25 Bolt & Nyloc Nut
F
Tool Support Spacer
4– each
Curve
direction
3. Insert ref# 16 (E) - 5/16” x 1.25” bolt through both tool support arms with ref # 17 (F)
spacer in the middle, thread on ref # 8 (E) - 5/16” Nyloc nut tighten only as a snug fit.
4. Insert ref# 9 (B) 3/8” x 2” carriage bolt through square hole of ref# 10 (D) Tool union and
through both Tool Supports and through ref# 11 (C) Fix plate using ref# 12 (A) 3/8” Nyloc
nut and tighten.
portion of
handles
pointed in
same
Nyloc
Nuts
Washers
Bolts
800-621-2789 HWP-24WH Rev A Page 6
Page 7
Right and Left
arms
Insert ref# 5 – bolt and ref#
handle assembly.
Insert ref# 5 –
Cross brace
HWP-24WH
5. With the wooden handles both pointing in the same direction, mount on the inside ref#
18 - Handle metal axle bracket to each handle using (2) ref# 5 - 5/16” x 1.5” bolt, ref# 26
5/16” washer and ref# 8 – 5/16” Nyloc nuts on the inside as shown above, and tighten.
Make sure the Handle metal axle brackets both left and right bends are mounted as
illustrated above.
6. With the Wooden handles pointing up, mount
Ref# 2 - Cross Brace, using ref# 5 - 5/16” x 1.5”
bolt with ref# 26 – 5/16” flat washer through
wooden handle 1
st
and ref# 8 - 5/16” Nyloc nut
on the inside with Cross brace.
7. With handle still laying curved side up, insert
ref# 5 – 5/16 x 1.5 bolt and ref# 26 - 5/16 flat
washer through each of the tool support arms
and the wooden handle using the same hole
location for each side.
Tighten only at a snug fit using ref# 8 – 5/16”
bolt and ref# 26
washer, through
st
handle 1
with
Nyloc nut on the
inside of handle
assembly.
Nyloc nut on the inside of handle assembly.
This is only temporary, final mounting and adjustment based on user, will be made later.
.
tool support
26 washer, through handle 1st
with nyloc nut on the inside of
800-621-2789 HWP-24WH Rev A Page 7
Page 8
HWP-24WH
Axle Bushing
Left and right frame
Metal handle bracket
Axle bolt
8. Slide axle bushing ref# 20 into wheel ref# 21
as shown below.
9. Lift handle and frame assembly to mount wheel.
10. Align Axle bushing, Left/Right frame and Handle metal axle bracket of each side and insert
ref# 19 – 5/16” x 4.5” Axle bolt, using ref# 8 – 5/16” Nyloc nut as shown below, and
tighten.
800-621-2789 HWP-24WH Rev A Page 8
Page 9
HWP-24WH
Four holes on each
“D” pin to be
11. Leave in this position and tighten all hardware except the handle tool support arms as
mentioned in step# 7
12. Using ref# 3 – “D” pin, temporarily mount ref#4 Cultivator tine set as shown with tines up.
This “D” pin will be used for all Plow Attachments.
used for all Plow
attachments
13. Your Maxim High Wheel Plow is now ready to tip right side up.
14. Adjust right and left tool
supports to adjust handle
to a comfortable and safe
operator height and
begin to use.
side, to be used for
handle adjustment
800-621-2789 HWP-24WH Rev A Page 9
Page 10
HWP-24WH
3.2 Final Set-up
1. Apply a small amount of dry silicone spray to axle bolt
4 PARTS BREAKDOWN
800-621-2789 HWP-24WH Rev A Page 10
Page 11
HWP-24WH
Ref #
Qty
Part #
Description
1 2 20003
Wood handle
2 1 30001
Cross brace
3 1 30002
"D" pin 4 1
40001
Cultivator tine
5 8 30003
5/16-18x1.5 Bolt
6 1 30004
Left Tool support
7 1 30005
Right Tool support
8
10
30006
5/16 Nyloc nut
9 1 30007
3/8-16x2 Carriage Bolt
10 1 40002
Tool Union
11 1 40003
Fix plate
12 1 30008
3/8-16 Nyloc nut
13 1 30009
1/4-20x2.25 Bolt
14 1 30010
Left frame
15 1 30011
Right frame
16 1 30012
5/16-18x1.25 Bolt
17 1 30015
Tool support spacer
18 2 30016
Handle metal axle bracket
19 1 30017
5/16-18x4.5 Bolt
20 1 30018
Axle bushing
21 1 40004
Wheel
22 1 40005
Furrow plow
23 1 40006
Hilling
24 1 30019
1/4-20 Nyloc nut
25 2 30020
1/4 Flat Washer
26 8 30021
5/16 Flat Washer
4.1 Parts List
800-621-2789 HWP-24WH Rev A Page 11
Page 12
HWP-24WH
5 WARRANTY & PRODUCT REGISTRATION
5.1 Warranty/Product Registration
Please register your product immediately after purchase. You can do that by visiting our
website at www.maximmfg.com
and complete our online product registration.
Or, complete the following warranty/production registration form on the next page and
return to:
Maxim
Attn: Warranty Registration Department
20195 South Diamond Lake Road, STE 100
Rogers, MN 55374
800-621-2789 HWP-24WH Rev A Page 12
Page 13
HWP-24WH
Or, Fax completed form to: 763-428-4821
800-621-2789 HWP-24WH Rev A Page 13
Page 14
HWP-24WH
PAGE INTENTIONALLY LEFT BLANK
800-621-2789 HWP-24WH Rev A Page 14
Page 15
HWP-24WH
800-621-2789 HWP-24WH Rev A Page 15
Page 16
HWP-24WH
Maxim
20195 S. Diamond Lake Rd, STE 100
Rogers, MN 5537
800-621-2789
800-621-2789 HWP-24WH Rev A Page 16
