OWNER’S MANUAL

Model GP100SILCAN

GEORGE FOREMAN

™

Portable Propane Grill

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. Open Lid.

4. If odor continues, immediately call your gas supplier or your fire department.

FOR YOUR SAFETY

1. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

WARNING

1. Do not store spare LP cylinder within 10 feet (3.05m) of this appliance.

2. Do not store or use gasoline or other flammable liquids or vapors within 25 feet (7.62m) of this appliance.

IMPORTANT SAFEGUARDS

READ AND SAVE THESE INSTRUCTIONS

WARNING: A risk of fire or explosion exists in all propane grills. Read this manual before use. Failure to follow all instructions may result in serious personal injury, property damage, or death.

When using propane grills, basic safety precautions should always be followed to reduce the risk of fire and injury to persons, including the following:

1. Read all instructions before using the grill.

2. Do not touch hot surfaces. Use handles or knobs and oven mitts or pot holders.

3. Keep children and pets away from the grill at all times.

4. This grill is not for use by children.

5. Do not leave this grill unattended while in use.

6. Do not move the grill when in use. Allow to cool before moving, putting on or taking off parts, and before cleaning and storing the grill.

7. To disconnect, turn Temperature Control Knob to LOCK/OFF.

8. Do not operate any grill after the grill malfunctions, or has been dropped or damaged in any manner. Contact Consumer Service for return authorization, examination, repair or adjustment.

9. The use of accessory attachments not recommended by the grill manufacturer may cause injuries.

10. This grill is for outdoor use only. NEVER operate grill in enclosed areas, as this could lead to gas accumulating from a leak, causing an explosion or a carbon monoxide buildup which could result in injury or death. DO NOT USE in garages, sheds or any enclosed areas.

11. Do not use grill for other than intended use.

12. Extreme caution must be used when moving a grill containing hot oil or other hot liquids. Allow liquid to cool before removing and emptying Drip Tray. Do not remove Grill from Base until Grill is cool.

13. Do not attempt to dislodge food or clean the grill when it is hot.

14. Fuel, such as charcoal briquettes, is not to be used with this grill.

SAVE THESE INSTRUCTIONS

THIS GRILL IS NOT FOR COMMERCIAL USE.

FOR OUTDOOR USE ONLY.

Additional Important Safeguards

1. CAUTION: This grill generates heat and escaping steam during use. Proper precautions must be taken to prevent the risk of burns, fires or other damage to persons or property. Use of protective oven mitts or gloves is recommended.

2. All users of this grill must read and understand this Owner's Manual before operating or cleaning this grill.

3. When using this grill, provide adequate air space above and on all sides for air circulation. Do not allow this grill to touch clothing, dish towels or other flammable materials during use.

4. IMPORTANT: Minimum clearance of 16 inches around all sides of the grill should always be maintained and the appliance shall not be located under overhead unprotected combustible construction.

5. If this grill begins to malfunction during use, immediately turn the Temperature Control Knob to LOCK/OFF. Do not use or attempt to repair the malfunctioning grill.

6. This outdoor cooking gas grill is not intended for use in or on recreational vehicles and/or boats.

7. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble or safely operate the grill.

8. When cooking with oil/grease, fire extinguishing materials shall be readily accessible. In the event of an oil/grease fire do not attempt to extinguish with water. Use Type BC dry chemical fire extinguisher or smother fire with dirt, sand or baking soda.

9. In the event of rain while cooking with oil/grease, turn off the grill burner and gas supply, and immediately cover the Grill Plate. Do not attempt to move the grill or Grill Plate.

10. When cooking, the grill must be on a level and stable surface in an area clear of combustible materials. An asphalt surface (blacktop) may not be acceptable for this purpose.

11. Make sure the Tempurature Control Knob is in the LOCK/OFF position when placing the Grill Plate into position.

12. The grill is not intended for and should never be used as a heater.

13. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids.

14. Do not obstruct the flow of combustion and ventilation air.

15. Always remove lid before lighting your grill.

16. Do not attempt to disconnect the regulator or any gas fitting while the unit is in operation.

17. Do not wear clothing with loose flowing sleeves while lighting or using the grill.

18. Use barbecue tools with long, heat-resistant handles.

19. The grill should never face directly into the wind.

20. Do not operate Grill in a high-traffic area.

21. After use, allow Grill to cool completely before cleaning.

22. We recommend storing Grill indoors or, if unable to store indoors, always cover Grill with protective cover. Always keep out of the reach of children.

Special Instructions for the Use of Regulator

.550 Min

(13.96mm)

.850 - .935

(21.58 - 23.75mm)

.666 - .750

(16.92 - 19.05mm)

and LP (Propane) Cylinders

• The propane grill is equipped with a regulator having a CGA No. 600 cylinder connection

CGA No. 600

device which is for connecting to a one pound PROPANE cylinder ONLY. See Illustration.

• Grill installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 or CSA B149.1, Natural Gas and Propane Installation Code.

• Use grill only with LP (propane) gas. Use grill only with the regulator/valve assembly supplied.

• Never use charcoal briquettes or lighter fluid in a gas grill.

• Discard used and empty fuel cylinder in a safe place.

• Store spare fuel canisters in a well-ventilated area away from the grill.

• Do not puncture or burn fuel canister.

• Do not operate the grill if there is a gas leak present.

• Do not enlarge orifice or burner ports when cleaning the regulator and burner.

• If you smell gas, turn Temperature Control Knob to LOCK/OFF to shut off gas to the grill. Extinguish any open flame and open Lid. If odor continues, immediately call your gas supplier or your fire department.

• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other grill.

• An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

• The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specifications for LP-gas cylinders of the U.S. Department of Transportation (DOT) CFR 49 or the National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods.

• If the grill is not in use, the Temperature Control Knob must be turned to LOCK/OFF to shut off the gas cylinder. Storage of a grill indoors is permissible only if the cylinder is disconnected and removed from the grill. Cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage or any other enclosed area.

• The regulator may make a humming or whistling noise during operation. This will not affect safety or use of grill.

•Save cylinder cap and reinstall when not in use.

• Cylinder supply system must be arranged for vapor withdrawal. The gas cylinder must be upright in use. Do not block the pressure relief valve during use or storage.

• Always remove one pound cylinder from grill when transporting and when not in use.

Getting To Know Your GP100SILCAN

Propane

Grill

}

Slots for Drip Tray

1. Lid Handle/Vent (P/N 21659)

2. Lid Assembly (P/N 21660SIL)

3. Screw/Washer (P/N 21661)

4 Grill Plate (P/N 21645)

5. Drip Tray (P/N 21646)

6. Temperature Control Knob (P/N 21647)

7. Regulator (P/N 21663)

8. Ignitor Assembly (P/N 21648)

9. Flame Viewing Hole

10. Lock Pin (2) (P/N 21657 each)

11. Transport Lock (P/N 21649)

12. Base Frame (P/N 21650)

13. Transport Handle (P/N 21651)

14. Pedestal Legs (4) (P/N 21652 each)

15. Leg Storage Rack (2) (P/N 21653)

16. Transport Wheels (2) (P/N 21654)

17. Match Holder (P/N 21656)

18. Grill Base

19. Burner Assembly

Before First Use

1. Remove the Grill and any packaging materials.

2. Place the Base Frame on a flat, level surface.

3. Slide the Transport Lock to the right and raise the Transport Handle from the storage position.

4. Remove the Grill Plate, Grill Base, Lid and Drip Tray. Wipe the Grill Base and Lid with a damp cloth to remove any dust. Wash the Grill Plate and Drip Tray in warm, soapy water. Rinse and dry thoroughly.

5. The Handle/Vent and mounting hardware, (Screw/Washer) are shipped in an inverted fashion, requiring minor assembly. Remove the Handle/Vent from the inside of the Lid by unscrewing the Screw/Washer. Remove all parts, then properly position the Handle/Vent on the top of the Lid. Make sure the Handle/Vent stop pin enters the Vent slot in the Lid. From the inside of the Lid, place the Screw/Washer through the hole in the Lid and Handle/Vent. Securely fasten with a Phillips head screw driver. See Figure 1.

6. Slide the Drip Tray into the slots in the Grill Base.

7. See "Grilling Positions" on the following pages and place the Grill Base on the Base Frame. Refer to Figure 2 and hook the Slotted Bracket around the Locator Peg under the Base Frame. Align the hole in the Grill Base with the Locator Peg on the opposite side of the Base Frame.

8. Place the Grill Plate on the Grill Base and place the Lid over the Grill Plate.

Figure 1

Drip Tray

Figure 2

Handle/Vent

Vent Slot

Lid

Screw/Washer

Slots for Drip Tray

Hook the Slotted Bracket Under Base Frame Locator Peg

Locator Peg

NOTE: If the Lid is to be removed temporarily it may be placed between the Grill and the Wheels as shown in Figure 3.

Figure 3

Grill Positions

The Wheel-It and Grill-It™Portable Propane Grill is compact enough to transport to any grilling location. Wheel-It from the storage shed to the patio, to a picnic in the park, or off on a camping trip. The Portable Propane Grill easily transforms from storage to transport and to high or low Grill-It positions.

Storage Position: This position makes the Grill compact enough for space saving storage. The Legs are stored in the Leg Storage Rack and the Transport Handle folds over the top of the Lid and snaps into place to secure all parts.

Transport Position: To transform the Grill to the transport position, raise the Transport Handle from the closed position and swing it over the Lid. Pull one of the Lock Pins from its storage location. Slide the Transport Handle sideways until the white marker line is just visible then rotate the Transport Handle to align the two arrows. Insert the Lock Pin into the front location to lock the Transport Handle. Slide the Transport Lock into the locked position and roll away

Transport

Lock Pin

Lock

Figure 4

Locked

Alignment

Arrow

Lock Pin

Transport Handle

Unlocked

Figure 5
