Maxfield Wireless Charging Pad mini Operating Manual

M A X F I E L D

OP E R AT I N G MA N U A L

W I R L E S S C H A R G I N G

P A D M i n i

Anti-slipping rubber

Micro USB input

LED indicator

P R O D U C T O V E R V I E W

USB cable

Micro USB connection

USB connection

Connect the PAD mini via USB cable with
an adapter. Then you plug the adapter
into a power socket. The LED indicator
will let you know in wich sate the Pad is.

In case the LED indicators does not work
right try to plug and unplug the adapter
from the power socket.

Now put your wireless charging able de

­vice in the middel of the PAD. It will start
charging automatically. To see the batte­ry state check your display.
After charging your device pleas remove
it from the PAD.

LED indicator Product status

Red Standby LED
Green (ashing) Communication

F I R S T S T E P S

Step 3

Step 2

Step 1

1

2

3

Attention : As proof that the Pad communicates with the receiver, the communication LED still

ashes after complete charging.

S A F E T Y N O T E S

ATTENTION!

Please do not use a damaged power supply or power socket. Do not use
the product in areas with a temperature range out of -20°C to 40°C. Do
not restore your product in places with high temperature or direct solar
radiation. Do not crinkle or damage the power cord. Do not make it wet
or use it with wet hands. Please keep the product away from metallic
objects as chains, keys etc. and keep it away from the inner of water
heaters, microwaves, high pressure vessel and other kitchen gadgets.
Do not lay any magnetcards, magnetic record media or precise instru-

ments on or near the product. It may have inuence on the function and

the work process. Do not lay the product in places that are easy to fall.
Do not take the product in your mouth. If children are using the product
watch out for the right handling. If the product gets wet please dry it
with a towel and contact our support. Do not try to repair or dismantle
the product on your own. It may cause damage and leads to expire of the
warrenty. People who use a heart-birth-maker should consult a doc­tor befor using this product. While using it keep a distance from 22cm
because the product can effect the function of the heart-birth-maker.
Products with a QI mark comply with the wireless charing standard spe-

cication of WPC.

For your own safety, please read the construction manual carefully. Af­ter opening the package please check it on its completness. The disre-

gard of the safety note may lead to heat, re, burn or frequent electric

shocks. Wrong handling may lead to martial as personelle damage
and in worst cases it may also lead to death.

L I A B I L I T Y E X C L U S I O N

Maxeld GmbH

Albert-Einstein-Str.1 . 74722 Buchen, Germany
Telefon: [phone] / 56435-0 . Fax: [phone]
info@maxeld.de . www.maxeld.de/en

Because we aren‘t abble to control the charging, the usa-

ge and the observance of the safety notes Maxeld can‘t

take liability for loss, damage and expences. Any claim on
compensation caused by operation, breakdown, failure or
coherent in any way will be declined. For personal injurys
as well as property damage caused by our supply, we won‘t
take liability. Insofar compulsory authorised, our commit­ment to pay damages, for whatever legal foundation, will be

dened on the invoice value of the product wich is affected

in the incidence. This does not apply when we have to liable
for gross negligence or because of statutory provisions.

IMPORTANT!

• Status 07/2014 • Technical changes reserved • No accountability for falsity and misprint
