SSB-4W
Instruction Manual
10 pgs1.68 Mb0

Maxell SSB-4W Instruction Manual

EN
SSB-4W
EN EN
EN-1
Contents
What’s in the Box ........................................................................................................2
Main Unit ................................................................................................................................ 6
......................................................................................................... 7
Prepare the Smart Remote Control .................................................................................... 8
Precautions Concerning Batteries ...................................................................................... 8
Place TV on top ....................................................................................................................9
Connect to Power ................................................................................................................ 9
USB DC 5V Charge ............................................................................................................... 9
Connect to TV ....................................................................................................................... 9
Connect to a Bluetooth
®
Device ....................................................................................... 12
Connect to an External Audio Device ............................................................................. 13
Basic Operation........................................................................................................14
Turn On/Off .......................................................................................................................... 14
Adjust Volume Level ........................................................................................................... 14
Mute Sound ......................................................................................................................... 14
Bass Boost ............................................................................................................................14
Select SRS Sound ................................................................................................................. 14
Program Smart Remote Control to Control TV ................................................................ 14
Specifi cations ...........................................................................................................
............................................................................................
16
17
EN-2
What’s in the Box
Main Unit
Instruction Manual
Smart Remote Control
(Maxell CR2025 lithium button
battery included)
Line Cable
(3.5mm to 3.5mm)
(For TV Headphone Output)
Line Cable
(RCA to RCA)
(For TV Line out) Optical Cable
AC Power Cable Quick Start Guide
DOs and DON’Ts Leaflet
Important Safety Instructions
23.6"(60 cm)
80 kg
(176 lbs)
EN
FR
ES
PT
SSB-4W
FCC & IC Compliance
Smart Remote Control
EN EN
EN-3
The lightning fl ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude as to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the apparatus.
Reading the user’s manual
• The contents of this user’s manual may be modifi ed without any prior notifi cation.
• The appearance and specifications may be partially modified without any prior notification.
• The Company shall not be responsible for any injury caused by fi re, earthquake or a third party, as well as any injury that occur due to
intentional or accidental mishandling
or improper use by the customer.
• Company shall not be held responsible
for any damages that may occur due to
employment of a usage method not designated in the user’s manual.
• Company shall not be held responsible
for any damages that may occur due to
malfunctioning of the Product resulting
from the use of this Product together with other devices.
• This Product is not intended for use in facilities and equipment which may affect human lives, including medical equipment, nuclear devices, aerospace equipment and transport equipment, as well in facilities and equipment which require a high degree of reliability. Company shall not be held responsible for any accident resulting in personal injury or death or any fi re accident that may occur
due to failure of this Product when this
Product is used in the control systems of those facilities and equipment.
Indicates that ‘there is a possibility of causing death or serious physical injury if this Product is erroneously handled’.
Indicates that ‘there is a possibility of causing physical injury*
1
or occurrence of
physical damage*
2
if this
Product is erroneously handled’.
*1: Serious physical injury implies injuries such as
loss of eyesight or injury, burns, electric shock, bone fracture or poisoning that have subsequent complications and which require hospitalization or long term hospital visit for medical treatment.
*2: Physical injury implies injury, burns and electric
shock which do not require hospitalization or long-term hospital visit for medical treatment.
This symbol shows that the user needs to exercise caution while handling this Product to prevent fi re, explosion and heating. The specifi c caution to be taken is written inside the symbol.
This symbol implies restriction of an action while handling this Product. The specifi c restriction is written inside or near the symbol.
This symbol implies compulsion of an action based on the instructions. The specifi c compulsion is written inside or near the symbol.
Warning
To reduce the risk of fi re or electric shock, do not expose this apparatus to rain or moisture.
Warning
The battery (battery or batteries or battery pack) must not be exposed to excessive heat such as
sunshine, fi re or the like.
Important Safety Instructions
WARNING
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER­SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning
!
Caution!
EN-4
Warning!
Do not repair, modify or disassemble.
It may cause fi re, electric shock or injury. The
Don’t
Company shall not be responsible for any physical damage caused by repairing, modification or disassembly. Also, any repairing of a fault caused by repairing, modification or disassembly by the user will be charged, even if it happens during the warranty period.
Keep the Product (Remote Control) out of reach of children.
They may accidentally swallow the battery
Don’t
and cause choking and damage the stomach. The cord may entangle around the child’s body and cause suffocation. If any accident occurs by any chance, please consult a doctor immediately.
Do not use in a rainy or snowy place, by the
Don’t
waterside or in the bathroom.
It may cause fire or electric shock.
Do not use if it is thundering.
Don’t
It may cause fire or electric shock.
Do not keep a fl ower vase, fl owerpot, cup, or any
container containing medicine, cosmetics or
Don’t
water, near the Product.
They may break and get into the Product and cause fire or electric shock.
Do not insert any kind of metal or easily combustible object through the aperture.
Don’t
It may cause fire or electric shock.
Do not block any ventilation openings.
Don’t
It may get heated and cause fire. Install in accordance with the manufacturer’s instructions.
Do not put more than 80kg on top of this
Don’t
apparatus.
It may damage the apparatus.
Do not use a wrong power plug out of the 2 power cords provided for this apparatus.
Don’t
It may damage the power plug and/or the power socket. It may cause fire or electric shock.
Caution!
Do not keep in a shaky place.
The Product may fall and get damaged.
Don’t
Do not keep in a place where lampblack or
Don’t
steam falls.
It may cause fire or accident.
Do not keep in a place which is directly hit by cold air, or a place which is extremely cold.
Don’t
Dew may fall and cause short circuit or burnout.
Do not listen in high volume continuously for a long time.
Don’t
Do not listen in high volume, which causes ringing in the ears, continuously for a long time. It may damage hearing.
Do not raise the volume excessively from the beginning.
Don’t
Sudden high volume may damage hearing. Minimize the volume before playing.
Do not keep in an excessively hot place. sush as
Don’t
radiators, heaters, stoves, or other apparatus (including amplifi ers) that produce heat.
The surface of the device or parts may get damaged, and may also cause fi re. Do not keep especially in a closed car in summer, and in a place where sunlight directly falls or near a stove. This may cause leakage of battery fluid.
Do not use in sandy beaches and sandy soil
where sand can easily enter, or in dusty locations.
Don’t
It may cause burnout, fire or accident.
Do not cover or wrap with a cloth or futon.
Heat may get generated and deform the
Don’t
Product, or Product may catch fire.
Do not keep a cathode-ray tube near it.
Don’t
Spots may appear because of it.
Ensure to refer the user’s manual to connect to
Don’t
an external device.
Connect to an external device after carefully reading this user’s manual and the user’s manual of the external device, as well as after turning off the power.
Do not plug or unplug the power plug with wet
Don’t
hands.
It may cause electric shock.
Insert the power plug completely and fi rmly into
Don’t
the outlet socket.
If the power plug is not inserted properly, fire may occur due to electric shock or dust deposition.
Turn off power when repairing or if not going to be used for a long time, and remove the power plug.
Hot adhering to this may cause electric shock or physical damage.
Important Safety Instructions
Caution!
