1) When communicating, adjust an amplifier gain at an optimum level on
the host system.
2) Do not install any parts of metal or magnetic material around the
antenna.
Carrier on/off ratio Ratio of on status: 50% or lower
Item Specifications
Power supply voltage 4.75~5.25 V
1) Max. 900mA
Current consumption
Operating condition: Primary condition is turning-on carrier.
2) Max. 110mA
Idle 1 and Idle 2 conditions: Primary condition is turning-off carrier
Carrier frequency 13.56MHz±15ppm or lower
Data rate 212kbps
-Communicating distance: 1.0 to 2.2mm (communicating using one card)
1.0 to 1.6mm (communicating using two cards)
(from antenna board to antenna side of RFID chip on board)
displacement (length direction): ±2.0mm
1) When communicating, adjust an amplifier gain at an optimum level on
the host system.
2) Do not install any parts of metal or magnetic material around the
antenna.
Carrier on/off ratio Ratio of on status: 50% or lower
* Values in the table above are provided for reference purpose only. The values fluctuate according
to actual system environments. Perform evaluation on an actual system environment, and adjust
communication distance, gain settings, and transverse displacement for secure communication.
The “communication distance” above refers to a distance between an antenna-coil surface of RFID
chip and a R/W antenna coil. A distance between an RFID chip package surface and a R/W
antenna coil is shorter than the values above as much as a thickness of package.
4MAXELL SEIKI CONFIDENTIAL
Coil-on-Chip RFID ME-MA21/MR21
4.4 Interface specifications
4.4.1 CN101 connector pin alignment (host)
Pin Pin name Function
1 GND
GND(0V) -
Direction
Ground
Remarks
2 TXD Data output Output Sending data signal (output)
3 RXD Data input Input
Receiving data signal (input)
(Connected to Vcc on board)
RFID chip presence/absence signal
Present: /DETECT=0
Absent: /DETECT=1
4 /DETECT
Presence/absence of
chip
Input
/DETECT=1 is applicable when “not used.”
(Pull-up with 1kΩ on board)
Antenna power supply control signal
ON: /ANTPWR=0
5 /ANTPWR Antenna power Input
OFF: /ANTPWR=1
Fixed to /ANTPWR=0 when “not used.”
(Pull-up with 1kΩ on board)
System reset signal
6 /RESET Reset signal Input
Reset: /RESET=0
Other than Reset: /RESET= open
/RESET is opened for “not used.”
7 VCC +5V power supply
-
4.4.2 CN102 connector pin alignment (antenna)
Pin Pin name Function
1 VANT
Antenna power supply
Direction
Output Core wire
2 GND GND - Shielded wire side
SIGNAL Analog signal Input Core wire
Remarks
MAXELL SEIKI CONFIDENTIAL 5
ME-MA21/MR21Coil-on-Chip RFID
4.4.3 RXD/TXD communication specifications
Item Specifications
Communication rate
(real rate *1)
19,200 bps(18,750 bps)
38,400 bps(37,500 bps)
*2
Communication mode RS232C half duplex
Synchronous mode Asynchronous
Flow control None
Number of start bits 1bit
Number of data bits 8bit
Number of stop bits 1bit
Number of parity bits bit/even
*1: The controller installed on this module uses a 6MHz oscillator. Because a communication
rate is generated by frequency division of the oscillator, actual rates of this module are
values in parentheses.
*2: A communication rate upon turning on the power (system resetting) is 19,200bps.
6MAXELL SEIKI CONFIDENTIAL
Coil-on-Chip RFID ME-MA21/MR21
5 Receiving property parameters
This setting is very important for stable reading and writing processings. Optimum receiving property
parameter values vary depending on communication characteristics of individual RFID chips and
positional relationship between the R/W antenna and the RFID chip. When communicating with
another RFID chip or after re-positioning the components (including removing and inserting a card), be
sure to optimize the receiving property parameters to agree with the receiving property of the RFID
chip.
Parameters to be optimized are slice level and gain. Switching of gain only also can optimize the
characteristics to some degree. To optimize the system more fitting to the using environments,
optimize the parameters in combination with a slice level.
Specify a comparator slice level using higher-order bits b7 to b4 (4 bits) of the receiving property
parameter. Also, specify an amplifier gain using lower-order bits b 3 to b0 (4 bits) of the parameter. The
following provides receiving property parameter setting registers and parameter values.
